PEUGEOT Connect Nav

Press "OK" to confirm.

To protect against unauthorised access
and make your systems as secure as
possible, the use of a complex security
code or password is recommended.

Manage connections

Press "Connect-App" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Manage connection".

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Radio

Selecting a station

Press "Radio Media" to display the
primary page.

Press "Frequency".

Press one of the buttons for an
automatic search for radio stations.

Move the cursor for a manual search
for frequencies up or down.

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio stations" in the
secondary page.

Press "Frequency".

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press "OK" to confirm.

Radio reception may be affected by the
use of electrical equipment not approved
by the Brand, such as a USB charger
connected to the 12 V socket.
The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

PEUGEOT Connect Nav

Make a long press on one of the
buttons to preset the station.

Activating / Deactivating
RDS

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Activate / Deactivate "Station
follow".

Press "OK" to confirm.

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100% of the territory.
This explains the loss of reception of the
station during a journey.

Display text information

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Presetting a station

Select a radio station or frequency.
(refer to the corresponding section)

Press "Presets".

Activate / Deactivate "Display radio
text".

Press "OK" to confirm.

PEUGEOT Connect Nav

Select "Announcements".

Activate / Deactivate "Traffic
announcement".

Press "OK" to confirm.

DAB (Digital Audio
Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality
reception.
The different multiplexes offer a choice
of radio stations arranged in alphabetical
order.

Press "Radio Media" to display the
primary page.

Select the audio source.

Press "Band" to select the "DAB" waveband.

DAB-FM auto tracking

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB-FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station (if
there is one).

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. While traffic
information is being broadcast, the current
media is automatically interrupted so that
the TA message can be heard. Normal
play of the media previously playing is
resumed at the end of the message.

PEUGEOT Connect Nav

Activate / Deactivate "Station
follow".

Press "OK".

If "DAB-FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a variation
in volume.
Once the digital signal quality is restored,
the system automatically changes back
to "DAB".

If the "DAB" station being listened to is
not available on "FM" ("DAB-FM" option
greyed out), or "DAB/FM auto tracking" is
not activated, the sound will cut out while
the digital signal is too weak.

Media

USB port

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Auxiliary socket (AUX)

(depending on model / depending on equipment)

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player, etc.)
to the auxiliary jack socket using an audio
cable (not supplied).

First adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

CD player

(depending on model / depending on
equipment)
Insert the CD in the player.

PEUGEOT Connect Nav

Selecting the source

Press "Radio Media" to display the
primary page.

Select "Source".

Choose the source.

Bluetooth

audio streaming

Streaming allows you to listen to music from
your smartphone.

The Bluetooth profile must be activated, first
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in streaming mode, the
telephone is considered to be a media
source.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those of
the portable device connected (artists /
albums / genres / playlists / audiobooks /
podcasts).
The default classification used is by
artists. To modify the classification used,
return to the first level of the menu then
select the desired classification (playlists
for example) and confirm to go down
through the menu to the desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The system supports USB mass storage
devices, BlackBerry

devices or Apple

players via USB ports. The adapter cable
is not supplied.
Device management is done by the audio
system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

To protect the system, do not use a USB
hub.

The audio equipment will only play audio files
with ".wma", ".aac", ".flac", ".ogg" and ".mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other file types (.mp4, etc.) can be read.
".wma" files must be of the standard wma
9 type.
The sampling rates supported are 32, 44 and
48 kHz.

PEUGEOT Connect Nav

It is advisable to restrict file names to
20 characters, without using special characters
(e.g. " " ? .; ù) in order to avoid any reading or
display problems.

Use only USB keys in FAT32 format (File
Allocation Table).

It is recommended that the original USB
cable for the portable device is used.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Telephone

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press "Telephone" to display the
primary page.

Press "Bluetooth search".

Select "Search".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the Bluetooth function in
your telephone.

PEUGEOT Connect Nav

Select the name of the chosen
telephone in the list.

Connection sharing

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "Mobile internet data".

Activation of the profile; "Mobile internet
data" is obligatory for connected
navigation having first activated sharing of
this connection on your smartphone.

Select one or more profiles.

