NOTICE

■

During setting up the display

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while setting up the display features.

Suggestion function

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators

: If equipped

Illustrations used in this text are intended as examples, and may differ from the image that is
actually displayed by the head-up display.

Navigation system-linked display area

Displays the following items which are linked to the navigation system:
• Route guidance to destination
• Street name
• Compass (heading-up display)

Driving support system display area (

P.92)

Speed limit/RSA (Road Sign Assist) display area (if equipped)

Displays the following items:
• Speed limit of the current road (linked to the navigation system) (U.S.A. only)
• RSA (Road Sign Assist) display (



P.259)

Driving information display area

Displays the following items:
• Speedometer

Head-up display

The head-up display projects a variety of driving-related information and the
operating state of the driving support systems on the windshield.

System components

B
C

2-1. Instrument cluster

• Shift position/shift range/gear position (



P.175)

Hybrid System Indicator/tachometer display area (



P.93)

HUD (Head-up display) switch

■

Displayed items when using Advanced

Drive (if equipped)

When using Advanced Drive, the displayed

items and their location will differ. Refer to

“Lexus Teammate Advanced Drive

OWNER’S MANUAL” at Lexus.com for

details.

■

Head-up display will operate when

The power switch is in ON mode.

■

When using the head-up display

The head-up display may seem dark or hard

to see when viewed through sunglasses,

especially polarized sunglasses. Adjust the

brightness of the head-up display or

remove your sunglasses.

■

Street name display

Only street names which are included in the

map data will be displayed.

■

Outside temperature display

●

In the following situations, the outside

temperature is displayed:

• When the ambient temperature is

approximately 37°F (3°C) or lower (In

this case, the outside temperature display

will be displayed and the low outside tem-

perature indicator will flash for approxi-

mately 10 seconds.)

• After the opening screen is displayed

(The outside temperature display will be

displayed for approximately 10 seconds.)

●

In the following situations, the correct

outside temperature may not be dis-

played, or the display may take longer

than normal to change:

• When stopped, or driving at low speeds

(less than 12 mph [20 km/h])

• When the outside temperature has

changed suddenly (at the entrance/exit of

a garage, tunnel, etc.)

●

When “--” or “E” is displayed, the system

may be malfunctioning. Take your vehicle

to your Lexus dealer.

WARNING

■

When using the head-up display

●

Check that the position and brightness

of the head-up display image does not

interfere with safe driving. Incorrect

adjustment of the image’s position or

brightness may obstruct the driver’s

view and lead to an accident, resulting

in death or serious injury.

●

Do not continuously look at the

head-up display while driving as you

may fail to see pedestrians, objects on

the road, etc. ahead of the vehicle.

NOTICE

■

Head-up display projector

●

Do not place any drinks near the

head-up display projector. If the pro-

jector gets wet, electrical malfunctions

may result.

●

Do not place anything on or put stick-

ers onto the head-up display projector.

Doing so could interrupt head-up dis-

play indications.

●

Do not touch the inside of the head-up

display projector or thrust sharp edges

or the like into the projector.

Doing so could cause mechanical mal-

functions.

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators

■

Enabling/disabling the head-up dis-
play

Press the HUD switch.

■

Changing settings of the head-up
display

The following settings can be changed
on

of the multi-information display.

(





Brightness and vertical position of
the head-up display

Select to adjust the brightness or vertical
position of the head-up display.



Hybrid System Indicator/tachome-
ter

Select to display the Hybrid System Indica-
tor, tachometer or no content.



Display content

Select to enable/disable the following
items:
• Route guidance to destination/street

name

• Driving support system display

• Compass (heading-up display)
• Audio system operation status

: Make sure to enable this display when

using the driving support systems



Display angle

Select to adjust the angle of the head-up
display.

■

Enabling/disabling of the head-up dis-

play

If the head-up display is disabled, it will

remain disabled when the power switch is

turned off then back to ON mode.

■

Display brightness

The brightness of the head-up display can
be adjusted on

of the multi-information

display. Also, it is automatically adjusted

according to the ambient brightness.

■

Head-up display automatic position

adjustment

If the display position is recorded into mem-

ory, the head-up display will be automati-

cally adjusted to the desired position.

(

P.130)

■

When the 12-volt battery is discon-

nected

The customize settings of the head-up dis-

play will be reset.

Using the head-up display

WARNING

■

Caution for changing settings of the

head-up display

As the hybrid system needs to be operat-

ing while changing the settings of the

head-up display, ensure that the vehicle

is parked in a place with adequate venti-

lation. In a closed area such as a garage,

exhaust gases including harmful carbon

monoxide (CO) may collect and enter

the vehicle. This may lead to death or a

serious health hazard.

2-1. Instrument cluster

Displays the operational status of the
following systems:



LTA (Lane Tracing Assist) (



P.237,

250)



Dynamic radar cruise control with
full-speed range (



P.262)

Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display. For
details, refer to the explanation of each sys-
tem.

