4-5. Using the driving support systems

cle.

●

When a vehicle is approaching at high

speed.

●

When equipment that may obstruct a

sensor is installed, such as a towing eye-

let, bumper protector (an additional trim

strip, etc.), bicycle carrier, or snow plow.

●

When backing up on a slope with a sharp

change in grade.

●

When backing out of a sharp angle park-

ing spot.

●

When towing a trailer.

●

When there is a significant difference in

height between your vehicle and the

vehicle that enters the detection area.

●

When a sensor or the area around a sen-

sor is extremely hot or cold.

●

If the suspension has been modified or

tires of a size other than specified are

installed.

●

If the front of the vehicle is raised or low-

ered due to the carried load.

●

When turning while backing up.

●

When a vehicle turns into the detection

area.

■

Situations in which the system may

operate even if there is no possibility of a

collision

Instances of the RCTA function unneces-

sarily detecting a vehicle and/or object may

increase in the following situations:

●

When the parking space faces a street

and vehicles are being driven on the

street.

●

When the distance between your vehicle

and metal objects, such as a guardrail,

wall, sign, or parked vehicle, which may

reflect electrical waves toward the rear of

the vehicle, is short.

249

4-5. Using the driving support systems

Driving

●

When equipment that may obstruct a

sensor is installed, such as a towing eye-

let, bumper protector (an additional trim

strip, etc.), bicycle carrier, or snow plow.

●

When a vehicle passes by the side of your

vehicle.

●

When a detected vehicle turns while

approaching the vehicle.

●

When there are spinning objects near

your vehicle such as the fan of an air con-

ditioning unit.

●

When water is splashed or sprayed

toward the rear bumper, such as from a

sprinkler.

●

Moving objects (flags, exhaust fumes,

large rain droplets or snowflakes, rain

water on the road surface, etc.).

●

When the distance between your vehicle

and a guardrail, wall, etc., that enters the

detection area is short.

●

Gratings and gutters.

●

When a sensor or the area around a sen-

sor is extremely hot or cold.

●

If the suspension has been modified or

tires of a size other than specified are

installed.

●

If the front of the vehicle is raised or low-

ered due to the carried load.

: If equipped

■

Parking Support Brake function
(static objects)



P.254

■

Parking Support Brake function
(rear-crossing vehicles)



P.256

PKSB (Parking Support
Brake)

The Parking Support Brake system
consists of the following functions
that operate when driving at a low
speed or backing up, such as when
parking. When the system deter-
mines that the possibility of a colli-
sion with a detected object is high, a
warning operates to urge the driver
to take evasive action. If the system
determines that the possibility of a
collision with a detected object is
extremely high, the brakes are
automatically applied to help avoid
the collision or help reduce the
impact of the collision.

PKSB (Parking Support Brake)
system

250

4-5. Using the driving support systems

WARNING

■

Cautions regarding the use of the

system

Do not overly rely on the system, as

doing so may lead to an accident.
Always drive while checking the safety of

the surroundings of the vehicle.
Depending on the vehicle and road con-

ditions, weather, etc., the system may not

operate.
The detection capabilities of sensors and

radars are limited. Always drive while

checking the safety of the surroundings

of the vehicle.

●

The driver is solely responsible for safe

driving. Always drive carefully, taking

care to observe your surroundings.

The Parking Support Brake system is

designed to provide support to lessen

the severity of collisions. However, it

may not operate in some situations.

●

The Parking Support Brake system is

not designed to stop the vehicle com-

pletely. Additionally, even if the system

has stopped the vehicle, it is necessary

to depress the brake pedal immedi-

ately as brake control will be canceled

after approximately 2 seconds.

●

It is extremely dangerous to check the

system operations by intentionally

driving the vehicle into the direction of

a wall, etc. Never attempt such actions.

■

When to disable the Parking Support

Brake

In the following situations, disable the

Parking Support Brake as the system

may operate even though there is no

possibility of a collision.

●

When inspecting the vehicle using a

chassis roller, chassis dynamo or free

roller.

●

When loading the vehicle onto a boat,

truck or other transport vessel.

●

If the suspension has been modified or

tires of a size other than specified are

installed.

●

If the front of the vehicle is raised or

lowered due to the carried load.

●

When equipment that may obstruct a

sensor is installed, such as a towing

eyelet, bumper protector (an addi-

tional trim strip, etc.), bicycle carrier,

or snow plow.

●

When using automatic car washing

devices.

●

If the vehicle cannot be driven in a sta-

ble manner, such as when the vehicle

has been in an accident or is malfunc-

tioning.

●

When the vehicle is driven in a sporty

manner or off-road.

●

When the tires are not properly

inflated.

●

When the tires are very worn.

●

When tire chains, a compact spare tire

or an emergency tire puncture repair

kit are used.

●

During emergency towing.

NOTICE

■

If “Parking Support Brake Unavail-

able” is displayed on the multi-infor-

mation display and the PKSB OFF

indicator is flashing

If this message is displayed immediately

after the power switch is changed to ON,

operate the vehicle carefully, paying

attention to your surroundings. It may be

necessary to drive the vehicle for a cer-

tain amount of time before the system

returns to normal. (If the system does not

return to normal after driving for a while,

clean the sensors and their surrounding

area on the bumpers.)

251

4-5. Using the driving support systems

Driving

The Parking Support Brake can be
enabled/disabled on the multi-infor-
mation display. All of the Parking Sup-
port Brake functions (static objects and
rear crossing vehicles) are
enabled/disabled simultaneously.
Use the meter control switches to
enable/disable the parking support
brake. (



P.89)

Press

to select

Press

to select

and

then press “OK”.

When the Parking Support Brake is dis-

abled, the PKSB OFF indicator (



P.76)

illuminates on the multi-information dis-

play.
When the Parking Support Brake is turned

on or off, operation of the Parking Support

Brake continues in the same condition the

next time the hybrid system is started.

If the hybrid system output restriction con-
trol or brake control operates, a buzzer
will sound and a message will be displayed
on the multi-information display, to alert
the driver. On vehicles with head-up dis-
play, the head-up display will display the
same message as the multi-information
display.
Depending on the situation, hybrid system
output restriction control will operate to
either limit acceleration or restrict output
as much as possible.