Press "OK" to confirm.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Automatic reconnection

On return to the vehicle, if the last
telephone connected is present again, it is
automatically recognised and within about
30 seconds of switching on the ignition,
the connection is established without any
action on your part (Bluetooth activated).

To modify the connection profile:

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Bluetooth connection" to
display the list of paired devices.

Press the "details" button.

Select one or more profiles.

Press "OK" to confirm.

The ability of the system to connect to just
one profile depends on the telephone.
All three profiles may connect by default.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check the instructions for your
telephone and with your service provider
for the services to which you have access.

The profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Go to the Brand's website for more information
(compatibility, additional help, etc.).

PEUGEOT Connect Nav

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Bluetooth connection" to
display the list of paired devices.

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Deleting a telephone

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted TEL button to accept an
incoming call.

And

Make a long press

on the steering mounted TEL button
to reject the call.

Select "End call".

Making a call

Using the telephone is not recommended
while driving.
Park the vehicle.
Make the call using the steering mounted
controls.

Calling a new number

Press "Telephone" to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call" to start the call.

PEUGEOT Connect Nav

Calling a contact

Press "Telephone" to display the
primary page.

Or make a long press

on the steering mounted TEL button.

Select "Contact".

Select the desired contact from the list offered.

Select "Call".

Calling a recently used
number

Press "Telephone" to display the
primary page.

Make a long press

on the steering mounted button.

Select "Calls".

Select the desired contact from the list offered.

It is always possible to make a call directly
from the telephone; as a safety measure,
first park the vehicle.

Managing contacts / entries

Press "Telephone" to display the
primary page.

Select "Contact".

Select "Create" to add a new
contact.

In the "Telephone" tab, enter the telephone
numbers for the contact.

In the "Address" tab, enter the addresses for
the contact.

In the "Email" tab, enter the email addresses
for the contact.

The "Email" function allows email
addresses to be entered for a contact, but
the system is not able to send emails.

PEUGEOT Connect Nav

Managing messages

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Messages" to display the list
of messages.

Select the "All" or "Sent" or
"Incoming" tab.

Select the detail of the message
chosen in one of the lists.

Press "Answer" to send a quick
message stored in the system.

Press "Call" to start the call.

Press "Play" to hear the message.

Access to "Messages" depends on the
compatibility of the smartphone and the
integral system.
Depending on the smartphone, access to
your messages or email may be slow.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your smartphone
and with your service provider for the
services available to you.

Managing quick messages

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Quick messages" to display
the list of messages.

Select the "Delayed" or "My arrival"
or "Not available" or "Other" tab
with the possibility of creating new
messages.

PEUGEOT Connect Nav

Press "Create" to write a new
message.

Select the message chosen in one
of the lists.

Press "Transfer" to select the
addressee(s).

Press "Play" to start playing the
message.

Managing email

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Email" to display the list of
messages.

Select the "Incoming" or "Sent" or
"Not read" tab.

Select the message chosen in one of the lists.

Press "Play" to start playing the
message.

Access to "Email" depends on the
compatibility of the smartphone and the
integral system.

Configuration

Audio settings

Press "Settings" to display the
primary page.

Select "Audio settings".

Select "Ambience".

"Position".

"Sound".

"Voice".

"Ringtone".

Press "OK" to save the settings.

PEUGEOT Connect Nav

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.
Available only with the front and rear
speakers configuration.

The audio settings Ambience (6 optional
ambiences) and Bass, Medium and
Treble are different and independent for
each audio source.
Activate or Deactivate "Loudness".
The settings for "Position" (All
passengers, Driver and Front only) are
common to all sources.
Activate or Deactivate "Touch tones",
"Volume linked to speed" and "Auxiliary
input".

Onboard audio: Arkamys

Sound Staging

optimises the distribution of sound in the
passenger compartment.

Profile settings

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary.

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting of the profiles".

Select "Profile 1" or "Profile 2" or "Profile 3"
or "Common profile".

Press this button to enter a name for
the profile using the virtual keypad.

Press "OK" to confirm.

Press this button to add a
photograph to the profile.

