405

9-1. For owners

9

For
owners

AVERTISSEMENT

Ne fixez rien et ne posez rien sur des

emplacements tels que la planche de

bord, la garniture du volant et la partie

inférieure du tableau de bord.

Ces éléments peuvent se transformer

en projectiles lorsque les coussins

gonflables conducteur, passager avant

et genoux SRS se déploient.

Ne fixez rien aux portes, à la vitre du

pare-brise, aux vitres latérales, aux

montants avant et arrière, au rail latéral

de toit et à la poignée de maintien.

Ne suspendez aucun cintre ou objet

dur aux crochets à vêtements. Tous

ces objets pourraient se transformer

en projectiles et causer des blessures

graves, voire mortelles en cas de

déploiement des coussins gonflables

rideaux SRS.

Si un cache en vinyle est placé sur la

zone où le coussin gonflable de

genoux SRS se déploie, assurez-vous

de le retirer.

N'utilisez aucun accessoire de siège

recouvrant les zones de déploiement

des coussins gonflables latéraux SRS,

car il risque de gêner le déploiement

des coussins gonflables SRS. De tels

accessoires peuvent empêcher les

coussins gonflables latéraux de

fonctionner correctement, désactiver

le système ou entraîner le déploiement

accidentel des coussins gonflables

latéraux, occasionnant des blessures

graves, voire mortelles.

Évitez de faire subir des chocs ou des

pressions excessives aux parties ren-

fermant les composants de coussins

gonflables SRS. En effet, cela pourrait

entraîner un dysfonctionnement des

coussins gonflables SRS.

Ne touchez aucun composant

immédiatement après le déploiement

(gonflage) des coussins gonflables

SRS, car ils peuvent être chauds.

Si vous avez des difficultés à respirer

après le déploiement des coussins

gonflables SRS, ouvrez une porte ou

une vitre pour faire entrer de l'air frais,

ou bien descendez du véhicule si cela

ne présente pas de danger. Essuyez

tout résidu dès que possible afin

d'éviter d'éventuelles irritations de la

peau.

Si les parties renfermant les coussins

gonflables SRS, comme les garnitures

du volant et des montants avant et

arrière, sont endommagées ou cra-

quelées, faites-les remplacer par votre

concessionnaire Lexus.

Ne placez rien sur le siège du pas-

sager avant, comme un coussin par

exemple. Cela a pour conséquence de

répartir le poids du passager sur toute

la surface du siège, ce qui empêche le

capteur de détecter correctement le

poids du passager. En conséquence,

les coussins gonflables frontaux SRS

du passager avant risquent de ne pas

se déployer en cas de collision.

406

9-1. For owners

Boulon de réglage A
Boulon de réglage B

Vérifiez que le réservoir de carbu-
rant du véhicule est plein et que la
zone autour des phares n'est pas
déformée.

Stationnez le véhicule sur une sur-
face plane.

Assurez-vous que la pression de
gonflage des pneus est au niveau
recommandé.

Faites asseoir quelqu'un dans le
siège conducteur.

AVERTISSEMENT

Modification et mise au rebut des

composants du système de coussins

gonflables SRS

Ne mettez pas votre véhicule au rebut et

ne procédez à aucune des modifications

suivantes sans consulter votre conces-

sionnaire Lexus. Les coussins gonflables

SRS peuvent ne pas fonctionner cor-

rectement ou se déployer (se gonfler)

accidentellement, provoquant la mort ou

de graves blessures.

Installation, dépose, démontage et

réparation des coussins gonflables

SRS

Réparations, modifications, dépose ou

remplacement du volant, du tableau

de bord, de la planche de bord, des

sièges ou de leur garnissage, des mon-

tants avant, latéraux et arrière ou des

rails latéraux de toit

Réparations ou modifications des ailes

avant, du pare-chocs avant ou des

flancs de l'habitacle

Installation d'un protège-calandre

(pare-buffle, pare-kangourou, etc.), de

chasse-neige, de treuils ou d'un

porte-bagages de toit

Modifications du système de suspen-

sion du véhicule

Installation d'appareils électroniques

tels que les émetteurs/récepteurs

radios mobiles et les lecteurs CD

Modifications de votre véhicule pour

une personne atteinte d'un handicap

physique

Headlight aim instructions
for Canadian owners (in
French)

The following is a French explana-
tion of headlight aim instructions
from the headlight aim section in
this manual.

Boulons de réglage du mouve-
ment vertical

Avant de vérifier le réglage des
phares

A

B

407

9-1. For owners

9

For owners

Balancez le véhicule plusieurs fois.

