5-3. Using the interior lights

Interio

r fe

atures

■

Turning the door position on

Press the door-linked interior light
switch

The lights are turned on and off according
to whether the doors are opened/closed.

■

Turning the lights on/off

Turns the lights on/off (touch the light)
The rear interior light turns on/off
together with the front interior light.

When a door is opened while the door
position is on, the lights turn on.

■

Turning the lights on/off



Front

Turns the lights on/off (touch the light)



Rear

Turns the lights on/off

■

Illuminated entry system

The lights automatically turn on/off accord-

ing to the power switch mode, the presence

of the electronic key, whether the doors are

locked/unlocked, and whether the doors

are open/closed.

■

To prevent the 12-volt battery from

being discharged

If the interior lights remain on when the

power switch is turned off, the lights will go

off automatically after 20 minutes.

■

When front interior light or front per-

sonal lights do not respond as normal

●

When water, dirt, etc., have adhered to

the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

■

The interior lights will turn on automati-

cally when

If any of the SRS airbags deploy (inflate) or

in the event of a strong rear impact, the

interior lights will turn on automatically.

Operating the interior lights

Operating the personal lights

278

5-3. Using the interior lights

The interior lights will turn off automatically

after approximately 20 minutes. The inte-

rior lights can be turned off manually. How-

ever, in order to help prevent further

collisions, it is recommended that they be

left on until safety can be ensured. (The inte-

rior lights may not turn on automatically

depending on the force of the impact and

conditions of the collision.)

■

Customization

Some functions can be customized. (Cus-

tomizable features:



P.417)

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

■

Removing light lenses

Never remove the lens for the front inte-

rior light and front personal lights. Other-

wise, the lights will be damaged. If a lens

needs to be removed, contact your

Lexus dealer.

279

5-4. Using the storage features

rio

r f

5-4.Using the storage features

Auxiliary boxes (



P.281)

Cup holders (



P.280)

Open tray (if equipped) (



P.281)/Wireless charger (if equipped) (

Console box (

Glove box (



P.280)

List of storage features

Location of the storage features

WARNING

■

Items that should not be left in the

vehicle

Do not leave glasses, lighters or spray

cans in the storage spaces, as this may

cause the following when cabin tempera-

ture becomes high:

●

Glasses may be deformed by heat or

cracked if they come into contact with

other stored items.

●

Lighters or spray cans may explode. If

they come into contact with other

stored items, the lighter may catch fire

or the spray can may release gas,

causing a fire hazard.

■

When storage compartments are not

in use

When driving or when the storage com-

partments are not in use, keep the lids

closed.

In the event of sudden braking or sudden

swerving, an accident may occur due to

an occupant being struck by an open lid

or the items stored inside.

280

5-4. Using the storage features

Open (press the glove box opener)

Unlock with the mechanical key

Lock with the mechanical key

■

Glove box light

The glove box light turns on when the tail

lights are on.

■

Trunk opener main switch



P.114

Press a button to open the console
box.

The console box can be opened from
either side.

■

Console box light

The console box light turns on when the tail

lights are on.



Front



Rear

To open, pull down the armrest and
open the lid.

Glove box

Console box

WARNING

■

Caution while driving

Keep the console box closed.

Injuries may result in the event of an acci-

dent or sudden braking.

NOTICE

■

To prevent damage to the console

box

When the console box is open, do not

apply excessive force in the direction

that it was opened.

Cup holders

281

5-4. Using the storage features

rio

r f



Instrument panel

Press in the button.



Front

■

Auxiliary box (front)

The insole for the auxiliary box can be

removed for cleaning.

WARNING

■

Items unsuitable for the cup holder

Do not place anything other than cups or

beverage cans in the cup holders. Even

when the lid is closed, items must not be

stored in the cup holders.

Other items may be thrown out of the

holder in the event of an accident or sud-

den braking, causing injury. If possible,

cover hot drinks to prevent burns.

NOTICE

■

To prevent damage to the cup holder

Stow the rear cup holder before stowing

the armrest.

Auxiliary boxes

Open tray (if equipped)

WARNING

■

Items unsuitable for the open tray

Observe the following precautions when

putting items in the open tray. Failure to

do so may cause items to be thrown out

of the tray in the event of sudden braking

or steering. In these cases, the items may

interfere with pedal operation or cause

driver distraction, resulting in an acci-

dent.

●

Do not store items in the tray that can

easily shift or roll out.

●

Do not stack items in the tray higher

than the tray’s edge.

●

Do not put items in the tray that may

protrude over the tray’s edge.

283

5-5. Using the other interior features

rio

r f

5-5.Using the other interior features

To set the visor in the forward posi-
tion, flip it down.

To set the visor in the side position,
flip down, unhook, and swing it to
the side.

To use the side extender, place the
visor in the side position, then slide
it backward.

Slide the cover to open.

The light turns on when the cover is
opened.

The GPS clock’s time is automatically
adjusted by utilizing GPS time infor-
mation.

For details, refer to the “MULTIMEDIA
OWNER’S MANUAL”.

Please use as a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).



Front

Open the lid.



Rear

Open the lid.

Other interior features

Sun visors

Vanity mirrors

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Clock

Power outlets

284

5-5. Using the other interior features

■

The power outlet can be used when

The power switch is in ACCESSORY or

ON mode.

■

When stopping the hybrid system

Disconnect electrical devices with charging

functions, such as mobile battery packs.

If such devices are left connected, the

hybrid system may not stop normally.

■

Using the power outlet

The shape of the console box partition

allows power cables to be passed through

when the console box lid is partially closed.

