Lexus GX460 (2023 year). Manual in english

1-1. For safe use

GX460_OM_OM60R43U_(U)

For safety

and security

WARNING

■

When children are in the vehicle

Do not allow children to play with the seat belt. If the seat belt becomes twisted around

a child’s neck, it may lead to choking or other serious injuries that could result in death.

If this occurs and the buckle cannot be unfastened, scissors should be used to cut the

belt.

■

When the child restraint system is not in use

●

Keep the child restraint system properly secured on the seat even if it is not in use. Do

not store the child restraint system unsecured in the passenger compartment.

●

If it is necessary to detach the child restraint system, remove it from the vehicle or

store it securely in the luggage compartment. This will prevent it from injuring passen-

gers in the event of a sudden stop, sudden swerve or accident.

1-1. For safe use

GX460_OM_OM60R43U_(U)

Installing child restraints

Child restraint LATCH anchors



7-passenger models

LATCH anchors are provided for the

right side second seat and between the

center and left side second seats. (But-

tons displaying the location of the

anchors are attached to the seats.)



6-passenger models

LATCH anchors are provided for both

second seats. (Buttons displaying the

location of the anchors are attached to

the seats.)

Seat belts equipped with a child
restraint locking mechanism (ALR/
ELR belts except driver’s seat belt)
(



P. 32)

Follow the child restraint system manufacturer’s instructions. Firmly secure
child restraints to the seats using the LATCH anchors or a seat belt. Attach the
top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint system is not compati-
ble with the LATCH (Lower Anchors and Tethers for Children) system.

1-1. For safe use

GX460_OM_OM60R43U_(U)

For safety

and security

While pushing the child restraint
system down into the seat, allow
the shoulder belt to retract until
the child restraint system is
securely in place.

After the shoulder belt has retracted

to a point where there is no slack in

the belt, pull the belt to check that it

cannot be extended.

■

Forward-facing



Convertible seat

Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (



P. 134)

Place the child restraint system
on the seat facing the front of the
vehicle.

1-1. For safe use

GX460_OM_OM60R43U_(U)

Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.

While pushing the child restraint
system into the seat, allow the
shoulder belt to retract until the
child restraint system is securely
in place.

After the shoulder belt has retracted

to a point where there is no slack in

the belt, pull the belt to check that it

cannot be extended.

If the child restraint has a top tether strap, the top tether strap should be
latched onto the top tether strap anchor. (



P. 66)

1-1. For safe use

GX460_OM_OM60R43U_(U)

For safety

and security

■

Booster seat

Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (



P. 134)

Place the child restraint system
on the seat facing the front of the
vehicle.

Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instructions
and insert the plate into the
buckle. Make sure that the belt is
not twisted.

Check that the shoulder belt is cor-

rectly positioned over the child’s

shoulder and that the lap belt is as

low as possible. (



P. 30)

Push the buckle release button and fully
retract the seat belt.

Removing a child restraint installed with a seat belt

1-1. For safe use

GX460_OM_OM60R43U_(U)

For safety

and security

Lift up the head restraint system until
it locks and secure the child restraint
system using the seat belt.

Latch the hook onto the anchor
bracket and tighten the top tether
strap.

Make sure the top tether strap is

securely latched.

■

Laws and regulations pertaining to anchorages

The LATCH system conforms to FMVSS225 or CMVSS210.2.

Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be

used.

This vehicle is designed to conform to the SAE J1819.

Child restraint systems with a top tether strap (right side third seat for
6-passenger models)

1-1. For safe use

GX460_OM_OM60R43U_(U)

WARNING

■

When installing a booster seat

To prevent the belt from going into ALR lock mode, do not fully extend the shoulder

belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to

the child. (



P. 32)

■

When installing a child restraint system

Follow the directions given in the child restraint system installation manual and fix the

child restraint system securely in place.

If the child restraint system is not correctly fixed in place, the child or other passengers

may be seriously injured or even killed in the event of sudden braking, sudden swerving

or an accident.

●

When installing a child restraint system in the center second seat, adjust both seat-

backs at the same angle.

●

When using the LATCH anchors for a child restraint system, move the seat as far

back as possible (second seat only), with the seatback close to the child restraint sys-

tem.