Pop-up displays for the following sys-
tems will be displayed when necessary.

■

Driving support systems

Displays a warning/suggestion/advice
message or the operating state of a rel-
evant system.



PCS (Pre-Collision System)
(



P.210, 223)



FCTA (Front Cross Traffic Alert) (if
equipped) (



P.234)



Intuitive parking assist (



P.280)



Parking Support Brake function (for
static objects) (



P.302)



Brake Override System (

P.160)



Drive-Start Control (

P.164)

Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display. For
details, refer to the explanation of each sys-
tem.

■

icons

These icons are linked to the
multi-information display

: Master warning icon

Displayed when a warning message is dis-
played on the multi-information display.
(

P.467)

: Information icon

Displayed when a suggestion pop-up dis-
play (



P.88) or advice pop-up display is

displayed on the multi-information display.

■

Warning message

Some warning messages are displayed
when necessary, according to certain
conditions.

Details of content displayed on the
head-up display may differ from that dis-
played on the multi-information display.

■

Audio system operation status

Displayed when an audio remote con-
trol switch on the steering wheel is
operated.

■

Hands-free system status

Displayed when the hands-free system
is operated.

■

When a pop-up display is displayed

When a pop-up display is displayed, a cur-

rent display may no longer be displayed. In

this case, the display will return after the

NOTICE

■

When changing the settings of the

head-up display

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while the changing the settings of the

head-up display.

Driving support system display
area

Pop-up display

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators

pop-up display disappears.

■

Hybrid System Indicator

Charge area
Hybrid Eco area
Eco area
Power area

Displayed content is the same as that dis-
played on the meter (Hybrid System Indi-
cator). For details, refer to P.82.

■

Tachometer

Displays the engine speed in revolu-
tions per minute.

Multi-information display
Center Display
Meter control switches

The energy monitor can be used to
check the vehicle drive status, hybrid
system operation status and energy
regeneration status.

■

Display procedure



Multi-information display

Press the

meter control

switch and select

, and then press

to select the energy monitor

display.



Center Display

Select

on the main menu.

Hybrid System Indica-
tor/tachometer

A
B
C
D

Energy monitor/consump-
tion screen

The state of the hybrid system can
be viewed on the multi-information
display and Center Display.

System components

Energy monitor

A
B
C

2-1. Instrument cluster

Select “Energy flow”.

■

Reading the display

The arrows will appear in accordance
with the energy flow. When there is no
energy flow, arrows will not be dis-
played.

The color of the arrows will change as fol-
lows

Light blue

/Blue

: When the hybrid bat-

tery (traction battery) is regenerated or
charged.

Yellow

/Orange

: When the hybrid bat-

tery (traction battery) is in use.
Red: When the gasoline engine is in use.

: Multi-information display

: Center Display



Multi-information display

Tire
Hybrid battery (traction battery)
Gasoline engine

The image shows all the arrows as an
example. The actual display will vary
depending on conditions.



Center Display

Gasoline engine
Electric motor (traction motor)
Hybrid battery (traction battery)
Tires

The image shows all the arrows as an
example. The actual display will vary
depending on conditions.

: Depending on the vehicle specification,

the energy monitor may not be dis-
played on the Center Display.

■

Color of the hybrid battery (traction

battery) on the Center Display

It will be green when the hybrid battery

(traction battery) is being charged, and yel-

low when the hybrid battery (traction bat-

tery) is being used.

■

Remaining charge amount warning of

hybrid battery (traction battery)

●

The buzzer sounds intermittently when

the hybrid battery (traction battery)

remains without charging while the shift

position is in N, or the remaining charge

amount drops below a certain level. If the

remaining charge amount drops further,

the buzzer sounds continuously.

●

When a warning message is shown on

the multi-information display and the

buzzer sounds, follow the instructions

displayed on the screen to perform trou-

bleshooting.

A
B
C

A
B
C
D

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators

■

Display procedure

Select

on the main menu.

Select “Trip information”.

Select “Current”.

■

Display

Resetting the consumption data
Fuel consumption in the past 15
minutes
Current fuel consumption
Average vehicle speed since the
hybrid system was started.
Trip range
Elapsed time since the hybrid sys-
tem was started.

Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
vary slightly from actual conditions.

■

Display procedure

Select

on the main menu.

Select “Trip information”.

Select “History”.

■

Display

Latest fuel consumption
Best recorded fuel consumption
Previous fuel consumption record
Resetting the history data
Updating the latest fuel consump-
tion data

Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
vary slightly from actual conditions.

■

Updating the history data

Update the latest fuel consumption by

selecting “Update” to measure the current

fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted

by selecting “Clear data”.

■

Trip range

Displays the estimated maximum distance

that can be driven with the quantity of fuel

remaining.
This distance is computed based on your

average fuel consumption.

As a result, the actual distance that can be

driven may differ from that displayed.

Current screen

History screen

A
B

C
D

E
F

A
B
C
D

fore
dri
ving

Before driving

3-1. Key information

Keys ...................................................

