Lexus RX500h (2023 year). Manual in english

601

8-2. Customization

Vehi

cle

spec

ifi

tions

■

RCD (Rear Camera Detection) function

(



P.342)

: If equipped

■

PKSB (Parking Support Brake)

(



P.345)

: If equipped

: This setting changes in accordance with My Settings

■

Lexus Teammate Advanced Park

*1, 2

(



P.356)

Function

Default setting

Customized setting

RCD (Rear Camera Detec-
tion) function

Off

—

Function

Default setting

Customized setting

PKSB (Parking Support Brake)
function

Off

—

Function

Default setting

Customized setting

Remote Park

Off

—

Vehicle speed during opera-
tion

Normal

Slow

—

Fast

Distance to objects

Normal

Far

—

Preferred parking method

Parallel

Perpendicular

—

Preferred parking direction

Forward

Reverse

—

Preferred exit direction (per-
pendicular)

Right

Left

—

Preferred exit direction (paral-
lel)

Left

Right

—

Camera view when parking

Normal

Wide

—

Camera view when exiting

Wide

Normal

—

Parking path adjustment

0 (Centered)

-3 (Inward) to 3

(Outward)

—

Road width adjustment

Normal

Slightly narrow

—

Narrow

602

8-2. Customization

: If equipped

: This settings can be changed on the Advanced Park guidance screen. (



P.365)

■

Safe Exit Assist (



P.323)

: This setting changes in accordance with My Settings

■

ASC (Active Sound Control) (RX500h) (



P.231)

■

Driving mode select switch (



P.390)

Park position adjustment (for-
ward)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

—

Park position adjustment
(reverse)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

—

Rear accessory setting

Off

3.9 in. (10 cm)

—

7.9 in. (20 cm)

11.8 in. (30 cm)

15.7 in. (40 cm)

Clear registered parking space

—

Function

Default setting

Customized setting

Safe Exit Assist

Off

—

Outside rear view mirrors dis-
play

Off

—

Detection sensitivity

Middle

High

—

Low

Function

Default setting

Customized setting

ASC (Active Sound Control)
volume

Medium

High

—

Low

Off

Function

Default setting

Customized setting

Powertrain control in custom-
ized mode

Normal

Power

—

Eco

Function

Default setting

Customized setting

603

8-2. Customization

Vehi

cle

spec

ifi

tions

: If equipped

■

Power switch (



P.208)

■

Rear seat reminder (



P.121)

: This setting changes in accordance with My Settings

■

Front automatic air conditioning system (



P.411)

: This setting changes in accordance with My Settings

: If equipped

Steering control in customized
mode

Normal

Sport

—

Suspention control in custom-
ized mode

Normal

Sport

—

Air conditioning operation in
customized mode

Normal

Eco

—

Function

Customized setting

ACC customization
Enabling/Disabling ACC
mode

On/Off

Function

Default setting

Customized setting

Rear seat reminder function

Off

—

Function

Default setting

Customized setting

Switching between outside air
and recirculated air mode
linked to “AUTO” switch opera-
tion

Off

A/C auto switch operation

Off

Exhaust gas sensor sensitivity

*1,

Standard

-3 to 3

Off

Function

Default setting

Customized setting

604

8-2. Customization

■

Seat heaters/seat ventilators

(



P.422)

: If equipped

: This setting changes in accordance with My Settings

■

Heated steering wheel

(



P.422)

: If equipped

: This setting changes in accordance with My Settings

■

Illumination (



P.424)

Function

Default setting

Customized setting

Driver’s seat temperature pref-
erence in automatic mode

Standard

-2 (cooler) to 2

(warmer)

Front passenger’s seat tem-
perature preference in auto-
matic mode

Standard

-2 (cooler) to 2

(warmer)

Function

Default setting

Customized setting

Steering wheel heating prefer-
ence in automatic mode

Standard

-2 (low) to 2 (high)

Function

Default setting

Customized setting

Time elapsed before the inte-
rior lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation after the power
switch is turned off

Off

—

Operation when you approach
the vehicle with the electronic
key on your person

Off

—

Operation when the doors are
unlocked

Off

—

Footwell lights

Off

—

Door-trim ornament lights

inside handle lights and front
tray light

Off

—

605

8-2. Customization

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings

: If equipped

■

Vehicle customization

●

When the doors remain closed after

unlocking the doors and the timer acti-

vated automatic door lock function acti-

vates, signals will be generated in

accordance with the operation buzzer

volume and operational signal (Emer-

gency flashers) function settings.

Time elapsed before the outer
foot lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation of the outer foot
lights when you approach the
vehicle with the electronic key
on your person

Off

—

Operation of the outer foot
lights when the doors are
unlocked

Off

—

Operation of the outer foot
lights when a door is opened

Off

—

Fading out of the outer foot
lights when they turn off

Long

Short

—

Operation of interior lights and
outer foot lights after the doors
are locked

Off

—

Color selection

*1, 2

Silky white

Custom

—

Brightness control

9 to 1

—

Off

Function

Default setting

Customized setting

606

8-3. Initialization

8-3.Initialization

Items to initialize

The following items must be initialized for normal system operation after such
cases as the 12-volt battery being reconnected, or maintenance being per-
formed on the vehicle:

List of items to initialize

Item

When to initialize

Reference

Message indicating
maintenance is
required (U.S.A. only)

• After the maintenance is performed

P.464

Tire pressure warning
system

• When the specified tire inflation pres-

sure has changed, such as due to car-
ried load, etc.

• When the tire inflation pressure is

changed such as when the tire size is
changed.

P.488

Oil maintenance

• After the maintenance is performed

P.476

Power back door

• After reconnecting or changing the

12-volt battery

P.134

607

For owners

9-1. For owners

Reporting safety defects for U.S.

owners ........................................

608

Reporting safety defects for

Canadian owners...................

608

Seat belt instructions for Cana-

dian owners (in French).......

609

SRS airbag instructions for Cana-

dian owners (in French)........

610

Headlight aim instructions for

Canadian owners (in French)
.........................................................

615

608

9-1. For owners

9-1.For owners

Reporting safety defects for
U.S. owners

If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying the Lexus Division of
Toyota Motor Sales, U.S.A., Inc.
(Toll-free: 1-800-25-LEXUS).

If NHTSA receives similar com-
plaints, it may open an investigation,
and if it finds that a safety defect
exists in a group of vehicles, it may
order a recall and remedy campaign.
However, NHTSA cannot become
involved in individual problems
between you, your dealer, or Lexus
Division of Toyota Motor Sales,
U.S.A., Inc.

