Peugeot 207 CC (2014 year). Manual - part 13

191

207CC_EN_CHAP11B_RNEG_ED01-2014

QUESTION

ANSWER

SOLUTION

The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio system.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off, the

audio system switches

off after a few minutes

of use.

When the engine is switched off, the audio system operating time

depends on the battery charge.

The switch-off is normal: the audio system switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

192

207CC_EN_CHAP11B_RNEG_ED01-2014

QUESTION

ANSWER

SOLUTION

TA is selected. However,

certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

I receive a risk area alert

for a risk area which is

not on my route.

The system announces all risk areas located in a conical zone forward of

the vehicle. It may detect risk areas on nearby or parallel roads.

Zoom the map to view the exact position of the

risk area.

The audible risk area

alert is not working.

Audible alerts are not active.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.

The alert volume level is set to minimum.

Increase the risk area alert volume.

The altitude is not

displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button, then

select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is

dependent on the conditions of reception of the

GPS signal.

The route is not

calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

193

207CC_EN_CHAP11B_RNEG_ED01-2014

QUESTION

ANSWER

SOLUTION

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my

Bluetooth telephone.

The telephone's Bluetooth function may be deactivated or the equipment

may not be visible.

Check that your telephone's Bluetooth

function is activated.

- Check that your telephone is visible.

A telephone connected

by Bluetooth is inaudible.

The volume level depends on both the system and the telephone.

Increase the PEUGEOT Connect Navigation

volume setting, possibly to maximum, and

increase the telephone volume level if necessary.

194

207CC_EN_CHAP11B_RNEG_ED01-2014

195

PEUGEOT Connect Sound (RD5)

Your PEUGEOT Connect Sound (RD5) is coded in such

a way that it will only operate in your vehicle.

For safety reasons, the driver must only carry out

operations which require prolonged attention while the

vehicle is stationary.

When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO SYSTEM / BLUETOOTH

01 First steps

02 Steering mounted controls

03 Main menu

04 Audio

05 PEUGEOT Connect USB

06 Bluetooth

07 Screen menu map(s)

Frequently asked questions

196

197

198

199

202

205

208

213

CONTENTS

196

01 FIRST STEPS

Eject CD.

Select source:

radio, audio CD/MP3 CD, USB,

Jack connection, Streaming,

AUX.

Select the screen display

mode:

Date, audio functions, trip

computer, telephone.

Automatic frequency search

down/up.

Select previous/next CD, MP3

or USB track.

Audio settings: front/

rear fader, left/right

balance, bass/treble,

loudness, audio

ambiences.

Display the list of

local stations.

Long press: CD

tracks or MP3 folders

(CD/USB).

TA (Trafﬁ c Announcements)

on/off.

Long press: PTY * (radio

Programme TYpe) mode.

Display main menu.

The DARK button changes the screen display

for improved driving comfort at night.

1 st press: upper bar only illuminated.

2 nd press: black screen.

3 rd press: return to standard display.

On/off, volume setting.

Buttons 1 to 6:

Select a pre-set radio station.

Long press: pre-set a station.

Select next frequency down/up.

Select previous/next MP3 folder.

Select previous/next folder/genre/

artist/playlist (USB).

Conﬁ rm.

Select wavebands

FM1, FM2, FMast

and AM.

Abandon the current

operation.

* Available according to version.

197

02 STEERING MOUNTED CONTROLS

Radio: select the previous/next pre-set

station.

USB: select genre/artist/folder from the

classiﬁ cation list.

Select the previous/next item in a menu.

Change audio source.

Conﬁ rm a selection.

Call/end call on the telephone.

Press for more than 2 seconds:

telephone main menu.

Radio: automatic search for a lower

frequency.

CD/MP3/USB: selection of the previous

track.

CD/USB: continuous press: fast reverse.

Move in the list.

Radio: automatic search for a higher

frequency.

CD/MP3/USB: selection of the next

track.

CD/USB: continuous press: fast

forwards play.

Move in the list.

Volume increase.

Volume decrease.

Mute: press the volume

increase and decrease

buttons simultaneously.

The sound is restored by

pressing one of the two

volume buttons.

198

03 MAIN MENU

AUDIO FUNCTIONS :

radio, CD, USB, options.

Screen C

For a detailed global view of the

menus available, refer to the

"Screen menu map" section.

TELEPHONE :

Bluetooth hands-free,

pairing, management

of a call.