3-2. Opening, closing and locking the

doors and trunk

Doors...............................................

102

Trunk................................................

107

Smart access system with

push-button start......................

114

3-3. Adjusting the seats

Front seats......................................

119

Power rear seat...........................

125

Driving position memory ........

130

Rear seat position memory....

134

Head restraints............................

135

3-4. Adjusting the steering wheel and

mirrors

Steering wheel.............................

139

Inside rear view mirror.............

140

Digital Rearview Mirror ...........

141

Outside rear view mirrors......

149

3-5. Opening, closing the windows

and moon roof

Power windows...........................

152

Moon roof .....................................

154

3-1. Key information

3-1.Key information

The following keys are provided with
the vehicle.

Electronic keys

• Operating the smart access system with

push-button start (



P.114)

• Operating the wireless remote control

function (

P.100)

Mechanical keys
Key number plate
Card key (electronic key) (if
equipped)

Operating the smart access system with
push-button start (

P.114)

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside

the card key should be used only if a

problem arises, such as when the card

key does not operate properly.

●

If it is difficult to take out the mechanical

key, push down the lock release button

using a pen tip etc. If it is still difficult to

pull it out, use a coin etc.

●

To store the mechanical key in the card

key, insert it while pressing the lock

release button.

●

If the battery cover is not installed and the

battery falls out or if the battery was

removed because the key got wet, rein-

stall the battery with the positive terminal

facing the Lexus emblem.

■

When riding in an aircraft

When bringing an electronic key onto an

aircraft, make sure you do not press any

buttons on the electronic key while inside

the aircraft cabin. If you are carrying an

electronic key in your bag etc., ensure that

the buttons are not likely to be pressed acci-

dentally. Pressing a button may cause the

electronic key to emit radio waves that

could interfere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

(The card key battery life is about a year

and a half.)

●

If the battery becomes low, an alarm will

sound in the cabin and a message will be

shown on the multi-information display

when the hybrid system is stopped.

Keys

The keys

B
C
D

3-1. Key information

fore
dri
ving

●

To reduce key battery depletion when the

electronic key is to not be used for long

periods of time, set the electronic key to

the battery-saving mode. (



●

As the electronic key always receives

radio waves, the battery will become

depleted even if the electronic key is not

used. The following symptoms indicate

that the electronic key battery may be

depleted. Replace the battery when nec-

essary.

• The smart access system with push-but-

ton start or the wireless remote control

does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface

does not turn on.

●

To avoid serious deterioration, do not

leave the electronic key within 3 ft. (1 m)

of the following electrical appliances that

produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and

battery chargers

• Recharging cellular phones or cordless

phones

• Table lamps

• Induction cookers

■

Replacing the battery

P.439

■

Confirmation of the number of regis-

tered keys

The number of keys already registered to

the vehicle can be confirmed. Ask your

Lexus dealer for details.

■

If “A New Key has been Registered

Contact Your Dealer for Details” is

shown on the multi-information display

This message will be displayed each time

the driver’s door is opened when the doors

are unlocked from the outside for approxi-

mately 10 days after a new electronic key

has been registered.

If this message is displayed but you have not

had a new electronic key registered, ask

your Lexus dealer to check if an unknown

electronic key (other than those in your

possession) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to

strong shocks or bend them.

●

Do not expose the keys to high tem-

peratures for a long period of time.

●

Do not get the keys wet or wash them

in an ultrasonic washer etc.

●

Do not attach metallic or magnetic

materials to the keys or place the keys

close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else

to the surface of the electronic key.

●

Do not place the keys near objects that

produce magnetic fields, such as TVs,

audio systems and induction cookers,

or medical electrical equipment, such

as low-frequency therapy equipment.

■

Carrying the electronic key on your

person

Carry the electronic key 3.9 in. (10 cm)

or more away from electric appliances

that are turned on. Radio waves emitted

from electric appliances within 3.9 in. (10

cm) of the electronic key may interfere

with the key, causing the key to not func-

tion properly.

■

In case of a smart access system with

push-button start malfunction or

other key-related problems

P.474

■

When an electronic key is lost

P.473

■

Handling the card key (if equipped)

●

Do not apply excess force when insert-

ing the mechanical key into the card

key. Doing so may damage the card

key.

100

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks the doors (



Unlocks the doors (



Opens the windows and moon
roof

(



Opens the trunk (

P.109)

Sounds the alarm

: This setting must be customized at your

Lexus dealer.

■

Theft deterrent panic mode

When

is pressed for longer than

about one second, an alarm will sound

intermittently and the vehicle lights will flash

to deter any person from trying to break

into or damage your vehicle.
To stop the alarm, press any button on the

electronic key.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in

NOTICE

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the key,

immediately remove the battery cover

and wipe the battery and terminals. (To

remove the battery cover, lightly grasp

and pull it.) If the battery is corroded,

have your Lexus dealer replace the

battery.

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover.