To contact NHTSA, you may call the
Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY:
1-800-424-9153); go to

http://www.safercar.gov

; or write to:

Administrator, NHTSA, 1200 New
Jersey Ave. SE., Washington, DC
20590. You can also obtain other
information about motor vehicle
safety from

http://www.safercar.gov

Reporting safety defects for
Canadian owners

Canadian customers who wish to
report a safety-related defect to
Transport Canada, Defects Investi-
gations and Recalls, may telephone
the toll-free hotline
1-800-333-0510, mail Transport
Canada - ASFAD, 330 Sparks
Street, Ottawa, ON, K1A 0N5, or
complete the online form at
https://www.tc.gc.ca/recalls.

609

9-1. For owners

For
owners



Déroulez la sangle diagonale de
telle sorte qu'elle passe bien sur
l'épaule, sans pour autant être en
contact avec le cou ou glisser de
l'épaule.



Placez la sangle abdominale le plus
bas possible sur les hanches.



Réglez la position du dossier de
siège. Asseyez-vous le dos droit et
calez-vous bien dans le siège.



Ne vrillez pas la ceinture de sécu-
rité.

■

Traitement des ceintures de sécu-
rité

Nettoyez avec un chiffon ou une
éponge humidifiés avec de l'eau savon-
neuse tiède. Vérifiez régulièrement
que les ceintures ne sont pas usées,
effilochées ou entaillées excessive-
ment.

Seat belt instructions for
Canadian owners (in French)

The following is a French explana-
tion of seat belt instructions
extracted from the seat belt section
in this manual.

See the seat belt section for more
detailed seat belt instructions in
English.

Utilisation correcte des cein-
tures de sécurité

Entretien et soin

AVERTISSEMENT

■

Détérioration et usure des ceintures

de sécurité

Inspectez le système de ceintures de

sécurité régulièrement. Contrôlez

l'absence de coupures, d'effilochages et

de pièces desserrées. N'utilisez pas une

ceinture de sécurité endommagée avant

qu'elle ne soit remplacée. Une ceinture

de sécurité endommagée ne permet pas

de protéger un occupant de blessures

graves ou mortelles.

610

9-1. For owners

Coussin gonflable conducteur/coussin gonflable du passager avant SRS

Contribuent à réduire l’impact au niveau de la tête et du thorax du conducteur et du pas-
sager avant

Coussin gonflable de genoux SRS

Contribue à réduire l’impact subi par le conducteur

Coussins gonflables de coussin de siège SRS

• Contribue à réduire l’impact subi par le passager avant

Coussins gonflables latéraux SRS

• Contribuent à réduire l’impact au niveau du thorax des occupants des sièges avant
• Contribuent à réduire l’impact au niveau du thorax des occupants des sièges arrière

latéraux

Coussins gonflables rideaux SRS

• Contribuent à réduire l’impact au niveau de la tête des occupants des sièges avant et des

sièges arrière latéraux

SRS airbag instructions for Canadian owners (in French)

The following is a French explanation of SRS airbag instructions extracted
from the SRS airbag section in this manual.

See the SRS airbag section for more detailed SRS airbag instructions in English.

Système de coussins gonflables SRS

611

9-1. For owners

For
owners

• Peut contribuer à empêcher les occupants d’être éjectés du véhicule en cas de tonneau

Votre véhicule est équipé de COUSSINS GONFLABLES INTELLIGENTS
conçus selon les normes de sécurité américaines applicables aux véhicules à
moteur (FMVSS208). L'ensemble des capteurs de coussins gonflables (ECU)
régule le déploiement des coussins gonflables sur la base des informations qu'il
reçoit des capteurs, etc., indiqués ci-dessus dans le schéma illustrant les com-
posants du système. Parmi ces informations figurent la gravité du choc et l'occupa-
tion du véhicule par les passagers. Le déploiement rapide des coussins gonflables
est obtenu au moyen d'une réaction chimique dans les dispositifs pyrotechniques,
qui produit un gaz inoffensif permettant d'amortir le mouvement des occupants.

AVERTISSEMENT

■

Précautions relatives aux coussins

gonflables SRS

Respectez les précautions suivantes.

Le non-respect de ces précautions peut

occasionner des blessures graves, voire

mortelles.

●

Le conducteur et tous les passagers

doivent porter correctement leur cein-

ture de sécurité.

Les coussins gonflables SRS sont des

dispositifs supplémentaires à utiliser

avec les ceintures de sécurité.

●

Le coussin gonflable conducteur SRS

se déploie avec une force con-

sidérable et peut occasionner des

blessures graves, voire mortelles, tout

particulièrement si le conducteur se

trouve très près du coussin gonflable.

L'autorité fédérale chargée de la sécu-

rité routière aux États-Unis (NHTSA)

conseille:

La zone à risque du coussin gonflable
conducteur se situant dans les premiers
2 à 3 in. (50 à 75 mm) de déploiement,
vous placer à 10 in. (250 mm) de votre
coussin gonflable conducteur vous
garantit une marge de sécurité suffisante.
Cette distance est à mesurer entre le
centre du volant et le sternum. Si votre
position de conduite actuelle vous place
à moins de 10 in. (250 mm) du coussin
gonflable conducteur, vous pouvez
changer votre position de conduite de
plusieurs façons:
• Reculez votre siège le plus possible, de

manière à pouvoir encore atteindre

confortablement les pédales.

612

9-1. For owners

AVERTISSEMENT

• Inclinez légèrement le dossier de

siège. Bien que les véhicules aient une

conception différente, un grand nom-

bre de conducteurs peuvent s'asseoir

à une distance de 10 in. (251 mm),

même avec le siège conducteur com-

plètement avancé, simplement en

inclinant un peu le dossier de siège. Si

vous avez des difficultés à voir la route

après avoir incliné le dossier de votre

siège, utilisez un coussin ferme et

antidérapant pour vous rehausser ou

remontez le siège si votre véhicule est

équipé de cette fonction.

• Si votre volant est réglable, inclinez-le

vers le bas. Cela a pour effet d'orienter

le coussin gonflable en direction de

votre poitrine plutôt que de votre tête

et de votre cou. Réglez votre siège

selon les recommandations de la

NHTSA, tout en conservant le con-

trôle du véhicule avec les pédales et le

volant, et en préservant la vue des

commandes du tableau de bord.

●

Si vous attachez une rallonge de cein-

ture de sécurité à une boucle de cein-

ture de sécurité du passager avant

sans l’attacher au pêne de la ceinture

de sécurité, le système de coussins

gonflables SRS détermine que le pas-

sager avant a attaché sa ceinture de

sécurité, bien que la ceinture de sécu-

rité ne soit pas bouclée. Dans ce cas,

les coussins gonflables frontaux SRS

du passager avant peuvent ne pas se

déployer correctement lors d’une col-

lision, pouvant occasionner des bless-

ures graves, voire mortelles. Veillez à

porter la ceinture de sécurité cor-

rectement en cas d’utilisation d’une

rallonge de ceinture de sécurité.

●

Le coussin gonflable frontal SRS se

déploie avec une force considérable et

peut occasionner des blessures

graves, voire mortelles, tout particu-

lièrement si le passager avant se

trouve très près du coussin gonflable.

