2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

■

Changing settings with the steering

wheel switches

If any of the following items have been set as

as a favorite steering wheel switch function,

settings of the head-up display can be

changed using the steering wheel switches.

●

: Display on/off

●

: Display mode

●

: Height

●

: Brightness

■

Enabling/disabling of the head-up dis-

play

If the head-up display is disabled, it will

remain disabled when the power switch is

turned off then back to ON.

■

Display brightness

In addition to the brightness setting, the

brightness of the display will change auto-

matically according to the ambient bright-

ness.

■

Head-up display automatic position

adjustment (vehicles with driving posi-

tion memory)

If the display position is recorded into mem-

ory, the head-up display will be automati-

cally adjusted to the desired position.

WARNING

■

Caution for changing settings of the

head-up display

As the hybrid system needs to be operat-

ing while changing the settings of the

head-up display, ensure that the vehicle

is parked in a place with adequate venti-

lation. In a closed area such as a garage,

exhaust gases including harmful carbon

monoxide (CO) may collect and enter

the vehicle. This may lead to death or a

serious health hazard.

NOTICE

■

When changing the settings of the

head-up display

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while the changing the settings of the

head-up display.

126

2-1. Instrument cluster



Vehicles without a head-up display

: Select menu icons

: Change displayed con-

tent, scroll up/down the screen and
move the cursor up/down
Return to the previous screen
Start/receive call

Linked with the hands-free system, sending
or receiving call is displayed. For details
regarding the hands-free system, refer to
the “MULTIMEDIA OWNER’S MAN-
UAL”.

Enter/Set



Vehicles with a head-up display

Center display
Steering switch

The function of each switch differs depending on the conditions and settings.
When a switch is touched, the function of each switch is displayed on the head-up display. If
the head-up display is off, or when it is not possible to display content on the head-up dis-
play, the functions will be displayed on the multi-information display.
Also, preferred functions for each switch can be set on the center display.

Displayed content

Components/Operations

B
C

A
B

127

2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

Switch function change switch

Each time this switch is pressed, the functions will change.

Switch icon display

The icon of each switch will be displayed. The touched switch will be highlighted. (

)

Switch function guide display

The function guide for the touched switch will be displayed.

■

Switching the display of the
multi-information display (vehicles
without a head-up display)

Press

of the meter con-

trol switch.



Switching driving information

Press the

meter control

switch to select

. Then press

or .

■

Switching the display of the
multi-information display (vehicles
with a head-up display)

Select

on the center display.

Select “Vehicle customise”.

Select “Meter”.

Select

of “Display

switching”.

The display changes each time the switch is

selected.

■

If the steering wheel switches do not

respond when touched (vehicles with a

head-up display)

●

It is easier to make the steering wheel

switches respond by moving your thumb

while touching them.

●

If the surface of a steering wheel switch is

dirty, turn the power switch off and then

clean the switches.

●

By turning winter glove mode on, the sen-

sitivity of the switch sensors can be

increased. (



P.623)

■

Switching with the steering wheel

switches (vehicles with a head-up dis-

play)

is set as a favorite

steering wheel switch function, the display
can be switched by pushing

Driving related information is dis-
played on the following displays.



Multi-information display



Head-up display (If equipped)



Center display

The items displayed will differ depend-
ing on the display.

The following items can be displayed
on the multi-information display.
Use the displayed values as a refer-
ence only.



Current fuel consumption

Displays instantaneous current fuel con-
sumption

Display of drive information

Drive information 1

128

2-1. Instrument cluster



Average fuel consumption

The following items can be displayed
on the multi-information display.



Average vehicle speed



Total driving time

The following items can be displayed
on the multi-information display.



Distance to empty

Displays the driving range with remaining
fuel.



Average fuel economy since start-
ing

Displays the average fuel consumption
since starting.

■

Distance to empty



P.118

The energy monitor and EV driving
ratio can be displayed on the
multi-information display.
The energy monitor screen can be dis-
played on the center display.

■

Displaying Energy monitor screen
on the center display

Select

on the main menu.

Select “Energy flow”.

■

Energy monitor

The energy monitor can be used to
check the vehicle drive status, hybrid
system operation status and energy
regeneration status.
The arrows will appear in accordance
with the energy flow. When there is no
energy flow, arrows will not be dis-
played.
The color of the arrows will change as
follows



Blue: When the hybrid battery (trac-
tion battery) is regenerated or
charged.



Orange: When the hybrid battery
(traction battery) is in use.



Red: When the gasoline engine is in
use.

The image shows all the arrows as an
example. The actual display will vary
depending on conditions.



Multi-information display

Gasoline engine
Tires
Hybrid battery (traction battery)

This illustration is for explanation only and
may differ depending on the specifications

Drive information 2

Drive information 3 (vehicles
without a head-up display)

Energy monitor/EV driving ratio
(If equipped)

A
B
C

129

2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

of the vehicle.



Center display

Gasoline engine
Front electric motor (traction
motor)
Hybrid battery (traction battery)
Rear electric motor (traction
motor)
Rear tires
Front tires

■

EV driving ratio since starting (If
equipped)

Displays the percentage of EV driving
since starting.
It is reset each time the hybrid system
stops.

■

Color of the hybrid battery (traction

battery) on the center display

It will be green when the hybrid battery

(traction battery) is being charged, and yel-

low when the hybrid battery (traction bat-

tery) is being used.

■

Remaining charge amount warning of

hybrid battery (traction battery)

●

The buzzer sounds intermittently when

the hybrid battery (traction battery)

remains without charging while the shift

position is in N, or the remaining charge

amount drops below a certain level. If the

remaining charge amount drops further,

the buzzer sounds continuously.

