567

9-1. For owners

9

For owners

AVERTISSEMENT

Les occupants des sièges avant ne

doivent en aucun cas tenir d'objets sur

leurs genoux.

Ne vous appuyez pas contre la porte,

le rail latéral de toit ou les montants

avant, latéraux ou arrière.

Ne laissez personne s'agenouiller sur

un siège en appui contre la porte ou

sortir la tête ou les mains à l'extérieur

du véhicule.

Ne fixez rien et ne posez rien sur des

emplacements tels que la planche de

bord, la garniture du volant et la partie

inférieure du tableau de bord.

Ne fixez rien à des emplacements tels

que les portes, la vitre du pare-brise,

les vitres latérales, les montants avant

ou arrière, des rails latéraux de toit et

des poignées de maintien.

Ne suspendez aucun cintre ou objet

dur aux crochets à vêtements. Ces

éléments peuvent se transformer en

projectiles si les coussins gonflables

rideaux SRS se déploient, le choc pou-

vant entraîner des blessures graves,

voire mortelles.

Si un cache en vinyle est fixé sur la

zone où le coussin gonflable de

genoux SRS se déploie, veillez à le

retirer.

568

9-1. For owners

AVERTISSEMENT

N'utilisez aucun accessoire de siège

recouvrant les zones de déploiement

des coussins gonflables SRS, car il ris-

que de gêner le déploiement des

coussins gonflables SRS. De tels

accessoires peuvent empêcher les

coussins gonflables SRS de se

déployer correctement, peuvent dés-

activer le système ou entraîner le

déploiement involontaire des coussins

gonflables SRS, ce qui peut éventuel-

lement occasionner des blessures

graves, voire mortelles.

Évitez de faire subir des chocs ou des

pressions excessives aux composants

des systèmes de coussins gonflables

SRS, aux portes avant ou à leur zone

adjacente.

En effet, cela pourrait entraîner un dys-

fonctionnement des coussins gonfla-

bles SRS.

Ne touchez aucun composant des

coussins gonflables SRS immédiate-

ment après leur déploiement (gon-

flage), car ils peuvent être chauds.

Si vous avez des difficultés à respirer

après le déploiement des coussins

gonflables SRS, ouvrez une porte ou

une vitre pour faire entrer de l'air frais,

ou bien descendez du véhicule si cela

ne présente pas de danger. Essuyez

tout résidu dès que possible afin

d'éviter d'éventuelles irritations de la

peau.

Si une zone renfermant un coussin

gonflable SRS est endommagée ou

craquelée, faites-la remplacer par

votre concessionnaire Lexus.

Ne placez rien sur le siège du pas-

sager avant, comme un coussin par

exemple. Cela a pour conséquence de

répartir le poids du passager sur toute

la surface du siège, ce qui empêche le

capteur de détecter correctement le

poids du passager. En conséquence,

les coussins gonflables frontaux SRS

du siège du passager avant risquent de

ne pas se déployer en cas de collision.

Modification et mise au rebut des

composants du système de coussins

gonflables SRS

Ne mettez pas votre véhicule au rebut et

ne procédez à aucune des modifications

suivantes sans consulter votre conces-

sionnaire Lexus. Les coussins gonflables

SRS peuvent ne pas fonctionner cor-

rectement ou se déployer involontaire-

ment, ce qui peut provoquer des

blessures graves, voire mortelles.

Dépose, repose, démontage ou répa-

ration des coussins gonflables SRS

Réparation, dépose ou modification

des pièces suivantes ou de leurs alen-

tours

• Volant

• Tableau de bord

• Planche de bord

• Sièges

• Garnissage des sièges

• Montants avant

• Montants latéraux

• Montants arrière

• Rails latéraux de toit

• Panneaux de portes avant

• Garniture de porte avant

• Haut-parleurs de porte avant

569

9-1. For owners

9

For owners

Véhicules sans phares à faisceau
unique

Boulon de réglage A
Boulon de réglage B

Véhicules avec phares à faisceau
unique

Boulon de réglage A
Boulon de réglage B

AVERTISSEMENT

Modifications des panneaux de portes

avant (par exemple, perçage de trous

dans les panneaux)

Réparation ou modification des pièces

suivantes ou de leurs alentours

• Aile avant

• Pare-chocs avant

• Côtés de l'intérieur du véhicule

Installation des pièces suivantes ou

accessoires

• Pare-buffle ou pare-kangourou

• Chasse-neige

• Treuils

• Porte-bagages de toit

Modifications de la suspension du

véhicule

Installation d'appareils électroniques

tels que les émetteurs/récepteurs

radios mobiles et les lecteurs CD

Modifications apportées à votre

véhicule pour les personnes atteintes

d'un handicap physique

Headlight aim instructions
for Canadian owners (in
French)

The following is a French explana-
tion of headlight aim instructions
from the headlight aim section in
this manual.