Hybrid system output restriction

control is operating (acceleration
restriction)

Acceleration greater than a certain
amount is restricted by the system.
Multi-information display: “Object
Detected Acceleration Reduced”
PKSB OFF indicator: Not illuminated
Buzzer: Does not sound



Hybrid system output restriction
control is operating (output
restricted as much as possible)

The system has determined that stronger-
than-normal brake operation is necessary.
Multi-information display: “BRAKE!”
PKSB OFF indicator: Not illuminated
Buzzer: Short beep



Brake control is operating

The system determined that emergency
braking is necessary.
Multi-information display: “BRAKE!”
PKSB OFF indicator: Not illuminated
Buzzer: Short beep



Vehicle stopped by system opera-
tion

The vehicle has been stopped by brake
control operation.
Multi-information display: “Switch to
Brake” (If the accelerator pedal is not
depressed, “Press Brake Pedal” will be dis-
played.)
PKSB OFF indicator: Illuminated
Buzzer: Short beep

If the Parking Support Brake deter-
mines that a collision with a detected

Enabling/Disabling the Parking
Support Brake

Displays and buzzers for hybrid
system output restriction control
and brake control

System overview

252

4-5. Using the driving support systems

object is possible, the hybrid system
output will be restricted to restrain any
increase in the vehicle speed. (Hybrid
system output restriction control: See
figure 2 below.)
Additionally, if the accelerator pedal
continues to be depressed, the brakes
will be applied automatically to reduce
the vehicle speed. (Brake control: See
figure 3 below.)



Figure 1 When the PKSB (Parking
Support Brake) is disabled

Hybrid system output

Braking force

Time



Figure 2 When hybrid system out-
put restriction control operates

Hybrid system output

Braking force

Time

Hybrid system output restriction
control begins operating (The sys-
tem determines that possibility of
collision with detected object is
high)

“BRAKE!” is displayed on the multi-infor-
mation display.

Hybrid system output reduced



Figure 3 When brake control oper-
ates

Hybrid system output

Braking force

Time

Hybrid system output restriction
control begins operating (The sys-
tem determines that possibility of
collision with detected object is
high)

“BRAKE!” is displayed on the multi-infor-
mation display.

Hybrid system output reduced

Brake control begins operating
(the system determines that possi-
bility of collision with detected
object is extremely high)

Brake control strength increased

“Switch to Brake” is displayed on

A
B
C

A
B
C
D

E
F

253

4-5. Using the driving support systems

Driving

the multi-information display

■

If the Parking Support Brake has oper-

ated

If the vehicle is stopped due to operation of

the Parking Support Brake, the Parking

Support Brake will be disabled and the

PKSB OFF indicator will illuminate. If the

Parking Support Brake operates unneces-

sarily, brake control can be canceled by

depressing the brake pedal or waiting for

approximately 2 seconds for it to automati-

cally be canceled. Then, the vehicle can be

operated by depressing the accelerator

pedal.

■

Re-enabling the Parking Support Brake

To re-enable the Parking Support Brake

when it is disabled due to operation of the

Parking Support Brake, either enable the

system again (



P.251), or turn the power

switch off and then back to ON. Addition-

ally, if the object becomes no longer in the

traveling direction of the vehicle or if the

traveling direction of the vehicle changes

(such as changing from moving forward to

backing up, or from backing up to moving

forward), the system will be re-enabled

automatically.

■

If “Parking Support Brake Unavailable”

is displayed on the multi-information

display and the PKSB OFF indicator is

flashing

If this message is displayed, a sensor on the

front or rear bumper may be dirty. Clean

the sensors and their surrounding area on

the bumpers.

■

If “Parking Support Brake Unavailable”

and “Parking Assist Unavailable Clean

Parking Assist Sensor” are displayed on

the multi-information display and the

PKSB OFF indicator is flashing

●

A sensor may be covered with ice, snow,

dirt, etc. In this case, remove the ice,

snow, dirt, etc., from the sensor to return

the system to normal. If this message is

shown even after removing dirt from the

sensor, or shown when the sensor was

not dirty to begin with, have the vehicle

inspected at your Lexus dealer.

●

A sensor may be frozen. Once the ice

melts, the system will return to normal.

●

Water may be continuously flowing over

the sensor surface, such as in a heavy

rain. When the system determines that it

is normal, the system will return to nor-

mal.

■

If a 12-volt battery terminal has been

disconnected and reconnected

The system needs to be initialized. To initial-

ize the system, drive the vehicle straight

ahead for 5 seconds or more at a speed of

approximately 22 mph (35 km/h) or more.

255

4-5. Using the driving support systems

Driving

■

When the vehicle moves in the
unintended direction due to the
wrong shift position being selected



P.237

■

The Parking Support Brake function

(static objects) will operate when

The function will operate when the PKSB

OFF indicator is not illuminated or flashing

(



P.75, 76) and all of the following condi-

tions are met:

●

Hybrid system output restriction control

• The Parking Support Brake is enabled.

• The vehicle speed is approximately 10

mph (15 km/h) or less.

• There is a static object in the traveling

direction of the vehicle and approxi-

mately 6 to 13 ft. (2 to 4 m) away.

• The Parking Support Brake determines

that a stronger-than-normal brake oper-

ation is necessary to avoid a collision.

●

Brake control

• Hybrid system output restriction control

is operating.

• The Parking Support Brake determines

that an immediate brake operation is

necessary to avoid a collision.

■

The Parking Support Brake function

(static objects) will stop operating when

The function will stop operating if any of the

following conditions are met:

●

Hybrid system output restriction control

• The Parking Support Brake is disabled.

• The system determines that the collision

has become avoidable with normal brake

operation.

• The static object is no longer approxi-

mately 6 to 13 ft. (2 to 4 m) away from the

vehicle or in the traveling direction of the

vehicle.

●

Brake control

• The Parking Support Brake is disabled.

• Approximately 2 seconds have elapsed

since the vehicle was stopped by brake

control.

• The brake pedal is depressed after the

vehicle is stopped by brake control.

• The static object is no longer approxi-

mately 6 to 13 ft. (2 to 4 m) away from the

vehicle or in the traveling direction of the

vehicle.

■

Detection range of the Parking Support

Brake function (static objects)

The detection range of the Parking Support

Brake function (static objects) differs from

the detection range of the intuitive parking

assist. (



P.242) Therefore, even if the

intuitive parking assist detects an object and

provides a warning, the Parking Support

Brake function (static objects) may not start

operating.

