Peugeot 207 CC (2014 year). Manual - part 14

207

1

2

3

SOURCE

06

  Initiate the pairing between the telephone and the

vehicle. This pairing can be initiated from the vehicle's

telephone function menu or via the telephone's

keypad. See steps 1 to 9 on the previous pages.

During the pairing phase, the vehicle must be

stationary with the key in the ignition.

  Select the telephone to be connected from the telephone function

menu.

 The audio system connects to a newly paired telephone

automatically.

       BLUETOOTH  AUDIO  STREAMING *

  Wireless transmission of the telephone's music fi les via the audio

equipment. The telephone must be able to manage the appropriate

Bluetooth profi les (Profi les A2DP/AVRCP).

  *   Depending on the compatibility of the telephone.

  **    In certain cases, playing of the Audio fi les must be initiated from the

keypad.

  ***   If the telephone supports the function.

  Activate the streaming source by

pressing the SOURCE button ** .

The tracks to be played can be

controlled as usual via the buttons on

the audio system control panel and

the steering mounted controls *** .

The contextual information can be

displayed on the screen.

 BLUETOOTH

208

07  SCREEN MENU MAP(S)

  Radio-CD

        MAIN  FUNCTION

  *    The  settings  vary  according  to  vehicle.

 Option  A

  Option  B...

Screen A

Option A1

 Option  A11

REG mode

CD repeat

Shuffl e play

  Vehicle  config *

R wiper in rev

  Options

Guide lighting

Diagnostic

RDS options

 View

 Abandon

1

2

1

3

1

2

3

3

1

2

2

2

2

1

2

2

209

07

  Units

Fuel consumption:

KM/L - L/100 - MPG

 SCREEN MENU MAP(S)

  Display  adjust

Month

Day

Hour

Minutes

Year

12 H/24 H mode

  Language

Italiano

Nederlands

Portuguès

Portuguès-Brazil

Français

Deutsch

English

Español

1

2

2

1

2

2

2

2

2

2

1

2

2

2

2

2

2

2

2

210

07  SCREEN MENU MAP(S)

  Press the OK dial for access to short-cut menus according to the display

on the screen:

Screen C

activate / deactivate RDS

activate / deactivate REG mode

activate / deactivate radiotext

  RADIO

activate / deactivate Intro

  CD / MP3 CD

activate / deactivate track repeat (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate random play (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate track repeat (of the

current folder / artist / genre / playlist)

  USB

activate / deactivate random play    (of the

current folder / artist / genre / playlist)

1

1

1

1

1

1

1

1

211

07

 Screen C

 SCREEN MENU MAP(S)

  Audio  functions

  Alternative  frequencies  (RDS)

 activate / deactivate

FM    preferences

  Regional  mode  (REG)

 activate / deactivate

  Radio-text  information  (RDTXT)

 activate / deactivate

1

2

3

4

3

4

3

4

Play modes

  Album  repeat  (RPT)

 activate / deactivate

  Track  random  play  (RDM)

 activate  /  deactivate

2

3

4

3

4

  Trip  computer

 Distance: x miles

Enter distance to destination

 Diagnostics

Alert log

 Systems  activated  or  deactivated

State of systems  *

1

2

3

3

2

3

2

  Pressing the MENU button displays:

  *    The  settings  vary  according  to  vehicle.

212

07  SCREEN MENU MAP(S)

  Bluetooth  telephone

 Connect/Disconnect an equipment

 Consult the paired equipment

Bluetooth confi guration

  Telephone  function

  Audio  Streaming  function

 Delete a paired equipment

 Perform a Bluetooth search

  Calls  list

Call

 Directory

  Terminate  the  current  call

Manage the telephone call

  Activate  secret  mode

1

2

3

3

3

4

4

4

2

3

4

2

3

3

 Video-brightness  adjustment

Display confi guration

Defi ne vehicle settings  *

  Personalisation-Configuration

 normal  video

 inverse  video

 brightness (- +) adjustment

 Setting the date and time

 setting  day/month/year

 hour/minute  adjustment

 choice of 12 h / 24 h mode

 Choice of units

 l/100 km - mpg - km/l

 °Celsius / °Fahrenheit

Choice of language

1

2

4

3

2

4

4

3

4

4

2

3

4

4

4

* The settings vary according to vehicle.