1

À l'aide d'un tournevis cruciforme,
tournez le boulon A dans n'importe
quel sens.

Mémorisez le sens dans lequel vous avez

tourné et le nombre de tours.

Phares à faisceau unique

Phares à faisceau triple

2

Tournez le boulon B du même
nombre de tours dans le même
sens qu'à l'étape

1

.

Si vous n'arrivez pas à régler le phare en

procédant de la sorte, confiez le véhicule à

votre concessionnaire Lexus pour qu'il

règle le faisceau des phares.

Réglage du faisceau des phares

409

Index

.

What to do if... (Troubleshooting)

.........................................................

410

Alphabetical Index.....................

413

410

What to do if... (Troubleshooting)

1-1.What to do if... (Troubleshooting)

What to do if... (Troubleshooting)

If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
(

P.348)

If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. (

P.348)

Is the electronic key battery weak or
depleted? (

P.307)

Is the engine switch in IGNITION
ON mode?

When locking the doors, turn the engine
switch off. (

P.131)

Is the electronic key left inside the
vehicle?

When locking the doors, make sure that
you have the electronic key on your per-
son.

The function may not operate prop-
erly due to the condition of the radio
wave. (

P.98)

Is the child-protector lock set?

The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. (

P.93)

The function to prevent the elec-
tronic key from being left inside the
trunk will operate and you can open
the trunk as usual. Take the key out
from the trunk. (

P.95)

Did you press the engine switch
while firmly depressing the brake
pedal? (

P.130)

Is the shift lever in P? (

P.130)

Is the electronic key anywhere
detectable inside the vehicle?
(

P.97)

Is the electronic key battery weak or
depleted?

In this case, the engine can be started in a

If you have a problem, check the
following before contacting your
Lexus dealer.

The doors cannot be locked,
unlocked, opened or closed

You lose your keys

The electronic key does not
operate properly

The doors cannot be locked or
unlocked

The rear door cannot be opened

The trunk lid is closed with the
electronic key left inside

If you think something is wrong

The engine does not start

411

What to do if... (Troubleshooting)

temporary way. (

P.350)

Is the battery discharged? (

P.351)

Is the engine switch in IGNITION
ON mode?

If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode. (

P.134)

Is the window lock switch pressed?

The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. (

P.115)

The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. (

P.132)

The seat belt reminder light is flash-
ing

Are the driver and the front passenger
wearing the seat belts? (

P.330)

The parking brake indicator is on

Is the parking brake released? (

P.139)

Depending on the situation, other
types of warning buzzer may also
sound. (

P.327, 336)

Did anyone inside the vehicle open
a door during setting the alarm?

The sensor detects it and the alarm sounds.
(

P.61)

Do one of the following to deactivate
or stop the alarm:

Unlock the doors.

Open the trunk.

Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine. (The alarm will be
deactivated or stopped after a few
seconds.)

Is the electronic key left inside the
vehicle or the moon roof opened?

Check the message on the multi-informa-
tion display. (

P.336)

When a warning light turns on or a
warning message is displayed, refer
to P.327, 336.

The shift lever cannot be shifted
from P even if you depress the
brake pedal

The windows do not open or
close by operating the power
window switches

The engine switch is turned off
automatically

A warning buzzer sounds during
driving

An alarm is activated and the
horn sounds

A warning buzzer sounds when
leaving the vehicle

A warning light turns on or a
warning message is displayed

412

What to do if... (Troubleshooting)

Stop the vehicle in a safe place and
replace the flat tire with the spare
tire. (

P.339)

Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. (

P.359)

When a problem has occurred

If you have a flat tire

The vehicle becomes stuck

413

Alphabetical Index

Alphabetical Index

A

A/C

Air conditioning filter .............................. 305
Automatic air conditioning system... 243
Micro dust and pollen filter...................248

ABS (Anti-lock Brake System).............. 229

Warning light...............................................329

ACA (Active Cornering Assist)........... 229
Active Cornering Assist (ACA)........... 229
Active Sound Control (ASC) ..................143
Adaptive Variable Suspension system229
AHB (Automatic High Beam) .................147
Air conditioning filter.................................305
Air conditioning system

Air conditioning filter .............................. 305
Automatic air conditioning system... 243
Micro dust and pollen filter...................248

Airbags

Airbag operating conditions...................30
Airbag precautions for your child........ 33
Correct driving posture.............................23
Curtain shield airbag operating condi-

tions..................................................................30

Curtain shield airbag precautions ....... 33
Front passenger occupant classification

system .............................................................36

General airbag precautions ................... 33
Locations of airbags....................................28
Modification and disposal of airbags .35
Side airbag operating conditions.........30
Side airbag precautions............................ 33
Side and curtain shield airbags operating

conditions......................................................30

Side and curtain shield airbags precau-

tions.................................................................. 33

SRS airbags .....................................................28
SRS warning light ......................................328