(RX350h)

●

When a warning message is shown on

the multi-information display and the

buzzer sounds, follow the instructions

displayed on the screen to perform trou-

bleshooting.

The following items can be displayed
on the multi-information display.

Boost gauge

Displays the boost pressure. The display
will change color if the specified pressure is
exceeded.

Engine oil temperature gauge

Displays the engine oil temperature. The
display will flash if the engine oil tempera-
ture exceeds 140 °C (284 °F).

Engine oil pressure gauge

Displays the engine oil pressure. A buzzer
will sound and warning message will be
displayed if the engine oil pressure
becomes low. (



P.554)

This display is intended for use as a guide-
line. Depending on factors such as the road
surface condition, temperature and vehicle
speed, the display may not show the actual
condition of the vehicle.

A
B

C
D

E
F

Boost gauge/engine oil tempera-
ture gauge/engine oil pressure
gauge (RX500h)

130

2-1. Instrument cluster

Displays lateral G-forces on the vehi-
cle on the multi-information display.
Displays around the periphery of the
G-force display, the left and right
steering amount, accelerator pedal
input, and brake fluid pressure.

Acceleration G-force on the vehi-
cle
Current G-force value (analyzed
value of front/rear and left/right
G-forces)
Record of the maximum G-forces
Accelerator pedal input
Brake fluid pressure
Left steering amount
Right steering amount



Resetting the record of maximum
G-forces

The display is reset each time the hybrid
system is started.



Peak hold function

If lateral G-forces of 0.5 G or greater are
generated, the G-force value display will
turn amber and be held for 2 seconds.

■

G-force display

●

The G-force values may not be zero even

when the vehicle is parked, such as when

it is parked on an incline.

●

Depending on the vehicle usage condi-

tions, the brake fluid pressure display may

not reach its maximum reading even

though the brake pedal is fully depressed.

●

If a 12-volt battery terminal is discon-

nected and reconnected, the steering

amount display may be disabled tempo-

rarily. After driving the vehicle for a while,

the display will be enabled.

Displays the current shift range or gear
position when the shift position is in D
or M.

Displays no drive information contents
on the multi-information display.

Fuel consumption information can be
displayed on the center display.

■

Displaying fuel consumption/his-
tory screen on the center display

Select

on the main menu.

Select “Trip information”.

Select “Current” or “History”.

G-force

C
D

E
F

Gear Position (RX500h)

Blank (No items)

Current fuel consumption/his-
tory screen

131

2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

■

Current fuel consumption screen

Resetting the history data
Fuel consumption in the past 15
minutes
Current fuel consumption
Average vehicle speed since the
hybrid system was started.
Trip range
Elapsed time since the hybrid sys-
tem was started.

Use the displayed average fuel consump-
tion as a reference. The image is an exam-
ple only, and may vary slightly from actual
conditions.

■

History fuel consumption screen

Latest fuel consumption
Best recorded fuel consumption
Previous fuel consumption record
Resetting the history data
Updating the latest fuel consump-

tion data

Use the displayed average fuel consump-
tion as a reference. The image is an exam-
ple only, and may vary slightly from actual
conditions.

■

Updating the history data

Update the latest fuel consumption by

selecting “Update” to measure the current

fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted

by selecting “Clear data”.

■

Trip range

Displays the estimated maximum distance

that can be driven with the quantity of fuel

remaining.
This distance is computed based on your

average fuel consumption.

As a result, the actual distance that can be

driven may differ from that displayed.

AWD operation status display can be
displayed on the center display.

■

Displaying AWD operation status
display on the center display

Select

on the main menu.

Select “All wheel drive”.

■

AWD operation status

Torque distribution display: Displays
the drive status of each wheel in 6
steps from 0 to 5.
The illustration used is intended as an
example, and may differ from the
image that is actually displayed on the
center display.

A
B

C
D

E
F

A
B
C
D

AWD operation status display

132

2-1. Instrument cluster

The tire pressure detected by the tire
pressure warning system can be dis-
played on the center display.

■

Displaying the tire pressure on the
center display

Select

on the main menu.

Select “Tyre pressure”.

■

Tire inflation pressure



P.511

The audio system-linked display dis-
plays the operating state of the audio
system on the multi-information dis-
play.
Operations such as selecting the audio
source or track, etc. can be performed.

The following information is displayed
on the multi-information display.



Route guidance to destination



Street name



Compass

■

Display position (vehicles with a

head-up display)

Depending on the display settings of the

head-up display, some content may be dis-

played on the head-up display and not in

the content display area of the multi-infor-

mation display.

The operating state of the following
systems can be displayed on the
multi-information display or head-up
display (if equipped).



Dynamic radar cruise control
(



P.317)



Cruise control (



P.331)



Speed limiter (if equipped)
(



P.336)



LTA (Lane Tracing Assist) (



P.292)



LDA (Lane Departure Alert)
(



P.301)



LCA (Lane Change Assist) (if
equipped) (



P.297)



RSA (Road Sign Assist) (if
equipped) (



P.314)



PDA (Proactive Driving Assist) (if
equipped) (



P.306)



PCS (Pre-Collision System)
(



P.279)

■

Display position (vehicles with a

head-up display)

When the display mode of the head-up dis-

play is set to display the maximum, driving

support system information will be dis-

Tire pressure

Audio system-linked display

Navigation system-linked dis-
play (if equipped)

Driving support system informa-
tion display

133

2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

played on the head-up display and not in

the content display area of the multi-infor-

mation display.

