Lexus NX450H+ (2024 year). Manual in english

The vehicle identification number (VIN) is the legal identifier for your vehicle. This
is the primary identification number for your Lexus. It is used in registering the
ownership of your vehicle.

10-1. Specifications

760

●

This number is stamped on the top left of the
instrument panel.

●

This number is also on the Certification Label.

●

On some models, this number is also stamped
under the right-hand front seat.

■

Engine number

The engine number is stamped on the engine block as shown.

Engine

Model

2.5 L 4-cylinder (A25A-FXS)

Type

4-cylinder in line, 4-cycle, gasoline

Bore and stroke

3.44 × 4.07 in. (87.5 × 103.4 mm)

10-1. Specifications

761

Vehicle specifications

Displacement

151.8 cu. in. (2487 cm

)

Valve clearance (engine cold)

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

91 (Research Octane Number 96) or high-
er [recommended]
87 (Research Octane Number 91) or high-
er [minimum]

Fuel tank capacity (Reference)

14.5 gal. (55.0 L, 12.1 Imp. gal.)

Electric motor (traction motor)

▶

Front

Type

Permanent magnet synchronous motor

Maximum output

134 kW

Maximum torque

199.1 ft•lbf (270 N•m, 27.5 kgf•m)

▶

Rear (AWD models)

Type

Permanent magnet synchronous motor

Maximum output

40 kW

Maximum torque

89.2 ft•lbf (121 N•m, 12.3 kgf•m)

Hybrid battery (traction battery)

Type

Lithium-ion battery

Voltage

3.7 V/cell

Capacity

51 Ah

Quantity

96 cells

Nominal voltage

355 V

10-1. Specifications

762

Lubrication system

■

Oil capacity (Drain and refill) (Reference)

With filter

4.5 qt. (4.3 L, 3.8 Imp. qt.)

Without filter

4.2 qt. (4.0 L, 3.5 Imp. qt.)

■

Engine oil selection

"Toyota Genuine Motor Oil" is used in your Lexus vehicle. Use Lexus approved
"Toyota Genuine Motor Oil" or equivalent to satisfy the following grade and
viscosity.

Oil grade: ILSAC GF-6B multigrade engine oil
Recommended viscosity: SAE 0W-16

Outside temperature

SAE 0W-16 is the best choice for good fuel economy and good starting in cold
weather. If SAE 0W-16 is not available, SAE 0W-20 oil may be used. However, it
must be replaced with SAE 0W-16 at the next oil change.

■

How to read oil container label

API registered mark is added to some oil con-
tainers to help you select the oil you should use.
Oil viscosity (0W-16 is explained here as an ex-
ample):

●

The 0W in 0W-16 indicates the characteristic of the oil which allows cold
startability.
Oils with a lower value before the W allow for easier starting of the engine in
cold weather.

*1 :

The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up the engine and turn off the hybrid system, wait more than 5 minutes, and

check the oil level on the dipstick.

10-1. Specifications

763

Vehicle specifications

●

The 16 in 0W-16 indicates the viscosity characteristic of the oil when the oil is at
high temperature.
An oil with a higher viscosity (one with a higher value) may be better suited if the
vehicle is operated at high speeds, or under extreme load conditions.

Cooling system

Capacity

(1)

Gasoline engine

Vehicles with towing pack-
age:
8.7 qt. (8.2 L, 7.2 Imp. qt.)
Vehicles without towing
package:
7.8 qt. (7.4 L, 6.5 Imp. qt.)

Power control unit

2.1 qt. (2.0 L, 1.6 Imp. qt.)

Coolant type

Use either of the following:

●

"Toyota Super Long Life
Coolant"

●

Similar high-quality eth-
ylene glycol-based non-
silicate, non-amine, non-
nitrite, and non-borate
coolant with long-life hy-
brid organic acid tech-
nology

Do not use plain water
alone.

(1)

The coolant capacity is a reference quantity. If replacement is necessary, contact your

Lexus dealer.

Ignition system (spark plug)

Make

DENSO FC16HR-Q8

Gap

0.03 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

10-1. Specifications

764

Electrical system

■

12-volt battery

Open voltage at 68°F (20°C):

12.0 V or higher
(Turn the power switch off and turn on the
high beam headlights for 30 seconds.)

■

Charging rates

Quick charge

15 A max.

Slow charge

5 A max.

Hybrid transmission

Fluid capacity

(1)

4.6 qt. (4.4 L, 3.9 Imp. qt.)