■

Situations in which the Parking Support

Brake function (static objects) may not

operate

When driving with the shift lever in N

Types of sensors

WARNING

■

To ensure the system can operate

properly



P.239

■

If the Parking Support Brake function

(static objects) operates unnecessar-

ily, such as at a railroad crossing



P.253

■

Notes when washing the vehicle



P.239

256

4-5. Using the driving support systems

■

Situations in which the system may not

operate properly



P.240

■

Situations in which the system may

operate even if there is no possibility of a

collision



P.241

: If equipped

This function will operate in situations
such as the following if a vehicle is
detected in the traveling direction of
the vehicle.

■

When reversing, a vehicle is
approaching and the brake pedal is
not depressed, or is depressed late



P.233

Parking Support Brake
function (rear-crossing vehi-
cles)

If a rear radar sensor detects a
vehicle approaching from the right
or left at the rear of the vehicle and
the system determines that the pos-
sibility of a collision is high, this
function will perform brake control
to reduce the likelihood of an
impact with the approaching vehi-
cle.

Examples of function operation

Types of sensors

257

4-5. Using the driving support systems

Driving

■

The Parking Support Brake function

(rear-crossing vehicles) will operate

when

The function will operate when the PKSB

OFF indicator is not illuminated or flashing

(



P.75, 76) and all of the following condi-

tions are met:

●

Hybrid system output restriction control

• The Parking Support Brake is enabled.

• The vehicle speed is approximately 10

mph (15 km/h) or less.

• Vehicles are approaching from the right

or left at the rear of the vehicle at a travel-

ing speed of approximately 5 mph (8

km/h) or more.

• The shift lever is in R.

• The Parking Support Brake determines

that a stronger than normal brake opera-

tion is necessary to avoid a collision with

an approaching vehicle.

●

Brake control

• Hybrid system output restriction control

is operating.

• The Parking Support Brake determines

that an emergency brake operation is

necessary to avoid a collision with an

approaching vehicle.

■

The Parking Support Brake function

(rear-crossing vehicles) will stop oper-

ating when

The function will stop operating if any of the

following conditions are met:

●

Hybrid system output restriction control

• The Parking Support Brake is disabled.

• The collision becomes avoidable with

normal brake operation.

• A vehicle is no longer approaching from

the right or left at the rear of the vehicle.

●

Brake control

• The Parking Support Brake is disabled.

• Approximately 2 seconds have elapsed

since the vehicle was stopped by brake

control.

• The brake pedal is depressed after the

vehicle is stopped by brake control.

• A vehicle is no longer approaching from

the right or left at the rear of the vehicle.

■

Detection area of the Parking Support

Brake function (rear-crossing vehicles)

The detection area of the Parking Support

Brake function (rear-crossing vehicles) dif-

fers from the detection area of the RCTA

function (



P.246). Therefore, even if the

RCTA function detects a vehicle and pro-

vides an alert, the Parking Support Brake

function (rear-crossing vehicles) may not

start operating.

■

Situations in which the system may not

operate properly



P.247

■

Situations in which the system may

operate even if there is no possibility of a

collision



P.248

WARNING

■

To ensure the system can operate

properly



P.232

258

4-5. Using the driving support systems



Vehicles without Adaptive Variable
Suspension system

Except F SPORT models

F SPORT models

Normal mode

Provides an optimal balance of fuel econ-
omy, quietness, and dynamic performance.
Suitable for city driving.
Press the switch to change the driving
mode to Normal mode when not in Nor-
mal mode.

Eco drive mode

Helps the driver accelerate in an eco-
friendly manner and improve fuel economy
through moderate throttle characteristics

and by controlling the operation of the air
conditioning system (heating/cooling).
When not in Eco drive mode, if the driving
mode select switch is turned toward you,
the “Eco” indicator comes on.

Sport mode

Assists acceleration response by con-
trolling the hybrid system and steering.
Suitable for when precise handling is desir-
able, for example when driving on moun-
tain roads.
When not in Sport mode, if the driving
mode select switch is turned backward, the
“Sport” indicator comes on and the Hybrid
System Indicator changes to the tachome-
ter. (



P.79, 83)



Vehicles with Adaptive Variable
Suspension system

Normal mode/Custom mode

Normal mode and Custom mode are
selected by pressing the driving mode
select switch. Each time the switch is
pressed, the driving mode changes
between Normal mode and Custom
mode. When Custom mode is selected,
the “Custom” indicator comes on.
Press the switch to change the driving
mode to Normal mode when not in Nor-
mal mode.

Driving mode select switch

The driving modes can be selected
to suit driving conditions.

Selecting the driving mode

A
B

259

4-5. Using the driving support systems

Driving

• Normal mode
Provides an optimal balance of fuel econ-
omy, quietness, and dynamic performance.
Suitable for city driving.
• Custom mode
Allows you to drive with the power train,
chassis and air conditioning system func-
tions set to your preferred settings.
Custom mode settings can only be
changed on the drive mode customization
display of Center Display. (



P.426)

Eco drive mode

Helps the driver accelerate in an eco-
friendly manner and improve fuel economy
through moderate throttle characteristics
and by controlling the operation of the air
conditioning system (heating/cooling).
When not in Eco drive mode, if the driving
mode select switch is turned toward you,
the “Eco” indicator comes on.

Sport mode

• SPORT S mode
Assists acceleration response by con-
trolling the hybrid system.
When not in Sport S mode, if the driving
mode select switch is turned away from
you, the “Sport S” indicator comes on and
the Hybrid System Indicator changes to
the tachometer. (



P.79, 83)

• SPORT S+ mode
Helps to ensure superior vehicle stability
by simultaneously controlling the steering
and suspension in addition to the hybrid
system. Suitable for sportier driving.
When in SPORT S mode, if the driving
mode select switch is turned backward, the
“Sport S+” indicator comes on.

■

Operation of the air conditioning sys-

tem in Eco drive mode

Eco drive mode controls the heating/cool-

ing operations and fan speed of the air con-

ditioning system to enhance fuel efficiency.

To improve air conditioning performance,

perform the following operations:

●

Turn off eco air conditioning mode

(



P.279)

●

Adjust the fan speed (



P.275, 278)

●

Turn off Eco drive mode

■

Automatic deactivation of Sport mode

and Custom mode (if equipped)

If the power switch is turned off after driving

in Sport mode or Custom mode, the driving

mode will be changed to Normal mode.

■

Driving mode pop-up display

When the driving mode is changed, the

selected driving mode will be temporarily

displayed on the Center Display. (Except

for Normal mode)
For Custom mode, select “Settings” on the

display to customize the driving mode.