Pop-up displays will be displayed on
the multi-information display or the
head-up display (if equipped) when
necessary.

When a pop-up display is displayed, a cur-
rent display may no longer be displayed. In
this case, the display will return after the
pop-up display disappears.

■

Driving support systems

Displays a warning/suggestion/advice
message or the operating state of a rel-
evant system.



Dynamic radar cruise control



Cruise control



LTA (Lane Tracing Assist)



LDA (Lane Departure Alert)



LCA (Lane Change Assist) (if
equipped)



PDA (Proactive Driving Assist) (if
equipped)



PCS (Pre-Collision System)



RSA (Road Sign Assist) (if
equipped)



SEA (Safe Exit Assist [with Door
Opening Control]) (if equipped)



FCTA (Front Crossing Traffic Alert)
(if equipped)



Automatic Rear Flashing Hazard
Lights (if equipped)

■

Warning message

Some warning messages are displayed
when necessary, according to certain
conditions.

■

Hands-free system status

Displayed when the hands-free system
is operated.

■

Suggestion function

Displays suggestions to the driver in
the following situations. To select a
response to a displayed suggestion,
use the steering switches.



Suggestion to enable the power
back door

If the power back door system is disabled
(setting on the center display set to off) and
the power back door switch on the instru-
ment panel is operated, a suggestion mes-
sage will be displayed asking if you wish to
enable the power back door system.
To enable the power back door system,
select “Yes”.
After enabling the power back door sys-
tem, press the power back door switch
again to open or close the power back
door.



Suggestion to close the power win-
dows (linked to windshield wiper
operation)

If the windshield wipers are operated with
a power window open, a suggestion mes-
sage will be displayed asking if you wish to
close the power windows.
To close all of the power windows, select
“Yes”.



Suggestion to close the power win-
dows (Driving at high speeds)

Pop-up display information

134

2-1. Instrument cluster

If the vehicle speed exceeds a certain
speed with a power window open, a sug-
gestion message will be displayed asking if
you wish to close the power windows.
To close all of the power windows, select
“Yes”.

■

Steering wheel switch operation
display



Vehicles without a head-up display

Displayed when an audio remote con-
trol switch or a talk switch on the steer-
ing wheel is operated.



Vehicles with a head-up display

When a steering wheel switch is
touched, the icon of each switch and a
function guide is displayed.

■

Navigation system-linked informa-
tion (if equipped)

Depending on the situation, navigation
system-linked route guidance to desti-
nation may be displayed.

The following items will be displayed
on the multi-information display when
the power switch is turned off.



Average fuel consumption since
starting



Distance driven since starting



Driving time since starting



EV driving ratio since starting

Displays the percentage of EV driving
since starting.

: It is reset each time the hybrid system

stops.

Items displayed when the power
switch is turned off

135

fore
driving

Before driving

3-1. Key information

Keys .................................................

136

3-2. Opening, closing and locking the

doors

Side doors .....................................

140

Power back door .......................

145

Smart entry & start system......

161

3-3. Adjusting the seats

Front seats.....................................

166

Rear seats......................................

168

Head restraints............................

175

3-4. Adjusting the steering wheel and

mirrors

Steering wheel ............................

178

Inside rear view mirror.............

179

Digital Rear-view Mirror.........

180

Outside rear view mirrors......

189

3-5. Opening, closing the windows

and moon roof

Power windows ..........................

192

Moon roof .....................................

195

Panoramic moon roof..............

198

3-6. Favorite settings

Driving position memory .......

202

My Settings..................................

206

136

3-1. Key information

3-1.Key information

The following keys are provided with
the vehicle.

Electronic keys

• Operating the smart entry & start sys-

tem (



P.161)

• Operating the wireless remote control

function (



P.138)

Mechanical keys
Key number plate
Card key (electronic key) (if
equipped)

Operating the smart entry & start system
(



P.161)

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside

the card key should be used only if a

problem arises, such as when the card

key does not operate properly.

●

If it is difficult to take out the mechanical

key, push down the release button using a

pen tip, etc. If it is still difficult to pull it out,

use a coin, etc.

●

To store the mechanical key in the card

key, insert it while pressing the release

button.

●

If the battery cover is not installed and the

battery falls out or if the battery was

removed because the key got wet, rein-

stall the battery with the positive terminal

facing the Lexus emblem.

■

When riding in an aircraft

When bringing an electronic key onto an

aircraft, make sure you do not press any

buttons on the electronic key while inside

the aircraft cabin. If you are carrying an

electronic key in your bag, etc., ensure that

the buttons are not likely to be pressed acci-

dentally. Pressing a button may cause the

electronic key to emit radio waves that

could interfere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

(The card key battery life is about a year

and a half.)

●

If the battery becomes low, an alarm will

sound in the cabin when the hybrid sys-

Keys

The keys

B
C
D

137

3-1. Key information

fore
driving

tem is stopped.

●

To reduce key battery depletion when the

electronic key is to not be used for long

periods of time, set the electronic key to

the battery-saving mode. (



P.162)

●

As the electronic key always receives

radio waves, the battery will become

depleted even if the electronic key is not

used. The following symptoms indicate

that the electronic key battery may be

depleted. Replace the battery when nec-

essary.

• The smart entry & start system or the

wireless remote control does not oper-

ate.

• The detection area becomes smaller.

• The LED indicator on the key surface

does not turn on.

●

You can replace the battery by yourself

(



P.527). However, as there is a danger

that the electronic key may be damaged,

it is recommended that replacement is

carried out by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer for details.