Fluid type

"Toyota Genuine ATF WS"

(1)

The fluid capacity is a reference quantity. If replacement is necessary, contact your

Lexus dealer.

NOTICE

■

Hybrid transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-
tion, or ultimately damage the transmission of your vehicle.

Rear differential (Rear electric motor)

Oil capacity

(1)

1.8 qt. (1.7 L, 1.5 Imp. qt.)

Oil type and viscosity

"Toyota Genuine ATF WS"

(1)

The oil capacity is a reference quantity.
If replacement is necessary, contact your Lexus dealer.

NOTICE

■

Transmission fluid type

Using differential gear oil other than the specified oil may cause abnormal noise or
vibration, or damage the differential gear of your vehicle.

Brakes

10-1. Specifications

765

Vehicle specifications

Pedal clearance

(1)

5.0 in. (128 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Pedal free play

0.04 - 0.25 in. (1 - 6 mm)

Fluid type

●

FMVSS No. 116 DOT 3 or SAE J1703

●

FMVSS No. 116 DOT 4 or SAE J1704

(1)

Minimum pedal clearance when depressed with a force of 67.5 lbf (300 N, 30.6 kgf)

while the engine is running.

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

▶

Type A

Tire size

235/60R18 103H

Tire inflation pressure (Recommended cold
tire inflation pressure)

Front: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Rear: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Driving at high speeds (above 100 mph
[160 km/h]) (in countries where such
speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar)

to the front and rear tires. Never exceed
the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

18 × 7 1/2 J

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

▶

Type B

Tire size

235/50R20 100V

10-1. Specifications

766

Tire inflation pressure (Recommended cold
tire inflation pressure)

Front: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Rear: 33 psi (230 kPa, 2.3 kgf/cm

or bar)

Driving at high speeds (above 100 mph
[160 km/h]) (in countries where such
speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar)

to the front and rear tires. Never exceed
the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

20 × 7 1/2 J

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

Light bulbs

Bulb No.

Type

Exterior

Front turn signal
lights (bulb
type)

WY21W

A: Wedge base bulbs (amber)

10-1. Specifications

767

Vehicle specifications

Fuel information

You must only use unleaded gasoline in your vehicle.
Recommended to use premium unleaded gasoline with octane rating of 91 (Re-
search Octane Number of 96) or higher for optimum engine performance. You
may use unleaded gasoline with octane rating as low as 87 (Research Octane
Number of 91). In this case, engine performance may be decreased.
Use of unleaded gasoline with an octane rating lower than 87 may result in engine
knocking. Persistent knocking can lead to engine damage.
At minimum, the gasoline you use should meet the specifications of ASTM D4814
in the U.S.A.

INFORMATION

■

Gasoline quality

In very few cases, driveability problems may be caused by the brand of gasoline you are
using. If driveability problems persist, try changing the brand of gasoline. If this does not
correct the problem, consult your Lexus dealer.

■

Recommendation of the use of gasoline containing detergent additives

●

Lexus recommends the use of gasoline that contains detergent additives to avoid the
build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or
keep clean intake systems, per EPA's lowest additives concentration program.

●

Lexus strongly recommends the use of Top Tier Detergent Gasoline. For more infor-
mation on Top Tier Detergent Gasoline and a list of marketers, please go to the official
website www.toptiergas.com.

■

Recommendation of the use of low emissions gasoline

Gasolines containing oxygenates such as ethers and ethanol, as well as reformulated
gasolines, are available in some cities. These fuels are typically acceptable for use,
providing they meet other fuel requirements.
Lexus recommends these fuels, since the formulations allow for reduced vehicle emis-
sions.

10-1. Specifications

768

■

Non-recommendation of the use of blended gasoline

●

Use only gasoline containing up to 15% ethanol.
DO NOT use any flex-fuel or gasoline that could
contain more than 15% ethanol, including from any
pump labeled E30 (30% ethanol

), E50

(50% ethanol

), E85 (85% ethanol

)

(which are only some examples of fuel containing
more than 15% ethanol).

●

If you use gasohol in your vehicle, be sure that it has an octane rating no lower than 87.

●

Lexus does not recommend the use of gasoline containing methanol.

■

Non-recommendation of the use of gasoline containing MMT

Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta-
dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that contains MMT. If fuel containing
MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instrument cluster may come on. If this happens,
contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knocking for a short time while accelerating or
driving uphill. This is normal and there is no need for concern.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper fuels are used, the engine will be damaged.

●

Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle's three-way catalytic converters
causing the emission control system to malfunction.

●

Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performance problems.