■

Customization (vehicles with Adaptive

Variable Suspension system)

Settings (e.g. custom mode) can be

changed. (Customizable fea-

tures:



P.435)

260

4-5. Using the driving support systems

■

ECB (Electronically Controlled
Brake System)

The electronically controlled system
generates braking force correspond-
ing to the brake operation

■

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the
brakes are applied suddenly, or if the
brakes are applied while driving on a
slippery road surface

■

Brake assist

Generates an increased level of brak-
ing force after the brake pedal is
depressed when the system detects a
panic stop situation

■

VSC (Vehicle Stability Control)

Helps the driver to control skidding
when swerving suddenly or turning on
slippery road surfaces

■

Enhanced VSC (Enhanced Vehi-
cle Stability Control)

Provides cooperative control of the
ABS, TRAC, VSC and EPS.

Helps to maintain directional stability
when swerving on slippery road sur-
faces by controlling steering perfor-
mance.

■

Secondary Collision Brake

When the airbag sensor detects a colli-
sion, the brakes and brake lights are
automatically controlled to reduce the
vehicle speed and that helps reduce
the possibility of further damage due to
a secondary collision

■

TRAC (Traction Control)

Helps to maintain drive power and
prevent the drive wheels from spinning
when starting the vehicle or accelerat-
ing on slippery roads

■

Active Cornering Assist (ACA)

Helps to prevent the vehicle from drift-
ing to the outer side by performing
inner wheel brake control when
attempting to accelerate during cor-
nering

■

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

■

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

■

E-Four (AWD models)

Electronic On-Demand AWD system.
Automatically switches from front-
wheel drive to all-wheel drive (AWD)
according to the driving conditions,
helping to ensure reliable handling and

Driving assist systems

To keep driving safety and perfor-
mance, the following systems oper-
ate automatically in response to
various driving situations. Be
aware, however, that these systems
are supplementary and should not
be relied upon too heavily when
operating the vehicle.

Summary of the driving assist
systems

261

4-5. Using the driving support systems

Driving

stability. Examples of conditions where
the system will switch to AWD are
when cornering, going uphill, starting
off or accelerating, and when the road
surface is slippery due to snow, rain,
etc.

■

AVS (Adaptive Variable Suspen-
sion system) (if equipped)

By independently controlling the
damping force of the shock absorbers
for each of the 4 wheels according to
the road and driving conditions, this
system helps riding comfort with supe-
rior vehicle stability, and helps good
vehicle posture. If Sport S+ mode is
selected using the driving mode select
switch, the damping force will become
more suitable for sporty driving.
(



P.258)

■

When the TRAC/VSC/ABS systems

are operating

The slip indicator light will flash while the

TRAC/VSC/ABS systems are operating.

■

Disabling the TRAC system

If the vehicle gets stuck in mud, dirt or snow,
the TRAC system may reduce power from
the hybrid system to the wheels. Pressing

the

switch to turn the system off may

make it easier for you to rock the vehicle in
order to free it.
To turn the TRAC system off, quickly press

and release the

switch.

The “Traction Control Turned Off” will be
shown on the multi-information display.

Press the

switch again to turn the

system back on.

■

Disabling both TRAC and VSC systems

To turn the TRAC and VSC systems off,

press and hold the

switch for more

than 3 seconds while the vehicle is stopped.
The VSC OFF indicator light will come on
and the “Traction Control Turned Off” will
be shown on the multi-information display.

Press the

switch again to turn the

system back on.

: Pre-collision brake assist and pre-colli-

sion braking will also be disabled. The
PCS warning light will come on and the
message will be shown on the multi-infor-
mation display. (



P.209)

■

When the message is displayed on the
multi-information display showing that
TRAC has been disabled even if the

switch has not been pressed

TRAC is temporary deactivated. If the

information continues to show, contact your

Lexus dealer.

■

Operating conditions of hill-start assist

control

When the following four conditions are met,

the hill-start assist control will operate:

●

The shift lever is in a position other than P

or N (when starting off forward/back-

ward on an upward incline).

●

The vehicle is stopped.

262

4-5. Using the driving support systems

●

The accelerator pedal is not depressed.

●

The parking brake is not engaged.

■

Automatic system cancelation of hill-

start assist control

The hill-start assist control will turn off in any

of the following situations:

●

The shift lever is shifted to P or N.

●

The accelerator pedal is depressed.

●

The parking brake is engaged.

●

2 seconds at maximum elapsed after the

brake pedal is released

■

Sounds and vibrations caused by the

ABS, brake assist, VSC, TRAC and hill-

start assist control systems

●

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the hybrid

system is started or just after the vehicle

begins to move. This sound does not indi-

cate that a malfunction has occurred in

any of these systems.

●

Any of the following conditions may

occur when the above systems are oper-

ating.

None of these indicates that a malfunc-

tion has occurred.

• Vibrations may be felt through the vehi-

cle body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

■

ECB operating sound

ECB operating sound may be heard in the

following cases, but it does not indicate that

a malfunction has occurred.

●

Operating sound heard from the engine

compartment when the brake pedal is

operated.

●

Motor sound of the brake system heard

from the front part of the vehicle when

the driver’s door is opened.

●

Operating sound heard from the engine

compartment when one or two minutes

passed after the stop of the hybrid sys-

tem.

■

Active Cornering Assist operation

sounds and vibrations

When Active Cornering Assist is operated,

operation sounds and vibrations may be

generated from the brake system, but this is

not a malfunction.

■

EPS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

■

Automatic reactivation of TRAC and

VSC systems

After turning the TRAC and VSC systems

off, the systems will be automatically re-

enabled in the following situations:

●

When the power switch is turned off

●

If only the TRAC system is turned off, the

TRAC will turn on when vehicle speed

increases. If both the TRAC and VSC

systems are turned off, automatic re-

enabling will not occur when vehicle

speed increases.

■

Secondary Collision Brake operating

conditions

The vehicle speed is approximately 6 mph

(10 km/h) or more and the airbag sensor

detects a collision. (The Secondary Colli-

sion Brake will not operate when the vehi-

cle speed is below approximately 6 mph

[10 km/h].)

■

Secondary Collision Brake automatic

cancellation

The Secondary Collision Brake is automati-

cally canceled in the following situations.

●

The vehicle speed drops below approxi-

mately 6 mph (10 km/h)

●

A certain amount of time elapses during

operation

●

The accelerator pedal is depressed a

large amount

■

Operating conditions of Active Corner-

ing Assist

The system operates in the following situa-

tions.