Le siège du passager avant doit être

éloigné le plus possible du coussin

gonflable, avec le dossier réglé de

façon à ce que le passager avant soit

assis bien droit dans le siège.

●

Les nourrissons et les enfants qui ne

sont pas correctement assis et/ou

attachés peuvent être grièvement

blessés ou tués par le déploiement

d'un coussin gonflable. Un nourrisson

ou un enfant trop petit pour utiliser une

ceinture de sécurité doit être cor-

rectement attaché au moyen d'un

siège de sécurité enfant. Lexus recom-

mande vivement d'installer tous les

nourrissons et enfants sur les sièges

arrière du véhicule et de prévoir pour

eux des systèmes de retenue adaptés.

Les sièges arrière sont plus sûrs pour

les nourrissons et les enfants que le

siège du passager avant. (



P.45)

●

Ne vous asseyez pas sur le bord du

siège et ne vous appuyez pas contre la

planche de bord.

●

Ne laissez pas un enfant rester debout

devant le coussin gonflable passager

avant SRS ou s'asseoir sur les genoux

du passager avant.

613

9-1. For owners

For
owners

AVERTISSEMENT

●

Les occupants des sièges avant ne

doivent en aucun cas tenir d'objets sur

leurs genoux.

●

Ne vous appuyez pas contre la porte,

le rail latéral de toit ou les montants

avant, latéraux ou arrière.

●

Ne laissez personne s'agenouiller sur

un siège en appui contre la porte ou

sortir la tête ou les mains à l'extérieur

du véhicule.

●

Ne fixez rien et ne posez rien sur des

emplacements tels que la planche de

bord, la garniture du volant et la partie

inférieure du tableau de bord.

●

Ne fixez rien à des emplacements tels

que les portes, la vitre du pare-brise,

les vitres latérales, les montants avant

ou arrière, des rails latéraux de toit et

des poignées de maintien.

●

Ne suspendez aucun cintre ou objet

dur aux crochets à vêtements. Ces

éléments peuvent se transformer en

projectiles si les coussins gonflables

rideaux SRS se déploient, le choc pou-

vant entraîner des blessures graves,

voire mortelles.

●

Si un cache en vinyle est fixé sur la

zone où le coussin gonflable de

genoux SRS se déploie, veillez à le

retirer.

614

9-1. For owners

AVERTISSEMENT

●

N'utilisez aucun accessoire de siège

recouvrant les zones de déploiement

des coussins gonflables SRS, car il ris-

que de gêner le déploiement des

coussins gonflables SRS. De tels

accessoires peuvent empêcher les

coussins gonflables SRS de se

déployer correctement, peuvent dés-

activer le système ou entraîner le

déploiement involontaire des coussins

gonflables SRS, ce qui peut éventuel-

lement occasionner des blessures

graves, voire mortelles.

●

Évitez de faire subir des chocs ou des

pressions excessives aux composants

des systèmes de coussins gonflables

SRS, aux portes avant ou à leur zone

adjacente.

En effet, cela pourrait entraîner un dys-

fonctionnement des coussins gonfla-

bles SRS.

●

Ne touchez aucun composant des

coussins gonflables SRS immédiate-

ment après leur déploiement (gon-

flage), car ils peuvent être chauds.

●

Si vous avez des difficultés à respirer

après le déploiement des coussins

gonflables SRS, ouvrez une porte ou

une vitre pour faire entrer de l'air frais,

ou bien descendez du véhicule si cela

ne présente pas de danger. Essuyez

tout résidu dès que possible afin

d'éviter d'éventuelles irritations de la

peau.

●

Si une zone renfermant un coussin

gonflable SRS est endommagée ou

craquelée, faites-la remplacer par

votre concessionnaire Lexus.

●

Ne placez rien sur le siège du pas-

sager avant, comme un coussin par

exemple. Cela a pour conséquence de

répartir le poids du passager sur toute

la surface du siège, ce qui empêche le

capteur de détecter correctement le

poids du passager. En conséquence,

les coussins gonflables frontaux SRS

du siège du passager avant risquent de

ne pas se déployer en cas de collision.

■

Modification et mise au rebut des

composants du système de coussins

gonflables SRS

Ne mettez pas votre véhicule au rebut et

ne procédez à aucune des modifications

suivantes sans consulter votre conces-

sionnaire Lexus. Les coussins gonflables

SRS peuvent ne pas fonctionner cor-

rectement ou se déployer involontaire-

ment, ce qui peut provoquer des

blessures graves, voire mortelles.

●

Dépose, repose, démontage ou répa-

ration des coussins gonflables SRS

●

Réparation, dépose ou modification

des pièces suivantes ou de leurs alen-

tours

• Volant

• Tableau de bord

• Planche de bord

• Sièges

• Garnissage des sièges

• Montants avant

• Montants latéraux

• Montants arrière

• Rails latéraux de toit

• Panneaux de portes avant

• Garniture de porte avant

• Haut-parleurs de porte avant

615

9-1. For owners

For
owners



Véhicules sans phares à faisceau
unique

Boulon de réglage A
Boulon de réglage B



Véhicules avec phares à faisceau
unique

Boulon de réglage A
Boulon de réglage B

AVERTISSEMENT

●

Modifications des panneaux de portes

avant (par exemple, perçage de trous

dans les panneaux)

●

Réparation ou modification des pièces

suivantes ou de leurs alentours

• Aile avant

• Pare-chocs avant

• Côtés de l'intérieur du véhicule

●

Installation des pièces suivantes ou

accessoires

• Pare-buffle ou pare-kangourou

• Chasse-neige

• Treuils

• Porte-bagages de toit

●

Modifications de la suspension du

véhicule

●

Installation d'appareils électroniques

tels que les émetteurs/récepteurs

radios mobiles et les lecteurs CD

●

Modifications apportées à votre

véhicule pour les personnes atteintes

d'un handicap physique

Headlight aim instructions
for Canadian owners (in
French)

The following is a French explana-
tion of headlight aim instructions
from the headlight aim section in
this manual.

Boulons de réglage du mouve-
ment vertical

A
B

616

9-1. For owners

Vérifiez que le réservoir de carbu-
rant du véhicule est plein et que la
zone autour des phares n'est pas
déformée.

Stationnez le véhicule sur une sur-
face plane.

Installez-vous dans le siège con-
ducteur.

Balancez le véhicule plusieurs fois.

À l'aide d'un tournevis cruciforme,
tournez le boulon A dans n'importe
quel sens.

Mémorisez le sens dans lequel vous avez

tourné et le nombre de tours.



Véhicules sans phares à faisceau
unique



Véhicules avec phares à faisceau
unique

Tournez le boulon B du même
nombre de tours dans le même
sens qu'à l'étape

Si vous n'arrivez pas à régler le phare en

procédant de la sorte, confiez le véhicule à

votre concessionnaire Lexus pour qu'il

règle le faisceau des phares.