●

Using unleaded gasoline with an octane number or rating lower than the level previ-
ously stated will cause persistent heavy knocking.
At worst, this will lead to engine damage.

■

Fuel-related poor driveability

If poor driveability (poor hot starting, vaporization, engine knocking, etc.) is encountered
after using a different type of fuel, discontinue the use of that type of fuel.

10-1. Specifications

769

Vehicle specifications

Tire information

Typical tire symbols

Tire size

DOT and Tire Identification Number (TIN)

Location of treadwear indicators

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the
plies in a tire.

Radial tires or bias-ply tires

A radial tire has [RADIAL] on the sidewall. A tire not marked [RADIAL] is a bias-ply
tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire
has a tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure

Maximum cold tire inflation pressure

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see

Uniform Tire Quality Grading(

→

P.773)

that follows.

Summer tires or all season tires

An all season tire has [M+S] on the sidewall. A tire not marked [M+S] is a summer tire.

10-1. Specifications

771

Vehicle specifications

Typical DOT and Tire Identification Number (TIN)

▶

Type A

DOT symbol

Tire Identification Number (TIN)

Tire manufacturer's identification mark

Tire size code

Manufacturer's optional tire type code (3 or
4 letters)

Manufacturing week

Manufacturing year

▶

Type B

DOT symbol

Tire Identification Number (TIN)

Tire manufacturer's identification mark

Manufacturer's code

Manufacturing week

Manufacturing year

Tire size

■

Typical tire size information

The illustration indicates typical tire size.

Tire use
(P = Passenger car, T = Temporary use)

Section width (millimeters)

Aspect ratio (tire height to section width)

Tire construction code
(R = Radial, D = Diagonal)

Wheel diameter (inches)

Load index (2 digits or 3 digits)

Speed symbol (alphabet with one letter)

*1 :

The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle

Safety Standards.

10-1. Specifications

772

■

Tire dimensions

Section width

Tire height

Wheel diameter

Tire section names

Bead

Sidewall

Shoulder

Tread

Belt

Inner liner

Reinforcing rubber

Carcass

Rim lines

Bead wires

Chafer

Uniform Tire Quality Grading

This information has been prepared in accordance with regulations issued by
the National Highway Traffic Safety Administration of the U.S. Department of
Transportation.
It provides the purchasers and/or prospective purchasers of Lexus vehicles with
information on uniform tire quality grading.
Your Lexus dealer will help answer any questions you may have as you read this
information.

■

DOT quality grades

All passenger vehicle tires must conform to Federal Safety Requirements in addi-
tion to these grades. Quality grades can be found where applicable on the tire
sidewall between tread shoulder and maximum section width.
For example: Treadwear 200 Traction AA Temperature A

10-1. Specifications

773

Vehicle specifications

■

Treadwear

The treadwear grade is a comparative rating based on the wear rate of the tire
when tested under controlled conditions on a specified government test course.
For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on
the government course as a tire graded 100.
The relative performance of tires depends upon the actual conditions of their use,
however, and may depart significantly from the norm due to variations in driving
habits, service practices and differences in road characteristics and climate.

■

Traction AA, A, B, C

The traction grades, from highest to lowest, are AA, A, B and C, and they represent
the tire’s ability to stop on wet pavement as measured under controlled conditions
on specified government test surfaces of asphalt and concrete.
A tire marked C may have poor traction performance.
Warning: The traction grade assigned to this tire is based on braking (straight
ahead) traction tests and does not include cornering (turning) traction.

■

Temperature A, B, C

The temperature grades are A (the highest), B, and C, representing the tire’s
resistance to the generation of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor laboratory test wheel.
Sustained high temperature can cause the material of the tire to degenerate and
reduce tire life, and excessive temperature can lead to sudden tire failure.
Grade C corresponds to a level of performance which all passenger car tires must
meet under the Federal Motor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory test
wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a tire that is
properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either separately or in com-
bination, can cause heat buildup and possible tire failure.