Boulons de réglage du mouve-
ment vertical

A
B

A
B

570

9-1. For owners

1

Vérifiez que le réservoir de carbu-
rant du véhicule est plein et que la
zone autour des phares n'est pas
déformée.

2

Stationnez le véhicule sur une sur-
face plane.

3

Installez-vous dans le siège con-
ducteur.

4

Balancez le véhicule plusieurs fois.

1

À l'aide d'un tournevis cruciforme,
tournez le boulon A dans n'importe
quel sens.

Mémorisez le sens dans lequel vous avez

tourné et le nombre de tours.

Véhicules sans phares à faisceau
unique

Véhicules avec phares à faisceau
unique

2

Tournez le boulon B du même
nombre de tours dans le même
sens qu'à l'étape

1

.

Si vous n'arrivez pas à régler le phare en

procédant de la sorte, confiez le véhicule à

votre concessionnaire Lexus pour qu'il

règle le faisceau des phares.

Véhicules sans phares à faisceau
unique

Véhicules avec phares à faisceau
unique

Avant de vérifier le réglage des
phares

Réglage du faisceau des phares

571

Index

.

What to do if... (Troubleshooting)

........................................................

572

Alphabetical Index....................

574

572

What to do if... (Troubleshooting)

1-1.What to do if... (Troubleshooting)

What to do if... (Troubleshooting)

If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
(

P.509)

If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. (

P.509)

Is the electronic key battery weak or
depleted? (

P.460)

Is the engine switch in ON?

When locking the doors, turn the engine
switch off. (

P.196)

Is the electronic key left inside the
vehicle?

When locking the doors, make sure that
you have the electronic key on your per-
son.

The function may not operate prop-

erly due to the condition of the radio
wave. (

P.127)

Is the child-protector lock set?

The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. (

P.109)

Did you press the engine switch
while firmly depressing the brake
pedal? (

P.194)

Is the electronic key anywhere
detectable inside the vehicle?
(

P.126)

Is the electronic key battery weak or
depleted?

In this case, the engine can be started in a
temporary way. (

P.511)

Is the battery discharged? (

P.514)

Is the window lock switch pressed?

The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. (

P.157)

If you have a problem, check the
following before contacting your
Lexus dealer.

The doors cannot be locked,
unlocked, opened or closed

You lose your keys

The electronic key does not
operate properly

The doors cannot be locked or
unlocked

The rear door cannot be opened

If you think something is wrong

The engine does not start

The windows do not open or
close by operating the power
window switches

573

What to do if... (Troubleshooting)

The auto power off function will be
operated if the vehicle is left in ACC
or ON (the engine is not running)
for a period of time. (

P.197)

The seat belt reminder light is flash-
ing

Are the driver and the passengers wearing
the seat belts? (

P.482

, 482

)

The parking brake indicator is on

Is the parking brake released? (

P.204)

Depending on the situation, other
types of warning buzzer may also
sound. (

P.479, 489)

Did anyone inside the vehicle open
a door during setting the alarm?

The sensor detects it and the alarm sounds.
(

P.71)

Do one of the following to deactivate
or stop the alarms:

Unlock the doors.

Turn the engine switch to ACC or
ON, or start the engine. (The alarm
will be deactivated or stopped after
a few seconds.)

Is the message displayed on the
multi-information display?

Check the message on the multi-informa-
tion display. (

P.489)

When a warning light turns on or a
warning message is displayed, refer
to P.479, 489.

Stop the vehicle in a safe place and
replace the flat tire with the spare
tire. (

P.500)

Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. (

P.522)

The engine switch is turned off
automatically

A warning buzzer sounds during
driving

An alarm is activated and the
horn sounds

A warning buzzer sounds when
leaving the vehicle

A warning light turns on or a
warning message is displayed

When a problem has occurred

If you have a flat tire

The vehicle becomes stuck

574

Alphabetical Index

Alphabetical Index

A

A/C

Air conditioning filter ...............................459
Front automatic air conditioning system

.......................................................................... 381

Front seat concentrated airflow mode

(S-Flow) ......................................................384

Rear air conditioning system ...............390

ABS (Anti-lock Brake System).............. 367

Warning light................................................ 481

ACA (Active Cornering Assist)........... 367
Active Cornering Assist (ACA)........... 367
Adaptive High-beam System...................212
Adaptive Variable Suspension System368
Advanced Park ............................................338
AHS (Adaptive High-beam System)....212
Air conditioning filter.................................459
Air conditioning system

Air conditioning filter ...............................459
Front automatic air conditioning system