Véhicules sans phares à faisceau
unique



Véhicules avec phares à faisceau
unique

Avant de vérifier le réglage des
phares

Réglage du faisceau des phares

618

What to do if... (Troubleshooting)

1-1.What to do if... (Troubleshooting)

What to do if... (Troubleshooting)



If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
(



P.548)



If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. (



P.548)



Is the electronic key battery weak or
depleted? (



P.501)



Is the power switch in ON?

When locking the doors, turn the power
switch off. (



P.211)



Is the electronic key left inside the
vehicle?

When locking the doors, make sure that
you have the electronic key on your per-
son.



The function may not operate prop-

erly due to the condition of the radio
wave. (



P.141)



Is the child-protector lock set?

The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. (



P.123)



Did you press the power switch
while firmly depressing the brake
pedal? (



P.208)



Is the electronic key anywhere
detectable inside the vehicle?
(



P.140)



Is the electronic key battery weak or
depleted?

In this case, the hybrid system can be
started in a temporary way. (



P.550)



Is the 12-volt battery discharged?
(



P.553)



Is the window lock switch pressed?

The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. (



P.171)

If you have a problem, check the
following before contacting your
Lexus dealer.

The doors cannot be locked,
unlocked, opened or closed

You lose your keys

The electronic key does not
operate properly

The doors cannot be locked or
unlocked

The rear door cannot be opened

If you think something is wrong

The hybrid system does not start

The windows do not open or
close by operating the power
window switches

619

What to do if... (Troubleshooting)



The auto power off function will be
operated if the vehicle is left in ACC
or ON (the hybrid system is not
operating) for a period of time.
(



P.211)



The seat belt reminder light is flash-
ing

Are the driver and the passengers wearing
the seat belts? (



P.519

, 520

)



The parking brake indicator is on

Is the parking brake released? (



P.226)

Depending on the situation, other
types of warning buzzer may also
sound. (



P.516, 526)



Did anyone inside the vehicle open
a door during setting the alarm?

The sensor detects it and the alarm sounds.
(



P.83)

Do one of the following to deactivate
or stop the alarms:



Unlock the doors.



Turn the power switch to ACC or
ON, or start the hybrid system. (The
alarm will be deactivated or stopped
after a few seconds.)



Is the message displayed on the
multi-information display?

Check the message on the multi-informa-
tion display. (



P.526)



When a warning light turns on or a
warning message is displayed, refer
to P.516, 526.



Stop the vehicle in a safe place and
replace the flat tire with the spare
tire. (



P.539)



Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. (



P.565)

The power switch is turned off
automatically

A warning buzzer sounds during
driving

An alarm is activated and the
horn sounds

A warning buzzer sounds when
leaving the vehicle

A warning light turns on or a
warning message is displayed

When a problem has occurred

If you have a flat tire

The vehicle becomes stuck

620

Alphabetical Index

Alphabetical Index

A/C

Air conditioning filter ...............................496
Front automatic air conditioning system

.............................................................................411

Front seat concentrated airflow mode

(S-Flow) ........................................................414

Rear air conditioning system ...............420

ABS (Anti-lock Brake System)..............393

Warning light................................................ 518

ACA (Active Cornering Assist)...........394
Active Cornering Assist (ACA)...........394
Adaptive High-beam System................. 234
Adaptive Variable Suspension System394
Advanced Park ............................................356
AHS (Adaptive High-beam System).. 234
Air conditioning filter................................. 496
Air conditioning system

Air conditioning filter ...............................496
Front automatic air conditioning system

.............................................................................411

Front seat concentrated airflow mode

(S-Flow) ........................................................414

Rear air conditioning system ...............420

Airbags

Airbag operating conditions...........33, 34
Airbag precautions for your child........35
Correct driving posture.............................27
Curtain shield airbag precautions .......35
Front passenger occupant classification

system .............................................................39

General airbag precautions ...................35
Modification and disposal of airbags .38
Side airbag precautions............................35
Side and curtain shield airbags precau-

tions..................................................................35

SRS airbags ......................................................32
SRS warning light ....................................... 518

Alarm...................................................................83

Warning buzzer.......................................... 516

Anchor brackets...................................... 51, 63

Antennas (smart access system with

push-button start).......................................139

Anti-lock Brake System (ABS)..............393

Warning light ................................................518

Approach warning......................................302
Armrest..............................................................441
Assist grips .......................................................441
Audio system-linked display......................110
Automatic headlight leveling system .. 233
Automatic light control system.............. 232
Automatic transmission..............................214

M mode ........................................................... 218
Paddle shift switches....................... 217, 218

Auxiliary boxes.............................................430
Average fuel economy............................... 105
Average vehicle speed .............................. 105
AWD Control................................................ 109

Back door .........................................................124
Back-up light

Wattage......................................................... 578

Back-up lights

Replacing light bulbs............................... 507

Battery (12-volt battery)

Battery checking ......................................... 481
If the 12-volt battery is discharged ... 553
Preparing and checking before winter

..........................................................................402

Replacing ......................................................558
Warning light .................................................517

Battery (traction battery) .............................77
Blind Spot Monitor (BSM).........................319
Boost gauge.....................................................107
Bottle holders................................................ 429
Brake

Brake hold.....................................................229
Fluid.......................................................479, 575
Parking brake ..............................................226
Regenerative braking ................................. 74
Warning light ................................................516

Brake assist ....................................................393

621

Alphabetical Index

Break-in tips.................................................... 188
Brightness control

Instrument panel light control ................ 97

BSM (Blind Spot Monitor).........................319
Buzzer

Driver monitor.............................................259

Camera

Driver monitor.............................................259

Care

Exterior ...........................................................458
Interior...............................................................461
Seat belts..........................................................461
Wheels and wheel ornaments............458

Cargo capacity.....................................193, 196
Cargo hooks ...................................................431
Cargo net hooks............................................431
Chains ..............................................................403
Child restraint system

Fixed with a LATCH system ..................58
Fixed with a seat belt...................................54
Front passenger occupant classification

system .............................................................39

Points to remember .................................... 46
Riding with children.....................................45
Types of child restraint system installation

method .............................................................51

Using a top tether anchorage................65
Using an anchor bracket..........................63

Child safety

12-volt battery precautions........481, 559
Airbag precautions......................................35
Child restraint system...................................51
Heated steering wheel and seat heater

precautions................................................ 422

How your child should wear the seat belt

............................................................................ 29

Moon roof precautions ............................173
Panoramic moon roof precautions....176
Power back door precautions..............124
Power window lock switch.......................171

Power window precautions .................. 170
Rear door child-protectors ....................123
Seat belt extender precautions..............30
Seat belt precautions ..................................45

Child-protectors............................................123
Cleaning

Exterior........................................................... 458
Interior .............................................................. 461
Radar sensor................................................254
Seat belts......................................................... 461
Wheels and wheel ornaments........... 458