Alarm.....................................................................61

Warning buzzer......................................... 327

Anchor brackets.......................................42, 51

Antennas (smart access system with

push-button start).........................................97

Anti-lock Brake System (ABS).............. 229

Warning light ...............................................329

Approach warning........................................192
Armrest............................................................259
ASC (Active Sound Control) ..................143
Assist grips .....................................................259
Audio system-linked display........................81
Automatic air conditioning system ...... 243
Automatic headlight leveling system ....146
Automatic High Beam ................................147
Automatic light control system................145
Automatic transmission..............................133

M mode ........................................................... 136
Paddle shift switches.......................135, 136
Snow mode.................................................... 135

Average fuel economy................................. 78
Average vehicle speed ................................ 78

B

Back-up lights

Replacing light bulbs..................................312

Battery

If the battery is discharged..................... 351
Preparing and checking before winter

..........................................................................234

Warning light ...............................................328

Blind Spot Monitor (BSM).........................197
Boost gauge......................................................80
Brake

Brake hold.......................................................142
Fluid.......................................................292, 369
Parking brake ............................................... 139
Warning light ...............................................327

Brake assist .................................................... 229
Break-in tips...................................................... 121
Brightness control

Instrument panel light control.................75

BSM (Blind Spot Monitor).........................197

414

Alphabetical Index

Buzzer

Hands off steering wheel warning (LTA)

.......................................................................... 183

C

Card key ............................................................86
Care

Exterior ...........................................................268
Interior..............................................................272
Seat belts.........................................................272
Wheels and wheel ornaments268, 269

Cargo capacity...............................................128
Cargo net .......................................................258
Center Display .............................................240
Chains ..............................................................235
Child restraint system

Fixed with a LATCH system .................. 49
Fixed with a seat belt...................................45
Front passenger occupant classification

system .............................................................36

Points to remember ......................................41
Riding with children.......................................41
Types of child restraint system installation

method ............................................................42

Using an anchor bracket............................51

Child safety

Airbag precautions...................................... 33
Battery precautions..................................354
Child restraint system..................................42
Heated steering wheel and seat heater

precautions..................................................251

How your child should wear the seat belt

............................................................................ 25

Moon roof precautions .............................118
Power window lock switch...................... 115
Power window precautions.................... 115
Rear door child-protectors.....................93
Removed electronic key battery precau-

tions...............................................................307

Seat belt extender precautions ............. 25
Seat belt precautions....................................41
Trunk precautions ........................................ 94

Child-protectors............................................. 93
Cleaning

Exterior........................................................... 268
Interior ............................................................. 272
Radar sensor.................................................160
Seat belts........................................................ 272
Wheels and wheel ornaments268, 269

Clock ............................................... 69, 70, 259
Coat hooks.....................................................259
Condenser .......................................................291
Console box .................................................. 257
Consumption screen .................................... 82
Cooling system.............................................290

Engine overheating.................................. 355

Cruise control

Dynamic radar cruise control with

full-speed range....................................... 187

Cup holders................................................... 257
Current fuel consumption .......................... 78
Curtain shield airbags .................................. 28
Customizable features..............................386

D

Daytime running light system...................145
Defogger

Outside rear view mirrors.....................245
Rear window................................................245
Windshield....................................................245

Differential

Front differential oil................................... 369
Rear differential oil.................................... 369

Dimensions .................................................... 362
Dinghy towing.................................................129
Display

Center Display............................................240
Dynamic radar cruise control with

full-speed range....................................... 187

Intuitive parking assist..............................203
LTA (Lane Tracing Assist).....................180
Multi-information display..........................76
RCTA................................................................ 210
Warning message.....................................336

415

Alphabetical Index

Distance until next engine oil change.....74
Do-it-yourself maintenance.....................277
Door courtesy lights...................................253

Wattage.......................................................... 373

Door lock

Doors..................................................................90
Smart access system with push-button

start................................................................... 97

Wireless remote control...........................88

Doors

Automatic door locking and unlocking

system .............................................................93

Door glasses....................................................114
Door lock..........................................................90
Open door warning buzzer ............91, 93
Outside rear view mirrors ........................112
Rear door child-protectors.....................93

Drive distance.................................................. 78
Drive info 1/Drive info 2/Drive info 3.... 78
Driver’s seat position memory