The USB Type-C charging ports are

used to supply 3 A of electricity at 5 V
to external devices.
The USB Type-C charging ports are
for charging only. They are not
designed for data transfer or other
purposes.
Depending on the external device, it
may not charge properly. Refer to the
manual included with the device
before using a USB Type-C charging
port.

■

Using the USB Type-C charging
ports



Front

Open the lid

To close, press in and release the lid.

NOTICE

■

When the power outlet is not in use

To avoid damaging the power outlet,

close the power outlet lid when the

power outlet is not in use. Foreign

objects or liquids that enter the power

outlet may cause a short circuit.

■

To prevent 12-volt battery discharge

Do not use the power outlet longer than

necessary when the hybrid system is off.

USB Type-C charging ports

285

5-5. Using the other interior features

rio

r f



Inside of console box



Rear

Open the lid.

■

The USB Type-C charging ports can be

used when

The power switch is in ACCESSORY or

ON mode.

■

Situations in which the USB Type-C

charging ports may not operate cor-

rectly

●

If a device which consumes more than 3

A at 5 V is connected

●

If a device designed to communicate with

a personal computer, such as a USB

memory device, is connected

●

If the connected external device is turned

off (depending on device)

●

If the temperature inside the vehicle is

high, such as after the vehicle has been

parked in the sun

■

About connected external devices

Depending on the connected external

device, charging may occasionally be sus-

pended and then start again. This is not a

malfunction.

A portable device can be charged by
just placing Qi standard wireless
charge compatible portable devices
according to the Wireless Power Con-
sortium, such as smartphones and
mobile batteries, etc., on the charge
area.

NOTICE

■

To prevent damage to the USB Type-

C charging ports

●

Do not insert foreign objects into the

ports.

●

Do not spill water or other liquids into

the ports.

●

Rear: When the USB Type-C

charging ports are not in use, close the

lids. If a foreign object or liquid enters a

port may cause a short circuit.

●

Do not apply excessive force to or

impact the USB Type-C charging

ports.

●

Do not disassemble or modify the USB

Type-C charging ports.

■

To prevent damage to external

devices

●

Do not leave external devices in the

vehicle. The temperature inside the

vehicle may become high, resulting in

damage to an external device.

●

Do not push down on or apply unnec-

essary force to an external device or

the cable of an external device while it

is connected.

■

To prevent 12-volt battery discharge

Do not use the USB Type-C charging

ports for a long period of time with the

hybrid system stopped.

Wireless charger (if equipped)

286

5-5. Using the other interior features

This function cannot be used with por-
table devices that are larger than the
charging tray. Also, depending on the
portable device, it may not operate as
normal. Please read the operation
manual for portable devices to be
used.

■

The “Qi” logo

The “Qi” logo is a trademark of the
Wireless Power Consortium.

■

Name for all parts

Operation indicator light

Charging tray

Charge area

Approximately 2.8 in. (7 cm)

Approximately 2.4 in. (6 cm)

: Portable devices and wireless chargers

contain charging coils.
The charging coil in the wireless charger
can be moved within the charge area
near the center of the charging tray. If

the charging coil inside a portable
device is detected in the charge area,
the charging coil inside the wireless
charger will move toward it and start
charging. If the charging coil inside a
portable device moves outside of the
charge area, charging will automatically
stop.
If 2 or more portable devices are placed
on the charging tray, their charging coils
may not be properly detected and they
may not be charged.

■

Using the wireless charger

Place the portable device on the
charging tray

Place the charging side of the portable
device down with the center of the device
in the center of the charge area.
Depending on the portable device, the
charging coil may not be located in the
center of the device. In this case, place the
portable device so that its charging coil is
in the center of the charge area.
When charging, the operation indicator
light (orange) comes on.
If charging is not occurring, try placing the
portable device as close to the center of
the charging area as possible.
When charging is complete, the operation
indicator light (green) comes on.

■

Recharging function



When charging is complete and

A
B
C
D

287

5-5. Using the other interior features

Interio

r fe

atures

after a fixed time in the charge sus-
pension state, charging restarts.



When a portable device is moved
significantly in the charge area, the
charging coil is disconnected and
charging is stopped momentarily.
However, if there is a charging coil
in the charge area, the charging coil
inside the wireless charger will
move toward it and then charging
restarts.

■

Rapid charging function



The following portable devices sup-
port rapid charging.

• Portable devices compliant with WPC

Ver1.2.4 and compatible with rapid
charging

• iPhone’s with an iOS version that sup-

ports 7.5 W charging (iPhone 8 and
later models)



When a portable device that sup-
ports rapid charging is charged,
charging automatically switches to
the rapid charging function.

■

Lighting conditions of operation indicator light

: Charging power will not be output during standby. A metallic object will not be heated,

if it is placed on the charging tray in this state.

: Depending on the portable device, there are cases where the operation indicator light

will continue being lit up orange even after the charging is complete.

■

When the wireless charger does not operate properly

When the wireless charger does not operate properly, handle the probable cause
based on the following tables.

Operation indicator light

Conditions

Charging tray side

Center display side

Turning off

Disappear

When the Wireless charger power supply is

off

Green (comes on)

Gray

On Standby (charging possible state)

When charging is complete

Orange (comes on)

Blue

When placing the portable device on the

charging area (detecting the portable device)

Charging

288

5-5. Using the other interior features

Operation indicator light

Suspected causes/Handling method

Charging tray side

Center Display side

Orange (flashing repeat-

edly once every second)

Gray

Vehicle to wireless charger commu-
nication failure



If the hybrid system is operating,
stop and then restart the hybrid
system.