Clock ...........................................................90, 92
Coat hooks..................................................... 442
Coin box..........................................................430
Condenser ..................................................... 479
Console box ..................................................428
Console box light ........................................428
Cooling system..............................................477

Engine overheating..................................560
Hybrid system overheating ..................562

Cornering lights........................................... 234

Replacing light bulbs............................... 507

Cruise control

Dynamic radar cruise control..............295

Cup holders...................................................428
Current fuel consumption ........................ 105
Curtain shield airbags .................................. 32
Customizable features..............................590

Daytime running light system................. 232
Daytime running lights

Replacing light bulbs............................... 507

Deck board....................................................433
Defogger

Outside rear view mirrors...................... 416
Rear window................................................. 416
Windshield...........................................415, 416

Differential

Rear differential oil.....................................575

Digital Rear-view Mirror............................157
Dimension ......................................................568

622

Alphabetical Index

Dinghy towing............................................... 207
DIRECT4........................................................ 394
Display

center display................................................ 104
Dynamic radar cruise control .............298
Head-up display ................................ 101, 104
Intuitive parking assist..............................328
Multi-information display............... 98, 104
RCD (Rear Camera Detection)........ 342
RCTA .............................................................. 337
Warning message.....................................526

Distance until next engine oil change.... 96
Do-it-yourself maintenance.................... 465
Door courtesy lights................................... 424

Wattage..........................................................578

Door lock

Power back door.........................................124
Side doors........................................................ 119
Smart access system with push-button

start..................................................................139

Wireless remote control........................... 115

Doors

Automatic door locking and unlocking

system ............................................................123

Door glasses..................................................169
Door lock warning buzzer .....................120
Outside rear view mirrors ......................166
Rear door child-protectors....................123
Side doors........................................................ 119

Drive distance................................................ 105
Driver’s seat position memory

Driving position memory.........................178
Memory recall function ...........................180
Power easy access system.....................178

Drive-Start Control (DSC) .......................192
Driving

Break-in tips..................................................188
Correct driving posture.............................27
Driving mode select switch..................390
Hybrid vehicle driving tips................... 400
Procedures.....................................................187
Winter drive tips.........................................402

Driving information display ...................... 105
Driving position memory............................178

Memory recall function............................180
Power easy access system .................... 178

Driving range ................................................. 105
Driving support system information.......110
DRS (Dynamic Rear Steering) .............. 394
DSC (Drive-Start Control) .......................192
Dynamic radar cruise control ................295

Warning message.....................................302

Dynamic Rear Steering (DRS) .............. 394

ECB (Electronically Controlled Brake Sys-

tem) ................................................................393

Eco heat/cool .................................................414
EDR (Event data recorder)........................... 9
E-Four .............................................................. 394
Elapsed time ................................................... 105
Electric motor (traction motor).................72
Electric Power Steering (EPS) .............. 394

Warning light ................................................519

Electronic key ..........................................114, 117

Battery-saving function............................ 140
If the electronic key does not operate

properly...................................................... 549

Replacing the battery................................501

Electronic sunshade

Jam protection function............................175
Operation........................................................174

Electronically Controlled Brake System

(ECB) ............................................................393

Emergency Driving Stop System ............311
Emergency flashers..................................... 510
Emergency, in case of

If a warning buzzer sounds....................516
If a warning light turns on........................516
If a warning message is displayed.....526
If the 12-volt battery is discharged ... 553
If the electronic key does not operate

properly...................................................... 549

If the hybrid system will not start ........547

623

Alphabetical Index

If the vehicle is submerged or water on

the road is rising......................................... 511

If you have a flat tire..................................539
If you lose your keys.................................548
If you think something is wrong ...........514
If your vehicle becomes stuck.............565
If your vehicle has to be stopped in an

emergency ................................................. 510

If your vehicle needs to be towed.......513
If your vehicle overheats....................... 560

Energy monitor ............................................. 106
Engine

ACCESSORY mode .................................211
Compartment ............................................. 473
Engine switch...............................................208
Hood..................................................................471
How to start the hybrid system ..........208
Identification number...............................569
If the hybrid system will not start........547
If your vehicle has to be stopped in an

emergency ................................................. 510

Ignition switch (power switch)............208
Overheating................................................ 560
Power switch ...............................................208
Tachometer ............................................90, 92

Engine coolant

Capacity.........................................................573
Checking ........................................................477
Preparing and checking before winter

.........................................................................402

Engine coolant temperature gauge90, 92
Engine oil

Capacity...........................................................571
Checking ....................................................... 474
Preparing and checking before winter

.........................................................................402

Warning light.................................................517

Engine oil maintenance data ...................476
Engine oil pressure gauge.........................107
Engine oil temperature gauge.................107

Engine switch (power switch) ................208

If your vehicle has to be stopped in an

emergency..................................................510

EPS (Electric Power Steering) .............. 394

Warning light ................................................519

EV drive mode................................................212
EV indicator.......................................................74
Event data recorder (EDR)........................... 9

FCTA (Front Cross Traffic Alert).........290
Fixed with an ISOFIX lower anchorage60
Flat tire

Tire pressure warning system ............ 485
Vehicles with a spare tire...................... 539

Floor mats.......................................................... 26
Fluid

Brake................................................................575
Transmission.................................................574
Washer ..........................................................480

Fog lights

Switch...............................................................240

Footwell lights ............................................... 424
Front automatic air conditioning system411
Front Cross Traffic Alert (FCTA).........290
Front fog lights

Replacing light bulbs............................... 507

Front passenger occupant classification

system .............................................................. 39

Front seats

Adjustment......................................................144
Cleaning.......................................................... 461
Correct driving posture ............................ 27
Driving position memory........................ 178
Head restraints............................................. 152
Memory recall function............................180
Power easy access system .................... 178
Seat heaters..................................................422
Seat position memory .............................. 178
Seat ventilators............................................422

Front side marker light

Light switch...................................................232

624

Alphabetical Index

Replacing light bulbs................................507

Front side marker lights

Wattage..........................................................578

Front turn signal lights

Replacing light bulbs................................507
Turn signal lever......................................... 226
Wattage..........................................................578

Fuel

Capacity.........................................................570
Fuel gauge ..............................................90, 92
Information....................................................579
Refueling ........................................................ 247
Type..................................................................570
Warning light................................................ 519

Fuel consumption

Average fuel economy............................ 105
Current fuel consumption...................... 105

Fuel filler door

Refueling ........................................................ 247

Fuel gauge.................................................90, 92
Fuses.................................................................503

Garage door opener.................................450
Gauges...............................................................90
Gear Position................................................. 108
G-force..............................................................107
Glove box.......................................................428
Glove box light.............................................428
Grocery bag hooks.................................... 432

Hands Free Power Back Door................128
Head restraints...............................................152
Headlight aim................................................505
Headlights

Adaptive High-beam System ............. 234
Light switch................................................... 232
Replacing light bulbs................................507