.......................................................................... 381

Front seat concentrated airflow mode

(S-Flow) ......................................................384

Rear air conditioning system ...............390

Airbags

Airbag operating conditions............ 31, 32
Airbag precautions for your child........ 33
Correct driving posture............................ 25
Curtain shield airbag precautions ....... 33
Front passenger occupant classification

system ..............................................................37

General airbag precautions ................... 33
Modification and disposal of airbags .36
Side airbag precautions............................ 33
Side and curtain shield airbags precau-

tions.................................................................. 33

SRS airbags .....................................................30
SRS warning light ..................................... 480

Alarm.....................................................................71

Warning buzzer......................................... 479

Anchor brackets.......................................49, 61

Antennas (smart access system with

push-button start).......................................125

Anti-lock Brake System (ABS).............. 367

Warning light ................................................481

Approach warning...................................... 279
Armrest............................................................... 411
Assist grips ........................................................ 411
Audio system-linked display...................... 96
Automatic headlight leveling system ..... 211
Automatic light control system................210
Automatic transmission............................. 198

M mode ..........................................................202
Paddle shift switches..................... 201, 202

Auxiliary boxes.............................................400
Average fuel economy................................. 92
Average vehicle speed ................................ 92
AWD Control.................................................. 96

B

Back door ..........................................................110
Back-up light

Wattage........................................................... 531

Back-up lights

Replacing light bulbs................................466

Battery

Battery checking ........................................442
If the battery is discharged..................... 514
Preparing and checking before winter

..........................................................................373

Replacing .........................................................517
Warning light ..............................................480

Blind Spot Monitor (BSM)........................ 301
Boost gauge...................................................... 94
Bottle holders................................................399
Brake

Brake hold.....................................................207
Fluid........................................................ 441, 529
Parking brake ..............................................204
Warning light ...............................................479

Brake assist .................................................... 367
Break-in tips.....................................................174

575

Alphabetical Index

Brightness control

Instrument panel light control ................84

BSM (Blind Spot Monitor)........................ 301
Buzzer

Driver monitor.............................................236

C

Camera

Driver monitor.............................................236

Care

Exterior ........................................................... 422
Interior.............................................................425
Seat belts........................................................425
Wheels and wheel ornaments............ 422

Cargo capacity.....................................179, 182
Cargo hooks .................................................. 401
Cargo net hooks........................................... 401
Chains .............................................................. 374
Child restraint system

Fixed with a LATCH system ..................56
Fixed with a seat belt................................... 52
Front passenger occupant classification

system ..............................................................37

Points to remember .................................... 44
Riding with children..................................... 43
Types of child restraint system installation

method ........................................................... 49

Using a top tether anchorage................63
Using an anchor bracket............................61

Child safety

Airbag precautions...................................... 33
Battery precautions.......................443518
Child restraint system................................. 49
Heated steering wheel and seat heater

precautions................................................392

How your child should wear the seat belt

.............................................................................27

Moon roof precautions ........................... 159
Panoramic moon roof precautions....162
Power back door precautions...............110
Power window lock switch.....................157
Power window precautions.................. 156

Rear door child-protectors ...................109
Seat belt extender precautions..............28
Seat belt precautions ..................................43

Child-protectors........................................... 109
Cleaning

Exterior............................................................422
Interior .............................................................425
Radar sensor..................................................231
Seat belts........................................................425
Wheels and wheel ornaments............422

Clock ...........................................................78, 80
Coat hooks.......................................................412
Coin box..........................................................400
Condenser .......................................................441
Console box ..................................................398
Console box light ........................................398
Cooling system.............................................440

Engine overheating....................................519

Cornering lights.............................................212

Replacing light bulbs................................466

Cruise control

Dynamic radar cruise control.............. 272

Cup holders...................................................398
Current fuel consumption .......................... 92
Curtain shield airbags ..................................30
Customizable features..............................543

D

Daytime running light system...................210
Daytime running lights

Replacing light bulbs................................466

Deck board....................................................403
Deck under tray ...........................................403
Defogger

Outside rear view mirrors.................... 386
Rear window............................................... 386
Windshield.......................................385, 386

Differential

Rear differential oil.................................... 528

Digital Rear-view Mirror............................143
Dimension ...................................................... 524
Dinghy towing.................................................193

576

Alphabetical Index

Display

center display....................................................91
Dynamic radar cruise control ............. 275
Head-up display ................................... 88, 91
Intuitive parking assist................................. 311
Multi-information display...................85, 91
RCD (Rear Camera Detection)........ 324
RCTA ................................................................319
Warning message.....................................489

Distance until next engine oil change....83
Do-it-yourself maintenance.................... 429
Door courtesy lights................................... 394

Wattage............................................................531

Door lock

Power back door..........................................110
Side doors...................................................... 105
Smart access system with push-button

start..................................................................125

Wireless remote control...........................101

Doors

Automatic door locking and unlocking

system ........................................................... 109

Door glasses................................................. 155
Door lock warning buzzer .................... 106
Outside rear view mirrors ......................152
Rear door child-protectors................... 109
Side doors...................................................... 105

