Nissan Qashqai (2007-2010). Manual - part 1920

WCS-26

< COMPONENT DIAGNOSIS >

WARNING CHIME SYSTEM

JCNWA0223GB

WCS

WARNING CHIME SYSTEM

WCS-27

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JCNWA0224GB

WCS-28

< ECU DIAGNOSIS >

COMBINATION METER

ECU DIAGNOSIS

COMBINATION METER

Reference Value

INFOID:0000000000936439

VALUES ON THE DIAGNOSIS TOOL

Monitor Item

Condition

Value/Status

SPEED METER
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

SPEED OUTPUT
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

TACHO METER
[rpm]

Ignition switch
ON

While driving

Equivalent to tachometer reading
NOTE:
8191.875 is displayed when the mal-
function signal is received

W TEMP METER
[

°

C]

Ignition switch
ON

—

Values according to engine coolant
temperature
NOTE:
215 is displayed when the malfunction
signal is input

FUEL METER
[lit]

Ignition switch
ON

—

Values according to fuel level

DISTANCE
[km]

Ignition switch
ON

—

Possible driving distance calculated by
combination meter

FUEL W/L

Ignition switch
ON

Low-fuel warning lamp ON

On

Low-fuel warning lamp OFF

Off

MIL

Ignition switch
ON

Malfunction indicator lamp ON

On

Malfunction indicator lamp OFF

Off

SEAT BELT W/L

Ignition switch
ON

Seat belt warning lamp ON

On

Seat belt warning lamp OFF

Off

BUZZER

Ignition switch
ON

Buzzer ON

On

Buzzer OFF

Off

C-ENG 2 W/L

Ignition switch
ON

Malfunction indicator lamp 2 ON

On

Malfunction indicator lamp 2 OFF

Off

GLOW IND

Ignition switch
ON

Glow indicator lamp ON

On

Glow indicator lamp OFF

Off

DOOR W/L

Ignition switch
ON

Door warning lamp ON

On

Door warning lamp OFF

Off

HI-BEAM IND

Ignition switch
ON

High-beam indicator lamp ON

On

High-beam indicator lamp OFF

Off

TURN IND

Ignition switch
ON

Turn signal indicator lamp ON

On

Turn signal indicator lamp OFF

Off

FR FOG IND

Ignition switch
ON

Front fog lamp indicator lamp ON

On

Front fog lamp indicator lamp OFF

Off

RR FOG IND

Ignition switch
ON

Rear fog lamp indicator lamp ON

On

Rear fog lamp indicator lamp OFF

Off

WCS

COMBINATION METER

WCS-29

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

OIL W/L

Ignition switch
ON

Oil pressure warning lamp ON

On

Oil pressure warning lamp OFF

Off

LIGHT IND

Ignition switch
ON

Tail lamp indicator lamp ON

On

Tail lamp indicator lamp OFF

Off

DPF W/L

Ignition switch
ON

DPF warning lamp ON

On

DPF warning lamp OFF

Off

VDC/TCS IND

Ignition switch
ON

VDC OFF indicator lamp ON

On

VDC OFF indicator lamp OFF

Off

ABS W/L

Ignition switch
ON

ABS warning lamp ON

On

ABS warning lamp OFF

Off

SLIP IND

Ignition switch
ON

SLIP Indicator lamp ON

On

SLIP indicator lamp OFF

Off

BRAKE W/L

Ignition switch
ON

Brake warning lamp ON

On

Brake warning lamp OFF

Off

OIL LEVEL IND

Ignition switch
ON

Oil level 1 is detected

LEVEL1

Oil level 2 is detected

LEVEL2

Oil level 3 is detected

LEVEL3

Oil level 4 is detected

LEVEL4

Oil level 5 is detected

LEVEL5

OIL LOW is detected

On

Oil level is not detected

CR NG

KEY G W/L

Ignition switch
ON

KEY warning lamp (green) ON

On

KEY warning lamp (green) OFF

Off

KEY R W/L

Ignition switch
ON

KEY warning lamp (red) ON

On

KEY warning lamp (red) OFF

Off

KEY KNOB IND

Ignition switch
ON

LOCK warning lamp ON

On

LOCK warning lamp OFF

Off

M RANGE SW

Ignition switch
ON

MANUAL MODE

On

Other than the above

Off

NM RANGE SW

Ignition switch
ON

MANUAL MODE

Off

Other than the above

On

AT SFT UP SW

Ignition switch
ON

Selector lever (+) position

On

Other than the above

Off

AT SFT DWN SW

Ignition switch
ON

Selector lever (–) position

On

Other than the above

Off

P RANGE IND

Ignition switch
ON

Selector lever in P position

On

Other than the above

Off

R RANGE IND

Ignition switch
ON

Selector lever in R position

On

Other than the above

Off

N RANGE IND

Ignition switch
ON

Selector lever in N position

On

Other than the above

Off

D RANGE IND

Ignition switch
ON

Selector lever in D position

On

Other than the above

Off

Monitor Item

Condition

Value/Status
