Lexus ES (2023 year). Manual in english

454

8-1. Specifications

Fuel

Fuel type

When you find these types of fuel label at the
gas station, use only the fuel with one of the fol-
lowing labels.

EU area:
Unleaded gasoline conforming to European
standard EN228 only
Except EU area:
Unleaded gasoline only

Research Octane Number

95 or higher

Fuel tank capacity (Reference)

50 L (13.2 gal., 11.0 Imp.gal.)

Electric motor (traction motor)

Type

Permanent magnet synchronous motor

Maximum output

88 kW

Maximum torque

202 N•m (20.6 kgf•m, 149 ft•lbf)

Hybrid battery (traction battery)

Type

Nickel-metal hydride battery

Voltage

7.2 V/module

Capacity

6.5 Ah (3HR)

Quantity

34 modules

Nominal voltage

244.8 V

455

8-1. Specifications

Vehic

le spe

cif

ion
s

■

Oil capacity (Drain and refill [Ref-
erence

])

: The engine oil capacity is a reference

quantity to be used when changing the
engine oil. Warm up the engine and turn
off the hybrid system, wait more than 5
minutes, and check the oil level on the
dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Lexus recom-
mends the use of approved “Toyota
Genuine Motor Oil”. Another motor
oil of matching quality can also be
used.
Oil grade:
0W-16:
API grade SN “Resource-Conserv-
ing”, SN PLUS “Resource-Conserv-
ing” or SP “Resource-Conserving”; or
ILSAC GF-6B multigrade engine oil
0W-20 and 5W-30:
API grade SM “Energy-Conserving”,
SN “Resource-Conserving”, SN PLUS
“Resource-Conserving” or SP
“Resource-Conserving”; or ILSAC
GF-6A multigrade engine oil
Recommended viscosity (SAE):
SAE 0W-16 is filled into your Lexus
vehicle at manufacturing, and the best
choice for good fuel economy and
good starting in cold weather.

If SAE 0W-16 oil is not available, SAE
0W-20 oil may be used. However, it
should be replaced with SAE 0W-16
at the next oil change.

Temperature range anticipated
before next oil change

Preferred

Oil viscosity (0W-16 is explained here
as an example):
• The 0W in 0W-16 indicates the

characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.

• The 16 in 0W-16 indicates the vis-

cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions.

How to read oil container labels:
Either or both API registered marks
are added to some oil containers to
help you select the oil you should use.

Lubrication system

With filter

4.5 L (4.8 qt., 4.0 Imp. qt.)

Without filter 4.2 L (4.4 qt., 3.7 Imp. qt.)

456

8-1. Specifications

API Service Symbol

Top portion: “API SERVICE SP” means
the oil quality designation by American

Petroleum Institute (API).
Center portion: “SAE 0W-16” means the
SAE viscosity grade.
Lower portion: “Resource-Conserving”
means that the oil has fuel-saving and envi-
ronmental protection capabilities.

ILSAC Certification Mark

The International Lubricant Specification
Advisory Committee (ILSAC) Certifica-
tion Mark is displayed on the front of the
container.

: The fluid capacity is a reference quantity.

If replacement is necessary, contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

■

Spark plug

Cooling system

Capacity

Gasoline
engine

6.1 L (6.4 qt., 5.4 Imp.qt.)

Power control
unit

1.8 L (1.9 qt., 1.6 Imp.qt.)

Coolant type

Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili-

cate, non-amine, non-nitrite, and non-borate coolant
with long-life hybrid organic acid technology

Do not use plain water alone.

Ignition system

Make

DENSO FC16HR-Q8

Gap

0.8 mm (0.031 in.)

457

8-1. Specifications

Vehic

le spe

cif

ion
s

: The fluid capacity is a reference quantity.

If replacement is necessary, contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system (12-volt battery)

Specific gravity reading at 20°C
(68°F):

1.25 or higher
If the specific gravity is lower than the standard value,
charge the battery.

Charging rates

Quick charge

15 A max.

Slow charge

5 A max.

Hybrid transmission

Fluid capacity

3.9 L (4.1 qt., 3.4 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Hybrid transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or ultimately damage the transmission of your vehicle.

Brakes

Pedal clearance

with 16-inch front wheel brake 85 mm (3.3 in.) Min.

with 17-inch front wheel brake 83 mm (3.3 in.) Min.

Pedal free play

1.0



6.0 mm (0.04



0.24 in.)