Downhill assist control system...............365
Drive distance.................................................. 92
Driver’s seat position memory

Driving position memory.........................164
Memory recall function ............................166
Power easy access system.....................164

Drive-Start Control (DSC) .......................178
Driving

Break-in tips...................................................174
Correct driving posture............................ 25
Driving mode select switch..................362
Procedures.....................................................173
Winter drive tips......................................... 373

Driving information display ........................ 92

Driving position memory............................164

Memory recall function............................ 166
Power easy access system .................... 164

Driving range ................................................... 92
Driving support system information........97
DSC (Drive-Start Control) .......................178
Dynamic radar cruise control .................272

Warning message.....................................279

Dynamic Torque Control AWD system

.......................................................................... 367

E

Eco Driving Indicator.................................... 93
Eco Driving Indicator Light........................ 93
Eco heat/cool ...............................................384
EDR (Event data recorder)........................... 9
Elapsed time ..................................................... 92
Electric Power Steering (EPS) .............. 367

Warning light ................................................481

Electronic key ......................................100, 103

Battery-saving function.............................126
If the electronic key does not operate

properly........................................................510

Replacing the battery.............................. 460

Electronic sunshade

Jam protection function.............................161
Operation.......................................................160

Emergency Driving Stop System .........288
Emergency flashers.................................... 470
Emergency, in case of

If a warning buzzer sounds...................479
If a warning light turns on.......................479
If a warning message is displayed.... 489
If the battery is discharged..................... 514
If the electronic key does not operate

properly........................................................510

If the engine will not start.......................508
If the vehicle is submerged or water on

the road is rising........................................471

If you have a flat tire .................................500
If you lose your keys................................509
If you think something is wrong.......... 477

577

Alphabetical Index

If your vehicle becomes stuck.............522
If your vehicle has to be stopped in an

emergency ................................................470

If your vehicle needs to be towed..... 473
If your vehicle overheats......................... 519

Engine

ACCESSORY mode ...............................196
Compartment ............................................. 437
Engine switch.................................................194
Fuel pump shut off system ....................478
Hood................................................................435
How to start the engine............................194
Identification number...............................525
If the engine will not start ......................508
If your vehicle has to be stopped in an

emergency ................................................470

Ignition switch (engine switch) .............194
Overheating.................................................. 519
Tachometer ............................................78, 80

Engine coolant

Capacity......................................................... 527
Checking .......................................................440
Preparing and checking before winter

......................................................................... 373

Engine coolant temperature gauge78, 80
Engine immobilizer system ........................ 70
Engine oil

Capacity.........................................................526
Checking ....................................................... 437
Preparing and checking before winter

......................................................................... 373

Warning light.............................................. 480

Engine oil maintenance data .................. 439
Engine oil pressure gauge.......................... 94
Engine oil temperature gauge.................. 94
Engine switch ..................................................194

Auto power off function ...........................197
Changing the engine switch modes..196
If your vehicle has to be stopped in an

emergency ................................................470

EPS (Electric Power Steering) .............. 367

Warning light................................................ 481

Event data recorder (EDR)........................... 9

F

FCTA (Front Cross Traffic Alert)..........267
Fixed with an ISOFIX lower anchorage58
Flat tire

Tire pressure warning system .............447
Vehicles with a spare tire......................500

Floor mats.......................................................... 24
Fluid

Brake................................................................529
Transmission................................................ 528
Washer ...........................................................444

Fog lights

Switch................................................................ 218

Footwell lights ............................................... 394
Front automatic air conditioning system

........................................................................... 381

Front Cross Traffic Alert (FCTA)..........267
Front fog lights

Replacing light bulbs................................466

Front passenger occupant classification

system ...............................................................37

Front seats

Adjustment.....................................................130
Cleaning.........................................................425
Correct driving posture ............................25
Driving position memory........................ 164
Head restraints.............................................138
Memory recall function............................ 166
Power easy access system .................... 164
Seat heaters..................................................392
Seat position memory .............................. 164
Seat ventilators............................................392

Front side marker light

Light switch.................................................... 210
Replacing light bulbs................................466

Front side marker lights

Wattage........................................................... 531

Front turn signal lights

Replacing light bulbs................................466
Turn signal lever .........................................204

578

Alphabetical Index

Wattage............................................................531

Fuel

Capacity.........................................................525
Fuel gauge ..............................................78, 80
Fuel pump shut off system ....................478
Information....................................................532
Refueling ........................................................ 225
Type..................................................................525
Warning light...............................................482

Fuel consumption

Average fuel economy.............................. 92
Current fuel consumption........................ 92

Fuel filler door

Refueling ........................................................ 225

Fuel gauge.................................................78, 80
Fuel pump shut off system........................ 478
Fuses................................................................. 462