If the power switch is in ACCES-
SORY, start the hybrid system.
(



P.148)

Green (flashing repeat-

edly once every second)

Disappear

Wireless charger and multimedia
system communication failure



If the hybrid system is operating,
stop and then restart the hybrid
system.

If the power switch is in ACCES-
SORY, start the hybrid system.
(



P.148)

Green (comes on)

Blue

AM radio stations are being auto-
matically selected



Wait until the system has com-
pleted the automatic selection of
AM radio stations. In the case
that automatic selection cannot
be completed, stop automatic
selection.

The smart access system with push-
button start is detecting the key.



Wait until key detection has com-
pleted.

Orange (repeatedly

flashes 3 times continu-

ously)

Gray

A metallic foreign substance is in the
charge area and charging has
stopped momentarily.



Remove the foreign substance
from the charge area.

289

5-5. Using the other interior features

Interio

r fe

atures

■

The wireless charger can be operated

when

The power switch is in ACCESSORY or

ON mode.

■

Usable portable devices

●

Qi standard wireless charge standard

can be used on compatible devices.

However, not all Qi standard devices and

compatibility are guaranteed.

●

Starting with mobile phones and smart-

phones, it is aimed for low power electri-

cally supplied portable devices of no

more than 5W.

●

However, charging exceeding 5 W is

supported by the following portable

devices.

• Charging at 7.5 W or less is supported

by iPhone’s that support 7.5 W charging.

• Charging at 10 W or less is supported by

portable devices compliant with EPP out-

put as defined by WPC standard

Ver1.2.4.

■

When covers and accessories are

attached to portable devices

Do not charge in situations where cover

and accessories not able to handle Qi are

attached to the portable device. Depending

on the type of cover (including for certain

genuine manufacturer parts) and acces-

sory, it may not be possible to charge.

When charging is not performed even with

the portable device placed on the charge

area, remove the cover and accessories.

■

AM radio cooperation function during

charging

●

When noise enters the AM radio during

charging, charging frequency will be

automatically changed to reduce noise.

●

During the AM radio automatic tuning,

charging is temporarily stopped in order

to prevent tuning error due to noise

Orange (repeatedly

flashes 3 times continu-

ously) or flashing

between green and

orange

Gray

The charging coil in the portable
device moved outside of the charge
area and charging has stopped
momentarily.



Remove the portable device
from the charging tray, check
that the operation indicator light
changes back to green, and then
place the portable device so that
it is near the center of the
charging tray. Also, if a case or
cover is installed to the portable
device, remove it.

Orange (repeatedly

flashes 4 times continu-

ously)

Gray

Safety shutdown resulting when the
temperature within the wireless
charger exceeded the set value



Stop charging, remove the porta-
ble device from the charging
tray, wait for the temperature to
drop, and then start charging
again.

Operation indicator light

Suspected causes/Handling method

Charging tray side

Center Display side

290

5-5. Using the other interior features

caused by charging. When tuning is fin-

ished, charging will be automatically

resumed.

■

Important points of the wireless charger

●

If the electronic key cannot be detected

within the vehicle interior, charging can-

not be done. When the door is opened

and closed, charging may be temporarily

suspended.

●

When charging, the wireless charging

device and portable device will get

warmer, however this is not a malfunc-

tion.

When a portable device gets warm while

charging, charging may stop due to the

protection function on the portable

device side. In this case, when the tem-

perature of the portable device drops

significantly, charge again.

The fan may start operating to lower the

temperature inside the wireless charger,

however this is not a malfunction.

■

Operation sounds

A buzzing noise may be heard when press-

ing the power switch to turn to ACCES-

SORY or ON mode or when detecting a

portable device. However, this is not a mal-

function.

WARNING

■

Caution while driving

When charging a portable device, for

safety reasons, the driver should not

operate the main part of the portable

device while driving.

■

Caution while in motion

Do not charge lightweight devices such

as wireless headphones while in motion.

These devices are very light and may be

ejected from the charging tray, which

may lead to unforeseen accidents.

■

Caution regarding interference with

electronic devices

People with implantable cardiac pace-

makers, cardiac resynchronization ther-

apy-pacemakers or implantable

cardioverters, as well as any other elec-

trical medical device, should consult their

physician about the usage of the wireless

charger.

■

To prevent malfunctions or burns

Observe the following precautions. Fail-

ure to do so may result in a equipment

failure and damage, catch fire, burns due

to overheat or electric shock.

●

Do not insert any metallic objects

between the charge area and the por-

table device while charging

●

Do not attach an aluminum sticker or

other metallic object to the charge

area

●

Do not attach an aluminum sticker or

other metallic object to the side of the

portable device (or to its case or

cover) that touches the charge area

●

Do not use the charging tray as a small

storage space

●

Do not subject to a strong force or

impact

●

Do not disassemble, modify or remove

●

Do not charge devices other than

specified portable devices

●

Keep away from magnetic items

●

Do not charge devices if the charge

area is covered in dust

●

Do not cover with a cloth or similar

material

NOTICE

■

Situations in which the function may

not operate normally

Devices may not be charged normally in

the following situations.

291

5-5. Using the other interior features

rio

r f

NOTICE

●

The portable device is fully charged

●

The portable device is being charged

with a cable connected

●

There is foreign matter between the

charge area and portable device

●

Charging has caused the portable

device to heat up

●

The temperature around the charging

tray is 95°F (35°C) or higher, such as

in extreme heat

●

The portable device is placed with its

charging side facing up

●

The portable device is placed in an

area misaligned from the charge area

●

The portable device is larger than the

charging tray

●

A foldable and portable device is

placed outside the charge area

●

The vehicle is in an area where strong

electrical waves or noise are emitted,

such as near a television tower, power

plant, gasoline station, broadcasting

station, large display, airport, etc.