●

To avoid serious deterioration, do not

leave the electronic key within 1 m (3 ft.)

of the following electrical appliances that

produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and

battery chargers

• Recharging cellular phones or cordless

phones

• Table lamps

• Induction cookers

●

If the electronic key is near the vehicle for

longer than necessary, even if the smart

entry & start system is not used, the key

battery may become depleted faster than

normal. When not using the smart entry

& start system, it is recommended not to

stay with the electronic key near the vehi-

cle longer than necessary.

■

Replacing the battery



P.527

■

Confirmation of the registered key

number

The number of keys already registered to

the vehicle can be confirmed. Ask any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer for

details.

■

If “A New Key has been Registered

Contact Your Dealer for Details” is

shown on the multi-information display

This message will be displayed each time

the driver’s door is opened when the doors

are unlocked from the outside for approxi-

mately one week after a new electronic key

has been registered.

If this message is displayed but you have not

had a new electronic key registered, ask

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer

to check if an unknown electronic key

(other than those in your possession) has

been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to

strong shocks or bend them.

●

Do not expose the keys to high tem-

peratures for long periods of time.

●

Do not get the keys wet or wash them

in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic

materials to the keys or place the keys

close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else

to the surface of the electronic key.

●

Do not place the keys near objects that

produce magnetic fields, such as TVs,

audio systems and induction cookers.

138

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks all the doors (



P.140)

Closes the windows

and the

moon roof

*1, 2

or panoramic moon

roof

*1, 2

(



P.140)

Unlocks all the doors (



P.140)

Opens the windows

and the

moon roof

*1, 2

or panoramic moon

NOTICE

●

Do not place the keys near medical

electrical equipment such as low-fre-

quency therapy equipment or micro-

wave therapy equipment, and do not

receive medical attention with the keys

on your person.

■

Carrying the electronic key on your

person

Carry the electronic key 10 cm (3.9 in.)

or more away from electric appliances

that are turned on. Radio waves emitted

from electric appliances within 10 cm

(3.9 in.) of the electronic key may inter-

fere with the key, causing the key to not

function properly.

■

In case of a smart entry & start system

malfunction or other key-related

problems



P.590

■

When an electronic key is lost



P.590

■

Handling the card key (if equipped)

●

Do not apply excess force when insert-

ing the mechanical key into the card

key. Doing so may damage the card

key.

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the key,

immediately remove the battery cover

and wipe the battery and terminals. (To

remove the battery cover, lightly grasp

and pull it.) If the battery is corroded,

have any authorized Lexus retailer or

Lexus authorized repairer, or any relia-

ble repairer replace the battery.

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover. Forcibly removing the battery

cover may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

A
B

C
D

139

3-1. Key information

fore
driving

roof

*1, 2

(



P.140)

Opens and closes the power back
door (



P.147)

: If equipped

: These settings must be customized at

any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.590)

■

When required to leave the vehicle’s

key with a parking attendant

Lock the glove box as circumstances

demand. (



P.461)

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.590

■

If a wrong key is used

The key cylinder rotates freely, isolated

from the internal mechanism.

Using the mechanical key

140

3-2. Opening, closing and locking the doors

3-2.Opening, closing and locking the doors

■

Smart entry & start system

Carry the electronic key to enable this
function.

Grip the door handle to unlock the
doors.

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (indentation
on the surface of the door handle)
to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.
Press and hold to close the windows

and

the moon roof

*1, 2

or panoramic moon

roof

*1, 2

Unlocks all the doors

Press and hold to open the windows

and

the moon roof

*1, 2

or panoramic moon

roof

*1, 2

: If equipped

: This setting must be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the power switch off.

Cancel the intrusion sensor and tilt sen-

sor of the alarm system to prevent unin-

tended triggering of the alarm while

changing the settings. (



P.102)

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5 seconds

while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

Side doors

The vehicle can be locked and
unlocked using the entry function,
wireless remote control or door
lock switches.

Unlocking and locking the doors
from the outside

141

3-2. Opening, closing and locking the doors

fore
driving

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

For vehicles with an alarm: To prevent unin-

tended triggering of the alarm, unlock the

doors using the wireless remote control and

open and close a door once after the set-

tings have been changed. (If a door is not
opened within 30 seconds after

pressed, the doors will be locked again and

the alarm will automatically be set.)

In a case that the alarm is triggered, imme-

diately stop the alarm. (



P.102)

■

Impact detection door lock release sys-

tem

If the vehicle is involved in a severe frontal

or rear collision, manual release handle

operation will be enabled for all of the

doors.

■

Operation signals

Doors:
The emergency flashers flash to indicate

that the doors have been locked/unlocked.

(Locked: Once; Unlocked: Twice)

Windows and moon roof or panoramic

moon roof:
A buzzer sounds.

■

Security feature

If a door is not opened within approximately

30 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

When the door cannot be locked by the

lock sensor on the surface of the door

handle

When the door cannot be locked even if the

lock sensor on the surface of the door han-

dle is touched by a finger, touch the lock

sensor with the palm.
When gloves are being worn, remove the

gloves.

■

Door lock buzzer

If an attempt to lock the doors is made when

a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the

door to stop the buzzer, and lock the vehi-

cle once more.

■

Setting the alarm (if equipped)

Locking the doors will set the alarm system.