213

 FREQUENTLY  ASKED  QUESTIONS

QUESTION

ANSWER

SOLUTION

 There is a difference in

sound quality between

the different audio

sources (radio, CD...).

 For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

 Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the musical ambience "None" and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

 The CD is ejected

automatically or is not

played by the player.

 The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.

 The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

   -   Check that the CD is inserted in the player the

right way up.

  -   Check the condition of the CD: the CD cannot

be played if it is too damaged.

  -   Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

  -   The audio equipment's CD player does not

play DVDs.

  -   Due to their quality level, certain writeable

CDs will not be played by the audio system.

 The message "USB

peripheral error" is

displayed on the screen.

 The Bluetooth connection

is cut.

 The battery of the peripheral may not be suffi ciently charged.

 Recharge the battery of the peripheral device.

 The USB memory stick is not recognised.

 The memory stick may be corrupt.

 Reformat the memory stick.

 I am unable to access my

voicemail.

 Few telephones or service providers allow the use of this function.

214

QUESTION

ANSWER

SOLUTION

 The CD player sound is

poor.

 The CD used is scratched or of poor quality.

 Insert good quality CDs and store them in suitable

conditions.

 The audio equipment settings (bass, treble, ambiences) are unsuitable.

 Set the treble or bass level to 0, without selecting

an ambience.

 The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

 An incorrect waveband is selected.

 Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

 The traffi c announcement

(TA) is displayed. I do

not receive any traffi c

information.

 The radio station is not part of the regional traffi c information network.

 Tune to a radio station which broadcasts traffi c

information.

 The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

 The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

 Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

 The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

 This phenomenon is normal and does not indicate

a failure of the audio equipment.

 The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

 Have the aerial checked by a PEUGEOT dealer.

 Sound cut-outs of 1 to

2 seconds in radio mode.

 During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

 Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

 With the engine off,

the audio equipment

switches off after a few

minutes of use.

 When the engine is switched off, the audio equipment operating time

depends on the battery charge.

 The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

 Start the vehicle's engine to increase the battery

charge.

 The message "the audio

system is overheated"

appears on the display.

 In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of

the CD.

 Switch the audio system off for a few minutes to

allow the system to cool.

215

VISUAL SEARCH

207CC_EN_CHAP12_RECHERCHE VISUELLE_ED01-2014

 EXTERIOR

  Door  mirrors ................................55

  Lighting  controls ....................80-82

 Static directional lighting .............83

 Headlamp  adjustment.................83

 Changing  bulbs..................138-139

   -   front  lamps
  -   foglamps
  -   direction  indicator  repeaters

  Electric  windows,

quarter lights ........................71-72

  Doors .....................................73-75

   -   opening/closing
  -   central  locking
  -   emergency  control
 Alarm .....................................69-70

  Remote  control  key................65-68

   -   opening/closing
  -   anti-theft  protection
  -   starting
  -   battery

  Accessories ..............................153

 Retractable  roof .........................6-7

  Fuel  tank .....................................77

 Misfuel  prevention ......................79

  Boot ............................................76

 Changing a wheel ..............133-136

   -   tools
  -   removal
 Boot luggage carrier .................152

  Visual  and  audible

rear parking sensors ........ 118-119

 Towbar ...............................151-152

 Towing ...............................150-151

  Changing  bulbs..................140-141

   -   rear  lamps
  -   3rd  brake  lamp
  -   number  plate  lamps

  Braking  assistance ...................100

 Trajectory  control ......................101

 Tyre under-infl ation detection .....99

 Tyre  pressure............................159

 Temporary  puncture

repair kit ...........................128-132

 Snow  chains .............................137

VISUAL SEARCH

207CC_EN_CHAP12_RECHERCHE VISUELLE_ED01-2014

 INTERIOR

  Boot fi ttings ............................60-61

   -   load  space  cover
  -   anti-swirl  net  (windstop)
  -   luggage  retaining  strap
 Installing the anti-swirl net