●

If the driver’s seat interferes with the child

restraint system and prevents it from being

attached correctly, attach the child restraint

system to the right-hand rear seat.

●

Adjust the front passenger seat so that it does

not interfere with the child restraint system.

●

Child restraint system installed on the third

seat should not contact the second seatbacks.

●

Only put a forward-facing child restraint sys-

tem on the front seat when unavoidable.

When installing a forward-facing child

restraint system on the front passenger seat,

move the seat as far back as possible even if

the “PASSENGER AIR BAG OFF” indicator

light is illuminated. Failure to do so may result

in death or serious injury if the airbags deploy

(inflate).

1-1. For safe use

GX460_OM_OM60R43U_(U)

For safety

and security

WARNING

■

When installing a child restraint system

●

When a booster seat is installed, always ensure that the shoulder belt is positioned

across the center of the child’s shoulder. The belt should be kept away from the child’s

neck, but not so that it could fall off the child’s shoulder. Failing to do so may result in

death or serious injury in the event of sudden braking, sudden swerving or an acci-

dent.

●

Ensure that the belt and plate are securely locked and the seat belt is not twisted.

●

Shake the child restraint system left and right, and forward and backward to ensure

that it has been securely installed.

●

After securing a child restraint system, never adjust the seat.

●

Follow all installation instructions provided by the child restraint system manufacturer.

●

When securing some types of child restrain systems in second or third row seats, it

may not be possible to properly use the seat belts in positions next to the child

restraint without interfering with it or affecting seat belt effectiveness. Be sure your

seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it

interferes with the child restraint, move to a different position. Failure to do so may

result in death or serious injury.

■

Do not use a seat belt extender

If a seat belt extender is used when installing a child restraint system, the seat belt will

not securely hold the child restraint system, which could cause death or serious injury

to the child or other passengers in the event of sudden braking, sudden swerving or an

accident.

■

To correctly attach a child restraint system to the anchors

When using the LATCH anchors, be sure that there are no foreign objects around the

anchors and that the seat belt is not caught behind the child restraint system. Make sure

the child restraint system is securely attached, or it may cause death or serious injury to

the child or other passengers in the event of a sudden stop, sudden swerve or accident.

1-1. For safe use

GX460_OM_OM60R43U_(U)

Exhaust gas precautions

Harmful substance to the human body is included in exhaust gases if inhaled.

WARNING

Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless.

Observe the following precautions.

Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident

caused by light-headedness, or may lead to death or a serious health hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the vehicle even when the back door is closed, open the

windows and have the vehicle inspected at your Lexus dealer as soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the

engine.

●

Do not leave the vehicle with the engine running for a long time.

If such a situation cannot be avoided, park the vehicle in an open space and ensure

that exhaust fumes do not enter the vehicle interior.

●

Do not leave the engine running in an area with snow build-up, or where it is snowing.

If snowbanks build up around the vehicle while the engine is running, exhaust gases

may collect and enter the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked periodically. If there is a hole or crack caused

by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle

inspected and repaired by your Lexus dealer.

1-2. LEXUS Enform

GX460_OM_OM60R43U_(U)

For safety

and security

LEXUS Enform Safety Connect



Microphone
LED light indicators
“SOS” button



: If equipped

Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, which operates 24 hours per day, 7 days
per week.
Safety Connect service is available by subscription on select, telematics hard-
ware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such then-
applicable Terms and Conditions.

System components

2
3

1-2. LEXUS Enform

GX460_OM_OM60R43U_(U)

Subscribers have the following Safety Connect services available:

●

Automatic Collision Notification

Helps drivers receive necessary response from emergency service providers.
(



P. 74)

: U.S. Patent No. 7,508,298 B2

●

Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (



P. 74)

●

Emergency Assistance Button (“SOS”)
Connects drivers to response-center support. (



P. 74)

●

Enhanced Roadside Assistance
Provides drivers various on-road assistance. (



P. 74)

After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call the following or push the “SOS” button in your vehicle for further sub-
scription details.

• The United States

1-800-25-LEXUS (1-800-255-3987)

• Canada

1-800-26-LEXUS (1-800-265-3987)

• Puerto Rico

1-877-539-8777

Services

Subscription

1-2. LEXUS Enform

GX460_OM_OM60R43U_(U)

For safety

and security

■

Safety Connect Services Information

●

Phone calls using the vehicle’s Bluetooth

technology will not be possible during

Safety Connect.