(



P.102)

■

Conditions affecting the operation of

the smart entry & start system or wire-

less remote control



P.162

■

If the smart entry & start system or the

wireless remote control does not oper-

ate properly

Use the mechanical key to lock and unlock

the doors. (



P.590)

Replace the key battery with a new one if it

is depleted. (



P.527)

Multi-information

display/Beep

Unlocking function

(Left-hand drive vehi-

cles)

(Right-hand drive

vehicles)

Exterior: Beeps 3

times

Holding the driver’s
door handle unlocks
only the driver’s
door.

Holding any of the
passenger door
handles unlocks all
the doors.

Exterior: Beeps

twice

Holding a door han-
dle unlocks all the
doors.

142

3-2. Opening, closing and locking the doors

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

using the smart entry & start system or

wireless remote control. Lock or unlock the

doors using the mechanical key. (



P.590)

■

Passenger

and rear seat reminder

function

As the first reminder so as not to forget lug-

gage, etc. in the front passenger seat or a

rear seat, when the power switch is turned

off after any of the following conditions are

met, a buzzer will sound and a message will

be displayed on the multi-information dis-

play for approximately 6 seconds.
Also, as the second reminder, when the

doors are locked, a buzzer will sound and

the emergency flashers will flash for a few

seconds, and a message will be displayed

on the multi-information display

●

Rear seat reminder function: The hybrid

system is started within approximately 10

minutes after opening and closing a rear

door.

Front passenger seat and rear seat

reminder function: The hybrid system is

started within approximately 15 minutes

after opening and closing a rear door or

the front passenger’s door.

●

A rear door or the front passenger’s door

has been opened and closed after the

hybrid system was started.

The second reminder will not be activated if

a rear door or the front passenger door was

opened before the doors are locked.
When this function is disabled by following

the message displayed on the meters, the

passenger and rear seat reminder will be

off.
This function will be re-enabled when the

hybrid system is turned on.
However, if a front passenger door and rear

door is opened and then closed within

approximately 2 seconds, the passenger

and rear seat reminder reminder function

may not operate.
The passenger and rear seat reminder func-

tion determines that luggage, etc. has been

placed in the front passenger seat or a rear

seat based on opening and closing of the

front passenger door or a rear door. There-

fore, depending on the situation, the pas-

senger and rear seat reminder function may

not operate and you may still forget lug-

gage, etc. in the front passenger seat or a

rear seat, or it may operate unnecessarily.

: On some models

■

Customization

Some functions can be customized.

(



P.623)

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant falling out,

resulting in death or serious injury.

●

Ensure that all doors are properly

closed and locked.

●

Do not press an inside door opener

switch while driving.

Except for India: Be especially careful for
the front doors, as the doors may be
opened even if the inside lock buttons
are in locked position.
For India: Be especially careful for the
driver’s door, as the door may be opened
even if the inside lock button is in locked
position.

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

When closing a door, swing it closed with

slight force applied to it. If you press on

the door by hand to close it, it may not be

closed completely.

143

3-2. Opening, closing and locking the doors

fore
driving

■

Door lock switches (to
lock/unlock)

Driver’s door: Locks all the doors
Doors other than the driver’s door:

Locks the doors

The indicator

comes on.

Driver’s door: Unlocks all the doors
Doors other than the driver’s door:
Unlocks the doors

The indicator

turns off.

Press the door opener switch of the
door handle to open the door.

Make sure to securely press the door
opener switch

on the inner side of the

door handle

■

If the 12-volt vehicle battery is dis-

charged

The doors cannot be locked or unlocked

using the smart entry & start system or

wireless remote control, and the door

opener switches will not operate.
Use the mechanical key to enable/disable

manual release handle operation. By ena-

bling manual release handle operation, the

door can be opened. (



P.593)

WARNING

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

■

When using the wireless remote con-

trol and operating the power windows
or the moon roof

or panoramic moon

roof

: If equipped

Operate the power windows or the

moon roof or panoramic moon roof after

checking to make sure that there is no

possibility of any passenger having any of

their body parts caught in the windows or

the moon roof or panoramic moon roof.

Also, do not allow children to operate the

wireless remote control. It is possible for

children and other passengers to get

caught in the power windows or the

moon roof or panoramic moon roof.

Unlocking and locking the doors
from the inside

Opening the doors from outside
the vehicle

144

3-2. Opening, closing and locking the doors

Press the front side of the door opener
switch to open the door.

Driver’s door: The door will open even if it
is locked.
When the door is unlocked, the door lock
indicator will turn off.

■

Inside door opener switch operating

conditions

When any of the following conditions are

met:

●

The vehicle speed is less than 4 km/h

(2.5 mph) and the parking brake is

engaged

●

The vehicle speed is less than 4 km/h

(2.5 mph) and the brake pedal is

depressed

●

The shift position is in P

■

When opening a door from inside the

vehicle

If the door is not fully unlatched, press the

door opener switch twice to open the door.

■

Manual release handles inside the vehi-

cle

The door opener switches inside the vehicle

can also be used to manually open the

doors.
A door can be opened through electronic

operation by pressing the door opener

switch, or it can be opened using the door

opener switch as a manual release handle

and pulling it twice.

The door cannot be opened from
inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children
from opening the rear doors. Push down
on each rear door switch to lock both rear
doors.

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.623.

Opening the doors from inside
the vehicle

Rear door child-protector lock

Automatic door locking and
unlocking systems

145

3-2. Opening, closing and locking the doors

fore
driving

Function

Operation

Shift position
linked door lock-
ing function

All doors are automati-
cally locked when shift-
ing the shift position
out of P.

Shift position
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
shifting the shift posi-
tion to P.

Driver’s door
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
driver’s door is
opened.