G

Garage door opener...................................414
Gauges............................................................... 78
Gear Position................................................... 95
G-force............................................................... 94
Glove box.......................................................398
Glove box light.............................................398
Grocery bag hooks....................................402

H

Hands Free Power Back Door................. 114
Head restraints.............................................. 138
Headlight aim................................................ 464
Headlights

Adaptive High-beam System ...............212
Light switch.....................................................210
Replacing light bulbs................................466

Head-up display..............................................88

Driving information display area...........88
Settings ..............................................................89

Heated steering wheel.............................. 392

Heaters

Front automatic air conditioning system

...........................................................................381

Heated steering wheel............................392
Outside rear view mirrors.................... 386
Rear air conditioning system .............. 390
Seat heaters..................................................392

High mounted stoplight

Replacing light bulbs................................466

Hill-start assist control............................... 367
Hood

Open................................................................435

Hooks

Cargo hooks................................................. 401
Cargo net hooks......................................... 401
Coat hooks .....................................................412
Grocery bag hooks..................................402
Retaining hooks (floor mat)..................... 24

Horn..................................................................... 141

I

I/M test ............................................................ 432
Identification

Engine..............................................................525
Vehicle ............................................................524

If your vehicle has to be stopped in an

emergency.................................................. 470

Ignition switch (engine switch).................194

Auto power off function............................197
Changing the engine switch modes. 196
If your vehicle has to be stopped in an

emergency.................................................470

Indicators ............................................................76
Initialization

Items to initialize ........................................ 559
Maintenance.................................... 428, 439
Power windows...........................................155

Inside rear view mirror......................142, 143
Instrument panel light control ...................84
Intercooler........................................................441
Intercooler coolant

Capacity .........................................................527

579

Alphabetical Index

Checking .......................................................440

Interior lights.................................................. 394
Intuitive parking assist

Function........................................................... 310
Warning message.......................................312

ISOFIX lower anchorage ...........................58

J

Jack

Positioning a floor jack............................435
Vehicle-equipped jack............................ 501

Jack handle ..................................................... 501
Jam protection function

Electronic sunshade.................................... 161
Moon roof...................................................... 158
Panoramic moon roof................................ 161
Power back door...........................................117
Power windows........................................... 155
Rear seats........................................................132

K

Keyless entry

Smart access system with push-button

start..................................................................125

Wireless remote control...........................101

Keys

Battery-saving function ............................126
Electronic key...............................................100
Engine switch.................................................194
If the electronic key does not operate

properly........................................................ 510

If you lose your keys................................ 509
Key number plate.......................................100
Keyless entry.........................................101, 125
Mechanical key............................................100
Replacing the battery...............................460
Warning buzzer...........................................126
Wireless remote control...........................101

Knee airbags ....................................................30

L

Lane change Assist (LCA)......................253
Lane Departure Alert (LDA) ................. 256
Lane Tracing Assist (LTA)

Operation......................................................248

LATCH anchors ............................................. 56
LCA (Lane change Assist)......................253
LDA (Lane Departure Alert) ................. 256
Lever

Auxiliary catch lever.................................435
Hood lock release lever.........................435
Shift lever.........................................................198
Turn signal lever .........................................204
Wiper lever.....................................................219

Lexus climate concierge ..........................380
Lexus Safety System + 3

AHS (Adaptive High-beam System) 212
Driver monitor.............................................236
Dynamic radar cruise control.............. 272
Emergency Driving Stop System ..... 288
FCTA (Front Cross Traffic Alert)......267
LCA (Lane change Assist)...................253
LDA (Lane Departure Alert)...............256
LTA (Lane Tracing Assist)....................248
PCS (Pre-Collision System)................238
PDA (Proactive driving assist)............262
RSA (Road Sign Assist)..........................270
Traffic Jam Assist....................................... 290

Lexus Teammate Advanced Park........338
License plate lights

Light switch.................................................... 210
Replacing light bulbs................................466

Light bulbs

Replacing ...................................................... 465

Lights

Automatic High Beam system............. 215
Fog light switch............................................ 218
Front personal lights................................ 395
Headlight switch.......................................... 210
Interior lights....................................394, 395
Interior lights list..........................................394

580

Alphabetical Index

Rear personal lights..................................395
Replacing light bulbs................................466
Turn signal lever.........................................204
Vanity lights....................................................413
Wattage............................................................531

LTA (Lane Tracing Assist)

Operation......................................................248

Luggage cover .............................................402

M

Maintenance

Do-it-yourself maintenance .................433
General maintenance.............................429
Maintenance data......................................524
Maintenance requirements ..................428

Malfunction indicator lamp .....................480
Max cool .........................................................385
Max heat .........................................................385
Meter

Clock .........................................................78, 80
Indicators .......................................................... 76
Instrument panel light control ................84
Meter control switches................................91
Meters ................................................................ 78
Multi-information display..........................85
Warning lights............................................. 479
Warning message.....................................489