●

When the camera of the portable

device largely protrudes

●

Any of the following objects that is

0.08 in (2 mm) or thicker is stuck or

installed between the charging side of

the portable device and the charge

area.

• Thick cases or covers

• A case that uses a magnet on the

charging side of the portable device

• A case or cover attached with an

uneven or tilted surface, so that the

charging side is not flat

• Thick decorations

• Accessories, such as finger rings,

straps, etc.

●

When the portable device is in contact

with, or is covered by any of the follow-

ing metallic objects:

• A card that has metal on it, such as alu-

minum foil, etc.

• A pack of cigarettes that includes alu-

minum foil

• A wallet or bag that is made of metal

• Coins

• A heating pad

• CDs, DVDs or other media

• A metal accessory

• A case or cover made of metal

●

Electric wave type wireless remote

controls are being used nearby

●

When the electronic key is taken out-

side the vehicle

●

2 or more portable devices are placed

on the charging tray at the same time

If charging is abnormal or the operation

indicator light continues to flash for any

other reason, the wireless charger may

be malfunctioning. Contact your Lexus

dealer.

■

To prevent malfunctions and data

corruptions

●

When charging, bringing a credit, or

other magnetic card, or magnetic stor-

age media close to the charge area

may clear any stored data due to mag-

netic influence. Also, do not bring a

wristwatch or other precision instru-

ment close to the charge area since

doing so may cause it to malfunction.

292

5-5. Using the other interior features

Fold down the armrest for use.

An assist grip installed on the ceiling
can be used to support your body
while sitting on the seat.

■

Rear sunshade

The rear sunshade can be raised and
lowered by operating the button
shown below.
Press the switch. (Raise/lower)

NOTICE

●

Do not charge with a non-contact IC

card such as a transportation system

IC card inserted between the charging

side of a portable device and the

charge area. The IC chip may become

extremely hot and damage the porta-

ble device or IC card. Be especially

careful not to charge a portable device

inside a case or cover with a non-con-

tact IC card attached.

●

Do not leave portable devices inside

the vehicle. The inside of the vehicle

can become hot in extreme heat,

which could cause a malfunction.

■

If the smartphone OS has been

updated

If the smartphone OS has been updated

to a newer version, its charging specifi-

cations may have changed significantly.

For details, check the information on the

manufacturer’s website.

■

To prevent 12-volt battery discharge

Do not use the wireless charger for a

long period of time when the hybrid sys-

tem is stopped.

Armrest

NOTICE

■

To prevent damage to the armrest

Do not apply too much load on the arm-

rest.

Assist grips

WARNING

■

Assist grips

Do not use the assist grip when getting in

or out of the vehicle or rising from your

seat.

NOTICE

■

To prevent damage to the assist grip

Do not hang any heavy object or put a

heavy load on the assist grip.

Rear sunshade (if
equipped)/rear door sunshades
(if equipped)

293

5-5. Using the other interior features

rio

r f

■

Rear door sunshades

Pull the tab of the rear door sunshade
and hook the sunshade on the anchors.

To retract the rear door sunshade, unhook
the sunshade and retract it slowly.

■

The rear sunshade can be used when

●

The power switch is in ON mode.

●

The rear sunshade can be operated for

approximately 1 minute even after the

power switch is turned to ACCESSORY

mode or turned off.

■

Reverse operation feature

To ensure adequate rear visibility, the rear

sunshade automatically lowers when the

shift lever is shifted to R.
However, the rear sunshade is raised again

if any of the following occurs:

●

The button is pressed again.

●

Shift the shift lever to P.

●

The shift lever is shifted out of R, and the

vehicle reaches a speed of 9 mph (15

km/h).

If the hybrid system is turned off after the

rear sunshade was lowered due to the

reverse operation feature, it will not be

raised even when the hybrid system is

turned on again and the vehicle reaches a

speed of 9 mph (15 km/h). To raise the

sunshade again, press the button.

: Occasionally, the reverse function may

not be carried out after the switch has
been pressed. Repeat the above opera-
tion to operate the function.

WARNING

■

When the rear sunshade is being

raised or lowered

When the rear sunshade is being oper-

ated, do not place fingers or other

objects in the fastener section or in the

opening. They may get caught, causing

injury.

NOTICE

■

To prevent 12-volt battery discharge

Do not operate the rear sunshade when

the hybrid system is not operating.

■

To ensure normal operation of the

sunshades

●

Do not operate the rear sunshade

when any objects are on top of its

opening/closing part.

The rear sunshade may not operate

properly.

294

5-5. Using the other interior features

Long objects can be loaded into the
vehicle by utilizing the trunk space and
rear seat area.

Fold down the armrest.

Fold down the handle and open the
armrest door.

The armrest door can be locked and
unlocked using the mechanical key.

Unlock

Lock

The coat hooks are provided with the
rear assist grips.

NOTICE

●

To ensure normal operation of the rear

sunshade and rear door sunshades,

observe the following precautions:

• Do not place excessive load on the

motor or other components of the rear

sunshade.

• Do not attach items to the rear sun-

shade and rear door sunshades.

• Keep the opening clean and clear of

obstructions.

• Do not operate the rear sunshade

continuously for long periods of time.

Trunk storage extension

WARNING

■

When not in use

Ensure that the armrest door is closed. In

the event of sudden braking, items stored

in the trunk may be thrown forward into

the cabin, resulting in injury.

