Peugeot 207 Dag (2010 year). Manual - part 6

Windscreen and headlamp
wash

B. rear wiper selection ring:

off,

intermittent wipe,

wiping with screenwash (ﬁ xed

duration).

  Reverse gear
When  reverse  gear  is  engaged,  if  the
windscreen  wipers  are  operating,  the
rear wiper will start.

Programming

 Pull the windscreen wiper stalk to-

wards you.

The headlamp wash is only activate if
the dipped headlamps are on .

Rear wiper

In  the  presence  of  snow  or  con-
siderable  frost  and  when  using  a
tailgate  bicycle  carrier,  deactivate
the  automatic  rear  wiper  via  the

multifunction screen conﬁ guration

menu.

The function is activated or
switched off via the multi-

function screen conﬁ gura-

tion menu.
By default, this function is
activated.

With daytime running lamps, to
activate the headlamp wash, posi-
tion the lighting stalk in the dipped
beam position.
On vehicles ﬁ tted with digital air

conditioning,  any  action  on  the
windscreen wash control results in
temporary  closing  of  the  air  intake
to avoid odours inside the passen-
ger compartment.

Special position of the windscreen
wipers

Automatic rain sensitive
windscreen wipers

The windscreen wipers operate automati-
cally, without any action on the part of the
driver, if rain is detected (sensor behind

the rear view mirror), adapting their speed

to the intensity of the rainfall.

  Activation
This is controlled manually by the driver
by  pushing  the  stalk   A   to  the   "AUTO"
position.
It is accompanied by a message on the
multifunction screen.

In  the  minute  following  switching  off  of
the ignition, any action on the stalk po-
sitions the wipers vertically on the wind-
screen.
This action enables you to position the
wiper blades for winter parking.
To  park  the  wipers  after  this  has  been
done, switch on the ignition and operate
the stalk.

Do not cover the rain sensor, cou-
pled with the sunshine sensor and
located  in  the  centre  of  the  wind-
screen behind the rear view mirror.
Switch  off  the  ignition  when  using
an automatic car wash.
In winter, it is advisable to wait until
the windscreen is completely clear
of  ice  before  activating  the  auto-
matic rain sensitive wipers.

The  automatic  rain  sensitive  wip-
ers  must  be  reactivated  if  the  ig-
nition  has  been  off  for  more  than
one minute, by pushing the stalk  A
downwards.

  Switching off
This is controlled manually by the driver
by  moving  the  stalk   A   to  another  posi-
tion and returning it to position  "0" .
It is accompanied by a message on the
multifunction screen.

Operating fault
If an automatic wiping malfunction oc-
curs, the wipers will operate in intermit-
tent mode.
Have it checked by a PEUGEOT dealer.

COURTESY LAMPS

3. Rear courtesy lamp

Front and rear courtesy lamps

In this position, the courtesy
lamp comes on gradually:

Map reading lamps

 With the ignition on, press the cor-

responding switch.

In permanent lighting mode, differ-
ent lighting times are available:
-

with the ignition off, approxi-
mately ten minutes,

in energy economy mode, ap-
proximately thirty seconds,

with the engine running, unlimited.

when the vehicle is unlocked,

when the key is removed from the ignition,

when the remote control locking button is
activated, in order to locate your vehicle.

Permanently off.

Permanent lighting.

It switches off gradually:
-

when the vehicle is locked,

when the ignition is switched on,

30 seconds after the last door is
closed.

1. Front courtesy lamp
2. Map reading lamp

CHILD SAFETY

  PEUGEOT recommends  that chil-
dren should travel in the  rear seats
of your vehicle:
   -

"rearwards-facing" up to the
age of 2,

"forwards-facing" over the
age of 2.

GENERAL POINTS RELATING
TO CHILD SEATS

CHILD SEAT IN THE FRONT

  "Rearwards-facing"
When a "rearwards-facing" child seat is
installed on the  front passenger seat ,
it is essential that the passenger airbag
is  deactivated.  Otherwise,   the  child
would risk being seriously injured or

killed if the airbag were to inﬂ ate .

* The rules for carrying children are

speciﬁ c to each country. Refer to the

current legislation in your country.

Although  one  of  PEUGEOT's  main  cri-
teria  when  designing  your  vehicle,  the
safety of your children also depends on
you.
For  maximum  safety,  please  observe
the following recommendations:
   -

in  accordance  with  European  reg-
ulations,   all  children  under  the
age  of  12  or  less  than  one  and  a
half metres tall must travel in ap-
proved child seats suited to their
weight

, on seats ﬁ tted with a seat

belt or ISOFIX mountings * ,

statistically, the safest seats in
your vehicle for carrying children
are the rear seats,

a child weighing less than 9 kg
must travel in the "rearwards-fac-
ing" position both in the front and
in the rear.