Head-up display..............................................101

Driving information display area...........101

Settings............................................................. 102

Heated steering wheel.............................. 422
Heaters

Front automatic air conditioning system

............................................................................. 411

Heated steering wheel............................422
Outside rear view mirrors...................... 416
Rear air conditioning system ...............420
Seat heaters..................................................422

High mounted stoplight

Replacing light bulbs............................... 507

High-voltage components ..........................77
Hill-start assist control............................... 394
Hood

Open..................................................................471

Hooks

Cargo hooks..................................................431
Cargo net hooks..........................................431
Coat hooks ...................................................442
Grocery bag hooks..................................432
Retaining hooks (floor mat).....................26

Horn................................................................... 155
Hybrid battery (traction battery)

Location..............................................................77
Specification ...................................................571
Warning message......................................... 81

Hybrid battery (traction battery) air vents

.............................................................................80

Hybrid system...................................................72

Acoustic Vehicle Alerting System .......75
Emergency shut off system..................... 80
EV drive mode..............................................212
High voltage components ........................77
Hybrid system precautions.......................77
If the hybrid system will not start ........547
Overheating.................................................562
Power (ignition) switch.......................... 208
Predictive efficient drive ...........................75
Regenerative braking ................................. 74
Starting the hybrid system.................... 208

Hybrid System Indicator.............................. 95

625

Alphabetical Index

Hybrid transmission....................................220

Paddle shift switches.....................223, 224
S mode............................................................ 224

Hybrid vehicle driving tips.......................400

I/M test ............................................................468
Identification

Engine .............................................................569
Vehicle........................................................... 568

If your vehicle has to be stopped in an

emergency................................................... 510

Ignition switch (power switch) ...............208

Auto power off function .............................211
Changing the power switch modes ....211
If your vehicle has to be stopped in an

emergency ................................................. 510

Immobilizer system........................................ 82
Indicators ...........................................................88
Initialization

Items to initialize ........................................ 606
Maintenance ....................................464, 476
Power windows............................................169

Inside rear view mirror......................156, 157
Instrument panel light control ....................97
Intercooler...................................................... 479
Intercooler coolant

Checking ........................................................477

Interior lights.................................................. 424
Intuitive parking assist

Function..........................................................328
Warning message.....................................330

ISOFIX lower anchorage ...........................60

Jack

Positioning a floor jack..............................471
Vehicle-equipped jack...........................540

Jack handle ....................................................540
Jam protection function

Electronic sunshade...................................175

Moon roof .......................................................172
Panoramic moon roof...............................175
Power back door.......................................... 131
Power windows........................................... 169
Rear seats ....................................................... 146

Keyless entry

Smart access system with push-button

start ................................................................. 139

Wireless remote control...........................115

Keys

Battery-saving function............................ 140
Electronic key ................................................. 114
If the electronic key does not operate

properly...................................................... 549

If you lose your keys................................ 548
Key number plate ......................................... 114
Keyless entry .........................................115, 139
Mechanical key.............................................. 114
Power switch............................................... 208
Replacing the battery................................501
Warning buzzer.......................................... 140
Wireless remote control...........................115

Knee airbags .................................................... 32

Lane change Assist (LCA).......................276
Lane Departure Alert (LDA) ................. 279
Lane Tracing Assist (LTA)

Operation........................................................271

LATCH anchors .............................................58
LCA (Lane change Assist).......................276
LDA (Lane Departure Alert) ................. 279
Lever

Auxiliary catch lever...................................471
Hood lock release lever...........................471
Shift lever..............................................214, 220
Turn signal lever .........................................226
Wiper lever.....................................................241

Lexus climate concierge ........................... 410

626

Alphabetical Index

Lexus Safety System + 3

AHS (Adaptive High-beam System)234
Driver monitor.............................................259
Dynamic radar cruise control .............295
Emergency Driving Stop System......... 311
FCTA (Front Cross Traffic Alert) .....290
LCA (Lane change Assist)................... 276
LDA (Lane Departure Alert)............... 279
LTA (Lane Tracing Assist)...................... 271
PCS (Pre-Collision System)..................261
PDA (Proactive driving assist) ...........285
RSA (Road Sign Assist) .........................293
Traffic Jam Assist .........................................313

Lexus Teammate Advanced Park........356
License plate lights

Light switch................................................... 232
Replacing light bulbs................................507

Light bulbs

Replacing...................................................... 506

Lights

Automatic High Beam system............ 237
Fog light switch...........................................240
Front personal lights.................................425
Headlight switch ........................................ 232
Interior lights..................................... 424, 425
Interior lights list.......................................... 424
Rear personal lights..................................425
Replacing light bulbs................................507
Turn signal lever......................................... 226
Vanity lights..................................................443
Wattage..........................................................578

LTA (Lane Tracing Assist)

Operation........................................................ 271

Luggage cover ............................................. 432

Maintenance

Do-it-yourself maintenance .................469
General maintenance.............................465
Maintenance data..................................... 568
Maintenance requirements ..................464

Malfunction indicator lamp .......................517

Max cool ...........................................................415
Max heat ...........................................................415
Meter

Clock..........................................................90, 92
Hybrid System Indicator ...........................95
Indicators.......................................................... 88
Instrument panel light control.................97
Meter control switches ............................ 104
Meters.................................................................90
Multi-information display..........................98
Warning lights..............................................516
Warning message.....................................526

Mirrors

Digital Rear-view Mirror..........................157
Inside rear view mirror.............................156
Outside rear view mirror defoggers 416
Outside rear view mirrors...................... 166
Vanity mirrors..............................................443

Moon roof

Door lock linked moon roof operation

............................................................................172

Door lock linked panoramic moon roof

operation ......................................................175

Jam protection function............................172
Operation......................................................... 171

Multi-information display............................98

Audio system-linked display...................110
AWD Control..............................................109
Boost gauge.................................................. 107
Drive information........................................105
Driving information display....................105
Driving support system information....110
Dynamic radar cruise control............. 298
Energy monitor............................................106
Engine oil pressure gauge ..................... 107
Engine oil temperature gauge ............. 107
Gear Position ...............................................108
G-force............................................................ 107
Meter control switches ............................ 104
Navigation system-linked display ........110
Pop-up display...............................................98
Pop-up display information.......................111

627

Alphabetical Index

Tire pressure................................................485
Warning message.....................................526

My Settings ......................................................182

Navigation system-linked display............110
Noise from under vehicle ...............................6

“ODO TRIP” switch ...................................... 96
Odometer ......................................................... 96
Odometer and trip meter display

Display items...................................................96
“ODO TRIP” switch....................................96

Oil

Engine oil .........................................................571
Rear differential oil ....................................575
Rear transaxle oil .......................................575

Opener

Fuel filler door.............................................. 247
Hood..................................................................471

Outer foot lights

Location.......................................................... 424
Replacing light bulbs................................507