(Windstop) ...........................62-64

 Warning  triangle .........................97

  Child  seats .............................86-93

 ISOFIX  mountings .................94-96

  Front  seats.............................52-54

 Rear  seats ..................................54

  Seat  belts...........................102-104

  Airbags ..............................105-108

 Mats ............................................57

  Glove  box ...................................59

 Deactivating the passenger's

airbag ...........................86-87,  106

  Roll-over  bars ...........................102

217

VISUAL SEARCH

207CC_EN_CHAP12_RECHERCHE VISUELLE_ED01-2014

 INSTRUMENTS  AND  CONTROLS

  Multifunction  screens .............33-41

 Seat belt warning lamps ...........103

 Hazard warning lamps ................98

  Instrument  panels .......................20

 Warning  lamps .......................21-27

 Indicators ...............................28-31

 Gear shift indicator ................... 110

 Buttons .......................................32

   -   trip  distance  recorder
  -   lighting  dimmer

  Lighting  controls ....................80-82

 Headlamp  adjustment.................83

  Speed  limiter...................... 114-115

 Cruise  control .................... 116-117

  Door  mirrors ................................55

 Electric  windows ....................71-72

  Dashboard

fuses ................................142-144

  Steering  wheel  adjustment .........54

 Horn ............................................98

  Courtesy  lamp ............................85

 Rear view mirror .........................56

 Sun  visor.....................................57

  Wiper  controls........................84-85

 Changing a wiper

blade .......................................149

 Trip  computer ........................42-44

PEUGEOT Connect  Nav ...163-194

 PEUGEOT Connect Sound

(RD5) ...............................195-214

 Setting the date/time..............33-41

 Emergency or assistance call .... 97,  162

  Ventilation ..............................45-46

 Heating ..................................47-48

 Manual air conditioning..........47-49

 Digital  air

conditioning .........................50-51

  Interior fi ttings ........................58-59

   -   glove  box
  -   12 V accessories socket / USB

port

 Central  locking .......................74-75

  Gearbox ..................... 109, 111-113

 Parking  brake ...........................109

 Retractable  roof

control ......................................6-7

 Controls for all four windows ......72

  Opening  the  bonnet ..................121

218

VISUAL SEARCH

207CC_EN_CHAP12_RECHERCHE VISUELLE_ED01-2014

 TECHNICAL DATA - MAINTENANCE

  Running out of Diesel ...............121

  Checking  levels .................124-125

   -   oil
  -   brake fl uid
  -   coolant
  -   screenwash/headlamp wash fl uid

  Changing  bulbs..................138-141

   -   front
  -   rear

  Petrol  engines...........................154

 Petrol  weights ...........................155

 Diesel  engine ............................156

 Diesel  weights ..........................157

 Dimensions ...............................158

 Identifi cation markings ..............159

  Opening  the  bonnet ..................121

 Under-bonnet layout, petrol ......122

 Under-bonnet layout, Diesel .....123

  Checking  components .......126-127

   -   air fi lter
  -   passenger compartment fi lter
  -   oil fi lter
  -   brake  pads/discs

  Engine  compartment

fuses ................................145-146

  Battery ...............................147-148

 Load shedding /economy mode... 149

219

ALPHABETICAL INDEX

207CC_EN_CHAP13_INDEX ALPHA_ED01-2014

Accessories .................................... 153

Accessory socket, 12V ..................... 59

Access to rear seats ......................... 53

Adjusting headlamps ........................ 83

Adjusting the steering wheel ............ 54

Airbag, knee ................................... 107

Airbags .....................................27, 105

Airbags, front .................................. 105

Airbags, lateral ............................... 107

Air conditioning ................................. 18

Air conditioning, digital ...............46, 50

Air conditioning, manual .............46, 47

Air distribution adjustment ..........48, 51

Air filter ...........................................