PERSONALISATION-

CONFIGURATION :

vehicle parameters,

display, languages.

TRIP COMPUTER :

entering of distances,

alerts, status of functions.

Screen A

199

SOURCE

BAND

AST

LIST

REFRESH

MENU

AUDIO

Press the SOURCE button several

times in succession and select the

radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to

carry out an automatic search of the

radio stations.

Press one of the buttons to carry out

a manual search up/down for radio

frequencies.

Press the LIST REFRESH button to

display the list of stations received

locally (30 stations maximum).

To update this list, press for more

than two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...)

may block reception, including in RDS mode. This is a normal effect of the

way in which radio waves are transmitted and does not indicate any failure

of the audio system.

RDS

RADIO

SELECTING A STATION

Press the MENU button.

Select AUDIO FUNCTIONS then

press OK.

Select the FM WAVEBAND

PREFERENCES function then

press OK.

Select ACTIVATE RDS then press

OK. RDS appears on the screen.

In radio mode, press OK directly to activate/deactivate RDS mode.

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However, in certain

conditions, coverage of an RDS station may not be assured throughout the

country as radio stations do not cover 100 % of the territory. Under conditions

of very weak reception, the system may change to a regional station.

200

SOURCE

AUDIO

Insert circular compact discs only.

Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no reﬂ ection on the

quality of the original player.

Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

PLAYING A CD

To play a disc which has already been

inserted, press the SOURCE button

several times in succession and

select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to display the list of tracks

on the CD.

Press and hold one of the buttons for

fast forward or backward.

RECEIVING TA MESSAGES

Press the TA button to activate or

deactivate trafﬁ c messages.

The TA (Trafﬁ c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a trafﬁ c

report is transmitted, the current audio source (Radio, CD, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

201

SOURCE

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music ﬁ les on a single disc.

In order to be able to play a recorded CDR or CDRW, when

recording, the ISO 9660 level 1.2 or Joliet ﬁ le format is

recommended.

If the disc is recorded in another format, it may not be played

correctly.

It is recommended that the same recording format is always used

for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.

In the particular case of a multi-session CD, the Joliet format is

recommended.

The audio system will only play ﬁ les with the extension ".mp3"

with a sampling rate of 22.05 KHz or 44.1 KHz. No other type

of ﬁ le (.wma, .mp4, .m3u...) can be played.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g. " ? ; ù) to avoid any playing or displaying

problems.

MP3 CD

INFORMATION AND ADVICE

AUDIO

Empty CDs are not recognised and may damage the system.

Insert an MP3 compilation in the player.

The audio equipment searches for all of the music tracks, which

may take anything between a few seconds and several tens of

seconds, before play begins.

MP3 CD

PLAYING AN MP3 COMPILATION

On a single disc, the CD player can read up to 255 MP3 ﬁ les

spread over 8 folder levels. However, it is advisable to keep to

a limit of two levels to reduce the access time before the CD is

played.

While the CD is being played, the folder structure is not followed.

All of the ﬁ les are displayed on a single level.

To play a disc which has already

been inserted, press the SOURCE

button several times in succession

and select CD.

Press one of the buttons to select a

track on the CD.

Press the LIST REFRESH button to display the list of directories of

the MP3 compilation.

Press and hold one of the buttons for

fast forward or backward play.

202

The system puts together playlists (temporary memory) created

over a period which depends on the capacity of the USB device.

The other sources are available during this time.

The playlists are updated each time the ignition is switched off or

each time a USB memory stick is connected.

When connecting for the ﬁ rst time, the classiﬁ cation suggested

is by folder. When you reconnect, the classiﬁ cation selected

previously is retained.

Connect the memory stick to the port, directly or

using a lead. If the audio equipment is switched

on, the USB source is detected as soon as it

is connected. Play begins automatically after a

delay which depends on the capacity of the USB

memory stick.

The ﬁ le formats supported are .mp3 (mpeg1

layer 3 only) and .wma (standard 9 only,

128 kbits/sec compression).

Certain playlist formats are supported (.m3u, ...)

On reconnection of the previous memory stick

used, play is resumed automatically with the last

track played.

This unit consists of a USB port and an auxiliary

Jack socket * . The audio ﬁ les are transmitted

from a portable device - digital player or a USB

memory stick - to your PEUGEOT Connect

Sound (RD5) and heard via the vehicle's

speakers.