Intermediate longitudinal

position

  "Forwards-facing"
When  a  "forwards-facing"  child  seat  is
installed on the  front passenger seat ,
adjust the vehicle's seat to the interme-
diate longitudinal position with the seat
back  upright  and  leave  the  passenger
airbag activated.

CHILD SAFETY

Passenger air bag OFF

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are
secured using a three point seat belt :

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

Groups 1, 2 and 3: from 9 to 36 kg

"RÖMER Baby-

Safe Plus"

Installed in the

rearwards-facing

position.

"KIDDY Life"

The use of the

restraining cushion

is compulsory for

carrying young

children

(from 9 to 18 kg).

Groups 2 and 3: from 15 to 36 kg

"RECARO Start''

"KLIPPAN Optima"

From the age of

6 years

(approximately 22 kg),

the booster is used

on its own.

"RÖMER KIDFIX"

Can be ﬁ tted to the vehicle's ISOFIX mountings.

The child is restrained by the seat belt.

CHILD SAFETY

Passenger air bag OFF

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are
secured using a three point seat belt :

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

Groups 1, 2 and 3: from 9 to 36 kg

"RÖMER Baby-

Safe Plus"

Installed in the

rearwards-facing

position.

"KIDDY Life"

The use of the

restraining cushion

is compulsory for

carrying young

children

(from 9 to 18 kg).

Groups 2 and 3: from 15 to 36 kg

"RECARO Start''

"KLIPPAN Optima"

From the age of

6 years

(approximately 22 kg),

the booster is used

on its own.

"RÖMER KIDFIX"

Can be ﬁ tted to the vehicle's ISOFIX mountings.

The child is restrained by the seat belt.

CHILD SAFETY

LOCATIONS FOR CHILD SEATS SECURED WITH THE SEAT BELT (SALOON)

In accordance with the European regulation, this table indicates the options for the installation of child seats secured using
the seat belt and universally approved (a) in relation to the weight of the child and the seat in the vehicle.

(a) Universal child seat: child seat which can be installed in all vehicles using the seat belt.
(b) Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat.
(c) Consult the legislation in force in your country before installing your child on this seat.
U : seat suitable for the installation of a child seat secured using the seat belt and universally approved "rear facing" and/or

"forward facing".

X : seat not suitable for the installation of a child seat of the weight group indicated.

Weight of the child/ indicative age

Seat

Less than 13 kg

(groups 0 (b) and 0+)
Up to 1 year approx

From 9 to 18 kg

(group 1)

From 1 to 3 years

approx

From 15 to 25 kg

(group 2)

From 3 to 6 years

approx

From 22 to 36 kg

(group 3)

From 6 to 10 years

approx

Front passenger seat (c)

- ﬁ xed

height adjustable

Outer rear seats

Centre rear seat

CHILD SAFETY

LOCATIONS FOR CHILD SEATS SECURED WITH THE SEAT BELT (SW)

(a) Universal child seat: child seat which can be installed in all vehicles using the seat belt.
(b) Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat.
(c) Consult the legislation in force in your country before installing your child on this seat.
U: seat suitable for the installation of a child seat secured using the seat belt and universally approved "rear facing" and/or

"forward facing".

Weight of the child /indicative age

Seat

Less than 13 kg

(groups 0 (b) and 0+)
Up to 1 year approx

From 9 to 18 kg

(group 1)

From 1 to 3 years approx

From 15 to 25 kg

(group 2)

From 3 to 6 years approx

From 22 to 36 kg

(group 3)

From 6 to 10 years approx

Front passenger seat (c)

- ﬁ xed

height adjustable

Outer rear seats

Centre rear seat

U *

* The rear left side seat becomes unusable.

CHILD SAFETY

  Installing a booster seat
The  chest  part  of  the  seat  belt  must
be positioned on the child's shoulder
without touching the neck.
Ensure  that  the  lap  part  of  the  seat
belt passes correctly over the child's
thighs.
PEUGEOT  recommends  the  use  of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder
level.

The  incorrect  installation  of  a  child
seat  in  a  vehicle  compromises  the
child's  protection  in  the  event  of  an
accident.
Remember to fasten the seat belts or

the child seat harnesses keeping the
slack relative to the child's body to a
minimum, even for short journeys.
When installing a child seat using the
seat belt, ensure that the seat belt is
tightened correctly on the child seat

and that it secures the child seat ﬁ rm-

ly on the seat of your vehicle.
For  optimum  installation  of  the  "for-
wards-facing" child seat, ensure that
the back of the child seat is in contact
with  the  back  of  the  vehicle's  seat
and that the head restraint does not
cause any discomfort.
If  the  head  restraint  has  to  be  re-
moved,  ensure  that  it  is  stored  or
attached  securely  to  prevent  it  from
being  thrown  around  the  vehicle  in
the event of sharp braking.