Air filter

Air filter

126

Air flow .............................................. 18

Air flow adjustment .....................48, 51

Air intake ....................................48, 51

Air recirculation ...........................48, 51

Air vents ........................................... 45

Alarm ................................................ 69

Anti-swirl net ...............................61, 62

Anti-theft ........................................... 66

Assistance call ..........................97, 162

Audible warning ................................ 98

Audio streaming (Bluetooth) ........... 207

Automatic illumination

of headlamps ................................. 82

Automatic operation

of hazard warning lamps ............... 98

Auxiliary sockets .......59, 182, 202, 204

Capacity, fuel tank ............................ 77

CD MP3 ..................................181, 201

Central locking .................................. 74

Changing a bulb ......................138-141

Changing a fuse ......................142-146

Changing a wheel....................133-136

Changing a wiper blade ................. 149

Changing the remote control

battery ........................................... 67

Changing the time ......................34, 36

Checking levels .......................122-125

Checking the engine oil level ...30, 124

Checking tyre pressures

(using the kit) ............................... 132

Checks.....................................121-127

Children .......................86-96, 104, 106

Child seats ..................................91, 95

Child seats, conventional ................. 91

Child seats, ISOFIX .....................94-96

Daytime running

lamps ............................................. 81

Deactivating the passenger

airbag .......................................... 106

Deadlocking ...................................... 65

Defrosting ...................................47, 49

Demisting....................................47, 49

Dials and gauges.............................. 20

Diesel additive level........................ 125

Dimensions ..................................... 158

Dipped beam ............................80, 138

Dipstick .....................................30, 124

Directional lighting,

static .............................................. 83

Direction indicators ...........97, 138, 140

Doors ................................................ 73

Doors emergency control ................. 75

Door pockets .................................... 58

Driving economically ........................ 18

Closing the boot ............................... 76

Closing the retractable

roof ..................................................

roof

roof

6

Connectors, audio ....59, 182, 202, 204

Control for retractable roof .................

Control for retractable roof

Control for retractable roof

7

Control for all four windows .............. 72

Control panel, audio ...............164, 196

Coolant level ................................... 125

Coolant temperature

indicator .........................................

indicator

indicator

31

Courtesy mirror .................................

Courtesy mirror

Courtesy mirror

57

Cruise control ................................. 116

Cup holder ........................................

Cup holder

Cup holder

58

Battery, remote control ...............67, 68

Bluetooth

(hands-free) .........................183, 205

Bluetooth

(telephone) ..........................183, 205

Bonnet ............................................ 121

Bonnet stay .................................... 121

Boot .................................................. 76

Boot luggage carrier .......................

Boot luggage carrier

Boot luggage carrier

152

Brake discs ..................................... 126

Brake lamps ................................... 140

Brake pads ..................................... 126

Braking assistance system ............. 100

Battery ....................................126, 147

Battery, charging ............................ 148

A

B

C

D

220

ALPHABETICAL INDEX

207CC_EN_CHAP13_INDEX ALPHA_ED01-2014

EBA (Emergency braking

assistance) .................................. 100

Eco-driving........................................ 18

Economy mode .............................. 149

Electric window controls ................... 71

Electronic engine

immobiliser ..............................

immobiliser

immobiliser

66, 68

Electronic stability programme

(ESP) .....................................25, 100

Emergency braking

system ......................................... 100

Emergency call .........................97, 162

Emergency warning lamps ............... 98

Energy economy mode .................. 149

Engine compartment ..............122, 123

Engine compartment

fusebox ........................................ 145

Engine, Diesel ..................78, 121, 123

Engine oil ........................................ 124

Engine oil level indicator ..........

Engine oil level indicator

Engine oil level indicator

30, 124

Engine, petrol ...........................78, 122

Engines...................................154, 156

Environment ........................18, 49, 68,

125, 148, 159

Equipment settings .........166, 188, 210

ESP/ASR ........................................ 101

Keeping children safe ....86-96, 104, 106

Key in ignition warning ..................... 67

Key with remote control ...............65-68

Labels, identification ....................... 159

Lamps, rear ....................................

Lamps, rear

Lamps, rear

140

Lamps, warning and

indicator ....................................

indicator

indicator

21-27

Level, brake fluid ............................ 125

Gearbox, automatic .......... 18, 111, 127

Gearbox, manual ...... 18, 109, 110, 127

Gear lever, automatic

gearbox ........................................111

Gear lever, manual gearbox ........... 109

Gear shift indicator .........................

