Nissan Qashqai (2007-2010). Manual - part 1286
POWER WINDOW MAIN SWITCH
PWC-61
< ECU DIAGNOSIS >
C
D
E
F
G
H
I
J
L
M
A
B
PWC
N
O
P
Wiring Diagram - POWER WINDOW CONTROL SYSTEM (LHD MODELS) -
INFOID:0000000001125411
12
16
GR
Front power window motor
(driver side) DOWN signal
Output
When front LH switch in
power window main switch
is DOWN at operated.
Battery voltage
13
2
LG
Encoder pulse signal 1
Input
When front power window
motor (driver side) oper-
ates.
15
Ground
Y
Encoder power supply
Output
When ignition switch ON.
10
16
12
BR
Front power window motor
(driver side) UP signal
Output
When front LH switch in
power window main switch
is UP at operated.
Battery voltage
17
Ground
B
Ground
—
—
0
19
Ground
P
Battery power supply
Input
Ignition switch OFF
Battery voltage
Terminal No.
Wire
color
Description
Condition
Voltage [V]
(Approx.)
+
-
Signal name
Input/
Output
JMKIA0070GB