As a safety precaution, do not leave:
-

a child or children alone and un-
supervised in a vehicle,

a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,

the keys within reach of children
inside the vehicle.

To prevent accidental opening of the
doors and rear windows, use the

"Child lock".
Take care not to open the rear win-
dows by more than one third.
To protect young children from the

rays of the sun, ﬁ t side blinds on the

rear windows.

Children under the age of 10 must

not  travel  in  the  "forwards-facing"
position on the front passenger seat,
unless the rear seats are already oc-
cupied  by  other  children,  cannot  be
used or are absent.
Deactivate  the  passenger  airbag
when a "rearwards-facing" child seat
is installed on the front seat.
Otherwise, the child would risk being
seriously injured or killed if the airbag

were to inﬂ ate.

CHILD SAFETY

The incorrect installation of a child
seat in a vehicle compromises the
child's protection in the event of an
accident.

For

information

regarding

the

ISOFIX child seats which can be
installed in your vehicle, refer to the
table giving the locations for the in-
stallation of ISOFIX child seats.

"ISOFIX" MOUNTINGS

Your vehicle has been approved in
accordance with the new ISOFIX regu-
lation s.
The seats, represented below, are ﬁ tted

with regulation ISOFIX mountings:

These are three rings for each seat:

two rings A , located between the
vehicle seat back and cushion, indi-
cated by a label,

a ring B

, for ﬁ xing the upper strap

referred to as the TOP TETHER .

This ISOFIX mounting system guaran-

tees you fast, reliable and safe ﬁ tting of

the child seat in your vehicle.
The ISOFIX child seats

are ﬁ tted with

two  locks  which  are  secured  easily  on
the two rings  A .
Some also have an  upper strap  which
is attached to ring  B .
To  attach  this  strap,  raise  the  vehicle
seat's head restraint then pass the hook

between its rods. Then ﬁ x the hook on

ring B and tighten the upper strap.

Saloon

CHILD SAFETY

ISOFIX CHILD SEAT RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE

This child seat can also be used on seats which are not ﬁ tted with ISOFIX mountings. In this case, it must be attached

to the vehicle seat using the three point seat belt.

Follow the instructions for ﬁ tting the child seat given in the seat manufacturer's installation guide.

RÖMER Duo Plus ISOFIX (size category B1 )

Group 1: from 9 to 18 kg

Installed in the forwards-facing position.

Fitted with an upper strap to be secured on the upper ring B ,

referred to as the TOP TETHER.

Three seat body angles: sitting, reclining, lying.

CHILD SAFETY

LOCATIONS FOR THE INSTALLATION OF ISOFIX CHILD SEATS (SALOON)

In accordance with the European regulation, this table indicates the options for the installation of ISOFIX child seats on the

vehicle seats ﬁ tted with ISOFIX mountings.
In the case of the universal and semi-universal ISOFIX child seats, the child seat's ISOFIX size category, determined by a
letter from A to G , is indicated on the child seat next to the ISOFIX logo.

IUF: seat suitable for the installation of an I

soﬁ x U niversal seat, " F orward facing" and secured using the "Top Tether" upper strap.

IL-SU: seat suitable for the installation an I

soﬁ x S emi- U niversal seat which is:

- "rear facing" ﬁ tted with a "Top Tether" upper strap or a stay,

- "forward facing" ﬁ tted with a stay,

- an infant car seat ﬁ tted with a "Top Tether" upper strap or a stay.

For the securing of the "Top Tether" upper strap, refer to the "Isoﬁ x Mountings" section.
X: seat which is not suitable for the installation of an ISOFIX seat of the size category indicated.

Weight of the child /indicative age

Less than 10 kg

(group 0)

Up to 6 months

approx

Less than 10 kg

(group 0)

Less than 13 kg

(group 0+)

Up to 1 year approx

From 9 to 18 kg (group 1)

From 1 to 3 years approx

Type of ISOFIX child seat

Infant car seat *

"rear facing"

"forward facing"

ISOFIX size category

Universal and semi-universal
ISOFIX child seats which can

be installed on the rear seats

IL-SU **

IUF **

IL-SU **

The ISOFIX infant car seat, ﬁ xed to the lower rings of a seat equipped with ISOFIX mountings, occupies the three rear seats.