Outside door handle lights...................... 424
Outside rear view mirrors

Adjustment......................................................166
BSM (Blind Sport Monitor) ...................319
Folding ..............................................................167
Linked mirror function when reversing

...........................................................................167

Mirror position memory...........................178
Outside rear view mirror defoggers.416
RCTA function............................................ 337
Safe Exit Assist............................................ 323

Outside temperature............................90, 92
Overheating..................................................560

Paddle shift switches... 217, 218, 223, 224

Panic mode ....................................................... 116
Panoramic moon roof

Jam protection function............................175
Operation........................................................174

Parking assist sensors (intuitive parking

assist).............................................................328

Parking brake

Operation......................................................226
Parking brake engaged warning buzzer

..........................................................................228

Warning light ...............................................522
Warning message.....................................228

Parking lights

Light switch...................................................232
Replacing light bulbs............................... 507

Parking Support Brake function (for

rear-crossing vehicles) ..........................352

Function..........................................................352

Parking Support Brake function (rear

pedestrians)................................................353

Function..........................................................353

Parking Support Brake function (static

objects).........................................................350

Function......................................................... 350

PCS (Pre-Collision System)

Function............................................................261
Warning light ................................................ 521

PDA (Proactive driving assist)...............285
Personal lights............................................... 424
PKSB (Parking Support Brake).............345
Pop-up display information..........................111
Power back door...........................................124

Hands Free Power Back Door ........... 128
Smart access system with push-button

start ................................................................. 125

Power control unit...........................................77
Power control unit coolant

Capacity .........................................................573
Checking ....................................................... 477
Preparing and checking before winter

..........................................................................402

Power easy access system ........................178

628

Alphabetical Index

Power outlets ................................................ 442
Power outlets (1500 W).......................... 444
Power steering (Electric power steering

system).......................................................... 394

Warning light................................................ 519

Power switch.................................................208

Auto power off function .............................211
Changing the power switch modes ....211

Power switch (engine switch)

If your vehicle has to be stopped in an

emergency ................................................. 510

Power windows

Door lock linked window operation..170
Jam protection function............................169
Operation........................................................169
Window lock switch ....................................171

Pre-Collision System (PCS)

Function............................................................261
Warning light.................................................521

Predictive efficient drive ..............................75

Radar cruise control (dynamic radar cruise

control) ......................................................... 295

Radiator........................................................... 479
RCD (Rear Camera Detection)

Function.......................................................... 342

RCTA

Function.......................................................... 337

RCTA function .............................................338
Rear air conditioning system..................420
Rear Cross Traffic Alert (RCTA) ......... 337
Rear door sunshades................................. 443
Rear seats .........................................................145

Adjustment......................................................146
Folding down the rear seatbacks........146
Head restraints .............................................152
Seat heaters.................................................. 422

Rear side marker lights

Light switch................................................... 232
Replacing light bulbs................................507

Rear turn signal lights

Replacing light bulbs............................... 507
Turn signal lever .........................................226
Wattage......................................................... 578

Rear view mirror

Digital Rear-view Mirror..........................157
Inside rear view mirror.............................156
Outside rear view mirrors...................... 166

Rear window defogger ...............................416
Rear window wiper..................................... 245
Refueling

Capacity ........................................................ 570
Fuel types...................................................... 570
Opening the fuel tank cap .................... 247

Regenerative braking....................................73
Remote Connect............................................ 70
Replacing

Electronic key battery...............................501
Fuses................................................................ 503
Light bulbs....................................................506
Tires ................................................................. 539

Resetting the message indicating mainte-

nance is required...................................... 464

Rev indicator .................................................... 94
Rev peak............................................................. 94
Road Sign Assist (RSA) ............................ 293
RSA (Road Sign Assist) ............................ 293

Safe Exit Assist.............................................. 323
Safety Connect.................................................67
Seat belt reminder light...................519, 520
Seat belts............................................................ 28

Automatic Locking Retractor.................30
Child restraint system installation...........51
Cleaning and maintaining the seat belt

........................................................................... 461

Emergency Locking Retractor..............30
How to wear your seat belt.....................29
How your child should wear the seat belt

.............................................................................29

629

Alphabetical Index

Pregnant women, proper seat belt use

............................................................................28

Reminder light and buzzer........519, 520
Seat belt extender ........................................ 29
Seat belt pretensioners................................31
SRS warning light ....................................... 518

Seat heaters................................................... 422
Seat position memory..................................178
Seat ventilators............................................. 422
Seating capacity.............................................196
Seats

Adjustment........................................... 144, 146
Adjustment precautions................ 144, 145
Child seats/child restraint system installa-

tion....................................................................45

Cleaning...........................................................461
Driving position memory.........................178
Folding down the rear seatbacks........146
Head restraints .............................................152
Power easy access system.....................178
Properly sitting in the seat.........................27
Seat heaters.................................................. 422
Seat position memory ...............................178
Seat ventilators............................................ 422

Sensor

Automatic headlight system................. 232
Automatic High Beam system............ 237
Digital Rearview Mirror............................. 161
Inside rear view mirror............................. 156
Intuitive parking assist..............................328
LDA (Lane Departure Alert with steering

control)........................................................ 279

LTA (Lane Tracing Assist)...................... 271
Radar sensor......................... 253, 319, 325
Rain-sensing windshield wipers......... 242
RCTA ..............................................................338

Service Connect...............................................71
Service plug.......................................................77
Service reminder message ..................... 464
Shift lever

Automatic transmission............................214
Hybrid transmission .................................220

Shift lever light .............................................. 424
Side airbags ...................................................... 32
Side doors..........................................................119
Side marker lights

Light switch...................................................232
Replacing light bulbs............................... 507

Side mirrors

Adjustment..................................................... 166
BSM (Blind Sport Monitor)................... 319
Folding...............................................................167
Linked mirror function when reversing

............................................................................167

Mirror position memory.......................... 178
RCTA function............................................337

Side turn signal lights

Replacing light bulbs............................... 507
Turn signal lever .........................................226

Side windows ..................................................169
Smart access system with push-button

start

Antenna location......................................... 139
Entry functions......................................119, 125
Starting the hybrid system.................... 208

Snow tires .......................................................402
Spare tire.........................................................539

Storage location ........................................ 540

Spark plug ...................................................... 574
Specifications................................................568
Speedometer ...........................................90, 92
Steering wheel

Adjustment.....................................................155
Heated steering wheel............................422
Meter control switches ............................ 104
Power easy access system .................... 178
Steering wheel position memory........ 178

Stop lights

Replacing light bulbs............................... 507

Storage features ...........................................427
Stuck

If the vehicle becomes stuck............... 565

Sun visors........................................................ 443

630

Alphabetical Index

Sunshade

Panoramic moon roof...............................174
Roof .................................................................... 172

Switches

Advanced Park main switch................364
Automatic High Beam system............ 237
Brake Hold switch .................................... 229
Digital Rear-view Mirror control switches