Driving position memory........................ 104
Memory recall function ........................... 105
Power easy access system.................... 104

Drive-Start Control (DSC)

Sudden start restraint control................125

Driving

Break-in tips.....................................................121
Correct driving posture.............................23
Driving mode select switch...................227
Procedures.....................................................120
Winter drive tips......................................... 234

Driving information display ........................ 78
Driving position memory........................... 104

Memory recall function ........................... 105
Power easy access system.................... 104

Driving range ................................................... 78
Driving support system information display

...............................................................................81

DSC (Drive-Start Control)

Sudden start restraint control................125

Dynamic radar cruise control with

full-speed range..........................................187

Warning message......................................195

E

Eco Driving Indicator.....................................79
Eco Driving Indicator Light.........................79
EDR (Event data recorder)............................7
Elapsed time ..................................................... 78
Electric Power Steering (EPS) .............. 229

Warning light .............................................. 330

Electronic key ..................................................86

Battery-saving function..............................98
If the electronic key does not operate

properly.......................................................349

Replacing the battery...............................307

Emergency flashers..................................... 318
Emergency, in case of

If a warning buzzer sounds...................327
If a warning light turns on.......................327
If a warning message is displayed.....336
If the battery is discharged..................... 351
If the electronic key does not operate

properly.......................................................349

If the engine will not start........................347
If the fuel filler door cannot be opened

..........................................................................349

If the vehicle is submerged or water on

the road is rising....................................... 319

If you have a flat tire ..................................339
If you lose your keys................................ 348
If you think something is wrong..........325
If your vehicle becomes stuck............ 359
If your vehicle has to be stopped in an

emergency..................................................318

If your vehicle needs to be towed .......321
If your vehicle overheats ....................... 355

Engine

ACCESSORY mode................................. 131
Compartment............................................. 285
Engine switch................................................130
Fuel pump shut off system.....................326

416

Alphabetical Index

Hood................................................................283
How to start the engine........................... 130
Identification number...............................363
If the engine will not start ....................... 347
If your vehicle has to be stopped in an

emergency ................................................. 318

Ignition switch (engine switch) ............ 130
Overheating.................................................355
Tachometer ............................................69, 70

Engine coolant

Capacity.........................................................367
Checking .......................................................290
Preparing and checking before winter

......................................................................... 234

Engine coolant temperature gauge69, 70
Engine immobilizer system ........................60
Engine oil

Capacity.........................................................365
Checking .......................................................287
Preparing and checking before winter

......................................................................... 234

Warning light...............................................328

Engine oil maintenance data ..................289
Engine oil pressure gauge..........................80
Engine oil temperature gauge..........70, 80
Engine switch ................................................. 130

Auto power off function ...........................132
Changing the engine switch modes... 131
If your vehicle has to be stopped in an

emergency ................................................. 318

Enhanced Vehicle Stability Control

(Enhanced VSC)...................................... 229

Enhanced VSC (Enhanced Vehicle Stabil-

ity Control).................................................. 229

EPS (Electric Power Steering) .............. 229

Warning light...............................................330

Event data recorder (EDR)............................7

F

Flat tire

Tire pressure warning system............. 297
Vehicles with a spare tire ......................339

Floor mats...........................................................22
Fluid

Automatic transmission......................... 368
Brake............................................................... 369
Washer ...........................................................294

Footwell lights ...............................................253

Wattage..........................................................373

Front passenger occupant classification

system .............................................................. 36

Front seats

Adjustment..................................................... 102
Cleaning......................................................... 272
Correct driving posture ............................ 23
Driving position memory........................ 104
Head restraints............................................. 107
Memory recall function............................105
Power easy access system .................... 104
Seat heaters................................................... 251
Seat position memory .............................. 104
Seat ventilators............................................. 251

Front side marker light

Light switch.................................................... 145
Replacing light bulbs..................................312

Front turn signal lights

Replacing light bulbs....................... 312, 313
Turn signal lever ..........................................138
Wattage..........................................................373

Fuel

Capacity ........................................................ 365
Fuel gauge...............................................69, 70
Fuel pump shut off system.....................326
Information....................................................374
Refueling...........................................................157
Type................................................................. 365
Warning light .............................................. 330

Fuel consumption

Average fuel economy ..............................78
Current fuel consumption........................78

Fuel filler door

If the fuel filler door cannot be opened

..........................................................................349

Refueling...........................................................157

417

Alphabetical Index

Fuel gauge.................................................69, 70
Fuel pump shut off system........................ 326
Fuses.................................................................308