●

Safety Connect is available beginning Fall 2009 on select Lexus models (in the contig-

uous United States only). Contact with the Safety Connect response center is depen-

dent upon the telematics device being in operative condition, cellular connection

availability, and GPS satellite signal reception, which can limit the ability to reach the

response center or receive emergency service support. Enrollment and Telematics

Subscription Service Agreement required. A variety of subscription terms is available;

charges vary by subscription term selected and location.

●

Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location

will function in the United States, including Hawaii and Alaska, Puerto Rico and in Can-

ada, and Enhanced Roadside Assistance will function in the United States, Puerto Rico

and in Canada.

●

Automatic Collision Notification, Emergency Assistance, Stolen Vehicle and Enhanced

Road Assistance will not function in the United States Virgin Islands.

For vehicles first sold in the USVI, no Safety Connect services will function in and out-

side the United States Virgin Islands.

●

Safety Connect services are not subject to section 255 of the Telecommunications Act

and the device is not TTY compatible.

■

Languages

The Safety Connect response center will offer support in multiple languages. The Safety

Connect system will offer voice prompts in English, Spanish, and French. Please indicate

your language of choice when enrolling.

■

When contacting the response center

You may be unable to contact the response center if the network is busy.

When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:

●

Green indicator light on = Active service

●

Green indicator light flashing = Safety Connect call in process

●

Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)

●

No indicator light (off) = Safety Connect service not active

Safety Connect LED light Indicators

1-2. LEXUS Enform

GX460_OM_OM60R43U_(U)

■

Automatic Collision Notification

In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occu-
pants to assess the level of emergency. If the occupants are unable to commu-
nicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be sent to the location.

■

Stolen Vehicle Location

If your vehicle is stolen, Safety Connect can work with local authorities to
assist them in locating and recovering the vehicle. After filing a police report,
call the Safety Connect response center at 1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-539-8777 in Puerto Rico or 1-800-265-
3987 in Canada, and follow the prompts for Safety Connect to initiate this
service.
In addition to assisting law enforcement with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circum-
stances, be shared with third parties to locate your vehicle. Further informa-
tion is available at Lexus.com.

■

Emergency Assistance Button (“SOS”)

In the event of an emergency on the road, push the “SOS” button to reach the
Safety Connect response center. The answering agent will determine your
vehicle’s location, assess the emergency, and dispatch the necessary assis-
tance required.

If you accidentally press the “SOS” button, tell the response-center agent that you

are not experiencing an emergency.

■

Enhanced Roadside Assistance

Enhanced Roadside Assistance adds GPS data to the already included war-
ranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect response-
center agent, who can help with a wide range of needs, such as: towing, flat
tire, fuel delivery, etc. For a description of the Roadside Assistance services
and their limitations, please see the Safety Connect Terms and Conditions,
which are available at Lexus.com.

Safety Connect services

1-2. LEXUS Enform

GX460_OM_OM60R43U_(U)

For safety

and security

Important! Read this information before using Safety Connect.

■

Exposure to radio frequency signals

The Safety Connect system installed in your vehicle is a low-power radio
transmitter and receiver. It receives and also sends out radio frequency (RF)
signals.
In August 1996, the Federal Communications Commission (FCC) adopted
RF exposure guidelines with safety levels for mobile wireless phones. Those
guidelines are consistent with the safety standards previously set by the fol-
lowing U.S. and international standards bodies.

●

ANSI (American National Standards Institute) C95.1 [1992]

●

NCRP (National Council on Radiation Protection and Measurement)
Report 86 [1986]

●

ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]

Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. Over 120 scientists, engineers, and physi-
cians from universities, and government health agencies and industries
reviewed the available body of research to develop the ANSI Standard
(C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.

Safety information for Safety Connect

1-3. Theft deterrent system

GX460_OM_OM60R43U_(U)

Engine immobilizer system

The indicator light flashes after the
engine switch has been turned off to
indicate that the system is operating.
The indicator light stops flashing after
the engine switch has been turned to
ACCESSORY or IGNITION ON
mode to indicate that the system has
been canceled.

