Peugeot 5008 (2017 year). Manual

PEUGEOT Connect Radio

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.

Onboard audio: the Sound Staging of
Arkamys

optimises the distribution of

sound in the passenger compartment.

DAB (Digital Audio
Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality
reception.
The different multiplexes offer a choice
of radio stations arranged in alphabetical
order.

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Waveband" to select the
"DAB band".

Press in the grey zone to confirm.

FM-DAB Follow-up

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
the "FM-DAB Follow-up" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station (if
there is one).

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "FM-DAB
Follow-up".

Press in the grey zone to confirm.

PEUGEOT Connect Radio

Media

USB port

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Auxiliary socket (AUX)

(depending on model / depending on equipment)

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player, etc.)
to the auxiliary jack socket using an audio
cable (not supplied).

First, adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

If "FM-DAB Follow-up" is activated, there
is a difference of a few seconds when the
system switches to "FM" analogue radio
with sometimes a variation in volume.
When the digital signal quality becomes
good, the system automatically switches
back to "DAB".

If the "DAB" station being listened to is
not available on "FM", or if the "FM-DAB
Follow-up" is not activated, the sound will
cut out while the digital signal is too weak.

PEUGEOT Connect Radio

Selecting the source

Press "Radio Media" to display the
primary page.

Press the "SOURCES" button.

Choose the source.

Bluetooth

audio streaming

Streaming allows you to listen to music from
your smartphone.

The Bluetooth profile must be activated, first
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your system.

If play does not start automatically, it may be
necessary to start the audio playback from the
smartphone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in Streaming mode, the
smartphone is considered to be a media
source.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts), you can also use
a classification structured in the form of a
library.
The default classification used is by artist.
To modify the classification used, return
to the first level of the menu then select
the desired classification (playlists for
example) and confirm to go down through
the menu to the desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The system supports USB Mass Storage
devices, BlackBerry

devices or Apple

players via USB ports. The adapter cable
is not supplied.
Device management is done by the audio
system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

To protect the system, do not use a USB
hub.

The audio equipment will only play audio files
with ".wav", ".wma", ".aac", ".ogg" and ".mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other file types (.mp4, etc.) can be read.
".wma" files must be of the standard wma
9 type.
Sampling frequencies supported are 11, 22,
44 and 48 kHz.

PEUGEOT Connect Radio

It is advisable to restrict file names to
20 characters, without using special characters
(e.g. " " ? .; ù) so as to avoid any reading or
display problems.

Use only USB keys in FAT32 format (File
Allocation Table).

It is recommended that the original USB
cable for the portable device is used.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Telephone

MirrorLink

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
MirrorLink

technology on the vehicle

screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system of
the smartphone as well as the date and
time of the smartphone and the system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "MirrorLink

" function requires a

compatible smartphone and applications.

Telephone not connected by
Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press "MirrorLink

" to start the

application in the system.

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

function.

PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that Bluetooth

be started on the

smartphone.

Telephone connected by
Bluetooth

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to display the
secondary page.

Press "MirrorLink

" to start the

application in the system.

Once the connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

CarPlay

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
CarPlay

technology on the vehicle screen

when the smartphone's CarPlay

function

has been previously activated.
As the principles and standards are
constantly changing, it is recommended
that you keep your smartphone's
operating system updated.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the
CarPlay

interface.

If the smartphone is already
connected by Bluetooth

PEUGEOT Connect Radio

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to go to the
secondary page.

Press on "CarPlay" to display the
CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

You can go to the CarPlay

navigation at any time by pressing
the system's Navigation button.

Android Auto smartphone
connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

On your smartphone, download the
Android Auto application.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
Android Auto technology on the vehicle
screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system
of the smartphone as well as the date
and time of the smartphone and the
system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "Android Auto" function requires the
use of a compatible smartphone and
applications.

Telephone not connected by
Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press "Android Auto" to start the
application in the system.

Depending on the smartphone, it may be
necessary to activate the "Android Auto"
function.

PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that Bluetooth

be started on the

smartphone

Telephone connected by
Bluetooth

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to display the
secondary page.

Press "Android Auto" to start the
application in the system.

Different audio sources remain accessible in
the margin of the Android Auto display, using
touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press "Telephone" to display the
primary page.

Press "Bluetooth search".
The list of telephones detected is
displayed.

Select the name of the chosen
telephone in the list.

PEUGEOT Connect Radio

On return to the vehicle, if the last
telephone connected is present again, it is
automatically recognised and within about
30 seconds of switching on the ignition,
the connection is established without any
action on your part (Bluetooth activated).

To modify the connection profile:

Press "Telephone" to display the
primary page.

Press the "PHONE" button to go to the
secondary page.