Forcibly removing the battery cover

may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

Using the mechanical key

101

3-1. Key information

fore
dri
ving

a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



■

When required to leave the vehicle’s

key with a parking attendant

Turn the trunk opener main switch off

(



P.113) and lock the glove box (



P.372)

as circumstances demand.

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys

P.473

■

If a wrong key is used

The key cylinder rotates freely, isolated

from the internal mechanism.

102

3-2. Opening, closing and locking the doors and trunk

3-2.Opening, closing and locking the doors and trunk

■

Smart access system with
push-button start

Carry the electronic key to enable this
function.

Grip the driver’s door handle to
unlock the door. Holding the
driver’s door handle for approxi-
mately 2 seconds unlocks all the
doors. Grip any passenger door
handle to unlock all the doors.

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (indentation
on the upper part of the door han-
dle) to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s
door. Pressing the button again within 5
seconds unlocks the other door.
Press and hold to open the windows and
moon roof.

: This setting must be customized at your

Lexus dealer.

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the power switch off.

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5

seconds while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

Doors

Unlocking and locking the doors
from the outside

103

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

To prevent unintended triggering of the

alarm, unlock the doors using the wireless

remote control and open and close a door

once after the settings have been changed.

(If a door is not opened within 60 seconds
after

is pressed, the doors will be

locked again and the alarm will automati-

cally be set.)

In a case that the alarm is triggered, imme-

diately stop the alarm. (



P.73)

■

Impact detection door lock release sys-

tem

In the event that the vehicle is subject to a

strong impact, all the doors are unlocked.

Depending on the force of the impact or the

type of accident, however, the system may

not operate.

■

Operation signals

A buzzer sounds and the emergency flash-

ers flash to indicate that the doors have

been locked/unlocked. (Locked: once;

Unlocked: twice)
A buzzer sounds to indicate that the win-

dows and moon roof are operating.

■

Security feature

If a door is not opened within approximately

60 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

When the doors cannot be locked by the

lock sensor on the upper part of the

door handle

When the doors cannot be locked even if

the lock sensor on the upper part of the

door handle is touched by a finger, touch

the lock sensor with the palm.
If you are wearing gloves, remove them.

■

Open door warning buzzer

If an attempt to lock the doors is made when

a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the

door to stop the buzzer, and lock the vehi-

cle once more.

■

Setting the alarm

Locking the doors will set the alarm system.

(

P.73)

■

Conditions affecting the operation of

the smart access system with push-but-

ton start or wireless remote control



P.116

■

If the smart access system with

push-button start or the wireless remote

control does not operate properly

Use the mechanical key to lock and unlock

the doors. (

Replace the key battery with a new one if it

is depleted. (

P.439)

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

using the smart access system with

push-button start or wireless remote con-

trol. Lock or unlock the doors using the

mechanical key. (



■

Rear seat reminder function

In order to remind you not to forget lug-

Multi-information

display/Beep

Unlocking function

Exterior: Beeps 3

times

Interior: Pings once

Holding the driver’s
door handle unlocks
only the driver’s
door.

Holding any of the
passenger door
handles unlocks all
the doors.

Exterior: Beeps

twice

Interior: Pings once

Holding a door han-
dle unlocks all the
doors.

104

3-2. Opening, closing and locking the doors and trunk

gage, etc. in the rear seat, when the power

switch is turned off after any of the following

conditions are met, a buzzer will sound and

a message will be displayed on the

multi-information display for approximately

6 seconds.

●

The hybrid system is started within

approximately 10 minutes after opening

and closing a rear door.

●

A rear door has been opened and closed

after the hybrid system was started.

However, if a rear door is opened and then

closed within approximately 2 seconds, the

rear seat reminder function may not oper-

ate.
The rear seat reminder function determines

that luggage, etc. has been placed in a rear

seat based on opening and closing of a rear

door. Therefore, depending on the situation,

the rear seat reminder function may not

operate and you may still forget luggage,

etc. in the rear seat, or it may operate

unnecessarily.

■

Customization

Some functions can be customized.

(



■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons (to lock)

Push down the inside lock button to
lock the door.

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant throwing out of

the vehicle, resulting in death or serious

injury.

●

Ensure that all doors are properly

closed and locked.

●

Do not pull the inside handle of the

doors while driving.

Be especially careful for the front doors,
as the doors may be opened even if the
inside lock buttons are in locked position.

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

■

Vehicle height control precautions

In the following situations, make sure to

check the safety of the area around the

vehicle, as the vehicle height may change

and part of someone’s body may be

caught in the vehicle, possibly causing

injury or the vehicle may be damaged.

●

When opening or closing a door

●

When locking the doors

Unlocking and locking the doors
from the inside

105

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Inside door handles (to unlock)



For the front doors

Pull the handle to unlock and open the
door.

When the door is unlocked, the inside lock
button will pop up.



For the rear doors

Pull the handle to unlock the door. Pull
the handle a second time to open the
door.

When the door is unlocked, the inside lock
button will pop up.