Power back door

The power back door can be
opened using the power back door
opener switch, smart entry & start
system or wireless remote control.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving the vehicle

Before driving the vehicle, make sure

that the power back door is fully closed. If

the power back door is not fully closed, it

may open unexpectedly while driving,

causing an accident.

■

Caution while driving

●

Keep the power back door closed

while driving.

If the power back door is left open, it may

hit nearby objects while driving or lug-

gage may be unexpectedly thrown out,

causing an accident.
In addition, exhaust gases may enter the

vehicle, causing death or a serious health

hazard. Make sure to close the power

back door before driving.

●

Never let anyone sit in the luggage

compartment. In the event of sudden

braking, sudden swerving or a colli-

sion, they are susceptible to death or

serious injury.

■

When children are in the vehicle

Observe the following precautions.

Failure to do so may result in death or

serious injury.

146

3-2. Opening, closing and locking the doors

WARNING

●

Do not allow children to play in the lug-

gage compartment.

If a child is accidentally locked in the lug-

gage compartment, they could have heat

exhaustion or other injuries.

●

Do not allow a child to open or close

the power back door.

Doing so may cause the power back

door to move unexpectedly, or cause the

child’s hands, arms, head, or neck to be

caught by the closing power back door.

■

Operating the power back door

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in death or

serious injury.

●

Remove any heavy loads, such as snow

and ice, from the power back door

before opening it. Failure to do so may

cause the power back door to sud-

denly shut again after it is opened.

●

When opening or closing the power

back door, thoroughly check to make

sure the surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the power back door is about to open

or close.

●

Use caution when opening or closing

the power back door in windy weather

as it may move abruptly in strong wind.

●

The power back door may suddenly

shut if it is not opened fully. It is more

difficult to open or close the back door

on an incline than on a level surface, so

beware of the back door unexpectedly

opening or closing by itself. Make sure

that the back door is fully open and

secure before using the luggage com-

partment.

●

When closing the power back door,

take extra care to prevent your fingers,

etc., from being caught.

●

When closing the power back door,

make sure to press it lightly on its outer

surface. If the back door handle is used

to fully close the power back door, it

may result in hands or arms being

caught.

●

Do not pull on the back door spindle

(



P.157) to close the power back

door, and do not hang on the back

door spindle.

Doing so may cause hands to be caught

or the back door spindle to break, caus-

ing an accident.

147

3-2. Opening, closing and locking the doors

fore
driving

■

Smart entry & start system

Carry the electronic key to enable this
function.

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

■

Wireless remote control



P.138

■

Door lock switch



P.143

■

Opening/closing the power back
door using the wireless remote
control

Press and hold the switch for approxi-
mately 1 second.

The power back door can be operated
when it is unlocked

Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.
Pressing and holding the switch again for
approximately 1 second will operate the
power back door in the opposite direction.

: Opening of the power back door when it

is locked can be enabled by a custom-
ized setting. (



P.623)

■

Opening/closing the power back
door from the inside

Press and hold the switch for approxi-
mately 1 second.

WARNING

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, it may suddenly shut again after

being opened, causing someone’s

hands, arms, head or neck to be

caught and injured. When installing an

accessory part to the power back

door, using a genuine Lexus part is

recommended.

Unlocking and locking the
power back door from the out-
side

Unlocking and locking the
power back door from the inside

Opening/closing the power back
door

148

3-2. Opening, closing and locking the doors

A buzzer will sound and the power back
door will automatically open or close.
However, if the power back door is locked,
it will not open.
Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.
Pressing and holding the switch again for
approximately 1 second will operate the
power back door in the opposite direction.

■

Back door opener switch



Open

When the power back door is unlocked:
Press the back door opener switch.
When the power back door is locked:
While carrying an electronic key, press and
hold the back door opener switch.
A buzzer will sound and the power back
door will automatically open.
Pressing the switch while the power back
door is opening/closing will stop the oper-
ation.



Press the

switch.

A buzzer will sound and the power back
door will automatically close.

Pressing the

switch while the power

back door is closing will stop the operation.
Pressing the switch again will open the
power back door automatically.



Close the back door and lock all
doors after moving away from the
back door (close & lock
[Walk-Away] function)

Close all of the doors except the
back door, carrying an electronic
key and press the

switch on the

lower part of the back door.

A different buzzer than the normal one will

sound and the close & lock (Walk-Away)

function will go into standby.

While the buzzer is sounding, move
away from the back door.

149

3-2. Opening, closing and locking the doors

fore
driving

When the sensor detects that you are away

from the back door, the buzzer will sound.

Depending on the direction of moving

away from the back door, the location and

how to hold the electronic key or circum-

stances, it may not be detected properly.
All the doors other than the back door will

be locked, and after the back door is

closed, the back door will also be locked.

When all the doors have been closed and

locked, the buzzer (if equipped) will sound

and the emergency flashers will flash.
The standby state is canceled if you do not

move away from the back door for 30 sec-

onds. To operate the function again, per-

form the procedure again from the

beginning.
If you approach the back door carrying the

electronic key, the back door operation will

stop, all the doors will be unlocked, and the

buzzer (if equipped) will sound and the

emergency flashers will flash.

If the

switch is pressed after the back

door operation has stopped, the close &

lock (Walk-Away) function will go into

standby again.



Close the back door and lock all
doors (close & lock function)

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

Press the

switch.

The power back door will close and all of
the doors will be locked at the same time.
A different buzzer than the normal one will
sound and the power back door will begin
closing automatically. When the power
back door is closed, all of the doors will
lock simultaneously and operation signals
will indicate that all of the doors have been
locked.