Mirrors

Digital Rear-view Mirror..........................143
Inside rear view mirror..............................142
Outside rear view mirror defoggers386
Outside rear view mirrors ......................152
Vanity mirrors................................................413

Moon roof

Door lock linked moon roof operation

.......................................................................... 158

Door lock linked panoramic moon roof

operation ....................................................... 161

Jam protection function........................... 158
Operation........................................................157

Multi-information display............................85

Audio system-linked display...................96

AWD Control................................................96
Boost gauge....................................................94
Drive information..........................................92
Driving information display......................92
Driving support system information....97
Dynamic radar cruise control..............275
Eco Driving Indicator..................................93
Engine oil pressure gauge .......................94
Engine oil temperature gauge ...............94
Gear Position .................................................95
G-force..............................................................94
Meter control switches ................................91
Navigation system-linked display ........96
Pop-up display...............................................85
Pop-up display information.....................97
Tire pressure ................................................447
Warning message.................................... 489

My Settings ..................................................... 168

N

Navigation system-linked display............ 96
Noise from under vehicle ...............................6

O

“ODO TRIP” switch ......................................84
Odometer .........................................................83
Odometer and trip meter display

Display items...................................................83
“ODO TRIP” switch....................................84

Oil

Engine oil........................................................526
Rear differential oil.................................... 528

Opener

Fuel filler door..............................................225
Hood................................................................435

Outer foot lights

Location..........................................................394
Replacing light bulbs................................466

Outside door handle lights...................... 394
Outside rear view mirrors

Adjustment..................................................... 152

581

Alphabetical Index

BSM (Blind Sport Monitor) .................. 301
Folding ..............................................................153
Linked mirror function when reversing

...........................................................................153

Mirror position memory...........................164
Outside rear view mirror defoggers386
RCTA function..............................................319
Safe Exit Assist............................................306

Outside temperature............................78, 80
Overheating....................................................519

P

Paddle shift switches........................201, 202
Panic mode ......................................................102
Panoramic moon roof

Jam protection function............................. 161
Operation....................................................... 160

Parking assist sensors (intuitive parking

assist).............................................................. 310

Parking brake

Operation......................................................204
Parking brake engaged warning buzzer

.........................................................................206

Warning light...............................................485
Warning message.....................................206

Parking lights

Light switch.....................................................210
Replacing light bulbs................................466

Parking Support Brake function (for

rear-crossing vehicles) .......................... 334

Function..........................................................334

Parking Support Brake function (rear

pedestrians)................................................335

Function..........................................................335

Parking Support Brake function (static

objects)...........................................................331

Function............................................................331

PCS (Pre-Collision System)

Function..........................................................238
Warning light...............................................483

PDA (Proactive driving assist)............... 262
Personal lights............................................... 394

PKSB (Parking Support Brake)............. 327
Pop-up display information.........................97
Power back door............................................110

Hands Free Power Back Door ............. 114
Smart access system with push-button

start .....................................................................111

Power easy access system ........................164
Power outlets ..................................................412
Power steering (Electric power steering

system).......................................................... 367

Warning light ................................................481

Power windows

Door lock linked window operation.156
Jam protection function...........................155
Operation.......................................................155
Window lock switch...................................157

Pre-Collision System (PCS)

Function..........................................................238
Warning light .............................................. 483

R

Radar cruise control (dynamic radar cruise

control) ..........................................................272

Radiator.............................................................441
RCD (Rear Camera Detection)

Function..........................................................324

RCTA

Function........................................................... 319

RCTA function .............................................320
Rear air conditioning system..................390
Rear Cross Traffic Alert (RCTA) ...........319
Rear door sunshades...................................413
Rear seats ..........................................................131

Adjustment......................................................132
Folding down the rear seatbacks........132
Head restraints.............................................138
Seat heaters..................................................392

Rear side marker lights

Light switch.................................................... 210
Replacing light bulbs................................466

Rear turn signal lights

Replacing light bulbs................................466

582

Alphabetical Index

Turn signal lever.........................................204
Wattage............................................................531

Rear view mirror

Digital Rear-view Mirror..........................143
Inside rear view mirror..............................142
Outside rear view mirrors ......................152

Rear window defogger .............................386
Rear window wiper..................................... 223
Refueling

Capacity.........................................................525
Fuel types.......................................................525
Opening the fuel tank cap.................... 225

Remote Connect............................................68
Replacing

Electronic key battery..............................460
Fuses ................................................................462
Light bulbs.....................................................465
Tires.................................................................500

Resetting the message indicating mainte-

nance is required......................................428

Rev indicator .................................................... 82
Rev peak............................................................. 82
Road Sign Assist (RSA) ............................ 270
RSA (Road Sign Assist) ............................ 270