■

Locking the front doors from the outside

without a key

Push down the inside lock button.

Close the door.

The door cannot be locked if the power

switch is in ACCESSORY or ON mode, or

the electronic key is left inside the vehicle.

However, the key may not be detected cor-

rectly and the door may be locked.

■

Door closer

In the event that a door is left slightly open,

the door closer will automatically close it to

the fully closed position.

●

The door closer will operate regardless

of the power switch mode.

●

The door closer will not function if the

door has been closed while pulling the

inside or outside door handle.

●

The door can be opened by pulling the

inside or outside door handle, even when

the door closer is operating (except

when the lock button is in the lock posi-

tion or the child-protector lock is set).

●

A motor sound may be heard for several

seconds after the door closer closes the

door. This does not indicate a malfunc-

tion.

■

Open door warning buzzer

If a door or the trunk is not fully closed, a

buzzer will sound when the vehicle speed

reaches 3 mph (5 km/h).

The open door(s) or trunk is indicated on

the multi-information display.

WARNING

■

Door closer

In the event that a door is left slightly

open, the door closer will automatically

close it to the fully closed position. It

takes several seconds before the door

easy closer begins to operate.

If the child-protector lock is set, the door

closer will not stop during operation even

if an attempt is made to open the door

from inside the vehicle. Be careful not to

catch fingers or anything else in the door.

Failure to do so may result in serious

injury.

106

3-2. Opening, closing and locking the doors and trunk

The door cannot be opened from
inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children
from opening the rear doors. Push down
on each rear door switch to lock both rear
doors.

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.509.

NOTICE

■

To prevent door closer malfunction

Do not frequently repeat opening and

closing of doors, or apply excessive force

to a door while the door closer is operat-

ing.

Rear door child-protector lock

Automatic door locking and
unlocking systems

Function

Operation

Speed linked
door locking
function

All doors are automati-
cally locked when vehi-
cle speed is
approximately 12 mph
(20 km/h) or higher.

Shift position
linked door lock-
ing function

All doors are automati-
cally locked when the
shift position is shifted
to a position other than
P.

Shift position
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
the shift position is
shifted to P.

Driver’s door
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
driver’s door is opened
within approximately
45 seconds after turn-
ing the power switch
off.

107

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

Trunk

The trunk can be opened using the
trunk opener switch, entry function
or wireless remote control.

The trunk can be closed using the
trunk closer.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving

●

Make sure that the trunk lid is fully

closed. If the trunk lid is not fully

closed, it may open unexpectedly

while driving and hit near-by objects or

luggage in the trunk may be thrown

out, causing an accident.

●

Do not allow children to play in the

trunk.

If a child is accidentally locked in the

trunk, they could suffer from heat

exhaustion, suffocation or other inju-

ries.

●

Do not allow a child to open or close

the trunk lid.

Doing so may cause the trunk lid to

open unexpectedly, or cause the

child’s hands, head, or neck to be

caught by the closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk. In the

event of sudden braking or a collision,

they are susceptible to death or serious

injury.

■

Using the trunk

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in serious

injury.

●

Remove any heavy loads, such as snow

and ice, from the trunk lid before

opening it. Failure to do so may cause

the trunk lid to suddenly shut again

after it is opened.

●

When opening or closing the trunk lid,

thoroughly check to make sure the

surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

Use caution when opening or closing

the trunk lid in windy weather as it may

move abruptly in strong wind.

●

The trunk lid may suddenly shut if it is

not opened fully. It is more difficult to

open or close the trunk lid on an

incline than on a level surface, so

beware of the trunk lid unexpectedly

opening or closing by itself. Make sure

that the trunk lid is fully open and

secure before using the trunk.

●

When closing the trunk lid, take extra

care to prevent your fingers etc. from

being caught.

●

When closing the trunk lid, make sure

to press it lightly on its outer surface. If

the trunk handle is used to fully close

the trunk lid, it may result in hands or

arms being caught.

108

3-2. Opening, closing and locking the doors and trunk

WARNING

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. Such additional weight on the trunk

lid may cause the lid to suddenly shut

again after it is opened.

■

Trunk easy closer

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

cally close it to the fully closed position. It

takes several seconds before the trunk

easy closer begins to operate. Be careful

not to catch fingers or anything else in

the trunk lid, as this may cause bone frac-

tures or other serious injuries.

■

Power trunk opener and closer

Observe the following precautions when

operating the power trunk opener and

closer.

Failure to do so may cause serious injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

If the trunk closer switch is pressed

while the trunk lid is opening during

automatic operation, the trunk lid

stops opening. Take extra care when

on an incline, as the trunk lid may open

or close suddenly.

●

On an incline, the trunk lid may sud-

denly shut after it opens automatically.

Make sure the trunk lid is fully open

and secure before using the trunk.

●

In the following situations, the power

trunk opener and closer may detect an

abnormality and automatic operation

may be stopped. In this case, the trunk

lid has to be operated manually. Take

extra care in this situation, as the

stopped trunk lid may suddenly shut,

causing an accident.