G

Garage door opener................................. 262
Gauges............................................................... 69
Gear Position...................................................80
G-force...............................................................80
Glove box....................................................... 256
Glove box light............................................. 257

H

Head restraints...............................................107
Headlight aim................................................. 310
Headlights

Automatic High Beam system..............147
Light switch.....................................................145
Replacing light bulbs..................................312

Heated steering wheel................................251
Heaters

Automatic air conditioning system... 243
Heated steering wheel..............................251
Outside rear view mirrors ....................245
Seat heaters....................................................251

High mounted stoplight

Replacing light bulbs..................................312

Hill-start assist control............................... 229
Hood

Open ...............................................................283

Hooks

Coat hooks...................................................259
Retaining hooks (floor mat)......................22

Horn.....................................................................110

I

I/M test ............................................................280
Identification

Engine .............................................................363
Vehicle............................................................362

Ignition switch (engine switch)................ 130

Auto power off function............................132
Changing the engine switch modes... 131
If your vehicle has to be stopped in an

emergency..................................................318

Indicators ........................................................... 66
Initialization

Items to initialize ........................................ 396
Maintenance.....................................276, 289
Power windows............................................. 114
Tire pressure warning system .............299

Inside door handle lights...........................253
Inside rear view mirror.................................110
Instrument panel light control ................... 75
Intercooler........................................................291
Intercooler coolant

Capacity .........................................................367
Checking ...................................................... 290

Interior lights..................................................253

Front interior light ......................................253
Rear interior light........................................253

Intuitive parking assist......................201, 203

Function..........................................................203
Warning message.................................... 205

J

Jack

Positioning a floor jack............................283
Vehicle-equipped jack .......................... 340

Jack handle ....................................................340
Jam protection function

Moon roof ........................................................ 117
Power windows............................................. 114

K

Keyless entry

Smart access system with push-button

start ...................................................................97

Wireless remote control.......................... 88

Keys

Battery-saving function..............................98

418

Alphabetical Index

Electronic key.................................................86
Engine switch................................................ 130
If the electronic key does not operate

properly.......................................................349

If you lose your keys.................................348
Key number plate.........................................86
Keyless entry..........................................90, 97
Mechanical key..............................................86
Replacing the battery...............................307
Warning buzzer............................................ 97
Wireless remote control...........................88

Knee airbags .................................................... 28

L

Lane Tracing Assist (LTA)

Operation........................................................175
Warning messages ................................... 183

Language (multi-information display) .....81
LATCH anchors ............................................. 49
Lever

Auxiliary catch lever.................................283
Hood lock release lever.........................283
Internal trunk release lever ......................96
Shift lever..........................................................133
Turn signal lever.......................................... 138
Wiper lever.................................................... 150

Lexus Enform Safety Connect.................. 54
Lexus Safety System + 2.5

AHB (Automatic High Beam)..............147
Dynamic radar cruise control with

full-speed range........................................187

LTA (Lane Tracing Assist)......................175
PCS (Pre-Collision System)................. 165
RSA (Road Sign Assist) .......................... 184

License plate lights

Light switch.....................................................145
Replacing light bulbs..................................312

Light bulbs

Replacing.......................................................... 311

Lights

Automatic High Beam system..............147
Front interior lights....................................253

Front personal lights.................................254
Headlight switch.......................................... 145
Interior lights.................................................253
Interior lights list..........................................253
Rear interior lights .....................................253
Rear personal lights..................................254
Replacing light bulbs..................................312
Trunk lid light...................................................95
Trunk light.........................................................95
Turn signal lever ..........................................138
Vanity lights ................................................. 260
Wattage..........................................................373

LTA (Lane Tracing Assist)

Operation........................................................175
Warning messages....................................183

Luggage mats ...............................................258

M

Maintenance

Do-it-yourself maintenance .................. 281
General maintenance ............................. 277
Maintenance data......................................362
Maintenance requirements ..................276

Malfunction indicator lamp .....................328
Menu icons.........................................................76
Meter

Changing the main meter location...... 74
Clock..........................................................69, 70
Indicators...........................................................66
Instrument panel light control.................75
Meter control switches ...............................77
Meters.................................................................69
Multi-information display..........................76
Settings................................................................ 81
Warning lights.............................................327
Warning message.....................................336

Micro dust and pollen filter .....................248
Mirrors

Inside rear view mirror...............................110
Outside rear view mirror defoggers245
Outside rear view mirrors........................ 112
Vanity mirrors............................................. 260

419

Alphabetical Index

Moon roof

Door lock linked moon roof operation

.............................................................................117

Jam protection function..............................117
Operation......................................................... 116