■

System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the grip portion of the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system (key with a

built-in transponder chip) of another vehicle

The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s on-
board computer.
Never leave the keys inside the vehicle when you leave the vehicle.

This system is designed to help prevent vehicle theft but does not guarantee
absolute security against all vehicle thefts.

NOTICE

■

To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of

the system cannot be guaranteed.

1-3. Theft deterrent system

GX460_OM_OM60R43U_(U)

For safety

and security

Alarm

The alarm uses light and sound to give an alert when an intrusion is detected.
The alarm is triggered in the following situations when the alarm is set:

●

For the U.S.A.: A locked door or glass hatch is unlocked or opened in any way
other than using the entry function, wireless remote control or mechanical
key. (The doors will lock again automatically.)

●

For Canada: A locked door or glass hatch is unlocked or opened in any way
other than using the entry function or the wireless remote control. (The doors
will lock again automatically.)

●

The hood is opened.

Close the doors, glass hatch and hood,
and lock all the doors. The system will
be set automatically after 30 seconds.

The indicator light changes from being

on to flashing when the system is set.

Do one of the following to deactivate or stop the alarms:

●

Unlock the doors.

●

Turn the engine switch to ACCESSORY or IGNITION ON mode, or start
the engine. (The alarm will be deactivated or stopped after a few seconds.)

The alarm

Setting the alarm system

Deactivating or stopping the alarm

1-3. Theft deterrent system

GX460_OM_OM60R43U_(U)

■

System maintenance

The vehicle has a maintenance-free type alarm system.

■

Items to check before locking the vehicle

To prevent unexpected triggering of the alarm and vehicle theft, make sure of the follow-

ing.

●

Nobody is in the vehicle.

●

The windows and moon roof are closed before the alarm is set.

●

No valuables or other personal items are left in the vehicle.

■

Triggering of the alarm

The alarm may be triggered in the following situations:

(Stopping the alarm deactivates the alarm system.)

■

Alarm-operated door lock

In the following cases, depending on the situation, the door may automatically lock to

prevent improper entry into the vehicle:

●

When a person remaining in the vehicle unlocks the door and the alarm is activated.

●

While the alarm is activated, a person remaining in the vehicle unlocks the door.

●

When recharging or replacing the battery.

●

For vehicles sold in Canada: The doors are

unlocked using the mechanical key.

●

A person inside the vehicle opens a door or

hood, or unlocks the vehicle using an inside

lock button.

●

The battery is recharged or replaced when the

vehicle is locked. (



P. 571)

GX460_OM_OM60R43U_(U)

2. Instrument cluster

Instrument cl

uste
r

Warning lights inform the driver of malfunctions in any of the vehicle’s systems.

Warning lights

(U.S.A.)

Brake system warning light

(



P. 535)

(flashes or

illuminates)

PCS warning light

(



P. 536)

(Canada)

Brake system warning light

(



P. 535)

Slip indicator light

(



P. 536)

Charging system warning

light (



P. 535)

Kinetic dynamic suspension

system warning light

(



P. 536)

High coolant temperature

warning light (



P. 535)

(flashes)

Low speed four-wheel

drive indicator light

(



P. 537)

Low engine oil pressure

warning light (



P. 535)

(flashes)

Center differential lock

indicator light (



P. 537)

(U.S.A.)

Malfunction indicator lamp

(



P. 535)

Open door warning light

(



P. 537)

(Canada)

Malfunction indicator lamp

(



P. 535)

Low fuel level warning light

(



P. 537)

SRS warning light

(



P. 535)

Driver’s and front

passenger’s seat belt

reminder light (



P. 537)

(U.S.A.)

ABS warning light

(



P. 536)

Tire pressure warning light

(



P. 537)

(Canada)

ABS warning light

(



P. 536)

LDA indicator (



P. 538)

GX460_OM_OM60R43U_(U)

2. Instrument cluster

: These lights turn on when the engine switch is turned to IGNITION ON mode to

indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if the lights
do not turn on, or turn off. Have the vehicle inspected by your Lexus dealer.

: This light is displayed on the multi-information display.

(flashes)

(U.S.A.)

Parking brake indicator

(



P. 536)

Brake Override System

warning light /Drive-Start

Control warning light

(



P. 538)

(flashes)

(Canada)

Parking brake indicator

(



P. 536)

GX460_OM_OM60R43U_(U)

2. Instrument cluster

Instrument cl

uste
r

The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.