• When the trunk lid contacts an obsta-

cle

• When the 12-volt battery voltage sud-

denly drops, such as when the power

switch is turned to ON mode or the

hybrid system is started during auto-

matic operation

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. The power trunk opener and closer

may not operate, causing itself to mal-

function, or the trunk lid may suddenly

shut again after it is opened.

■

Hands Free Power Trunk Lid (if

equipped)

Observe the following precautions.

Failure to do so may cause serious injury.

●

Exhaust gasses cause the exhaust

pipes to become quite hot. When

operating the Hands Free Power Trunk

Lid, be careful not to touch the exhaust

pipe.

●

Do not operate the Hands Free Power

Trunk Lid if there is little space under

the rear bumper.

■

Jam protection function

Observe the following precautions.

Failure to do so may cause serious injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

109

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Trunk opener switch

Press the trunk opener switch.

The trunk lid will fully open.

■

Smart access system with
push-button start

While carrying the electronic key,
press the button.

The trunk lid will fully open.
If the button is pressed while the trunk lid is
opening, the trunk lid will stop moving.

When all the doors are unlocked using
one of the following methods, the trunk
can be opened without the electronic
key:



Entry function



Wireless remote control



Door lock switches



Automatic door unlocking system



Mechanical key

■

Wireless remote control

Press and hold the switch.

A buzzer will sound and the trunk lid will
fully open.

WARNING

●

The jam protection function may not

work if something gets caught just

before the trunk lid fully closes. Be

careful not to catch fingers or anything

else in the trunk lid.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

NOTICE

■

To prevent trunk easy closer malfunc-

tions

Do not apply force to the trunk lid while

the trunk easy closer is operating.

■

To prevent damage to the power

trunk opener and closer

●

Make sure that there is no luggage or

snow on the trunk lid before operating

the power trunk opener and closer. In

addition, make sure that there is no ice

between the trunk lid and frame that

prevents movement of the trunk lid.

Operating the power trunk opener

and closer when excessive load is

present on the trunk lid may cause a

malfunction.

●

Do not apply excessive force to the

trunk lid while the power trunk opener

and closer is operating.

Opening/closing the trunk

110

3-2. Opening, closing and locking the doors and trunk

If the button is pressed while the trunk lid is
opening, the trunk lid will stop moving.

■

Hands Free Power Trunk Lid (if
equipped)



Vehicles with Advanced Drive

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion area, approximately 11.8 to 19.7
in. (30 to 50 cm) from the rear
bumper.

Kick sensor
Hands Free Power Trunk Lid opera-
tion detection area

Smart access system with
push-button start operation detec-
tion area (



P.115)



Vehicles without Advanced Drive

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion area, approximately 11.8 to 19.7
in. (30 to 50 cm) from the rear
bumper.

Kick sensor
Hands Free Power Trunk Lid opera-
tion detection area
Smart access system with
push-button start operation detec-
tion area (



P.115)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling it back.

• Perform the entire kick operation

within 1 second.

A
B

111

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

• The trunk lid will not start operating

while a foot is detected under the
rear bumper.

• Operate the Hands Free Power

Trunk Lid without contacting the
rear bumper with your foot.

• If another electronic key is in the

cabin or trunk, it may take slightly
longer than normal for the opera-
tion to begin.

Kick sensor
Hands Free Power Trunk Lid opera-
tion detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the trunk will auto-
matically fully open/close.

If a foot is moved under the rear bumper

while the trunk lid is opening, the trunk lid

will stop moving.

If a foot is moved under the rear bumper

while the trunk lid is closing, the trunk lid

will open.

■

Trunk closer switch

Press the trunk closer switch.

A buzzer will sound and the trunk lid will
fully close.
Pressing the switch while the trunk lid is
closing opens the trunk lid again.

■

Trunk grip

Using the trunk grip, pull down the
trunk lid without applying sideways
force and push the trunk lid down from
the outside to close it.

■

Trunk lid light/trunk light

●

The trunk lid light/trunk light turns on

when the trunk is opened.

●

If the trunk lid light/trunk light is left on

when the power switch is turned off, the

light will go off automatically after 20

minutes.

■

Trunk easy closer

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

cally close it to the fully closed position.

●

The trunk easy closer will operate

regardless of the power switch mode.

●

If the trunk easy closer does not operate,

open the trunk to the half open position

or more and then close it.

■

Function to prevent the trunk being

locked with the electronic key inside

●

When all doors are locked, closing the

A
B

112

3-2. Opening, closing and locking the doors and trunk

trunk lid with the electronic key left inside

the trunk will sound an alarm.

In this case, the trunk lid can be opened

pressing the trunk release button on the

trunk lid.

●

If the spare electronic key is put in the

trunk with all the doors locked, the key

confinement prevention function is acti-

vated so the trunk can be opened. In

order to prevent theft, take all electronic

keys with you when leaving the vehicle.