Multi-information display.............................76

Audio system-linked display.....................81
Boost gauge....................................................80
Drive information 1/Drive information

2/Drive information 3............................. 78

Driving information display...................... 78
Driving support system information dis-

play .....................................................................81

Dynamic radar cruise control with

full-speed range........................................187

Eco Driving Indicator ................................. 79
Engine oil pressure gauge.......................80
Engine oil temperature gauge...............80
Gear Position.................................................80
G-force..............................................................80
LTA (Lane Tracing Assist).....................180
Menu icons...................................................... 76
Meter control switches...............................77
Navigation system-linked display..........81
Pop-up display............................................... 76
Settings ................................................................81
Speedometer.................................................. 79
Tire pressure................................................ 297
Warning message.....................................336

N

Navigation system-linked display..............81
Noise from under vehicle .............................. 5

O

“ODO TRIP” switch .......................................74
Odometer ..........................................................74
Odometer and trip meter display

Display items....................................................74
“ODO TRIP” switch.....................................74
Pop-up display............................................... 75

Oil

Engine oil....................................................... 365
Front differential oil................................... 369
Rear differential oil.................................... 369

Opener

Fuel filler door................................................157
Hood................................................................283
Trunk ...................................................................95

Outside rear view mirrors

Adjustment....................................................... 112
BSM (Blind Sport Monitor)....................197
Folding................................................................ 113
Linked mirror function when reversing

............................................................................. 112

Mirror position memory.......................... 104
Outside rear view mirror defoggers245
RCTA function............................................. 210

Outside temperature............................69, 70
Overheating..................................................355

P

Paddle shift switches..........................135, 136
Panic mode .......................................................88
Parking assist sensors (intuitive parking

assist).............................................................203

Parking brake

Operation....................................................... 139
Parking brake engaged warning buzzer

............................................................................. 141

Warning light ...............................................333
Warning message........................................ 141

Parking lights

Light switch.................................................... 145
Replacing light bulbs..................................312

Parking Support Brake function (for

rear-crossing vehicles) .......................... 225

Function..........................................................225

Parking Support Brake function (static

objects)......................................................... 222

Function.......................................................... 222

PCS (Pre-Collision System)

Function...........................................................165

420

Alphabetical Index

PCS OFF switch......................................... 168
Warning light............................................... 332

Personal lights...............................................253
PKSA (Parking Support Alert)................201
PKSB (Parking Support Brake)...............216

Warning message.....................................220

Power easy access system ....................... 104
Power outlets ................................................260
Power steering (Electric power steering

system).......................................................... 229

Warning light...............................................330

Power window switch lights....................253
Power windows

Door lock linked window operation... 115
Jam protection function..............................114
Operation..........................................................114
Window lock switch ................................... 115

Pre-Collision System (PCS)

Function........................................................... 165
PCS OFF switch......................................... 168
Warning light............................................... 332

R

Radar cruise control (dynamic radar cruise

control with full-speed range)...............187

Radiator.............................................................291
RCTA

Function............................................................210
Warning message.........................................211

RCTA (Rear Cross Traffic Alert) ...........201
RCTA function ................................................ 211
Rear Cross Traffic Alert (RCTA) ...........210
Rear seats ........................................................ 103

Head restraints .............................................107

Rear side marker lights

Light switch.....................................................145

Rear sunshades ..............................................261
Rear turn signal lights

Replacing light bulbs........................312, 314
Turn signal lever.......................................... 138
Wattage.......................................................... 373

Rear view mirror

Inside rear view mirror...............................110
Outside rear view mirrors........................ 112

Rear window defogger ............................. 245
Refueling

Capacity ........................................................ 365
Fuel types...................................................... 365
If the fuel filler door cannot be opened

..........................................................................349

Opening the fuel tank cap ......................157

Remote Touch ..............................................238
Replacing

Electronic key battery..............................307
Fuses................................................................308
Light bulbs........................................................ 311
Tires ..................................................................339

Resetting the message indicating mainte-

nance is required.......................................276

Rev indicator .....................................................72
Rev peak..............................................................73
Road Sign Assist ........................................... 184
RSA (Road Sign Assist) ............................. 184

S

Seat belt reminder light.............................330
Seat belts............................................................ 24

Automatic Locking Retractor.................26
Child restraint system installation......... 42
Cleaning and maintaining the seat belt

.......................................................................... 272

Emergency Locking Retractor..............26
How to wear your seat belt.....................25
How your child should wear the seat belt

.............................................................................25

Pregnant women, proper seat belt use

............................................................................. 24

Reminder light and buzzer .................. 330
Seat belt extender.........................................25
Seat belt pretensioners.............................. 27
SRS warning light.......................................328