Coat hooks

WARNING

■

Items that should not be hanged

Do not hang coat hangers or other hard

or sharp objects on the hook. If the SRS

curtain shield airbags deploy, these items

may become projectiles, causing death

or serious injury.

295

5-5. Using the other interior features

rio

r f

■

HomeLink

programming procedure

The programming procedures can also be

found at the following URL.

Website: www.homelink.com/lexus

For support, contact customer support at

the following.
Help Line: 1-800-355-3515

The HomeLink

wireless control sys-

tem in your vehicle has 3 buttons
which can be programmed to operate
3 different devices. Refer to the pro-
gramming methods on the following
pages to determine the method which
is appropriate for the device.

HomeLink

indicator light

Garage door operation indicators

HomeLink

icon

Illuminates while HomeLink

is operating.

Buttons

■

Codes stored in the HomeLink

mem-

ory

●

The registered codes are not erased

even if the 12-volt battery cable is discon-

nected.

●

If learning failed when registering a dif-
ferent code to a HomeLink

button that

already has a code registered to it, the

already registered code will not be

erased.

Garage door opener

The garage door opener can be
programmed using the
HomeLink

to operate garage

doors, gates, entry doors, door
locks, home lighting systems, secu-
rity systems, and other devices.

System components

WARNING

■

When programming a garage door

or other remote control device

The garage door or other device may

operate, so ensure people and objects

are out of danger to prevent potential

harm.

296

5-5. Using the other interior features

■

Before programming HomeLink



During programming, it is possible
that garage doors, gates, or other
devices may operate. For this rea-
son, make sure that people and
objects are clear of the garage door
or other devices to prevent injury or
other potential harm.



It is recommended that a new bat-
tery be placed in the remote control
transmitter for more accurate pro-
gramming.



Garage door opener motors manu-
factured after 1995 may be
equipped with rolling code protec-
tion. If this is the case, you may need
a stepladder or other sturdy, safe
device to reach the “Learn” or
“Smart” button on the garage door
opener motor.

■

Programming HomeLink

Steps

through

must be performed

within 60 seconds, otherwise the indi-
cator light will stop flashing and pro-
gramming will not be able to be
completed.

Press and release the HomeLink

button you want to program and
check that the HomeLink

indica-

tor light flashes (orange).

Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink

buttons.

Keep the HomeLink

indicator light in

view while programming.

Program a device.



Programming a device other than
an entry gate (for U.S.A. owners)

Press and hold the remote control
transmitter button until the

WARNING

■

Conforming to federal safety stan-

dards

Do not use the HomeLink

compatible

transceiver with any garage door opener

or device that lacks safety stop and

reverse features as required by federal

safety standards.
This includes any garage door that can-

not detect an interfering object. A door

or device without these features

increases the risk of death or serious

injury.

■

When operating or programming
HomeLink

Never allow a child to operate or play
with the HomeLink

buttons.

Programming the HomeLink

297

5-5. Using the other interior features

Interio

r fe

atures

HomeLink

indicator light changes

from slowly flashing orange to rapidly
flashing green (rolling code) or contin-
uously lit green (fixed code), then
release the button.



Programming an entry gate (for
U.S.A. owners)/Programming a
device in the Canadian market

Press and release the remote control
transmitter button at 2 second inter-
vals, repeatedly, until the HomeLink

indicator light changes from slowly
flashing (orange) to rapidly flashing
(green) (rolling code) or continuously
lit (green) (fixed code).

Test the HomeLink

operation by

pressing the newly programmed
button and observing the indicator
light:



Indicator light illuminates: Program-
ming of a fixed code device has
completed. The garage door or
other device should operate when a
HomeLink

button is pressed and

released.



Indicator light flashes rapidly: The
garage door opener motor or other
device is equipped with a rolling
code. To complete programming,
firmly press and hold the
HomeLink

button for 2 seconds

then release it.



If the garage door or other device
does not operate, proceed to “Pro-
gramming a rolling code system”.

Repeat the steps above to program
another device for any of the
remaining HomeLink

buttons.

■

Programming a rolling code sys-
tem

2 or more people may be necessary to
complete rolling code programming.

Locate the “Learn” or “Smart” but-
ton on the garage door opener
motor in the garage.

This button can usually be found where the

hanging antenna wire is attached to the

unit. The name and color of the button may

vary by manufacturer. Refer to the owner’s

manual supplied with the garage door

opener motor for details.

Press and release the “Learn” or
“Smart” button.

Perform

within 30 seconds after per-

forming

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and release

298

5-5. Using the other interior features

it. Repeat this sequence
(press/hold/release) up to 3 times
to complete programming.
If the garage door opener motor
operates when the HomeLink

button is pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communication
with a garage door (only available
for compatible devices)

When enabled, 2-way communication
allows you to check the status of the
opening and closing of a garage door
through indicators in your vehicle.
2-way communication is only available
if the garage door opener motor used
is a compatible device. (To check
device compatibility, refer to
www.homelink.com.)

Within 5 seconds after program-
ming the garage door opener has
been completed, if the garage door
opener motor is trained to
HomeLink

, both garage door

operation indicators will flash rap-
idly (green) and the light on the
garage door opener motor will
blink twice, indicating that 2-way
communication is enabled.

If the indicators do not flash, perform

and

within the first 10 presses of the

HomeLink

button after programming

has been completed.

Press a programmed HomeLink

button to operate a garage door.

Within 1 minute of pressing the
HomeLink

button, after the

garage door operation has
stopped, press the “Learn” or
“Smart” button on the garage door
opener motor. Within 5 seconds of
the establishment of 2-way com-
munication with the garage door
opener, both garage door opera-
tion indicators in the vehicle will
flash rapidly (green) and the light
on the garage door opener motor
will blink twice, indicating that 2-
way communication is enabled.