●

If the electronic key is put in the trunk with

all the doors locked, the key may not be

detected depending on the location of

the key and the surrounding radio wave

conditions. In this case, the key confine-

ment prevention function cannot be acti-

vated, causing the doors to lock when the

trunk is closed. Make sure to check

where the key is before closing the trunk.

●

The key confinement prevention function

cannot be activated if any one of the

doors is unlocked. In this case, open the

trunk using the trunk opener.

■

Overload protection function

The trunk lid will not operate when exces-

sive load is present on the top of the trunk

lid.

■

Fall-down protection function

While the trunk lid is opening automatically,

applying excessive force to it will stop the

opening operation to prevent the trunk lid

from rapidly falling down.

■

Jam protection function

While the trunk lid is closing automatically,

the trunk lid will stop closing and open if

something gets caught.

■

Internal trunk release lever

The trunk lid can be opened by pulling the

glow-in-the-dark lever located on the inside

of the trunk lid to the side.
The lever will continue to glow for some

time after the trunk lid is closed.

■

Using the mechanical key

The trunk can be also opened using the

mechanical key. (



If the trunk is unlocked using the mechani-

cal key, the power trunk lid and trunk easy

closer will not be operational. To return

them to an operational state, fully close the

trunk lid by hand.

■

If the smart access system with

push-button start or the wireless remote

control does not operate properly

Use the mechanical key to unlock the trunk.

(

Replace the key battery with a new one if it

is depleted.

■

Hands Free Power Trunk Lid operating

conditions (if equipped)

●

When the Hands Free Power Trunk Lid

(kick sensor) operation setting is turned

on and the power switch is turned off

●

When an electronic key is carried within

the operation range

■

Situations in which the Hands Free

Power Trunk Lid may not operate prop-

erly (if equipped)

In the following situations, the Hands Free

Power Trunk Lid may not operate properly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Trunk Lid again.

●

When standing excessively close to the

rear bumper

●

When an external radio wave source

interferes with the communication

113

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

between the electronic key and the vehi-

cle (



●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Trunk Lid,

such as a pay parking spot, gas station,

electrically heated road, or fluorescent

light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the
Hands Free Power Trunk Lid (kick sensor)
operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Trunk Lid (if

equipped)

When an electronic key is in the operation

detection area, the Hands Free Power Trunk

Lid may operate unintentionally, so be care-

ful in the following situations:

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Trunk Lid,

such as a pay parking spot, gas station,

electrically heated road, or fluorescent

light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the

Hands Free Power Trunk Lid (kick sensor)

operation setting off.

■

Open door warning buzzer



P.105

■

Customization

Some functions can be customized.

(

The trunk opener switch can be tem-
porarily disabled to protect luggage
stored in the trunk against theft.
Turn the main switch in the glove box
off to disable the trunk opener.

Luggage security system

114

3-2. Opening, closing and locking the doors and trunk

Off

The trunk lid cannot be opened even with
the wireless remote control, entry function
or Hands Free Power Trunk Lid.

■

When leaving a key to the vehicle with a

parking attendant

P.101

■

Antenna location

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key (including the card
key) on your person, for example in
your pocket. The driver should
always carry the electronic key.



Locks and unlocks the doors
(





Opens the trunk (



P.109)



Starts the hybrid system (



P.169)

A
B
C
D

115

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Effective range (areas within which the

electronic key is detected)

When locking or unlocking the doors

The system can be operated when the
electronic key is within about 2.3 ft. (0.7 m)
of an outside door handle. (Only the doors
detecting the key can be operated.)

When opening the trunk

The system can be operated when the
electronic key is within about 2.3 ft. (0.7 m)
of the trunk release button.

When starting the hybrid system or
changing power switch modes

The system can be operated when the
electronic key is inside the vehicle.

■

Alarms and warning messages

An alarm sounds and warning messages

are displayed on the multi-information dis-

play to protect against unexpected acci-

dents or theft of the vehicle resulting from

erroneous operation. When a warning mes-

sage is displayed, take appropriate mea-

sures based on the displayed message.

(



P.467)

When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

●

When an interior alarm sounds continu-

ously

■

If “Key Detected in Vehicle” is shown on

the multi-information display

An attempt was made to lock the doors

using the smart access system with

push-button start while the electronic key

was still inside the vehicle. Retrieve the elec-

tronic key from the vehicle and lock the

doors again.

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the 12-volt battery from being

discharged while the vehicle is not in opera-

tion for a long time.

●

In the following situations, the smart

access system with push-button start may

Situation

Correction

procedure

An attempt was made to

lock the vehicle while a

door was open.

Close all of the
doors and lock

the doors

again.

The trunk was closed

while the electronic key

was still inside the trunk

and all the doors were

locked.

Retrieve the

electronic key
from the trunk

and close the

trunk lid.

Situation

Correction

procedure

The power switch was

turned to ACCESSORY

mode while the driver’s

door was open (The

driver’s door was opened

when the power switch

was in ACCESSORY

mode).

