Nissan Qashqai (2007-2010). Manual - part 934





HAC-96

< ECU DIAGNOSIS >

[AUTOMATIC AIR CONDITIONER]

BCM (BODY CONTROL MODULE)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

14

(L/R)

Ground

A/C switch

Output

A/C switch

Not pressed

Battery voltage

Pressed

0 V

15

(LG/B)

Ground

Fan switch

Output

Fan switch

Not pressed

Battery voltage

Pressed

0 V

AUTO AMP.

HAC-97

< ECU DIAGNOSIS >

[AUTOMATIC AIR CONDITIONER]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

AUTO AMP.

Reference Value

INFOID:0000000000954679

TERMINAL LAYOUT

PHYSICAL VALUES

JPIIA0179ZZ

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

1

(L)

Ground

Blower motor control signal

Output

• Ignition switch ON
• Blower speed: 1st- 6th

speed (manual)

2.5 V

• Ignition switch ON
• Blower speed: 7th speed

(manual)

9.0 V

3

(V)

Ground

A/C LAN signal

Input/

Output

Ignition switch ON

5

(L)

Ground

A/C switch signal

Output

A/C switch

Not pressed

12 V

Pressed

 0 V

7

(O)

Ground

Sunload sensor

Input

9

(O)

Ground

Engine coolant temperature
signal

Input

At idle [after warming up, ap-
prox. 80

°

C (176

°

F)]

NOTE: The wave forms vary
depending on coolant temper-
ature.

SJIA1453J

SJIA1438J

HAC-98

< ECU DIAGNOSIS >

[AUTOMATIC AIR CONDITIONER]

AUTO AMP.

14

(Y)

Ground

Speed sensor (8-pulse)

Input

Speed meter operated (When
vehicle speed is approx. 40
km/h)

NOTE: Maximum voltage may be 5
V due to specifications (connected
units)

16

(R)

Ground

Illumination signal

Input

Ignition switch ON

 12 V

Ignition switch OFF

 0 V

17

(B)

Ground

Ground

Ignition switch ON

 0 V

18

(Y)

Ground

Power supply from IGN 2

Ignition switch ON

Battery voltage

20

(W)

Ground

Power supply for each door
motor

Input

Ignition switch ON

Battery voltage

21

(R)

Ground

A/C PD cut

Input

Ignition switch ON

0 V

22

(R)

Ground

Rear window defogger feed-
back signal

Input

Rear window defogger: OFF

0 V

Rear window defogger: ON

12 V

23

(SB)

Ground

Rear window defogger ON
signal

Input

When rear window defogger
switch is depressed.

When rear window defogger
switch is released.

24

(LG)

Ground

Blower motor ON signal

Input

AUTO SW: ON (Blower motor
operate.)

0 V

AUTO SW: OFF

12 V

25

(P)

Ground

Intake sensor

Input

26

(GR)

Ground

Sensor Ground

Ignition switch ON

0 V

27

(BR)

Ground

In-vehicle sensor

Input

28

(G)

Ground

OAT sensor

Input

34

(O)

Ground

High-level VENT SW signal

Input

High-level VENT SW: OFF

12 V

High-level VENT SW: ON

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

JSNIA0012GB

ZJIA1036J

JPIIA0013GB

AUTO AMP.

HAC-99

< ECU DIAGNOSIS >

[AUTOMATIC AIR CONDITIONER]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

36

(B)

Ground

Illumination ground

Ignition switch ON

0 V

38

(R)

Ground

Blower motor feedback signal

Input

Blower speed: 1st

10 V

39

(Y)

Ground

Power supply from BATT

Ignition switch OFF

Battery voltage

40

(GR)

Ground

Power supply from IGN

Ignition switch ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output