■

Reprogramming a single
HomeLink

button

When the following procedure is per-
formed, buttons which already have
devices registered to them can be
overwritten:

With one hand, press and hold the
desired HomeLink

button.

When the HomeLink

indicator

starts flashing (orange), continue to
hold the HomeLink

button and

perform “Programming
HomeLink

”

(it takes 20 sec-

onds for the HomeLink

indicator

to start flashing).

■

Before programming

●

Install a new battery in the transmitter.

299

5-5. Using the other interior features

Interio

r fe

atures

●

The battery side of the transmitter must
be pointed away from the HomeLink

Press the appropriate HomeLink

button. The HomeLink

indicator light

should turn on.
The status of the opening and closing
of a garage door is shown by the indi-
cators.

Opening

Closing

This function is only available if the garage
door opener motor used is a compatible
device. (To check device compatibility,
refer to www.homelink.com.)

The indicators can operate within
approximately 820 ft. (250 m) of the
garage door. However, if there are
obstructions between the garage door
and the vehicle, such as houses and

trees, feedback signals from the
garage door may not be received.
To recall the previous door operation
status, press and release either

HomeLink

buttons

and

simulta-

neously. The last recorded status will
be displayed for 3 seconds.

Press and hold the 2 outside buttons
for 10 seconds until the HomeLink

indicator light changes from continu-
ously lit (orange) to rapidly flashing
(green).

If you sell your vehicle, be sure to erase the
programs stored in the HomeLink

mem-

ory.

Operating HomeLink

Color

Status

Orange (flashing)

Currently open-

ing/closing

Green

Opening/closing

has completed

Red (flashing)

Feedback signals

cannot be received

A
B

Erasing the entire HomeLink

memory (all three codes)

300

5-5. Using the other interior features

: If equipped

To turn the compass on or off, press
and hold the button for more than 3
seconds.

Directions are displayed as follows:

■

Conditions unfavorable to correct

operation

The compass may not show the correct

direction in the following conditions:

●

The vehicle is stopped immediately after

turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth’s

magnetic field is subject to interference

by artificial magnetic fields (underground

car park/parking lot, under a steel tower,

between buildings, roof car park/parking

lot, near an intersection, near a large

vehicle, etc.).

●

The vehicle has become magnetized.

(There is a magnet or metal object near

the inside rear view mirror.)

●

The 12-volt battery has been discon-

nected.

●

A door is open.

Compass

The compass on the inside rear
view mirror indicates the direction
in which the vehicle is heading.

Operation and displays

Display

Direction

“N”

North

“NE”

Northeast

“E”

East

“SE”

Southeast

“S”

South

“SW”

Southwest

“W”

West

“NW”

Northwest

WARNING

■

While driving the vehicle

Do not adjust the display. Adjust the dis-

play only when the vehicle is stopped.

NOTICE

■

To avoid the compass malfunctions

Do not place magnets or any metal

objects near the inside rear view mirror.

Doing this may cause the compass sen-

sor to malfunction.

■

To ensure normal operation of the

compass

●

Do not perform a circling calibration

of the compass in a place where the

earth’s magnetic field is subject to

interference by artificial magnetic

fields.

●

During calibration, do not operate

electric systems (moon roof, power

windows, etc.) as they may interfere

with the calibration.

301

5-5. Using the other interior features

Interio

r fe

atures

■

Deviation

The direction display deviates from the
true direction determined by the
earth’s magnetic field. The amount of
deviation varies depending on the geo-
graphic position of the vehicle.

If you cross over one of the map boundar-
ies shown in illustration, the compass will
deviate.
To obtain higher precision or perfect cali-
bration, refer to “Deviation calibration”.

■

Deviation calibration

Stop the vehicle.

Press and hold the button for 6 sec-
onds. A number (1 to 15) appears
on the compass display.

Referring to the map above, press
the button to select the number of
the zone you are in.

If the direction is displayed several seconds

after adjustment, the calibration is com-

plete.

■

Circling calibration

Stop the vehicle in a place where it
is safe to drive in a circle.

Press and hold the button for 9 sec-
onds.

“C” appears on the compass display.

Drive the vehicle at 5 mph (8
km/h) or less in a circle until a
direction is displayed.

Calibrating the compass

303

Mai
nte

e a

are

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting the vehi-

cle exterior................................

304

Cleaning and protecting the vehi-

cle interior .................................

307

6-2. Maintenance

Maintenance requirements ...

310

General maintenance...............

311

Emission inspection and mainte-

nance (I/M) programs ..........

314

6-3. Do-it-yourself maintenance

Do-it-yourself service precau-

tions...............................................

315

Hood................................................

317

Positioning a floor jack.............

317

Engine compartment................

319

12-volt battery.............................

325

Tires ................................................

327

Tire inflation pressure..............

335

Wheels...........................................

337

Air conditioning filter...............

338

Cleaning the hybrid battery (trac-

tion battery) air intake vent and
filter ..............................................

340

Electronic key battery.............

343

Checking and replacing fuses

........................................................

345

Headlight aim..............................

347

Light bulbs....................................

349

304

6-1. Maintenance and care

6-1.Maintenance and care



Working from top to bottom, liber-
ally apply water to the vehicle body,
wheel wells and underside of the
vehicle to remove any dirt and dust.



Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.



For hard-to-remove marks, use car
wash soap and rinse thoroughly with
water.



Wipe away any water.