Insert a USB memory stick
containing the photograph in the
USB port.
Select the photograph.

Press "OK" to accept the transfer of
the photograph.

Press "OK" again to save the
settings.

The location for the photograph is
square; the system reshapes the original
photograph if in another format.

Press this button to initialise the
profile selected.

PEUGEOT Connect Nav

Select "Ambience".

"Position".

"Sound".

"Voice".

"Ringtone".

Press "OK" to save the settings.

Modifying system settings

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Screen configuration".

Select "Animation".

Activate or deactivate: "Automatic
scrolling".

Select "Brightness".

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel.

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "System settings".

Initialisation of the profile selected
activates the English language by default.

Select a "Profile" (1 or 2 or 3) to associate the
"Audio settings" with it.

Select "Audio settings".

Select "Units" to change the units of distance,
fuel consumption and temperature.

Select "Factory settings" to return to the initial
settings.

Returning the system to factory settings
activates the English language by default.

Select "System info" to display the versions of
the different modules installed in the system.

PEUGEOT Connect Nav

Select the language

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Languages" to change the
language.

Setting the date

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting the time-date".

Select "Date".

Press on this button to define the
date.

Press "OK" to confirm.

Select the display format of the date.

Adjustment of the time and date is only
available if "GPS synchronisation" is
deactivated.
The change between winter and summer
time is done by changing the time zone.

Setting the time

Press "Settings" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting the time-date".

Select "Time".

Press this button to adjust the time
using the virtual keypad.

Press "OK" to confirm.

Press this button to define the time
zone.

PEUGEOT Connect Nav

Press "OK" to confirm.

The system does not automatically
manage the change between winter and
summer time (depending on country).

Colour schemes

As a safety measure, the procedure
for changing the colour scheme is only
possible when the vehicle is stationary.

Press "Settings" to display the
primary page.

Select "Colour schemes".

Select a colour scheme in the list
then press "OK" to confirm.

Every time the colour scheme is changed,
the system restarts, temporarily displaying
a black screen.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

Frequently asked
questions

The following information groups together the
answers to the most frequently asked questions
concerning your audio system.

PEUGEOT Connect Nav

Navigation

QUESTION

RESPONSE

SOLUTION

The route calculation is not
successful.

The guidance criteria may be in conflict with the current
location (exclusion of toll roads on a toll road).

Check the route settings in the "Navigation" menu.

The POIs do not appear.

The POIs have not been selected.

Select the POIs in the list of POIs.

The audible warning of "Danger
areas" does not work.

The audible warning is not active or the volume is too
low.

Activate the audible warning in the "Navigation" menu
and check the voice volume in the audio settings.

The system does not suggest
a detour around an incident on
the route.

The guidance criteria do not take account of TMC
messages.

Select setting for the "Traffic info "function in the list of
route settings (Without, Manual or Automatic).

I receive a "Danger zone" alert
which is not on my route.

Other than guidance, the system announces all "Danger
zones" positioned in a cone located in front of the
vehicle. It may provide an alert for "Danger zones"
located on nearby or parallel roads.

Zoom in on the map to see the exact position of the
"Danger zone". Select "On the route" to no longer
receive alerts other than navigation instructions or to
reduce the time for the announcement.

Certain traffic jams along the
route are not indicated in real
time.

On starting, it is several minutes before the system
begins to receive the traffic information.

Wait until the traffic information is being received correctly
(display of the traffic information icons on the map).

In certain countries, only major routes (motorways, etc.)
are listed for the traffic information.

This is perfectly normal. The system is dependent on
the traffic information available.

The altitude is not displayed.

On starting, the initialisation of the GPS may take up to
3 minutes to receive more than 4 satellites correctly.

Wait until the system has started up completely so that
there is GPS coverage by at least 4 satellites.

Depending on the geographical environment (tunnel,
etc.) or the weather, the conditions of reception of the
GPS signal may vary.

This behaviour is normal. The system is dependent on
the GPS signal reception conditions.

My navigation is no longer
connected.

During start-up and in certain geographical areas, the
connection may be unavailable.

Check that the connected services are activated
(settings, contract).

Content .. 19 20 21 22 ..