S

Safe Exit Assist..............................................306
Safety Connect................................................ 65
Seat belt reminder light.............................482
Seat belts............................................................ 26

Automatic Locking Retractor ................28
Child restraint system installation......... 49
Cleaning and maintaining the seat belt

.........................................................................425

Emergency Locking Retractor..............28
How to wear your seat belt......................27
How your child should wear the seat belt

.............................................................................27

Pregnant women, proper seat belt use

............................................................................ 26

Reminder light and buzzer...................482
Seat belt extender .........................................27

Seat belt pretensioners..............................29
SRS warning light......................................480

Seat heaters................................................... 392
Seat position memory..................................164
Seat ventilators............................................. 392
Seating capacity.............................................182
Seats

Adjustment...........................................130, 132
Adjustment precautions................. 130, 131
Child seats/child restraint system installa-

tion ....................................................................43

Cleaning.........................................................425
Driving position memory........................ 164
Folding down the rear seatbacks........132
Head restraints.............................................138
Power easy access system .................... 164
Properly sitting in the seat ........................25
Seat heaters..................................................392
Seat position memory .............................. 164
Seat ventilators............................................392

Sensor

Automatic headlight system.................. 210
Automatic High Beam system............. 215
Digital Rearview Mirror............................147
Inside rear view mirror..............................142
Intuitive parking assist...............................310
LDA (Lane Departure Alert with steering

control) ........................................................256

LTA (Lane Tracing Assist)....................248
Radar sensor.......................230, 302, 307
Rain-sensing windshield wipers.........220
RCTA...............................................................320

Service Connect............................................. 69
Service reminder message .....................428
Shift lever

Automatic transmission...........................198

Shift lever light .............................................. 394
Side airbags ......................................................30
Side doors........................................................ 105
Side marker lights

Light switch.................................................... 210
Replacing light bulbs................................466

583

Alphabetical Index

Side mirrors

Adjustment......................................................152
BSM (Blind Sport Monitor) .................. 301
Folding ..............................................................153
Linked mirror function when reversing

...........................................................................153

Mirror position memory...........................164
RCTA function..............................................319

Side turn signal lights

Replacing light bulbs................................466
Turn signal lever.........................................204

Side windows ................................................. 155
Smart access system with push-button

start

Antenna location..........................................125
Entry functions....................................... 105, 111
Starting the engine......................................194

Snow tires ....................................................... 373
Spare tire.........................................................500

Storage location.......................................... 501

Spark plug ...................................................... 527
Specifications................................................ 524
Speedometer ...........................................78, 80
Steering wheel

Adjustment........................................................141
Heated steering wheel............................392
Meter control switches................................91
Power easy access system.....................164
Steering wheel position memory ........164

Stop & Start system .................................... 296

Warning light...............................................483

Stop lights

Replacing light bulbs................................466

Storage features .......................................... 397
Stuck

If the vehicle becomes stuck................ 522

Sun visors..........................................................413
Sunshade

Panoramic moon roof.............................. 160
Roof ................................................................... 158

Switches

Advanced Park main switch................343

Automatic High Beam system............. 215
Brake Hold switch.....................................207
Digital Rear-view Mirror control switches

............................................................................143

Door lock switches .................................... 107
Driving mode select switch ..................362
Driving position memory switches .... 164
Dynamic radar cruise control switch275
Electronic sunshade switch ...................160
Emergency flashers switch ...................470
Engine switch................................................ 194
Fog light switch............................................ 218
Garage door opener switches.............414
Heated steering wheel switch.............392
Ignition switch............................................... 194
Instrument panel light control switches

.............................................................................84

Intuitive parking assist switch.................. 311
Light switches ............................................... 210
Meter control switches ................................91
Moon roof switches....................................157
“ODO TRIP” switch....................................84
Outside rear view mirror switches.... 152
Paddle shift switches..................... 201, 202
Panoramic moon roof switches ..........160
Parking brake switch................................204
PKSB (Parking Support Brake) switch

..........................................................................328

Power window switches .........................155
RCD (Rear Camera Detection) switch

..........................................................................324

RCTA switch................................................. 319
Seat heater switches.................................392
Seat ventilator switches ..........................392
“SOS” button...................................................65
Stop & Start cancel switch....................296
Tilt and telescopic steering control switch

............................................................................. 141

Vehicle-to-vehicle distance switch...275
VSC OFF switch ...................................... 368
Window lock switch...................................157
Windshield wiper and washer switch219

584

Alphabetical Index

T

Tachometer...............................................78, 80

Rev indicator...................................................82
Rev peak ...........................................................82

Tail lights

Light switch.....................................................210
Replacing light bulbs................................466

The Secondary Collision Brake ............368
Theft deterrent system

Alarm .................................................................... 71
Engine immobilizer system ..................... 70

Tire inflation pressure

Maintenance data..................................... 530
Tire inflation pressure display function