Press "Bluetooth connection" to
display the list of paired devices.

Press the "details" button of a paired
device.

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "Internet data".

Select one or more profiles.

Press "OK" to confirm.

The ability of the system to connect to just
one profile depends on the telephone.
All three profiles may connect by default.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check the instructions for your
telephone and with your service provider
for the services to which you have access.

The profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Go to the Brand's website for more information
(compatibility, additional help, etc.).

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press "Telephone" to display the
primary page.

Press the "PHONE" button to go to the
secondary page.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the "Bluetooth" function in
your telephone.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Automatic reconnection

PEUGEOT Connect Radio

Press "Bluetooth connection" to
display the list of paired devices.

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Deleting a telephone

Press the basket at the top right
of the screen to display a basket
alongside the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted PHONE button to accept
an incoming call.

And

Make a long press

on the steering mounted PHONE
button to reject the call.

Press "End call".

Making a call

Using the telephone is not recommended
while driving.
Park the vehicle.
Make the call using the steering mounted
controls.

Calling a new number

Press "Telephone" to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call" to start the call.

Calling a contact

Press "Telephone" to display the
primary page.

Or make a long press

on the steering mounted PHONE
button.

Press "Contacts".

Select the desired contact from the list offered.

Press "Call".

PEUGEOT Connect Radio

Calling a recently used
number

Press "Telephone" to display the
primary page.

Make a long press

on the steering mounted button.

Press "Recent calls".

Select the desired contact from the list offered.

It is always possible to make a call directly
from the telephone; as a safety measure,
first park the vehicle.

Setting the ringtone

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Ring volume" to display the
volume bar.

Press the arrows or move the cursor
to set the ring volume.

Configuration

Profile settings

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary.

Press "Settings" to display the
primary page.

Press "Profiles".

Select "Profile 1" or "Profile 2" or "Profile 3"
or "Common profile".

Press this button to enter a name for
the profile using the virtual keypad.

Press "OK" to save.

PEUGEOT Connect Radio

Press the back arrow to confirm.

Press this button to activate the
profile.

Press the back arrow again to
confirm.

Press this button to initialise the
profile selected.

Adjust brightness

Press "Settings" to display the
primary page.

Press Brightness.

Move the cursor to adjust the brightness
of the screen and/or of the instrument
panel (according to version).

Press in the grey zone to confirm.

Modifying system settings

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "System configuration".

Select "Units" to change the units of distance,
fuel consumption and temperature.

Press "Factory settings" to return to the initial
settings.

Returning the system to factory settings
activates the English language by default
(according to version).

Select "System info" to display the versions of
the different modules installed in the system.

Press the back arrow to confirm.

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Screen configuration".

Press "Brightness".

Move the cursor to adjust the brightness
of the screen and/or of the instrument
panel (according to version).

Press "Animation".

Activate or deactivate: "Automatic
scrolling".

Select "Animated transitions".

Press the back arrow to confirm.

PEUGEOT Connect Radio

Select the language

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Select "Language" to change the
language.

Press the back arrow to confirm.

Setting the time

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Date and time".

Select "Time".

Press this button to adjust the time
using the virtual keypad.

Press "OK" to save the time.

Press this button to define the time
zone.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

Press the back arrow to save the
settings.

The system does not automatically
manage the change between winter and
summer time (depending on the country
of sale).

Setting the date

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Date and time".

Select "Date".

Press on this button to define the
date.

Press the back arrow to save the
date.

Select the display format of the date.

Press the back arrow again to
confirm.

PEUGEOT Connect Radio

Radio

QUESTION

RESPONSE

SOLUTION

The reception quality of the tuned radio station
gradually deteriorates or the stored stations
are not working (no sound, 87.5 MHz is
displayed , etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the "RDS" function by means of the
upper band to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception,
including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a dealer.

I cannot find some radio stations in the list of
received stations.
The name of the radio station changes.

The station is not received or has changed its
name in the list.

Press the round arrow on the "List" tab of the
"Radio" page.

Some radio stations send other information
in place of their name (the title of the song for
example).
The system interprets these details as the
station name.

PEUGEOT Connect Radio

Media

QUESTION

RESPONSE

SOLUTION

Playback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick
may greatly slow down access to reading
the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some information characters in the currently
playing media are not displayed correctly.

The audio system does not display some types
of characters.

Use standard characters to name tracks and
folders.

Playback of streaming files does not start.

The connected device does not automatically
launch playback.

Start playback from the device.

Names of tracks and playing time are not
displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer
of this information.

PEUGEOT Connect Radio

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone at the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, etc.).

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

Telephone

Peugeot 5008 (2017 year). Manual - part 23
