PRECAUTIONS

DLK-219

< PRECAUTION >

[WITH I-KEY, WITHOUT SUPER LOCK]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.

Work

INFOID:0000000000939205

• After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their

operational.

• Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

PIIB3706J

DLK-220

< PREPARATION >

[WITH I-KEY, WITHOUT SUPER LOCK]

PREPARATION

PREPARATION

PREPARATION

Commercial Service Tools

INFOID:0000000001116408

Tool name

Description

Engine ear

Locating the noise

Remover tool

Remove the clips, pawls, and metal clips

Power tool

SIIA0995E

PIIB7923J

PIIB1407E

PRE-INSPECTION FOR DIAGNOSTIC

DLK-221

< ON-VEHICLE MAINTENANCE >

[WITH I-KEY, WITHOUT SUPER LOCK]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

ON-VEHICLE MAINTENANCE

PRE-INSPECTION FOR DIAGNOSTIC

Basic Inspection

INFOID:0000000001035832

BASIC INSPECTION

1.

CHECK POWER DOOR LOCK AND UNLOCK SWITCH OPERATION

Check door lock and unlock operation by operating door lock and unlock switch.
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Refer to

DLK-203, "DOOR LOCK AND UNLOCK SWITCH : Symptom Table"

.

2.

CHECK INTELLIGENT KEY OPERATION

Check door lock and unlock operation by operating the Intelligent Key remote control button.
Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Refer to

DLK-203, "INTELLIGENT KEY : Symptom Table"

.

3.

CHECK DOOR REQUEST SWITCH OPERATION

Check door lock and unlock operation by operating door request switch.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Refer to

DLK-204, "DOOR REQUEST SWITCH : Symptom Table"

.

4.

CHECK KEY REMINDER OPERATION

Check key reminder operation. Refer to

DLK-35, "KEY REMINDER : System Description"

.

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Refer to

DLK-205, "KEY REMINDER : Symptom Table"

.

5.

CHECK AUTO DOOR LOCK OPERATION

Check auto door lock operation. Refer to

DLK-38, "AUTO DOOR LOCK : System Description"

.

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Refer to

DLK-205, "AUTO DOOR LOCK : Symptom Table"

.

6.

CHECK VEHICLE SPEED SENSING AUTO DOOR LOCK OPERATION

Check vehicle speed sensing auto door lock operation. Refer to

DLK-41, "VEHICLE SPEED SENSING AUTO

DOOR LOCK : System Description"

.

Is the inspection result normal?

YES

>> GO TO 7.

NO

>> Refer to

DLK-206, "VEHICLE SPEED SENSING AUTO DOOR LOCK : Symptom Table"

.

7.

CHECK BACK DOOR OPENER OPERATION

Check back door opener operation by operating the back door opener switch.

Is the inspection result normal?

YES

>> GO TO 8.

NO

>> Refer to

DLK-207, "BACK DOOR OPENER SWITCH : Symptom Table"

.

8.

CHECK WARNING FUNCTION

Check warning function. Refer to

DLK-52, "System Description"

.

Is the inspection result normal?

YES

>> GO TO 9.

DLK-222

< ON-VEHICLE MAINTENANCE >

[WITH I-KEY, WITHOUT SUPER LOCK]

PRE-INSPECTION FOR DIAGNOSTIC

NO [Buzzer (combination meter)]>>  Refer  to

DLK-208, "BUZZER (COMBINATION METER) : Symptom

Table"

.

NO (Intelligent Key warning buzzer)>> Refer to

DLK-208, "INTELLIGENT KEY WARNING BUZZER : Symp-

tom Table"

.

NO (Warning lamp)>> Refer to

DLK-209, "WARNING LAMP : Symptom Table"

.

NO (Back door open warning)>> Refer to

DLK-209, "BACK DOOR : Symptom Table"

.

9.

CHECK HAZARD AND BUZZER REMINDER FUNCTION

Check hazard and buzzer reminder function by Intelligent Key or request switch. Refer to

DLK-322, "System

Description"

.

Is the inspection result normal?

YES

>> GO TO 10.

NO (Hazard warning lamp)>> Refer to

DLK-211, "HAZARD WARNING LAMP : Symptom Table"

.

NO (Intelligent Key warning buzzer)>> Refer to

DLK-211, "INTELLIGENT KEY WARNING BUZZER : Symp-

tom Table"

.

10.

CHECK OUT

CHECK OUT.

>> INSPECTION END