10-1. Specifications

774

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km
under that condition

Maximum inflation pressure

The maximum cold inflated pressure to
which a tire may be inflated, shown on the
sidewall of the tire

Recommended inflation pressure

Cold tire inflation pressure recommended
by a manufacturer

Accessory weight

The combined weight (in excess of those
standard items which may be replaced) of
transmission, power steering, power brakes,
power windows, power seats, radio and
heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)

Curb weight

The weight of a motor vehicle with standard
equipment, including the maximum capaci-
ty of fuel, oil and coolant, and if so equip-
ped, air conditioning and additional weight
optional engine

Maximum loaded vehicle weight

The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occu-
pants specified in the second column of
Table 1

(1)

that follows

Occupant distribution

Distribution of occupants in a vehicle as
specified in the third column of Table 1

(1)

below

10-1. Specifications

775

Vehicle specifications

Tire related term

Meaning

Production options weight

The combined weight of installed regular
production options weighing over 5 lb. (2.3
kg) in excess of the standard items which
they replace, not previously considered in
curb weight or accessory weight, including
heavy duty brakes, ride levelers, roof rack,
heavy duty 12-volt battery, and special trim

Rim

A metal support for a tire or a tire and
tube assembly upon which the tire beads
are seated

Rim diameter (Wheel diameter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer's designation for
a rim by style or code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight (Total load capaci-
ty)

The rated cargo and luggage load plus 150
lb. (68 kg) times the vehicle’s designated
seating capacity

Vehicle maximum load on the tire

The load on an individual tire that is deter-
mined by distributing to each axle its share
of the maximum loaded vehicle weight, and
dividing by two

Vehicle normal load on the tire

The load on an individual tire that is deter-
mined by distributing to each axle its share
of curb weight, accessory weight, and nor-
mal occupant weight (distributed in accord-
ance with Table 1

(1)

below), and dividing by

two

Weather side

The surface area of the rim not covered by
the inflated tire

Bead

The part of the tire that is made of steel
wires, wrapped or reinforced by ply cords
and that is shaped to fit the rim

Bead separation

A breakdown of the bond between compo-
nents in the bead

10-1. Specifications

776

Tire related term

Meaning

Bias ply tire

A pneumatic tire in which the ply cords that
extend to the beads are laid at alternate
angles substantially less than 90 degrees to
the centerline of the tread

Carcass

The tire structure, except tread and sidewall
rubber which, when inflated, bears the load

Chunking

The breaking away of pieces of the tread or
sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber
compounds

Cracking

Any parting within the tread, sidewall, or
innerliner of the tire extending to cord ma-
terial

A pneumatic tire with an inverted flange tire
and rim system in which the rim is designed
with rim flanges pointed radially inward and
the tire is designed to fit on the underside
of the rim in a manner that encloses the rim
flanges inside the air cavity of the tire

Extra load tire

A tire designed to operate at higher loads
and at higher inflation pressures than the
corresponding standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of
a tubeless tire that contains the inflating
medium within the tire

Innerliner separation

The parting of the innerliner from cord ma-
terial in the carcass

10-1. Specifications

777

Vehicle specifications

Tire related term

Meaning

Intended outboard sidewall

(a) The sidewall that contains a whitewall,
bears white lettering, or bears manufactur-
er, brand, and/or model name molding that
is higher or deeper than the same molding
on the other sidewall of the tire, or
(b) The outward facing sidewall of an asym-
metrical tire that has a particular side that
must always face outward when mounted
on a vehicle

Light truck (LT) tire

A tire designated by its manufacturer as
primarily intended for use on lightweight
trucks or multipurpose passenger vehicles

Load rating

The maximum load that a tire is rated to
carry for a given inflation pressure

Maximum load rating

The load rating for a tire at the maximum
permissible inflation pressure for that tire

Maximum permissible inflation pressure

The maximum cold inflation pressure to
which a tire may be inflated

Measuring rim

The rim on which a tire is fitted for physical
dimension requirements

Open splice

Any parting at any junction of tread, side-
wall, or innerliner that extends to cord ma-
terial

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors
of the sidewalls of an inflated tire, including
elevations due to labeling, decorations, or
protective bands or ribs

Passenger car tire

A tire intended for use on passenger
cars, multipurpose passenger vehicles, and
trucks, that have a gross vehicle weight rat-
ing (GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between
adjacent plies

10-1. Specifications

778

Tire related term

Meaning

Pneumatic tire

A mechanical device made of rubber,
chemicals, fabric and steel or other materi-
als, that, when mounted on an automotive
wheel, provides the traction and contains
the gas or fluid that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially
90 degrees to the centerline of the tread

Reinforced tire

A tire designed to operate at higher loads
and at higher inflation pressures than the
corresponding standard tire

Section width

The linear distance between the exteriors
of the sidewalls of an inflated tire, excluding
elevations due to labeling, decoration, or
protective bands