●

TRAC/VSC can operate

●

The system determines that the vehicle is

drifting to the outer side when attempting

to accelerate during cornering

●

The brake pedal is released

263

4-5. Using the driving support systems

Driving

■

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

steering input or stop the vehicle and turn

the hybrid system off. The EPS system

should return to normal within 10 minutes.

■

If a message about AWD system is

shown on the multi-information display

(AWD models)

If one of the following messages is shown on

the multi-information display, perform each

action.

●

“AWD System Overheated Switching to

2WD Mode”

The AWD system is overheating. Reduce
load on the system by stopping the vehicle
for a while or driving the vehicle at a speed
of 6 mph (10 km/h) or more. If the message
disappears, it is possible to drive the vehicle
normally.

●

“AWD System Overheated 2WD Mode

Engaged”

The AWD system has been canceled and
switched to the front-wheel drive due to
overheating. Reduce load on the system by
stopping the vehicle for a while or driving
the vehicle at a speed of 6 mph (10 km/h)
or more. If the message disappears, it is
possible to drive the vehicle normally.

●

“AWD System Malfunction 2WD Mode

Engaged Visit Your Dealer”

The AWD system has been stopped and
switched to the front-wheel drive due to a
malfunction. Have your vehicle inspected
by your Lexus dealer immediately.

WARNING

■

The ABS does not operate effectively

when

●

The limits of tire gripping performance

have been exceeded (such as exces-

sively worn tires on a snow covered

road).

●

The vehicle hydroplanes while driving

at high speed on wet or slick road.

■

Stopping distance when the ABS is

operating may exceed that of normal

conditions

The ABS is not designed to shorten the

vehicle’s stopping distance. Always

maintain a safe distance from the vehicle

in front of you, especially in the following

situations:

●

When driving on dirt, gravel or snow-

covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with pot-

holes or uneven surfaces

■

TRAC/VSC may not operate effec-

tively when

Directional control and power may not

be achievable while driving on slippery

road surfaces, even if the TRAC/VSC

system is operating.

Drive the vehicle carefully in conditions

where stability and power may be lost.

■

Active Cornering Assist does not

operate effectively when

●

Do not rely solely upon Active Cor-

nering Assist. Active Cornering Assist

may not operate effectively when

accelerating down slopes or driving on

slippery road surfaces.

●

When Active Cornering Assist fre-

quently operates, Active Cornering

Assist may temporarily stop operating

to ensure proper operation of the

brakes, TRAC, VSC.

264

4-5. Using the driving support systems

WARNING

■

Hill-start assist control does not oper-

ate effectively when

●

Do not overly rely on hill-start assist

control. Hill-start assist control may

not operate effectively on steep

inclines and roads covered with ice.

●

Unlike the parking brake, hill-start

assist control is not intended to hold

the vehicle stationary for an extended

period of time. Do not attempt to use

hill-start assist control to hold the vehi-

cle on an incline, as doing so may lead

to an accident.

■

When the TRAC/ABS/VSC is acti-

vated

The slip indicator light flashes. Always

drive carefully. Reckless driving may

cause an accident. Exercise particular

care when the indicator light flashes.

■

When the TRAC/VSC systems are

turned off

Be especially careful and drive at a

speed appropriate to the road condi-

tions. As these are the systems to help

ensure vehicle stability and driving force,

do not turn the TRAC/VSC systems off

unless necessary.

■

Secondary Collision Brake

Do not overly rely on the Secondary

Collision Brake. This system is designed

to help reduce the possibility of further

damage due to a secondary collision,

however, that effect changes according

to various conditions. Overly relying on

the system may result in death or serious

injury.

■

Replacing tires

Make sure that all tires are of the speci-

fied size, brand, tread pattern and total

load capacity. In addition, make sure that

the tires are inflated to the recom-

mended tire inflation pressure level.

The ABS, TRAC and VSC systems will

not function correctly if different tires are

installed on the vehicle.

Contact your Lexus dealer for further

information when replacing tires or

wheels.

■

Handling of tires and the suspension

Using tires with any kind of problem or

modifying the suspension will affect the

driving assist systems, and may cause a

system to malfunction.

265

4-6. Driving tips

Driving

4-6.Driving tips

When using Eco drive mode, the
torque corresponding to the accelera-
tor pedal depression amount can be
generated more smoothly than it is in
normal conditions. In addition, the
operation of the air conditioning sys-
tem (heating/cooling) will be mini-
mized, improving the fuel economy.
(



P.258)

The Eco-friendly driving is possible by
keeping the indicator of Hybrid System
Indicator within Eco area. (



P.80,

85)

Shift the shift lever to D when stopped
at a traffic light, or driving in heavy traf-
fic, etc. Shift the shift lever to P when
parking. When using the N, there is no
positive effect on fuel consumption. In
the N, the gasoline engine operates
but electricity cannot be generated.
Also, when using the air conditioning
system, etc., the hybrid battery (trac-
tion battery) power is consumed.



Drive your vehicle smoothly. Avoid
abrupt acceleration and decelera-
tion. Gradual acceleration and
deceleration will make more effec-
tive use of the electric motor (trac-
tion motor) without having to use
gasoline engine power.



Avoid repeated acceleration.
Repeated acceleration consumes
hybrid battery (traction battery)
power, resulting in poor fuel con-
sumption. Battery power can be
restored by driving with the acceler-
ator pedal slightly released.

Make sure to operate the brakes gen-
tly and in a timely manner. A greater
amount of electrical energy can be
regenerated when slowing down.

Repeated acceleration and decelera-
tion, as well as long waits at traffic
lights, will lead to bad fuel economy.
Check traffic reports before leaving
and avoid delays as much as possible.
When driving in a traffic jam, gently
release the brake pedal to allow the
vehicle to move forward slightly while
avoiding overuse of the accelerator
pedal. Doing so can help control
excessive gasoline consumption.

Hybrid Electric Vehicle driv-
ing tips

For economical and ecological
driving, pay attention to the follow-
ing points:

Using Eco drive mode

Use of Hybrid System Indicator

Shift lever operation

Accelerator pedal/brake pedal
operation

When braking

Delays

266

4-6. Driving tips

Control and maintain the vehicle at a
constant speed. Before stopping at a
toll booth or similar, allow plenty of
time to release the accelerator and
gently apply the brakes. A greater
amount of electrical energy can be
regenerated when slowing down.