Gear shift indicator

Gear shift indicator

110

Glove box ......................................... 59

G.P.S. ............................................. 169

Guidance ........................................ 169

Guide-me-home..........................80, 82

Hands-free kit .........................183, 205

Hazard warning lamps................97, 98

Headlamps, directional .............83, 138

Headlamp wash ................................ 84

Head restraints, front ..................52, 54

Heated seats .................................... 54

Heating .......................................47, 50

Height and reach adjustment,

steering wheel ............................... 54

Horn .................................................. 98

Filling with fuel ............................ 77–79

Fitting a wheel ................................ 136

Fittings, boot ..................................... 60

Flashing indicators ...........97, 138, 140

Foglamps, rear .........................

Foglamps, rear

Foglamps, rear

80, 140

Front foglamps .........................80, 138

Front seats .................................52, 54

Fuel.............................................18, 78

Fuel consumption ............................. 18

Fuel filler flap ..............................77, 79

Fuel gauge ....................................... 77

Fuel tank .....................................77, 79

Fusebox,

dashboard ................................... 143

Jack ................................................ 133

JACK socket .....................59, 182, 202

E

I

G

H

F

J

K

L

Indicators, direction ..........97, 138, 140

Inflating accessories

(using the kit) ............................... 132

Inflating tyres .................................... 18

Inputs for audio

system ...................59, 182, 202, 204

Instrument panel

lighting ........................................... 32

Instrument panels ............................. 20

Instrument panel screen ........... 20, 110

Interior fittings ................................... 58

Interior lamp ..................................... 85

ISOFIX .........................................94-96

ISOFIX mountings ............................ 94

221

ALPHABETICAL INDEX

207CC_EN_CHAP13_INDEX ALPHA_ED01-2014

Main beam ................................80, 138

Maintenance ..................................... 18

Map reading lamps ........................... 85

Markings, identification ................... 159

Mat.................................................... 57

Menu, main .............................166, 198

Mirror, rear view ................................ 56

Mirrors, door .....................................

Mirrors, door

Mirrors, door

55

Misfuel prevention ............................ 79

Motorway function

(direction indicators) ...................... 97

Mountings for ISOFIX

seats .............................................. 94

MP3 CD ..................................181, 201

Music media

players .................................180, 200

Oil change ...................................... 124

Oil consumption .............................. 124

Oil filter ...........................................

Oil filter

Oil filter

126

Oil level .....................................30, 124

Opening the bonnet ........................ 121

Opening the boot .............................. 76

Opening the doors ......................73, 75

Opening the fuel filler flap ................ 77

Opening the retractable roof ..............

Opening the retractable roof

Opening the retractable roof

6

Opening the windows ....................... 71

Operation indicator lamps ...........21-27

Paint colour code............................ 159

Parking brake .........................109, 127

Parking sensors,

audible and visual ....................... 118

Particle emission

filter ..............................................

filter

filter

126

Passenger compartment filter ........

Passenger compartment filter

Passenger compartment filter

126

PEUGEOT CONNECT

ASSISTANCE .............................. 162

PEUGEOT Connect Navigation

(RNEG) ..........................40, 163, 164

PEUGEOT CONNECT SOS .......... 162

PEUGEOT Connect Sound

(RD5) ........................................... 195

M

O

P

N

Level, headlamp wash.................... 125

Lighting ............................................. 80

Lighting bulbs (replacement) ....138-141

Lighting control stalk......................... 80

Lighting dimmer ................................

Lighting dimmer

Lighting dimmer

32

Lighting, guide-me home ............80, 82

Lighting, interior ................................

Lighting, interior

Lighting, interior

85

Lighting on reminder......................... 81

Loading .....................................18, 152

Load reduction mode...................... 149

Locating your vehicle........................ 66

Locking from the inside .................... 74

Locking the boot ............................... 76

Locking the doors ............................. 65

Low fuel level..............................25, 77

Luggage retaining strap.................... 60

Navigation....................................... 169

Net .................................................... 61

Number plate lamps ....................... 140

PEUGEOT Connect USB ................. 59

Player, CD MP3 ......................181, 201

Port, USB .........................59, 182, 202

Priming the fuel system .................. 121

Protecting

children .....................86-96, 104, 106

Puncture ......................................... 128

Radio ......................................179, 199

Rear screen

(demisting) ..................................... 49

Recharging the battery ................... 148

Reduction of electrical

load .............................................. 149

Regeneration of the particle

emissions filter ............................

emissions filter

emissions filter

126

Reinitialising the electric

windows ......................................... 71

Reinitialising the remote

control ............................................ 67

Remote control ............................65-68

Removing a wheel .......................... 133

Removing the mat ............................ 57

Repair kit, puncture ........................ 128

Replacing bulbs .......................138-141

Replacing fuses .......................142-146

Replacing the air filter ....................

