Lifan 620. Service manual - part 43



Table 3-10

DTC

C1 202   C1 205

C1 208   C1 211

Cause

Air gap error: no signal because of

air gap too large or sensor short

circuit (resistance is 0), or gear ring

is not properly installed.

Note:

 Air gap is the gap between gear ring and

①

sensor;

 If faults corresponding to more than 2

②

DTC can be

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same DTC).



. Air gap adjust

※

ment method

☞ Not to adjust the type of air gap, but to set automatically according to the tolerance of relevant

part. As a result, confirm the part with abnormal air gap and replace or adjust to specified air gap (by

burnishing the mounting surface contact area of sensor); a thin washer should be placed on the

mounting surface of sensor to adjust to specified air gap.

173

Table 3-11



DTC

C1 201  C1 204

C1 207  C1 210

Cause

Note:

 Foreign materials, like

①

engine oil and scrap iron in

gear may cause asymmetrical sensor signal;

 Air gap means the gap between gear ring and sensor;

②



 If faults corresponding to more than 2 DTC can be

③

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same fault code).

Gear ring or sensor disturbance:

If nonstandard gear ring is installed





174



Table 3-12

DTC

C1 101    C1 102

Cause

Battery voltage abnormal:

Occurring when voltage too high or

too low

Note: If faults corresponding to more than 2 DTC can be

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same fault code).







175



Table 3-13

DTC C2402

Motor fuse/motor fault

Note: If faults corresponding to more than 2 DTC can be

confirmed, delete the DTC (that can be deleted), drive the

vehicle at a speed of over 40 km/h, confirm the fault

corresponding to this DTC again and refer to the recorded

DTC (and confirm the same fault code).

Cause





176