If the

switch is pressed while the power

back door is closing, the operation will
stop.
Pressing the switch again will open the
power back door automatically.
Vehicles with Double locking system: The
double locking system will not operate at
this time.

■

Closing the power back door using
the back door handle

Lower the power back door using the
back door handle, then a buzzer will
sound and the power back door will
automatically close.

■

Hands Free Power Back Door (if
equipped)

While carrying an electronic key,
stand within the smart entry & start
system operation range, approxi-

150

3-2. Opening, closing and locking the doors

mately 50 to 60 cm (19.7 to 23.6
in.) from the rear bumper.

Kick sensor
Hands Free Power Back Door
operation detection area
Smart entry & start system opera-
tion detection area (



P.161)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 10 cm (3.9 in.) of the rear
bumper and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation
within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform

a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the power back door
will automatically fully open/close.

If kick operation is performed again in the

middle of back door operating, the opera-

tion will stop.

■

Closing and locking the back door
after moving away from the back
door using the kick sensor (Hands
Free close & lock [Walk-Away]
function)

*1, 2

: If equipped

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

While carrying an electronic key,
stand within the smart entry & start
system operation range, approxi-

A
B

151

3-2. Opening, closing and locking the doors

fore
driving

mately 50 to 60 cm (19.7 to 23.6
in.) from the rear bumper.

Kick sensor
Hands Free Power Back Door
operation detection area
Smart entry & start system opera-
tion detection area (



P.161)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 10 cm (3.9 in.) of the rear
bumper and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation
within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform

a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a different
buzzer than the normal one will
sound and the Hands Free close &
lock (Walk-Away) function will go
into standby.

While the buzzer is sounding, move
away from the back door.

When the sensor detects that you are away

from the back door, the buzzer will sound.

Depending on the direction of moving

away from the back door, the location and

how to hold the electronic key or circum-

stances, it may not be detected properly.
All the doors other than the back door will

be locked, and after the back door is

closed, the back door will also be locked.

When all the doors have been closed and

locked, the buzzer (if equipped) will sound

and the emergency flashers will flash.
The standby state is canceled if you do not

move away from the back door for 30 sec-

onds. To operate the function again, per-

form the procedure again from the

beginning.
If you approach the back door carrying the

electronic key, the back door operation will

stop, all the doors will be unlocked, and the

buzzer (if equipped) will sound and the

emergency flashers will flash.

A
B

152

3-2. Opening, closing and locking the doors

If the power back door is operated after

the back door operation has stopped, the

Hands Free close & lock (Walk-Away)

function will go into standby again.

■

Luggage compartment lights

●

The luggage compartment lights turn on

when the back door is opened.

●

When the power switch is turned off, the

lights will go off automatically after 20

minutes.

■

Back door closer

In the event that the power back door is left

slightly open, the back door closer will auto-

matically close it to the fully closed position.

●

The back door closer can function when

the power switch is in any mode.

●

The power back door can be opened

using the back door opener switch even if

the back door closer is operating.

■

Power back door operating conditions

If the following conditions are met with the

power back door operation enabled, the

power back door can be opened and

closed automatically.

●

The power back door is unlocked. How-

ever, the power back door will operate if

it is locked, in the following situations:

• When an electronic key is being carried

and the back door opener switch is

pressed.

• When opening of the power back door

using the wireless remote control when it

is locked is enabled. (



P.147)

●

When the power switch is in ON, the

vehicle speed must be lower than 3 km/h

(2 mph) and one of the following condi-

tions must be met in addition to the above

conditions:

• The parking brake is engaged.

• The brake pedal is depressed.

• The shift position is in P.

■

Operation of the power back door

●

When the power back door begins to

operate, a buzzer will sound.

●

When the power back door is disabled,

the power back door will not operate but

can be opened and closed manually.

●

The power back door turns to manual

operation when the back door opener

switch is pressed while the power back

door is in an automatic opening/closing

operation.

●

If anything obstructs the power back

door while opening, a buzzer will sound

and the power back door will stop imme-

diately. If anything obstructs the power

back door while closing, a buzzer will

sound and the power back door will auto-

matically move slightly in the opposite

direction and then stop.

■

Jam protection function

Sensors are installed in the right and left

sides of the power back door. When the

door is automatically closing and the sen-

sors are pushed due to an object being

caught, etc., the jam protection function will

operate.
From that position the door will automati-

cally move a little in the opposite direction

and then the function will stop.

■

Fall-down protection function

While the power back door is opening

automatically, applying excessive force to it

will stop the opening operation to prevent

the power back door from suddenly shut-

ting.

■

Back door closing assist

If the back door is lowered manually when

the back door is stopped at an open posi-

tion, the back door will fully close automati-

cally.

■

Back door reserve lock function

This function reserves the locking of the

power back door when the power back

door is open. If the following operations are

153

3-2. Opening, closing and locking the doors

fore
driving

performed, all of the doors except the

power back door will lock and then the

power back door will lock when it is com-

pletely closed.

Close all of the doors, except the power

back door.

Perform an automatic closing operation

of the power back door and lock the

doors using the wireless remote control

(



P.138) or smart entry & start system

(



P.140) while the power back door is

closing.

Operation signals will indicate that all the-

doors have been closed and locked.

(



P.141)

●

If the electronic key is placed inside the

vehicle after starting a close operation via

the door reserve lock function, the elec-

tronic key may become locked inside the

vehicle.

●

If the back door does not fully close due

to the operation of the jam protection

function, etc., while the back door is auto-

matically closing after a reserve lock

operation is performed, the reserve lock

function is canceled and all the doors will

unlock.