Wax the vehicle when the water-
proof coating deteriorates.

If water does not bead on a clean surface,
apply wax when the vehicle body is cool.

■

Self-restoring coat

The vehicle body has a self-restoring coat-

ing that is resistant to small surface

scratches caused in a car wash etc.

●

The coating lasts for 5 to 8 years from

when the vehicle is delivered from the

plant.

●

The restoration time differs depending on

the depth of the scratch and outside tem-

perature.

The restoration time may become

shorter when the coating is warmed by

applying warm water.

●

Deep scratches caused by keys, coins,

etc. cannot be restored.

●

Do not use wax that contain abrasives.

■

Automatic car washes

●

Before washing the vehicle:

• Fold the mirrors

• Turn off the power trunk lid (if equipped)
Start washing from the front of the vehicle.
Make sure to extend the mirrors before
driving.

●

Brushes used in automatic car washes

may scratch the vehicle surface, parts

(wheel, etc.) and harm your vehicle’s

paint.

●

Rear spoiler may not be washable in

some automatic car washes. There may

also be an increased risk of damage to

vehicle.

■

High pressure car washes

As water may enter the cabin, do not bring

the nozzle tip near the gaps around the

doors or perimeter of windows, or spray

these areas continuously.

■

Notes for the smart access system with

push-button start

If the door handle becomes wet while the

electronic key is within the effective range,

the door may lock and unlock repeatedly. In

that case, follow the following correction

procedures to wash the vehicle:

●

Place the key in a position 6 ft. (2 m) or

more separate from the vehicle while the

vehicle is being washed. (Take care to

ensure that the key is not stolen.)

●

Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



P.117)

■

Wheels and wheel ornaments

●

Remove any dirt immediately by using a

neutral detergent.

●

Wash detergent off with water immedi-

ately after use.

●

To protect the paint from damage, make

sure to observe the following precau-

tions.

• Do not use acidic, alkaline or abrasive

detergent

• Do not use hard brushes

• Do not use detergent on the wheels

when they are hot, such as after driving or

Cleaning and protecting the
vehicle exterior

Perform cleaning in a manner
appropriate to each component
and its material.

Cleaning instructions

305

6-1. Maintenance and care

Mai
nte

e a

are

parking in hot weather

■

Brake pads and calipers

Rust may form if the vehicle is parked with

wet brake pads or disc rotors, causing them

to stick. Before parking the vehicle after it is

washed, drive slowly and apply the brakes

several times to dry the parts.

■

Bumpers

Do not scrub with abrasive cleaners.

■

Front side windows water-repellent

coating

The following precautions can extend the

effectiveness of the water-repellent coat-

ing.

●

Remove any dirt, etc. from the front side

windows regularly.

●

Do not allow dirt and dust to accumulate

on the windows for a long period.

Clean the windows with a soft, damp

cloth as soon as possible.

●

Do not use wax or glass cleaners that

contain abrasives when cleaning the win-

dows.

●

Do not use any metallic objects to

remove condensation build up.

■

Plated portions

If dirt cannot be removed, clean the parts as

follows:

●

Use a soft cloth dampened with an

approximately 5% solution of neutral

detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to

remove any remaining moisture.

●

To remove oily deposits, use alcohol wet

wipes or a similar product.

WARNING

■

When washing the vehicle

Do not apply water to the inside of the

engine compartment. Doing so may

cause the electrical components etc. to

catch fire.

■

When cleaning the windshield (vehi-

cles with rain-sensing windshield wip-

ers)

Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wip-

ers may operate unexpectedly in the fol-

lowing situations, and may result in hands

being caught or other serious injuries

and cause damage to the wiper blades.

Off

AUTO

●

When the upper part of the windshield

where the raindrop sensor is located is

touched by hand

●

When a wet rag or similar is held close

to the raindrop sensor

●

If something bumps against the wind-

shield

●

If you directly touch the raindrop sen-

sor body or if something bumps into

the raindrop sensor

■

Precautions regarding the exhaust

pipes

As exhaust gases cause the exhaust

pipes to become quite hot, do not touch

the exhaust pipes while the hybrid system

is operating or immediately after the

hybrid system is turned off.
When washing the vehicle, be careful not

to touch the exhaust pipes until they have

cooled sufficiently, as touching hot

exhaust pipes can cause burns.

306

6-1. Maintenance and care

WARNING

■

Precaution regarding the rear

bumper with Blind Spot Monitor

If the paint of the rear bumper is chipped

or scratched, the system may malfunc-

tion. If this occurs, consult your Lexus

dealer.

NOTICE

■

To prevent paint deterioration and

corrosion on the body and compo-

nents (aluminum wheels etc.)

●

Wash the vehicle immediately in the

following cases:

• After driving near the sea coast
• After driving on salted roads
• If coal tar, pollen or tree sap is present

on the paint surface

• If dead insects, insect droppings or

bird droppings are present on the

paint surface

• After driving in an area contaminated

with soot, oily smoke, mine dust, iron

powder or chemical substances

• If the vehicle becomes heavily soiled

with dust or mud

• If liquids such as benzene and gasoline

are spilled on the paint surface

●

If the paint is chipped or scratched,

have it repaired immediately.

●

To prevent the wheels from corroding,

remove any dirt and store in a place

with low humidity when storing the

wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic

substances or scrub with a hard brush.

This may damage the surfaces of the

lights.

●

Do not apply wax to the surfaces of the

lights.

Wax may cause damage to the lenses.

■

When using an automatic car wash

(vehicles with rain-sensing windshield

wipers)

Set the wiper switch to the off position.
If the wiper switch is in “AUTO”, the wip-

ers may operate and the wiper blades

may be damaged.