Sidewall

That portion of a tire between the tread and
bead

Sidewall separation

The parting of the rubber compound from
the cord material in the sidewall

Snow tire

A tire that attains a traction index equal
to or greater than 110, compared to the
ASTM E-1136 Standard Reference Test Tire,
when using the snow traction test as descri-
bed in ASTM F-1805-00, Standard Test
Method for Single Wheel Driving Traction
in a Straight Line on Snow-and Ice-Cov-
ered Surfaces, and which is marked with

an Alpine Symbol (

) on at least one

sidewall

Test rim

The rim on which a tire is fitted for testing,
and may be any rim listed as appropriate for
use with that tire

Tread

That portion of a tire that comes into con-
tact with the road

Tread rib

A tread section running circumferentially
around a tire

10-1. Specifications

779

Vehicle specifications

Tire related term

Meaning

Tread separation

Pulling away of the tread from the tire car-
cass

Treadwear indicators (TWI)

The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire
assembly securely during testing

(1)

Table 1—Occupant loading and distribution for vehicle normal load for various desig-

nated seating capacities

Designated seating capaci-
ty, Number of occupants

Vehicle normal load, Num-
ber of occupants

Occupant distribution in a
normally loaded vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second seat

11 through 15

2 in front, 1 in second seat, 1
in third seat, 1 in fourth seat

16 through 20

2 in front, 2 in second seat,
2 in third seat, 1 in fourth
seat

10-1. Specifications

780

Customizable features

User customization function outline

Your vehicle includes a variety of electronic features that can be personalized to
suit your preferences. The settings of these features can be changed using the
center display or at your Lexus dealer.

WARNING

As the hybrid system needs to be operating during customization, ensure that the vehicle
is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Possibly may leading to death or a serious health hazard.

NOTICE

While performing customization, make sure that the hybrid system is operating, in order
to prevent the 12-volt battery from becoming discharged.

10-2. Customizable features

781

Vehicle specifications

Method to change settings

Setting on the center display

Set by selecting

Stop the vehicle in a place where operations can be performed safely, engage the
parking brake, and change the shift position to P.

Select

on the center display.

Select [Vehicle customize] or [Driving assist].

Select the item to change the settings of from the list.

The setting of each items can be changed. For details, see the customizable items list.

For functions that can be turned on/off, select

(ON) /

(OFF)

Set by selecting

Select

on the center display.

Select [Driving assist].

Select the item to change the settings of from the list.

Each time the switch is selected, the setting will be enabled/disabled.
When enabling is selected, the item display will be emphasized.

10-2. Customizable features

782

Customizable features

Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.

Settings that can be changed using the center display

Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available, — = Not available

Gauges, meters and multi-information display

The language, units of measure, etc. of some items displayed on the meter or
multi-information display will be changed according to settings on the center
display. Refer to "MULTIMEDIA OWNER'S MANUAL".

Function

Default setting

Customized

setting

Meter display
type

(1)

Type 1

Type 2

—

Type 3

Tachometer set-
ting

Change ac-
cording to driv-
ing mode

Always tachom-
eter

—

Always Hybrid
System Indica-
tor

EV indicator

(1)

Off

—

Rev indicator

(2)

4000 rpm

2000 - 6000
rpm

—

Off

Rev peak

(2)

Off

—

Suggestion
function

(1)

On (when the
vehicle is stop-
ped)

(3)

Off

Rear seat re-
minder func-
tion

(1)

Off

—

(1)

This setting changes in accordance with My Settings

* :

If equipped

10-2. Customizable features

783

Vehicle specifications

(2)

F SPORT models

(3)

The setting can be changed on [Notifications] of

Head-up Display

Function

Default setting

Customized

setting

Display

(1)

Off

—

Display mode

(1)

Normal

Maximum

—

Minimum

(1)

This setting changes in accordance with My Settings

Steering wheel switches (vehicles with a head-up display)

Function

Default setting

Customized

setting

Right steering
wheel switch fa-
vorite func-
tions

(1)

Display control Custom

—

Left steering
wheel switch fa-
vorite func-
tions

(1)

Audio

Climate

—

Custom

Switch sensor
high sensitivity
mode (winter
glove mode)

(1)

Off

—

(1)

This setting changes in accordance with My Settings

* :

If equipped

10-2. Customizable features

784

Door lock

Function

Default setting

Customized

setting

Door lock
switch indicator
illumination time

30 seconds

60 seconds

—

600 seconds

1200 seconds

Inside door
opener switch
operation ad-
justment (door
opening func-
tion adjustment)

Short

Mid

—

Long

Multi-informa-
tion display/
buzzer opera-
tion when a
door opener
switch inside the
vehicle is oper-
ated