Turn the power

switch off and

close the

driver’s door.

The power switch was

turned off while the

driver’s door was open.

Close the

driver’s door.

116

3-2. Opening, closing and locking the doors and trunk

take some time to unlock the doors.

• The electronic key has been left in an

area of approximately 6 ft. (2 m) of the

outside of the vehicle for 10 minutes or

longer.

• The smart access system with push-but-

ton start has not been used for 5 days or

longer.

●

If the smart access system with push-but-

ton start has not been used for 14 days or

longer, the doors cannot be unlocked at

any doors except the driver’s door. In this

case, take hold of the driver’s door han-

dle, or use the wireless remote control or

the mechanical key, to unlock the doors.

■

Turning an electronic key to bat-

tery-saving mode

When battery-saving mode is set, battery

depletion is minimized by stopping the elec-

tronic key from receiving radio waves.

Press

twice while pressing and holding

. Confirm that the electronic key indica-

tor flashes 4 times.
While the battery-saving mode is set, the

smart access system with push-button start

cannot be used. To cancel the function,

press any of the electronic key buttons.

■

Conditions affecting operation

The smart access system with push-button

start uses weak radio waves. In the following

situations, the communication between the

electronic key and the vehicle may be

affected, preventing the smart access sys-

tem with push-button start, wireless remote

control and immobilizer system from oper-

ating properly. (Ways of coping:

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit radio

waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Another vehicle’s electronic key or a

wireless key that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

●

When the electronic key is placed near a

battery charger or electronic devices

●

When the vehicle is parked in a pay park-

ing spot where radio waves are emitted.

■

Note for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is near the ground or

in a high place, or too close to the center

of the rear bumper when the trunk is

opened.

• The electronic key is on the instrument

panel, rear package tray or floor, or in the

door pockets or glove box when the

hybrid system is started or power switch

117

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

modes are changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the doors

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

or unlocked by anyone. However, only

the doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

hybrid system if the electronic key is near

the window.

●

The doors may unlock or lock if a large

amount of water splashes on the door

handle, such as in the rain or in a car

wash, when the electronic key is within

the effective range. (The doors will auto-

matically be locked after approximately

60 seconds if the doors are not opened

and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock sensor while

wearing gloves may delay or prevent lock

operation.

●

When the lock operation is performed

using the lock sensor, recognition signals

will be shown up to two consecutive

times. After this, no recognition signals

will be given.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In this case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 6 ft.

(2 m) or more away from the vehicle.

(Take care to ensure that the key is not

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a message may be shown on

the multi-information display and a

buzzer will sound outside the vehicle. To

turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if

it comes into contact with ice, snow, mud,

etc. Clean the lock sensor and attempt to

operate it again.

●

A sudden approach to the effective

range or door handle may prevent the

doors from being unlocked. In this case,

return the door handle to the original

position and check that the doors unlock

before pulling the door handle again.

●

If there is another electronic key in the

detection area, it may take slightly longer

to unlock the doors after the door handle

is gripped.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 6 ft. (2 m)

of the vehicle.

●

The smart access system with push-but-

ton start can be deactivated in advance.

●

Setting the electronic key to battery-sav-

ing mode helps to reduce key battery

depletion. (



■

To operate the system properly

●

Make sure to carry the electronic key

when operating the system. Do not get

the electronic key too close to the vehicle

when operating the system from the out-

side of the vehicle.

Depending on the position and holding
condition of the electronic key, the key may
not be detected correctly and the system
may not operate properly. (The alarm may
go off accidentally, or the door lock pre-
vention function may not operate.)

●

Do not leave the electronic key inside the

trunk.

The key confinement prevention function

118

3-2. Opening, closing and locking the doors and trunk

may not operate, depending on the loca-

tion of the key (the inside edge of the

trunk), conditions (inside a metal bag,

close to metallic objects) and the radio

waves in the surrounding area. (



P.111)

■

If the smart access system with

push-button start does not operate

properly

●

Locking and unlocking the doors and

trunk:



P.474

●

Starting the hybrid system:



P.475

■

Customization

Some functions can be customized.

(



■

If the smart access system with

push-button start has been deactivated

in a customized setting

●

Locking and unlocking the doors and

opening the trunk:

Use the wireless remote control or

mechanical key. (



P.102, 109, 474)

●

Starting the hybrid system and changing

power switch modes:



P.475

●

Stopping the hybrid system:

P.170

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should keep

away from the smart access system

with push-button start antennas.

(



P.114)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

your Lexus dealer for details, such as

the frequency of radio waves and tim-

ing of the emitted radio waves. Then,

consult your doctor to see if you

should disable the entry function.

●

Users of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask your Lexus dealer for details on dis-

abling the entry function.

119

3-3. Adjusting the seats

fore
dri
ving

3-3.Adjusting the seats

■

Seat adjustment switches

Seat position adjustment
Seatback angle adjustment
Head restraint height adjustment (if
equipped) (