Use the air conditioning only when
necessary. Doing so can help reduce
excessive gasoline consumption.
In summer: When the ambient tem-
perature is high, use the recirculated
air mode. Doing so will help to reduce
the burden on the air conditioning sys-
tem and reduce fuel consumption as
well.
In winter: Because the gasoline engine
will not automatically cut out until it and
the interior of the vehicle are warm, it
will consume fuel. Also, fuel consump-
tion can be improved by avoiding
overuse of the heater.

Make sure to check the tire inflation
pressure frequently. Improper tire
inflation pressure can cause poor fuel
economy.
Also, as snow tires can cause large
amounts of friction, their use on dry
roads can lead to poor fuel economy.
Use tires that are appropriate for the
season.

Carrying heavy luggage will lead to
poor fuel economy. Avoid carrying
unnecessary luggage. Installing a large
roof rack will also cause poor fuel
economy.

Since the gasoline engine starts up and
cuts out automatically when cold,
warming up the engine is unnecessary.
Moreover, frequently driving short dis-
tances will cause the engine to repeat-
edly warm up, which can lead to excess
fuel consumption.

Highway driving

Air conditioning

Checking tire inflation pressure

Luggage

Warming up before driving

267

4-6. Driving tips

Driving



Use fluids that are appropriate to
the prevailing outside temperatures.

• Engine oil
• Engine/power control unit coolant
• Washer fluid



Have a service technician inspect
the condition of the 12-volt battery.



It is recommended that the vehicle is
fitted with four snow run-flat tires or
purchase a set of tire chains for the
front tires.

Ensure that all tires are the same size and
brand, and that chains match the size of the
tires.

Perform the following according to the
driving conditions:



Do not try to forcibly open a window
or move a wiper that is frozen. Pour
warm water over the frozen area to
melt the ice. Wipe away the water
immediately to prevent it from

Winter driving tips

Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.

Preparation for winter

WARNING

■

Driving with snow tires

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in a loss of

vehicle control and cause death or seri-

ous injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air

pressure.

●

Do not drive in excess of 75 mph (120

km/h), regardless of the type of snow

tires being used.

●

Use snow tires on all, not just some

wheels.

■

Driving with tire chains

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in the vehicle

being unable to be driven safely, and may

cause death or serious injury.

●

Do not drive in excess of the speed

limit specified for the tire chains being

used, or 30 mph (50 km/h), which-

ever is lower.

●

Avoid driving on bumpy road surfaces

or over potholes.

●

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

●

Slow down sufficiently before entering

a curve to ensure that vehicle control

is maintained.

●

Do not use LTA (Lane Tracing Assist).

NOTICE

■

Repairing or replacing snow tires

Request repairs or replacement of snow

tires from Lexus dealers or legitimate tire

retailers.

This is because the removal and attach-

ment of snow tires affects the operation

of the tire pressure warning valves and

transmitters.

Before driving the vehicle

268

4-6. Driving tips

freezing.



To ensure proper operation of the
climate control system fan, remove
any snow that has accumulated on
the air inlet vents in front of the
windshield.



Check for and remove any excess
ice or snow that may have accumu-
lated on the exterior lights, outside
rear view mirrors, windows, vehi-
cle’s roof, chassis, around the tires
or on the brakes.



Remove any snow or mud from the
bottom of your shoes before getting
in the vehicle.

Accelerate the vehicle slowly, keep a
safe distance between you and the
vehicle ahead, and drive at a reduced
speed suitable to road conditions.



Park the vehicle and move the shift
lever to P without setting the park-
ing brake. The parking brake may
freeze up, preventing it from being
released. If the vehicle is parked
without setting the parking brake,
make sure to block the wheels.
Failure to do so may be dangerous
because it may cause the vehicle to
move unexpectedly, possibly lead-
ing to an accident.

When the parking brake is in automatic
mode, release the parking brake after shift-
ing the shift lever to P. (



P.174)



If the vehicle is left parked with the
brakes damp in cold temperatures,
there is a possibility of the brakes
freezing.



If the vehicle is parked without set-
ting the parking brake, confirm that
the shift lever cannot be moved out
of P

: The shift lever will be locked if it is

attempted to be shifted from P to any
other position without depressing the
brake pedal. If the shift lever can be
shifted from P, there may be a problem
with the shift lock system. Have the vehi-
cle inspected by your Lexus dealer
immediately.

Use the correct tire chain size when
mounting the tire chains. Chain size is
regulated for each tire size.

Side chain:

0.12 in. (3 mm) in diameter

When driving the vehicle

When parking the vehicle

WARNING

■

When parking the vehicle

When parking the vehicle without apply-

ing the parking brake, make sure to

chock the wheels. If you do not chock the

wheels, the vehicle may move unexpect-

edly, possibly resulting in an accident.

Selecting tire chains

269

4-6. Driving tips

Driving

0.39 in. (10 mm) in width

0.98 in. (25 mm) in length

Cross chain:

0.16 in. (4 mm) in diameter

0.55 in. (14 mm) in width

0.98 in. (25 mm) in length

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

■

Tire chain installation

Observe the following precautions when

installing and removing chains:

●

Install and remove tire chains in a safe

location.

●

Install tire chains on the front tires only.

Do not install tire chains on the rear tires.

●

Install tire chains on front tires as tightly

as possible. Retighten chains after driving

1/4 - 1/2 mile (0.5 - 1.0 km).

●

Install tire chains following the instruc-

tions provided with the tire chains.

To enable the windshield wipers to be
lifted when heavy snow or icy condi-
tions are expected, change the rest
position of the windshield wipers from

the retracted position below the hood
to the service position using the wiper
lever. (



P.189)

Regulations on the use of tire
chains

NOTICE

■

Fitting tire chains

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

Windshield wipers

270

4-6. Driving tips



Specific design characteristics give
it a higher center of gravity than
ordinary passenger cars. This vehi-
cle design feature causes this type
of vehicle to be more likely to roll-
over. Utility vehicles have a signifi-
cantly higher rollover rate than
other types of vehicles.



An advantage of the higher ground
clearance is a better view of the
road allowing you to anticipate
problems.



It is not designed for cornering at
the same speeds as ordinary pas-
senger cars any more than low-
slung sports cars designed to per-
form satisfactorily under off-road
conditions. Therefore, sharp turns at
excessive speeds may cause roll-
over.

Your vehicle is not designed to be
driven off-road. However, in the event
that off-road driving cannot be
avoided, please observe the following
precautions to help avoid the areas
prohibited to vehicles.

Utility vehicle precautions

This vehicle belongs to the utility
vehicle class, which has higher
ground clearance and narrower
tread in relation to the height of its
center of gravity.