USB memory stick (1.1, 1.2 and 2.0) or Apple

player of generation 5 or later:

- USB memory sticks should be formatted

FAT or FAT 32 (NTFS not supported),

the Apple

player lead is essential,

- navigation through the ﬁ le database is also

possible by means of the steering mounted

controls.

The list of compatible equipment and the compression rates supported

are available from PEUGEOT dealers.

USING THE PEUGEOT CONNECT USB

CONNECTING A USB MEMORY STICK

Other Apple

players of earlier generations and

players using the MTP protocol * :

- play via Jack-Jack lead only (not supplied),

- navigation through the ﬁ le database is from

the portable device.

* According to vehicle.

203

LIST

REFRESH

LIST

REFRESH

USING THE PEUGEOT CONNECT USB

Press LIST brieﬂ y to display the

previously selected classiﬁ cation.

Navigate through the list using the left/

right and up/down buttons.

Conﬁ rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist (as deﬁ ned in the

Apple

player).

Selection and Navigation are described in steps 1 to 4 above.

Do not connect a hard disk or USB connection device other

than audio equipment to the USB port. This could damage your

installation.

CONNECTING AN APPLE

CONNECTING AN APPLE PLAYER VIA THE USB PORT

Press one of these buttons to gain

access to the previous/next track on

the classiﬁ cation list currently being

played.

Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to gain

access to the previous/next Genre,

Folder, Artist or Playlist on the

classiﬁ cation list currently being

played.

Press and hold LIST to display the

different classiﬁ cations.

Select by Folder/Artist/Genre/Playlist,

press OK to select the classiﬁ cation

required, then press OK again to conﬁ rm.

- by Folder: all folders containing audio

ﬁ les recognised on the peripheral

device.

- by Artist: all of the artist names

deﬁ ned in the ID3 Tags, classiﬁ ed in

alphabetical order.

- by Genre: all of the genres deﬁ ned in

the ID3 Tags.

- by Playlist: in accordance with the

playlists recorded on the USB device.

USB PLAYER

204

SOURCE

The display and control is via the portable device.

First adjust the volume of your portable device.

Then adjust the volume of your audio

system.

USING THE AUXILIARY SOCKET (AUX)

ADJUSTING THE VOLUME

OF THE AUXILIARY SOURCE

RCA SOCKET

Connect the portable device (MP3

player…) to the audio sockets (white and

red, RCA type) using a suitable cable (not

supplied).

Press the SOURCE button several

times in succession and select AUX.

The RCA auxiliary socket permits the connection of a portable device

(MP3 player...).

USB PLAYER

205

MENU

BLUETOOTH

For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary

and the ignition on.

Press the MENU button.

A window is displayed with a message that a search is in progress.

Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (telephone

conﬁ guration).

In the menu, select:

Bluetooth telephone function - Audio

- Bluetooth conﬁ guration

Perform a Bluetooth search

The services offered depend on the network, the SIM card and the

compatibility of the Bluetooth equipment used.

Consult your telephone's manual and your operator to ﬁ nd out which

services are available to you.

BLUETOOTH TELEPHONE

SCREEN C

The TELEPHONE menu permits access to the following functions

in particular: Directory * , Call list, Pairing management.

The ﬁ rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed in the screen:

enter a code with at least 4 digits.

Conﬁ rm by pressing OK.

A message that the pairing has been successful appears in the screen.

Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

A message is displayed in the screen of the

telephone chosen. To accept the pairing, enter the

same code on the telephone, then conﬁ rm with OK.

The automatic connection authorised is only active after the

telephone has been conﬁ gured.

The directory and the call list can be accessed after the

synchronisation period.

(Available according to model and version)

* If your telephone is fully compatible.

If pairing fails, the number of attempts is not limited.

Go to www.peugeot.co.uk for more information (compatibility,

more help, ...).

PAIRING A TELEPHONE/FIRST CONNECTION

206

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed

display in the vehicle's screen.

Select the YES tab on the display

using the buttons and conﬁ rm by

pressing OK.

Press the steering mounted control to accept

the call.

MAKING A CALL

From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

Press the steering mounted control for more than

two seconds for access to your directory, then

navigate with the thumb wheel.

To dial a number, use your telephone's keypad,

with the vehicle stationary.

During a call, press the steering mounted control

for more than 2 seconds.

Conﬁ rm with OK to end the call.

BLUETOOTH

ENDING A CALL

Content .. 11 12 13 14 ..