Off

—

Inside/outside
door opener
switch operat-
ing method

Unlatch while
pushing switch

0.6 Seconds

—

Operating from
inside the cabin:
0.6 Seconds
Operating from
outside:
Unlatch while
pushing switch

Operating from
inside the cabin:
Unlatch while
pushing switch
Operating from
outside:
0.6 Seconds

10-2. Customizable features

785

Vehicle specifications

Function

Default setting

Customized

setting

Unlocking using
a mechanical
key

Driver’s door
unlocked in one
step, all doors
unlocked in two
step

All doors un-
locked in one
step

—

Shift position
linked door
locking func-
tion

(1)

Off

Automatic door
unlocking func-
tion

(1)

Shift position
linked door un-
locking opera-
tion

Off

Driver’s door
linked door un-
locking opera-
tion

(2)

(1)

This setting changes in accordance with My Settings

(2)

All doors are automatically unlocked when driver’s door is opened within approxi-

mately 45 seconds after turning the power switch off.

Power back door

Function

Default setting

Customized

setting

Back door auto-
matic open and
stop position

Stop at the de-
sired position
(height)

(1)

—

1 to 5

Power back
door operations

Off

—

Operation buz-
zer volume

—

Kick Sensor

*(2)

Off

—

* :

If equipped

10-2. Customizable features

786

Function

Default setting

Customized

setting

Kick operation
buzzer

*(2)

Off

—

The function
that validates

the
switch of the
wireless remote
control when
locking the door

Off

—

Close & lock
(walk away)
function

Off

—

Hands free
close & lock
(walk away)
function

Off

—

(1)

Configured by operating the

switch of the lower back door.

(2)

When the towing hitch is installed, the kick sensor does not work

Smart access system with push-button start and wireless remote control

Function

Default setting

Customized

setting

Operation buz-
zer volume

(1)

Off

1 to 7

Operation sig-
nal (Emergency
flashers)

(1)

Off

Time elapsed
before automat-
ic door lock
function is acti-
vated if door is
not opened

60 seconds

Off

30 seconds

10-2. Customizable features

787

Vehicle specifications

Function

Default setting

Customized

setting

after being un-
locked

(1)

60 seconds

120 seconds

Open door
warning buzzer

Off

—

(1)

This setting changes in accordance with My Settings

Smart access system with push-button start

Function

Default setting

Customized

setting

Smart access
system with
push-button
start

Off

—

The doors that
are unlocked
using the smart
access system
with push-but-
ton start can be
selected

(1)

Driver’s door

All the doors

Number of con-
secutive door
lock operations

2 times

As many as de-
sired

—

Time elapsed
before unlock-
ing all the door
when gripping
and holding the
driver’s door
handle

2 seconds

Off

—

1.5 seconds

2.5 seconds

(1)

This setting changes in accordance with My Settings

* :

If equipped

10-2. Customizable features

788

Wireless remote control

Function

Default setting

Customized

setting

Unlocking op-
eration

(1)

Driver’s door
unlocked in one
step, all doors
unlocked in two
step

All doors un-
locked in one
step

Panic function

Off

—

Power back
door unlocking
operation

Press and hold
(short)

One short press

—

Push twice

Press and hold
(long)

Off

Locking opera-
tion when door
opened

(1)

Off

(1)

This setting changes in accordance with My Settings

Driving position memory

Function

Default setting

Customized

setting

Driver’s seat
movement
when exiting the
vehicle

(1)

Standard

Off

Partial

Steering wheel
movement

(1)

Tilt only

Telescopic only

—

Tilt and tele-
scopic

Off

(1)

This setting changes in accordance with My Settings

* :

If equipped

10-2. Customizable features

789

Vehicle specifications

Outside rear view mirrors

Function

Default setting

Customized

setting

Automatic mir-
ror folding and
extending oper-
ation

Linked to the
locking/unlock-
ing of the doors

Off

—

Linked to oper-
ation of the
power switch

Power windows and moon roof

Function

Default setting

Customized

setting

Mechanical key
linked operation

Off

—

Wireless re-
mote control
linked operation

Off

On (open only) —

Moon roof

Function

Default setting

Customized

setting

Linked opera-
tion of compo-
nents when me-
chanical key is
used (open on-
ly)

Slide only

Tilt only

—

Linked opera-
tion of compo-
nents when
wireless remote
control is used

Slide only

Tilt only

—

10-2. Customizable features

790

Lexus NX450H+ (2024 year). Manual in english - page 24