Utility vehicle feature

WARNING

■

Utility vehicle precautions

Always observe the following precau-

tions to minimize the risk of death or seri-

ous injury or damage to your vehicle:

●

In a rollover crash, an unbelted person

is significantly more likely to die than a

person wearing a seat belt. Therefore,

the driver and all passengers should

always fasten their seat belts.

●

Avoid sharp turns or abrupt maneu-

vers, if at all possible.

Failure to operate this vehicle cor-

rectly may result in loss of control or

vehicle rollover causing death or seri-

ous injury.

●

Loading cargo on the roof luggage

carrier will make the center of the

vehicle gravity higher. Avoid high

speeds, sudden starts, sharp turns,

sudden braking or abrupt maneuvers,

otherwise it may result in loss of con-

trol or vehicle rollover due to failure to

operate this vehicle correctly.

●

Always slow down in gusty crosswinds.

Because of its profile and higher cen-

ter of gravity, your vehicle is more sen-

sitive to side winds than an ordinary

passenger car. Slowing down will

allow you to have better control.

●

Do not drive horizontally across steep

slopes. Driving straight up or straight

down is preferred. Your vehicle (or

any similar off-road vehicle) can tip

over sideways much more easily than

forward or backward.

Off-road driving

271

4-6. Driving tips

Driving



Drive your vehicle only in areas
where off-road vehicles are permit-
ted to travel.



Respect private property. Get
owner’s permission before entering
private property.



Do not enter areas that are closed.
Honor gates, barriers and signs that
restrict travel.



Stay on established roads. When
conditions are wet, driving tech-
niques should be changed or travel
delayed to prevent damage to
roads.



AWD models: Avoid driving on
very steep, slippery roads and other
surfaces, such as sand, where the
tires are liable to lose traction. Your
vehicle may not perform as well as
conventional AWD on-road vehi-
cles on these surfaces.

■

Additional information for off-road driv-

ing



For owners in U.S. mainland, Hawaii and

Puerto Rico:

To obtain additional information pertaining

to driving your vehicle off-road, consult the

following organizations.

●

State and Local Parks and Recreation

Departments

●

State Motor Vehicle Bureau

●

Recreational Vehicle Clubs

●

U.S. Forest Service and Bureau of Land

Management

WARNING

■

Off-road driving precautions

Always observe the following precau-

tions to minimize the risk of death or seri-

ous injury or damage to your vehicle:

●

Drive carefully when off the road. Do

not take unnecessary risks by driving

in dangerous places.

●

Do not grip the steering wheel spokes

when driving off-road. A bad bump

could jerk the wheel and injure your

hands. Keep both hands and especially

your thumbs on the outside of the rim.

●

Always check your brakes for effec-

tiveness immediately after driving in

sand, mud, water or snow.

●

After driving through tall grass, mud,

rock, sand, water, etc., check that

there is no grass, bush, paper, rags,

stone, sand, etc. adhering or trapped

to the underbody. Clear off any such

matter from the underbody. If the vehi-

cle is used with these materials

trapped or adhering to the underbody,

a breakdown or fire could occur.

●

When driving off-road or in rugged

terrain, do not drive at excessive

speeds, jump, make sharp turns, strike

objects, etc. This may cause loss of

control or vehicle rollover causing

death or serious injury. You are also

risking expensive damage to your

vehicle’s suspension and chassis.

NOTICE

■

To prevent water damage

Take all necessary safety measures to

ensure that water damage to the hybrid

battery (traction battery), hybrid system

or other components does not occur.

●

Water entering the engine compart-

ment may cause severe damage to the

hybrid system. Water entering the

interior may cause the hybrid battery

stowed under the rear seats to short

circuit.

272

4-6. Driving tips

NOTICE

●

Water entering the hybrid transmis-

sion and rear electric motor (traction

motor) will cause deterioration in

hybrid transmission quality. The mal-

function indicator may come on, and

the vehicle may not be drivable.

●

Water can wash the grease from

wheel bearings, causing rusting and

premature failure, and may also enter

the hybrid transmission case, reducing

the gear oil’s lubricating qualities.

■

When you drive through water

If driving through water, such as when

crossing shallow streams, first check the

depth of the water and the bottom of the

riverbed for firmness. Drive slowly and

avoid deep water.

■

Inspection after off-road driving

●

Sand and mud that has accumulated

around brake discs may affect braking

efficiency and may damage brake sys-

tem components.

●

Always perform a maintenance

inspection after each day of off-road

driving that has taken you through

rough terrain, sand, mud, or water. For

scheduled maintenance information,

refer to the “Warranty and Services

Guide/Owner’s Manual Supple-

ment/Scheduled Maintenance”.

273

Interio

r fe

atures

Interior features

5-1. Lexus Climate Concierge

Lexus Climate Concierge.....

274

5-2. Using the air conditioning system

and defogger

Automatic air conditioning sys-

tem................................................

275

Heated steering wheel/seat heat-

ers/seat ventilators................

282

5-3. Using the interior lights

Interior lights list.........................

285

5-4. Using the storage features

List of storage features............

288

Luggage compartment features

.........................................................

291

5-5. Using the other interior features

Other interior features ...........

296

Garage door opener...............

306

Compass.........................................

311

274

5-1. Lexus Climate Concierge

5-1.Lexus Climate Concierge

Select

in the main menu on the

Center Display.

Select “Climate”.

If the option screen is displayed, select

“Front”.

Select “Climate concierge”.

The indicator on the air conditioning con-
trol screen illuminates, and the automatic
air conditioning system, seat heaters and
ventilators (if equipped), and heated steer-
ing wheel (if equipped) operate in auto-
matic mode.
If any of the system is operated manually,
the indicator turns off. However, all other
functions continue to operate in automatic
mode.

■

Automatic air conditioning system
(



P.275)

The temperature can be adjusted inde-

pendently for the driver seat and pas-
senger seat.

■

Seat heaters and ventilators (if
equipped) (



P.282)

Heating or ventilation is automatically
selected according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc.
The seat heater and ventilator of the
front passenger seat operate in auto-
matic mode if a passenger is detected.

■

Heated steering wheel (if
equipped) (



P.282)

Heated steering wheel operates auto-
matically according to the set tem-
perature of the air conditioning system,
the outside temperature, etc.

■

Seat heater/ventilator operation

When automatic mode is selected using the

seat heater/ventilator switch, passenger

detection is not performed.