Replacing the air filter

Replacing the air filter

126

Replacing the oil filter .....................

Replacing the oil filter

Replacing the oil filter

126

Replacing the passenger

compartment filter .......................

compartment filter

compartment filter

126

Replacing wiper blades .................. 149

Resetting the service

indicator .........................................

indicator

indicator

29

R

222

ALPHABETICAL INDEX

207CC_EN_CHAP13_INDEX ALPHA_ED01-2014

Speed limiter ..................................

Speed limiter

Speed limiter

114

Speedometer ....................................

Speedometer

Speedometer

20

Stability control

(ESP) ........................................... 101

Starting the vehicle ................... 67, 111

Steering mounted controls,

audio ....................................165, 197

Stopping the vehicle ................. 67, 111

Storage ............................................. 58

Sun visor ..........................................

Sun visor

Sun visor

57

Synchronising

the remote control ......................... 67

System, navigation ......................... 169

Systems, ASR and ESP ................. 101

System settings ......................166, 186

Under-inflation

(detection) ..................................... 99

Unlocking .......................................... 65

Unlocking from the inside ................. 74

Unlocking the boot......................65, 76

Update risk areas ........................... 176

USB

(PEUGEOT Connect) .................. 202

Vehicle

configuration ................166, 186, 210

Ventilation .......................45, 46, 48, 51

Towing another vehicle ................... 150

Traction control

(ASR) .....................................25, 101

Traffic information

(TA) ..............................178, 179, 200

Traffic information

(TMC) ..................................177, 178

Trailer .............................................

Trailer

Trailer

151

Trip computer .............................

Trip computer

Trip computer

42, 43

Trip distance recorder ......................

Trip distance recorder

Trip distance recorder

32

Tyre pressures ................................ 159

Tyres ................................................. 18

Tyre under-inflation detection ........... 99

Table of weights......................154, 156

Tables of engines ...................155, 157

Tables of fuses ............................... 142

Tank, fuel ....................................77, 79

Technical data .........................154-159

Telephone ...............................183, 205

Temperature adjustment .............48, 50

Temperature control

for heated seats ............................ 54

Temporary puncture repair kit ........ 128

Third brake lamp ............................ 140

Ticket holder .....................................

Ticket holder

Ticket holder

58

Time ............................................34, 36

TMC (Traffic info) ............................ 177

Total distance recorder .....................

Total distance recorder

Total distance recorder

32

Towbar ............................................

Towbar

Towbar

151

Towed loads ...........................155, 157

T

U

V

Screen,

colour 16/9 ....................40, 166, 186

Screen menu map ..........186, 208, 210

Screen, monochrome ..........33, 25, 37,

198, 208, 210

Screen, multifunction

(with audio equipment) ......35, 37, 40

Screen, multifunction

(without audio equipment) ............. 33

Screenwash ...................................... 84

Screenwash fluid level.................... 125

Seat adjustment ............................... 52

Seat belts ................................102-104

Seats, rear ................................

Seats, rear

Seats, rear

54, 103

Serial number, vehicle .................... 159

Service indicator .........................

Service indicator

Service indicator

28, 29

Service warning lamp ....................... 24

Servicing ...............................18, 28, 29

Short-cut menus ............................. 167

Sidelamps .........................80, 138, 140

Side repeater ..................................

Side repeater

Side repeater

138

Snow chains ................................... 137

Spare wheel ................................... 134

S

Resetting the trip recorder ................

Resetting the trip recorder

Resetting the trip recorder

32

Retractable roof ..................................

Retractable roof

Retractable roof

6

Rev counter ......................................

Rev counter

Rev counter

20

Reversing lamps ............................. 140

Risk areas (update) ........................ 176

Roll-over bars ................................. 102

Routine checks ............................... 126

Running out of fuel

(Diesel) ........................................ 121