To install it on the rear seats of a 3-door model, the front seat belt must be adjusted to the lowest position.

Infant car seats and "car cots" cannot be installed on the front passenger seat.

The head restraint of the seat equipped with ISOFIX mountings must be removed and stored.

CHILD SAFETY

LOCATIONS FOR THE INSTALLATION OF ISOFIX CHILD SEATS (SW)

In accordance with the European regulation, this table indicates the options for the installation of ISOFIX child seats on the

IUF: seat suitable for the installation of an I

soﬁ x U niversal seat, " F orward facing" and secured using the "Top Tether" upper strap.

IL-SU: seat suitable for the installation an I

soﬁ x S emi- U niversal seat which is:

- "rear facing" ﬁ tted with a "Top Tether" upper strap or a stay,

- "forward facing" ﬁ tted with a stay,

- an infant car seat ﬁ tted with a "Top Tether" upper strap or a stay.

For the securing of the "Top Tether" upper strap, refer to the "Isoﬁ x Mountings" section.

(a) The head restraint where the ISOFIX seat is ﬁ tted must be removed and stored safely.

Weight of the child /indicative age

Less than 10 kg

(group 0)

Up to 6 months

approx

Less than 10 kg

(group 0)

Less than 13 kg

(group 0+)

Up to 1 year approx

From 9 to 18 kg (group 1)

From 1 to 3 years approx

Type of ISOFIX child seat

Infant car seat *

"rear facing"

"forward facing"

ISOFIX size category

C **

Universal and semi-universal
ISOFIX child seats which can

be installed on the rear seats

IL-SU(a)

IUF(a)

IL-SU(a)

The ISOFIX infant car seat, ﬁ xed to the lower rings of a seat equipped with ISOFIX mountings, occupies the three rear

seats and prevents use of the 2/3 - 1/3 modularity.

Infant car seats and "car cots" cannot be installed on the front passenger seat.

** The front seat must be adjusted ﬁ ve notches back from the fully forward position.

CHILD SAFETY

This system is independent and in
no circumstances does it take the
place of the central locking control.
Check the status of the child lock

each time you switch on the ignition.
Always  remove  the  key  from  the
ignition  when  leaving  the  vehicle,
even for a short time.
In  the  event  of  a  serious  impact,
the electric child lock is deactivated
automatically to allow the rear pas-
sengers to exit the vehicle.

MANUAL CHILD LOCK

Mechanical system to prevent opening

of the rear door using its interior control.
The control is located on the edge of
each rear door.



Turn the red control one quarter of

a turn to the left using the ignition
key.

ELECTRIC CHILD LOCK

Remote control system to prevent open-

ing of the rear doors using their interior
controls.
The control is located in the centre of
the dashboard.

      Press button  A .
The  indicator  lamp  on  button   A   comes
on, accompanied by a message on the
multifunction screen.

Locking

Unlocking


Turn the red control one quarter of

a turn to the right using the ignition
key.

Activation

  Deactivation
      Press button  A  again.
The indicator lamp on button  A  switches
off, accompanied by a message on the
multifunction screen.

SAFETY

DIRECTION INDICATORS

Selection of the left or right direction in-
dicators to signal a change of direction
of the vehicle.

If you forget to cancel the direc-
tion indicators for more than twenty
seconds, the volume of the audible
signal will increase if the speed is
above 40 mph (60 km/h).

 Lower the lighting stalk when moving

to the left.

 Raise the lighting stalk when moving

to the right.

"Motorway" function



Press brieﬂ y upwards or downwards,

without going beyond the point of re-
sistance; the direction indicators will

ﬂ ash 3 times.

EMERGENCY OR ASSISTANCE
CALL

This system allows you to make an
emergency or assistance call to the
emergency services or to the dedicated
PEUGEOT service.

For more information on the use of this
function, refer to the "Audio and tele-
matics" section.

SAFETY

100

HAZARD WARNING LAMPS

A visual warning by means of the direc-
tion indicators to alert other road users
to a vehicle breakdown, towing or ac-
cident.

 Press this button, the direction indi-

cators ﬂ ash.

They can operate with the ignition off.

Automatic operation of hazard
warning lamps

When braking in an emergency, de-
pending on the deceleration, the hazard
warning lamps come on automatically.
They switch off automatically the ﬁ rst

time you accelerate.
 You can also switch them off by

pressing the button.

HORN

 Press one of the spokes of the steering

wheel.

Use the horn moderately and only
in the following cases:
-

immediate danger,

when approaching an area
where there is no visibility.

Audible warning to alert other road users
to an imminent danger.

Content .. 4 5 6 7 ..