Indicators

Turn signal indicator

(



P. 211)

Dynamic radar cruise

control indicator (



P. 255)

(U.S.A.)

Headlight indicator

(



P. 213)

LDA indicator (



P. 249)

(Canada)

Tail light indicator

(



P. 213)

(flashes)

LDA indicator (



P. 249)

Headlight high beam

indicator (



P. 214)

2, 3

Slip indicator (



P. 369)

Automatic High Beam

indicator (



P. 216)

VSC OFF indicator

(



P. 370)

(if equipped)

Fog light indicator

(



P. 220)

(if equipped)

Multi-terrain Select

indicator (



P. 292)

Eco Driving Indicator

Light (



P. 96)

(if equipped)

Crawl Control indicator

(



P. 361)

Cruise control indicator

(



P. 255)

(if equipped)

Downhill assist control

system indicator

(



P. 365)

Cruise control “SET”

indicator (



P. 255)

“2nd STRT” indicator

(



P. 207)

GX460_OM_OM60R43U_(U)

2. Instrument cluster

Low speed four-wheel

drive indicator light

(



P. 357)

TRAC OFF indicator

(



P. 370)

Center differential lock

indicator (



P. 358)

(if equipped)

MUD & SAND mode

indicator (



P. 293)

Intuitive parking assist

indicator (



P. 267)

(if equipped)

MOGUL mode indicator

(



P. 293)

2, 4

PCS warning light

(



P. 240)

(if equipped)

ROCK mode indicator

(



P. 293)

Security indicator

(



P. 76, 77)

(if equipped)

LOOSE & ROCK mode

indicator (



P. 293)

Smart access system with

push-button start indicator

(



P. 200)

(if equipped)

ROCK & DIRT mode

indicator (



P. 293)

BSM indicator (



P. 374)

(if equipped)

MTS AUTO indicator

(



P. 293)

5, 6

BSM (Blind Spot Monitor)

outside rear view mirror

indicators (



P. 374)

(if equipped)

Sport mode indicator

(



P. 356)

1, 7

Low outside temperature

indicator (



P. 88)

(if equipped)

Comfort mode indicator

(



P. 356)

2, 8

“PASSENGER AIR

BAG” indicator lights

(



P. 47)

GX460_OM_OM60R43U_(U)

2. Instrument cluster

Instrument cl

uste
r

: This light is displayed on the multi-information display.

: These lights turn on when the engine switch is turned to IGNITION ON mode to

: The light flashes to indicate that the system is operating.

: The light comes on when the system is turned off.

: In order to confirm operation, the BSM outside rear view mirror indicators illumi-

nate in the following situations:

• When the engine switch is turned to IGNITION ON mode while the system is set

to on.

• When the system is set to on while the engine switch is in IGNITION ON mode.

If the system is functioning correctly, the BSM outside rear view mirror indicators
will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction with the system.
If this occurs, have the vehicle inspected by your Lexus dealer.

: This light illuminates on the outside rear view mirrors.

: When the outside temperature is approximately 37°F (3°C) or lower, the indicator

will flash for approximately 10 seconds, then stay on.

: This light illuminates on the center panel.

WARNING

■

If a safety system warning light does not come on

Should a safety system light such as the ABS/Multi Terrain ABS and the SRS warning

light not come on when you start the engine, this could mean that these systems are not

available to help protect you in an accident, which could result in death or serious

injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.

GX460_OM_OM60R43U_(U)

2. Instrument cluster

Gauges and meters

The units used on the speedometer may differ depending on the target region.

Tachometer

Displays the engine speed in revolutions per minute

Engine coolant temperature gauge

Displays the engine coolant temperature

Shift position and shift range

Displays the selected shift position or selected shift range (



P. 206)

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to 122°F

(50°C). Low outside temperature indicator comes on when the ambient temperature

is 37°F (3°C) or lower.

Fuel gauge

Displays the quantity of fuel remaining in the tank

Speedometer

Displays the vehicle speed

Multi-information display

Presents the driver with a variety of driving-related data



P. 91)

Lexus GX460 (2023 year). Manual in english - page 2