■

When using a high pressure car wash

●

When washing the vehicle, do not

spray the camera or its surrounding

area directly with a high pressure

washer. Shock applied from high pres-

sure water may cause the device to not

operate normally.

●

Do not spray water directly on the

radar which is equipped behind the

emblem. Otherwise it may cause the

device to be damaged.

●

Do not bring the nozzle tip close to

boots (rubber or resin manufactured

cover), connectors or the following

parts. The parts may be damaged if

they come into contact with high-pres-

sure water.

• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

●

Keep the cleaning nozzle at least 11.9

in. (30 cm) away from the vehicle

body. Otherwise resin section, such as

moldings and bumpers, may be

deformed and damaged. Also, do not

continuously hold the nozzle in the

same place.

●

Do not spray the lower part of the

windshield continuously.

If water enters the air conditioning sys-

tem intake located near the lower part

of the windshield, the air conditioning

system may not operate correctly.

●

Do not wash the underside of the vehi-

cle using a high pressure car washer.

307

6-1. Maintenance and care

Mai
nte

e a

are



Remove dirt and dust using a vac-
uum cleaner. Wipe dirty surfaces
with a cloth dampened with luke-
warm water.



If dirt cannot be removed, wipe it off
with a soft cloth dampened with
neutral detergent diluted to approx-
imately 1%.
Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.

■

Shampooing the carpets

There are several commercial foaming-

type cleaners available. Use a sponge or

brush to apply the foam. Rub in overlapping

circles. Do not use water. Wipe dirty sur-

faces and let them dry. Excellent results are

obtained by keeping the carpet as dry as

possible.

■

Handling the seat belts

Clean with mild soap and lukewarm water

using a cloth or sponge. Also check the

belts periodically for excessive wear, fray-

ing or cuts.

■

When cleaning the carpeted portions of

the glove box, console box, etc.

If a strong adhesive tape is used, there is a

possibility that the surface of the carpet

could be damaged.

Cleaning and protecting the
vehicle interior

Perform cleaning in a manner
appropriate to each component
and its material.

Protecting the vehicle interior

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehi-

cle, such as on the floor, on the rear

seats, in the hybrid battery (traction

battery) air vents, and in the trunk.

(



P.64)

Doing so may cause the hybrid bat-

tery, electrical components, etc. to

malfunction or catch fire.

●

Do not get any of the SRS components

or wiring in the vehicle interior wet.

(



P.28)

An electrical malfunction may cause

the airbags to deploy or not function

properly, resulting in death or serious

injury.

●

Vehicles with wireless charger: Do not

let the wireless charger (



P.285) get

wet. Failure to do so may cause the

charger to become hot and cause

burns or could cause electric shock

resulting in death or serious injury.

■

Cleaning the interior (especially

instrument panel)

Do not use polish wax or polish cleaner.

The instrument panel may reflect off the

windshield, obstructing the driver’s view

and leading to an accident, resulting in

death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of

detergent, as they may discolor the

vehicle interior or cause streaks or

damage to painted surfaces:

• Non-seat portions: Organic sub-

stances such as benzene or gasoline,

alkaline or acidic solutions, dye, and

bleach

• Seats: Alkaline or acidic solutions,

such as thinner, benzene, and alcohol

308

6-1. Maintenance and care



Remove dirt using a water-damp-
ened soft cloth or synthetic chamois.



Wipe the surface with a dry soft
cloth to remove any remaining
moisture.

■

Cleaning the areas with satin-finish

metal accents

The metal areas use a layer of real metal for

the surface. It is necessary to clean them

regularly. If dirty areas are left uncleaned

for long periods of time, they may be diffi-

cult to clean.



Remove dirt and dust using a vac-
uum cleaner.



Wipe off any excess dirt and dust
with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approxi-
mately 5% neutral wool detergent.



Wring out any excess water from
the cloth and thoroughly wipe off all
remaining traces of detergent.



Wipe the surface with a dry soft
cloth to remove any remaining
moisture. Allow the leather to dry in
a shaded and ventilated area.

■

Caring for leather areas

Lexus recommends cleaning the interior of

the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.

NOTICE

●

Do not use polish wax or polish

cleaner. The instrument panel’s or

other interior part’s painted surface

may be damaged.

■

Preventing damage to leather sur-

faces

Observe the following precautions to

avoid damage to and deterioration of

leather surfaces:

●

Remove any dust or dirt from leather

surfaces immediately.

●

Do not expose the vehicle to direct

sunlight for extended periods of time.

Park the vehicle in the shade, espe-

cially during summer.

●

Do not place items made of vinyl, plas-

tic, or containing wax on the uphol-

stery, as they may stick to the leather

surface if the vehicle interior heats up

significantly.

■

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio sys-

tem may be damaged if water comes into

contact with electrical components such

as the audio system above or under the

floor of the vehicle. Water may also

cause the body to rust.

■

When cleaning the inside of the wind-

shield

Do not allow glass cleaner to contact the

lens. Also, do not touch the lens.

(



P.177)

■

Cleaning the inside of the rear win-

dow

●

Do not use glass cleaner to clean the

rear window, as this may cause dam-

age to the rear window defogger

heater wires or antenna. Use a cloth

dampened with lukewarm water to

gently wipe the window clean. Wipe

the window in strokes running parallel

to the heater wires or antenna.

●

Be careful not to scratch or damage

the heater wires or antenna.

Cleaning the areas with satin-
finish metal accents

Cleaning the leather areas

Lexus ES300H (2023 year). Manual in english - page 9