......................................................................... 447

Warning light...............................................483

Tire information............................................534

Glossary........................................................ 538
Size....................................................................536
Tire identification number .....................535
Uniform Tire Quality Grading............536

Tire pressure display...................................447
Tire pressure warning system

Function.......................................................... 447
Installing tire pressure warning valves

and transmitters ......................................449

Registering ID codes...............................452
Registering the position of each wheel

.........................................................................449

Selecting wheel set...................................454
Setting the tire pressure .........................450
Warning light...............................................483

Tires

Chains............................................................. 374
Checking .......................................................445
If you have a flat tire.................................500
Inflation pressure........................................455
Information....................................................534
Replacing......................................................500
Rotating tires................................................ 447
Size................................................................... 530

Snow tires ......................................................373
Spare tire.......................................................500
Tire inflation pressure display function

..........................................................................447

Tire pressure warning system .............447
Warning light .............................................. 483

Tools................................................................... 501
Top tether anchorage................................... 63
Top tether strap.................................................61
Total load capacity...................................... 524
Towing

Dinghy towing.............................................. 193
Emergency towing....................................473
Towing eyelet...............................................475
Trailer towing................................................183

TRAC (Traction Control) ........................ 367
Traction Control (TRAC) ........................ 367
Traffic Jam Assist.........................................290
Trail Mode...................................................... 364
Trailer Sway Control.................................. 367
Trailer towing ................................................. 183
Transmission

Automatic transmission...........................198
Driving mode select switch ..................362
M mode ..........................................................202
Paddle shift switches..................... 201, 202

Trip meters ........................................................83
Turn signal lights

Replacing light bulbs................................466
Turn signal lever .........................................204
Wattage........................................................... 531

U

USB charging ports....................................404

V

Vanity lights......................................................413

Wattage........................................................... 531

Vanity mirrors .................................................413
Vehicle data recording....................................7
Vehicle identification number................ 524

585

Alphabetical Index

Vehicle Stability Control (VSC) ........... 367
Ventilators (seat ventilators)................... 392
VSC (Vehicle Stability Control) ........... 367

W

Warning buzzers

ABS ................................................................... 481
Airbags .......................................................... 480
Approach warning.................................... 279
Brake system ............................................... 479
Charging system ...................................... 480
Cruise control .............................................484
Door lock........................................................ 106
Downshifting....................................202, 203
Dynamic radar cruise control .............484
Electric power steering ........................... 481
High coolant temperature .................... 479
Inappropriate pedal operation ............ 481
Intuitive parking assist...................316, 483
LDA (Lane Departure Alert)...............484
Low engine oil pressure........................ 480
LTA (Lane Tracing Assist)........248, 484
Open window.............................................. 156
PDA (Proactive Driving Assist) .........484
Pre-collision system .................................483
Pre-collision warning...............................238
Seat belt..........................................................482
Tire pressure................................................483

Warning lights............................................... 479

ABS ................................................................... 481
Brake hold operated indicator ...........486
Brake system ............................................... 479
Charging system ...................................... 480
Cruise control indicator.........................484
Driving assist information indicator..485
Dynamic radar cruise control indicator

.........................................................................484

Electric power steering ........................... 481
High coolant temperature .................... 479
Inappropriate pedal operation warning

light ................................................................. 481

Intuitive parking assist OFF indicator

......................................................................... 483

LDA indicator............................................. 484
Low engine oil pressure........................480
Low fuel level ...............................................482
LTA indicator.............................................. 484
Malfunction indicator lamp..................480
Parking brake indicator ......................... 485
PDA indicator............................................. 484
Pre-collision system................................. 483
Seat belt reminder light...........................482
Slip indicator................................................ 485
SRS...................................................................480
Stop & Start cancel indicator.............. 483
Tire pressure ............................................... 483

Warning messages.....................................489
Washer

Adding.............................................................444
Preparing and checking before winter

..........................................................................373

Switch.................................................................219

Washing and waxing.................................. 422
Weight

Cargo capacity..................................179, 182
Load limits ...................................................... 182
Weight.............................................................524

Wheels............................................................. 457

Size................................................................... 530

Window lock switch .....................................157
Windows

Power windows...........................................155
Rear window defogger.......................... 386
Washer .............................................................219

Windshield wipers

Position..............................................................221
Rain-sensing windshield wipers...........219

Winter driving tips....................................... 373
Wireless charger.........................................405
Wireless remote control

Battery-Saving Function...........................126
Locking/Unlocking .....................................101
Replacing the battery.............................. 460

586

Alphabetical Index

For information regarding the

equipment listed below, refer to
the “MULTIMEDIA OWNER’S
MANUAL”.

· Voice control system
· Navigation system
· Audio/visual system
· Panoramic view monitor
· Lexus parking assist monitor















Content      ..     16      17      18