Seat heaters.....................................................251
Seat position memory................................. 104

421

Alphabetical Index

Seat ventilators...............................................251
Seating capacity.............................................128
Seats

Adjustment......................................................102
Adjustment precautions...........................102
Child seats/child restraint system installa-

tion......................................................................41

Cleaning..........................................................272
Driving position memory........................ 104
Head restraints .............................................107
Power easy access system.................... 104
Properly sitting in the seat.........................23
Seat heaters....................................................251
Seat position memory .............................. 104
Seat ventilators..............................................251

Sensor

Automatic headlight system...................145
Automatic High Beam system..............147
Inside rear view mirror................................. 111
Intuitive parking assist..............................203
LTA (Lane Tracing Assist)......................175
Parking Support Brake function

(rear-crossing vehicles)...................... 225

Parking Support Brake function (static

objects)........................................................ 223

Radar sensor.......................................160, 197
Rain-sensing windshield wipers.......... 155
RCTA ..................................................................211

Service reminder message ......................276
Shift lever

Automatic transmission............................133

Side airbags ...................................................... 28
Side marker lights

Light switch.....................................................145
Replacing light bulbs..................................312

Side mirrors

Adjustment........................................................112
BSM (Blind Sport Monitor) ...................197
Folding ............................................................... 113
Linked mirror function when reversing

.............................................................................112

Mirror position memory.......................... 104

RCTA function............................................. 210

Side turn signal lights

Replacing light bulbs..................................312
Turn signal lever ..........................................138

Side windows ................................................... 114
Smart access system with push-button

start

Antenna location...........................................97
Entry functions................................................90
Starting the engine .....................................130

Snow mode ......................................................135
Snow tires ....................................................... 234
Spare tire.........................................................339

Storage location ........................................ 340

Spark plug ......................................................368
Specifications................................................ 362
Speedometer ...................................69, 70, 79
Steering wheel

Adjustment.....................................................109
Heated steering wheel............................. 251
Meter control switches ...............................77
Power easy access system .................... 104
Steering wheel position memory........ 104

Stop lights

Replacing light bulbs..................................312

Storage features .......................................... 256
Stuck

If the vehicle becomes stuck............... 359

Sun visors........................................................260
Sunshade

Roof...................................................................... 117

Switch

ASC (Active Sound Control) dial.......143

Switches

Activating the Automatic High Beam147
Automatic High Beam system..............147
Brake Hold switch.......................................142
Door lock switches ......................................92
Driving mode select switch .................. 227
Driving position memory switches .... 104
Dynamic radar cruise control with

full-speed range switch ........................ 187

422

Alphabetical Index

Emergency flashers switch.................... 318
Engine switch................................................ 130
Garage door opener switches .......... 262
Heated steering wheel switch...............251
Ignition switch............................................... 130
Instrument panel light control switches

............................................................................ 75

Intuitive parking assist switch...............204
Light switches................................................145
LTA (Lane Tracing Assist) switch......180
Meter control switches...............................77
Moon roof switches .................................... 116
“ODO TRIP” switch.....................................74
Outside rear view mirror switches.......112
Paddle shift switches.......................135, 136
Parking brake switch .................................139
PCS OFF switch......................................... 168
PKSB (Parking Support Brake) switch

........................................................................... 217

Power door lock switch............................ 92
Power window switches............................114
RCTA switch....................................................211
Rear sunshades switch .............................261
Rear window and outside rear view mir-

ror defoggers switch............................ 243

Seat heater switches ..................................251
Seat ventilator switches............................251
Snow mode switch .....................................135
“SOS” button ..................................................54
Tilt and telescopic steering control switch

.......................................................................... 109

Tire pressure warning reset switch ..299
Trunk opener main switch .......................96
Trunk opener switch...................................95
Vehicle-to-vehicle distance switch ....187
VSC OFF switch.......................................230
Window lock switch ................................... 115
Windshield wiper and washer switch150
Windshield wiper de-icer .....................249

T

Tachometer...............................................69, 70

Rev indicator ................................................... 72
Rev peak............................................................ 73

Tail lights

Light switch.................................................... 145
Replacing light bulbs..................................312

The Secondary Collision Brake ............230
Theft deterrent system

Alarm.....................................................................61
Engine immobilizer system......................60

Tire inflation pressure

Maintenance data......................................370
Tire inflation pressure display function

..........................................................................297

Warning light ................................................ 331

Tire information............................................ 376

Glossary........................................................380
Size....................................................................378
Tire identification number...................... 377
Uniform Tire Quality Grading............379