...........................................................................157

Door lock switches.......................................121
Driving mode select switch..................390
Driving position memory switches.....178
Dynamic radar cruise control switch298
Electronic sunshade switch....................174
Emergency flashers switch.................... 510
EV drive mode switch ..............................212
Fog light switch...........................................240
Garage door opener switches ..........450
Heated steering wheel switch............. 422
Ignition switch..............................................208
Instrument panel light control switches

............................................................................ 97

Intuitive parking assist switch...............329
Light switches.............................................. 232
Meter control switches............................ 104
Moon roof switches .....................................171
“ODO TRIP” switch....................................96
Outside rear view mirror switches.....166
Paddle shift switches 217, 218, 223, 224
Panoramic moon roof switches...........174
Parking brake switch ............................... 226
PKSB (Parking Support Brake) switch

.........................................................................346

Power switch ...............................................208
Power window switches..........................169
RCD (Rear Camera Detection) switch

......................................................................... 342

RCTA switch................................................ 337
Seat heater switches ................................ 422
Seat ventilator switches.......................... 422
“SOS” button .................................................. 67

Tilt and telescopic steering control switch

...........................................................................155

Vehicle-to-vehicle distance switch.. 298
VSC OFF switch ...................................... 395
Window lock switch.................................... 171
Windshield wiper and washer switch241

Tachometer...............................................90, 92

Rev indicator ...................................................94
Rev peak............................................................94

Tail lights

Light switch...................................................232
Replacing light bulbs............................... 507

The Secondary Collision Brake ............395
Theft deterrent system

Alarm...................................................................83
Immobilizer system......................................82

Tire inflation pressure

Maintenance data......................................576
Tire inflation pressure display function

......................................................................... 485

Warning light .............................................. 520

Tire information............................................. 581

Glossary........................................................585
Size................................................................... 583
Tire identification number..................... 582
Uniform Tire Quality Grading...........583

Tire pressure display..................................485
Tire pressure warning system

Function......................................................... 485
Installing tire pressure warning valves

and transmitters...................................... 486

Registering ID codes .............................. 490
Registering the position of each wheel

..........................................................................487

Selecting wheel set .................................... 491
Setting the tire pressure.........................488
Warning light .............................................. 520

Tires

Chains ............................................................ 403
Checking ...................................................... 483

631

Alphabetical Index

If you have a flat tire..................................539
Inflation pressure........................................493
Information..................................................... 581
Replacing.......................................................539
Rotating tires................................................484
Size....................................................................576
Snow tires......................................................402
Spare tire........................................................539
Tire inflation pressure display function

.........................................................................485

Tire pressure warning system.............485
Warning light...............................................520

Tools..................................................................540
Top tether anchorage................................... 65
Top tether strap............................................... 63
Total load capacity......................................568
Towing

Dinghy towing.............................................207
Emergency towing .....................................513
Trailer towing.................................................197

TRAC (Traction Control) ........................ 394
Traction battery (hybrid battery)

Hybrid battery (traction battery) air vents

............................................................................80

Location..............................................................77
Specification...................................................571
Warning message..........................................81

Traction Control (TRAC) ........................ 394
Traction motor (electric motor) ................72
Traffic Jam Assist...........................................313
Trail Mode...................................................... 392
Trailer Sway Control..................................394
Trailer towing ..................................................197
Transaxle

Rear transaxle oil .......................................575

Transmission

Automatic transmission............................214
Driving mode select switch..................390
Hybrid transmission .................................220
M mode............................................................218
Paddle shift switches 217, 218, 223, 224
S mode............................................................ 224

Trip meters ........................................................ 96
Turn signal lights

Replacing light bulbs............................... 507
Turn signal lever .........................................226
Wattage......................................................... 578

USB charging ports.................................... 434

Vanity lights.................................................... 443

Wattage......................................................... 578

Vanity mirrors ............................................... 443
VDIM (Vehicle Dynamics Integrated Man-

agement)...................................................... 394

Vehicle data recording....................................7
Vehicle Dynamics Integrated Manage-

ment (VDIM).............................................. 394

Vehicle identification number................568
Vehicle Stability Control (VSC) ...........393
Ventilators (seat ventilators)................... 422
VSC (Vehicle Stability Control) ...........393

Warning buzzers

ABS....................................................................518
Airbags.............................................................518
Approach warning....................................302
Brake system.................................................516
Charging system..........................................517
Cruise control............................................... 521
Door lock........................................................ 120
Downshifting ........................... 218, 219, 224
Dynamic radar cruise control............... 521
Electric power steering............................519
High coolant temperature......................516
Hybrid system overheat...........................517
Inappropriate pedal operation.............518
Intuitive parking assist................. 334, 520
LDA (Lane Departure Alert)................ 521

632

Alphabetical Index

Low engine oil pressure...........................517
LTA (Lane Tracing Assist)............271, 521
Open window...............................................170
PDA (Proactive Driving Assist) ...........521
Pre-collision system ...................................521
Pre-collision warning.................................261
Seat belt...............................................519, 520
Tire pressure................................................520

Warning label ...................................................77
Warning lights.................................................516

ABS ................................................................... 518
Brake hold operated indicator ...........523
Brake system ................................................ 516
Charging system .........................................517
Cruise control indicator...........................521
Driving assist information indicator.. 522
Dynamic radar cruise control indicator

...........................................................................521

Electric power steering ........................... 519
High coolant temperature ..................... 516
Hybrid system overheat warning light

...........................................................................517

Inappropriate pedal operation warning

light ................................................................. 518

Intuitive parking assist OFF indicator

.........................................................................520

LDA indicator................................................521
Low engine oil pressure...........................517
Low fuel level................................................ 519
LTA indicator.................................................521
Malfunction indicator lamp.....................517
Parking brake indicator.......................... 522
PDA indicator................................................521
Pre-collision system ...................................521
Seat belt reminder light ...............519, 520
Slip indicator ................................................522
SRS..................................................................... 518
Tire pressure................................................520

Warning messages..................................... 526
Washer

Adding ........................................................... 480

Preparing and checking before winter

..........................................................................402

Switch.................................................................241

Washing and waxing..................................458
Weight

Cargo capacity..................................193, 196
Load limits ...................................................... 196
Weight............................................................568

Wheels.............................................................495

Size....................................................................576

Window lock switch ...................................... 171
Windows

Power windows........................................... 169
Rear window defogger............................ 416
Washer .............................................................241

Windshield wipers

Position............................................................243
Rain-sensing windshield wipers...........241

Winter driving tips.......................................402
Wireless charger.........................................435
Wireless remote control

Battery-Saving Function.......................... 140
Locking/Unlocking .....................................115
Replacing the battery................................501

For information regarding the

equipment listed below, refer to
the “MULTIMEDIA OWNER’S
MANUAL”.

· Voice control system
· Navigation system
· Audio/visual system
· Panoramic view monitor
· Lexus parking assist monitor

Lexus RX500h (2023 year). Manual in english - page 19