Lexus Climate Concierge

The seat heaters (if equipped), seat
ventilators (if equipped) and heated
steering wheel (if equipped) are
each automatically controlled
according to the set temperature of
the air conditioning system, the out-
side and cabin temperature, etc.
Lexus Climate Concierge allows a
comfortable condition to be main-
tained without adjusting each sys-
tem.

Turning on Lexus Climate Con-
cierge

Operation of each system

275

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

5-2.Using the air conditioning system and defogger

Left-hand side temperature control switch

Fan speed control switch

Automatic mode switch

Off switch

Windshield defogger switch

Rear window and outside rear view mirror defoggers switch

Outside/recirculated air mode switch

Airflow mode control switch

Right-hand side temperature control switch

Automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
The air conditioning system can be operated using the air conditioning control
panel and air conditioning control screen on the Center Display (



P.278).

Air conditioning controls

A
B
C
D

E
F

276

5-2. Using the air conditioning system and defogger

■

Adjusting the temperature setting

Operate the temperature control
switch upwards to increase the tem-
perature and downwards to decrease
the temperature.

■

Setting the fan speed

Operate the fan speed control switch
upwards to increase the fan speed and
downwards to decrease the fan speed.

Press the off switch to turn the fan off.

■

Change the airflow mode

Operate the airflow mode control
switch upwards or downwards.

The mode changes as follows each time
the switch is operated.

Air flows to the upper body.

Air flows to the upper body and
feet.

Air flows to the feet.

Air flows to the feet and the wind-
shield defogger operates.

■

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.

The mode switches between outside air
mode (the indicator is off) and recirculated
air mode (the indicator is on) each time the
switch is pressed.

■

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the windshield defogger switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows quickly, turn the air flow and tem-
perature up.
To return to the previous mode, press the
windshield defogger switch again when the
windshield is defogged.

■

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window and to remove raindrops, dew
and frost from the outside rear view
mirrors.
Press the rear window and outside
rear view mirror defoggers switch.

The defoggers will automatically turn off
after a period of time.

■

Windshield wiper de-icer (if
equipped)



P.279

A
B

C
D

277

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

■

When the outside temperature exceeds

75°F (24°C) and the air conditioning

system is on

●

In order to reduce the air conditioning

power consumption, the air conditioning

system may switch to recirculated air

mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a

default mode when the power switch is

turned to ON.

●

It is possible to switch to outside air mode

at any time by pressing the outside/recir-

culated air mode switch.

■

Fogging up of the windows

●

The windows will easily fog up when the

humidity in the vehicle is high. Selecting

“A/C” will dehumidify the air from the

outlets and defog the windshield effec-

tively.

●

If you turn “A/C” off, the windows may

fog up more easily.

●

The windows may fog up if the recircu-

lated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode tem-

porarily is recommended in preventing

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

●

Outside/recirculated air mode may

automatically switch depending on the

temperature setting or the inside tem-

perature.

■

Registering air conditioning settings to

electronic keys (vehicles with driving

position memory)

●

Unlocking the vehicle using an electronic

key and turning the power switch to ON

will recall that key’s registered air condi-

tioning settings.

●

When the power switch is turned off, the

current air conditioning settings will auto-

matically be registered to the electronic

key that was used to unlock the vehicle.

●

The system may not operate correctly if

more than one electronic key is in the

vicinity or if the smart access system with

push-button start is used to unlock a pas-

senger door.

●

The doors that can recall the air condi-

tioning setting when unlocked using the

smart access system with push-button

start can be changed.

For details, con-

tact your Lexus dealer.

: The doors that can recall the driving posi-

tion memory are changed at the same
time.

■

Operation of the air conditioning sys-

tem in Eco drive mode

●

In Eco drive mode, the air conditioning

system is controlled as follows to priori-

tize fuel efficiency

• Engine speed and compressor operation

controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic

mode is selected

●

To improve air conditioning perfor-

mance, perform the following operations

• Turn off eco air conditioning mode

(



P.278)

• Adjust the fan speed

• Turn off Eco drive mode

■

When the outside temperature is low

The dehumidification function may not

operate even when “A/C” is selected.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning

system to the outside air mode.

●

During use, various odors from inside

and outside the vehicle may enter into

and accumulate in the air conditioning

system. This may then cause odor to be

emitted from the vents.

●

To reduce potential odors from occur-

ring, the start timing of the blower may be

delayed for a short period of time imme-

278

5-2. Using the air conditioning system and defogger

diately after the air conditioning system is

started in automatic mode.

●

When parking, the system automatically

switches to outside air mode to encour-

age better air circulation throughout the

vehicle, helping to reduce odors that

occur when starting the vehicle.

■

Using the Intelligent Assistant

Air conditioning system can be operated

using the Intelligent Assistant. For details,

refer to the “MULTIMEDIA OWNER’S

MANUAL”.

■

Air conditioning filter



P.355

■

Air conditioning system refrigerant

●

A label regrading the refrigerant of the

air conditioning system is attached to the

hood at the location shown in the follow-

ing illustration.

●

The meaning of each symbol on the label

are as follows:

■

Customization

Settings (e.g. A/C automatic mode switch

operation) can be changed.

(Customizable features:



P.435)

■

Air conditioning control screen

Select

in the main menu on the

Center Display.

Select “Climate”.

If the option screen is displayed, select

“Front”.

Caution

Air conditioning system

Air conditioning system
lubricant type

Requires registered tech-
nician to service air con-
ditioning system

Flammable refrigerant

WARNING

■

To prevent the windshield from fog-

ging up

Do not use the windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

■

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

■

When repairing/replacing parts of

the air conditioning system

Have repair/replacement performed by

your Lexus dealer. When a part of the air

conditioning system, such as the evapo-

rator, is to be replaced, it must be

replaced with a new one.

Air conditioning control screen

279

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

Sub menu

Selecting the sub menu item to switch the
screen display.
“Front”: Display the air conditioning con-
trol screen
“Options”: Display the option screen

Select the air flow mode

Each time the switch is selected, the airflow
mode is changed.

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Turn the function on/off

Each of the following functions can be
switched on and off.
When the function is on, the indicator illu-
minates on the control screen.
“A/C”: Set cooling and dehumidification
function
“Sync”: Adjust the temperature for driver
and front passenger seats simultaneously
(“Sync” mode) (



P.280)

: Select front seat concentrated

air flow mode (S-FLOW) (



P.281)

“Climate concierge”: Set Lexus Climate

Concierge (



P.274)

Fan speed level display

The current fan speed level is displayed.