●

Before leaving the vehicle, make sure that

all the doors are closed and locked.

■

Close & lock (Walk-Away) function

operating conditions

This function can be operated when all of

the following conditions are met:

●

Close & lock (Walk-Away) function is

enabled.

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the power

back door are closed.

●

The brake pedal is not depressed.

●

The power switch is off.

●

The electronic key is within the effective

range (detection areas).

■

Situations in which the close & lock

(Walk-Away) function may not operate

properly

In the following situations, the function may

not operate properly:

●

When the smart entry & start system

does not operate properly.

●

When the close & lock function does not

operate properly.

●

When moving away from the back door

while the close & lock (Walk-Away) func-

tion is in the standby state.

■

Close & lock function

operating condi-

tions

This function can be operated when all of

the following conditions are met:

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the power

back door are closed.

●

The power switch is off.

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Situations in which the close & lock
function

may not operate properly

In the following situations, the close & lock

function may not operate properly:

●

If the

switch on the lower part of the

power back door (



P.148) is pressed by

a hand which is holding an electronic key

●

If the

switch on the lower part of the

power back door (



P.148) is pressed

when the electronic key is in a bag, etc.

that is placed on the ground

●

If the

switch on the lower part of the

power back door (



P.148) is pressed

with the electronic key not near the vehi-

cle.

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable

154

3-2. Opening, closing and locking the doors

repairer.

■

Hands Free Power Back Door operating

conditions (if equipped)

●

The Hands Free Power Back Door (kick

sensor) setting is on.

●

When an electronic key is carried within

the operation range.

■

Situations in which the Hands Free

Power Back Door may not operate

properly (if equipped)

In the following situations, the Hands Free

Power Back Door may not operate prop-

erly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Back Door again.

●

When standing excessively close to the

rear bumper

●

When an external radio wave source

interferes with the communication

between the electronic key and the vehi-

cle (



P.162)

●

When the vehicle is parked near metal, or

an external radio wave or electrical noise

source which affects the sensitivity of the

Hands Free Power Back Door, such as a

pay parking spot, gas station, electrically

heated road, fluorescent light, or metal

plate

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the

Hands Free Power Back Door (kick sen-

sor) operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Back Door (if

equipped)

When an electronic key is in the operation

detection area, the Hands Free Power Back

Door may operate unintentionally, so be

careful in the following situations:

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Back

Door, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the

Hands Free Power Back Door (kick sensor)

155

3-2. Opening, closing and locking the doors

fore
driving

operation setting off.

■

Hands Free close & lock (Walk-Away)
function

operating conditions

This function can be operated when all of

the following conditions are met:

●

Hands Free close & lock (Walk-Away)
function is enabled

●

Hands Free Power Back Door

is ena-

bled.

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the back door

are closed.

●

The brake pedal is not depressed.

●

The power switch is off.

●

The electronic key is within the effective

range (detection areas).

: If equipped

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Situations in which the Hands Free close
& lock (Walk-Away) function

*1, 2

may

not operate properly

In the following situations, the function may

not operate properly:

●

When the smart entry & start system

does not operate properly.

●

When the close & lock function does not

operate properly.

●

When moving away from the back door

while the Hands Free close & lock

(Walk-Away) function is in the standby

state.

●

When the Hands Free Power Back Door
does not operate properly.

: If equipped

: This setting can be customized at any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

If the power back door stops the auto-

matic operation

When the automatic operation of the

power back door is enabled and the power

back door is left open for a long time , it may

stop the automatic operation.
To re-enable the automatic operation, fully

close the power back door manually.

■

When reconnecting the 12-volt battery

To operate the power back door properly,

close the back door completely by hand

then operate for unlocking.

■

If the power back door opener is inoper-

ative

The power back door can be unlocked from

the inside

Remove the cover.

To prevent damage, cover the tip of the

screwdriver with a rag.

Loosen the screw.

Turn the cover.

156

3-2. Opening, closing and locking the doors

Move the lever.

When installing, reverse the steps listed.

■

Customization

Some functions can be customized.

(



P.623)

WARNING

■

Back door closer

●

In the event that the power back door

is left slightly open, the back door

closer will automatically close it to the

fully closed position. It takes several

seconds before the back door closer

begins to operate. Be careful not to get

fingers caught or anything else in the

power back door, as this may cause

bone fractures or other serious inju-

ries.

●

Use caution when using the back door

closer as it still operates when the

power back door system is disabled.

■

Power back door

Observe the following precautions when

operating the power back door.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the power back door is about to open

or close.

●

If the power back door system is disa-

bled while the power back door is

operating, the power back door will

stop operating. The power back door

must then be operated manually. Take

extra care in this situation, as the

power back door may open or close

suddenly.

●

If the operating conditions of the

power back door (



P.152) are no

longer met, a buzzer may sound and

the power back door may stop open-

ing or closing. The power back door

must then be operated manually. Take

extra care on an incline in this situation,

as the power back door may move

suddenly.

●

On an incline, the power back door

may suddenly shut after it opens. Make

sure the power back door is fully open

and secure.

●

In the following situations, the power

back door may detect an abnormality

and automatic operation may be

stopped. In this case, the power back

door must then be operated manually.

Take extra care in this situation, as the

stopped power back door may sud-

denly open or close, causing an acci-

dent.

• When the power back door contacts

an obstacle

• When the 12-volt battery voltage sud-

denly drops, such as when the power

switch is turned to ON or the hybrid

system is started during automatic

operation

Lexus RX (2023 year). Manual in english - page 4