Tire pressure display.................................. 297
Tire pressure warning system

Function..........................................................297
Initializing........................................................299
Installing tire pressure warning valves

and transmitters...................................... 298

Registering ID codes ..............................300
Warning light ................................................ 331

Tires

Chains .............................................................235
Checking .......................................................295
If you have a flat tire ..................................339
Inflation pressure........................................302
Information....................................................376
Replacing .......................................................339
Rotating tires ................................................297
Size....................................................................370
Snow tires ......................................................234
Spare tire........................................................339

423

Alphabetical Index

Tire inflation pressure display function

......................................................................... 297

Tire pressure warning system............. 297
Warning light.................................................331

Tools..................................................................340
Top tether strap.................................................51
Total load capacity...................................... 362
Towing

Dinghy towing...............................................129
Emergency towing .....................................321
Towing eyelet .............................................. 323
Trailer towing.................................................128

TRAC (Traction Control) ........................ 229
Traction Control (TRAC) ........................ 229
Trailer towing ..................................................128
Transmission

Automatic transmission............................133
Driving mode select switch...................227
M mode............................................................136
Paddle shift switches.......................135, 136
Snow mode ....................................................135

Trip meters .........................................................74
Trunk.................................................................... 94

Internal trunk release lever ......................96
Smart access system with push-button

start...................................................................95

Trunk features..............................................258
Trunk lid light...................................................95
Trunk light.........................................................95
Trunk opener main switch .......................96
Trunk opener switch...................................95
Wireless remote control...........................95

Trunk lid light.................................................... 95
Trunk light.......................................................... 95

Wattage.......................................................... 373

Turn signal lights

Replacing light bulbs..................................312
Turn signal lever.......................................... 138

V

Vanity lights....................................................260

Wattage.......................................................... 373

Vanity mirrors ...............................................260
VDIM (Vehicle Dynamics Integrated Man-

agement)...................................................... 229

Vehicle data recording....................................6
Vehicle Dynamics Integrated Manage-

ment (VDIM).............................................. 229

Vehicle identification number................ 362
Vehicle Stability Control (VSC) ........... 229
Ventilators (seat ventilators).....................251
VSC (Vehicle Stability Control) ........... 229

W

Warning buzzers

ABS...................................................................329
Airbags............................................................328
Approach warning......................................192
Brake hold.....................................................333
Brake Override System .........................329
Brake system................................................327
Charging system........................................328
Downshifting ....................................... 136, 137
Drive-Start Control...................................329
Electric power steering.......................... 330
Engine..............................................................328
Hands off steering wheel warning (LTA)

...........................................................................183

High coolant temperature.....................327
Intuitive parking assist...................209, 331
Low engine oil pressure.........................328
LTA (Lane Tracing Assist).175, 178, 331
Open door................................................91, 93
Open window ................................................115
PKSA (Parking Support Alert) ...........202
PKSB (Parking Support Brake) .........332
Pre-collision braking..................................167
RCTA (Rear Cross Traffic Alert) ......332
Seat belt......................................................... 330

Warning lights............................................... 327

ABS...................................................................329
Brake hold operated indicator ...........333
Brake Override System .........................329
Brake system................................................327

424

Alphabetical Index

Charging system .......................................328
Drive-Start Control ..................................329
Electric power steering ..........................330
High coolant temperature .................... 327
Intuitive parking assist OFF indicator331
Low engine oil pressure.........................328
Low fuel level...............................................330
LTA indicator.................................................331
Malfunction indicator lamp...................328
Parking brake indicator..........................333
PKSB OFF indicator................................ 332
Pre-collision system ................................. 332
RCTA OFF indicator............................... 332
Seat belt reminder light ..........................330
Slip indicator ................................................333
SRS....................................................................328
Tire pressure..................................................331

Warning messages.....................................336
Washer

Adding ............................................................294
Preparing and checking before winter

......................................................................... 234

Switch ............................................................... 150

Washing and waxing..................................268
Weight

Cargo capacity.............................................128
Load limits .......................................................128
Weight ............................................................362

Wheels.............................................................304

Size....................................................................370

Window lock switch ......................................115
Windows

Power windows..............................................114
Rear window defogger ..........................245
Washer............................................................ 150

Windshield wipers ....................................... 150
Winter driving tips....................................... 234
Wireless remote control

Battery-Saving Function ...........................98
Locking/Unlocking .....................................88
Replacing the battery...............................307

For information regarding the

equipment listed below, refer to
the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.

· Navigation system
· Audio/visual system
· Lexus parking assist monitor
· Lexus Enform















Content      ..     11      12      13