458

8-1. Specifications

: Minimum pedal clearance when depressed with a force of 300 N (30.6 kgf, 67.4 lbf)

while the hybrid system is operating.
When performing the brake pedal inspection, also be sure to check that the brake sys-
tem warning light is not illuminated when the hybrid system is operating. (If the brake
system warning light is illuminated, refer to P.404)

: Make sure to confirm that the brake system warning light (yellow) does not illuminate. (If

the brake system warning light illuminates, refer to P.404)



17-inch tires

Parking brake indicator

When pushing the parking brake
switch for 1 to 2 seconds: comes on
When pulling the parking brake switch
for 1 to 2 seconds: turns off

Fluid type

SAE J1703 or FMVSS No. 116 DOT 3
SAE J1704 or FMVSS No.116 DOT 4

Steering

Free play

Less than 30 mm (1.2 in.)

Tires and wheels

Tire size

215/55R17 94W
215/55R17 94V

Tire inflation pressure
(Recommended cold tire
inflation pressure)

Vehicle speed

Front tire and rear tire

More than 160 km/h (100
mph)

320 kPa (3.2 kgf/cm

or bar,

46 psi)

160 km/h (100 mph) or less

240 kPa (2.4 kgf/cm

or bar,

35 psi)

Wheel size



7 1/2J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

459

8-1. Specifications

Vehic

le spe

cif

ion
s



18-inch tires



19-inch tires



Compact spare tire (if equipped)

Tire size

235/45R18 94Y
235/45R18 94W

Tire inflation pressure
(Recommended cold tire
inflation pressure)

Vehicle speed

Front tire and rear tire

More than 160 km/h (100
mph)

320 kPa (3.2 kgf/cm

or bar,

46 psi)

160 km/h (100 mph) or less

240 kPa (2.4 kgf/cm

or bar,

35 psi)

Wheel size



Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

235/40R19 96Y XL

Tire inflation pressure
(Recommended cold tire
inflation pressure)

Vehicle speed

Front tire and rear tire

More than 220 km/h (137
mph)

320 kPa (3.2 kgf/cm

or bar,

46 psi)

220 km/h (137 mph) or less

230 kPa (2.3 kgf/cm

or bar,

33 psi)

Wheel size



Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

T155/70D17 110M

Tire inflation pressure
(Recommended cold tire
inflation pressure)

420 kPa (4.2 kgf/cm

or bar, 60 psi)

Wheel size



4 T

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Light bulbs (vehicles with single-beam headlights)

Light bulbs

Type

Front turn signal lights

Wedge base bulbs (amber)

460

8-1. Specifications

■

Use of ethanol blended gasoline in a

gasoline engine

Lexus allows the use of ethanol blended

gasoline where the ethanol content is up to

10%. Make sure that the ethanol blended

gasoline to be used has a Research Octane

Number that follows the above.

■

If your engine knocks

●

Consult any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

●

You may occasionally notice light knock-

ing for a short time while accelerating or

driving uphill. This is normal and there is

no need for concern.

Fuel information

When you find these types of fuel
label at the gas station, use only the
fuel with one of the following labels.

EU area:
You must only use unleaded gaso-
line conforming to European stan-
dard EN228.
Select unleaded gasoline with a
Research Octane Number of 95 or
higher for optimum engine perfor-
mance.

Except EU area:
You must only use unleaded gaso-
line.
Select unleaded gasoline with a
Research Octane Number of 95 or
higher for optimum engine perfor-
mance.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper

fuels are used, the engine will be dam-

aged.

●

Do not use gasoline with metallic addi-

tives, for example manganese, iron or

lead, otherwise it may cause damage

on your engine or emission control

system.

●

Do not add aftermarket fuel additives

which contain metallic additives.

●

EU area: Bioethanol fuel sold under

names such as “E50” or “E85” and

fuel containing a large amount of etha-

nol should not be used. The use of

these fuels will damage the vehicle’s

fuel system. In case of any doubt, ask

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

●

Except EU area: Bioethanol fuel sold

under names such as “E50” or “E85”

and fuel containing a large amount of

ethanol should not be used. Your vehi-

cle can use gasoline mixed with 10%

max ethanol. The use of fuel with more

than 10% ethanol content (E10) will

damage the vehicle’s fuel system. You

must ensure that refueling is carried

out only from a source where fuel

specification and quality can be guar-

anteed. In case of any doubt, ask any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

●

Do not use the methanol blended gas-

oline such as M15, M85, M100. The

use of gasoline containing methanol

may cause engine damage or failure.

461

8-2. Customization

Vehic

le spe

cif

ion
s

8-2.Customization

■

Changing by using the meter con-
trol switches

Press

to select

Operate the meter control
switches to select the desired item
to be customized.

According to the display, select the
desired setting.

To go back to the previous screen or exit
the customize mode, press

■

Changing using the Center Dis-
play

Select

on the main menu.

Select “Vehicle customize” on the
sub menu.

Various setting can be changed. Refer to

the list of settings that can be changed for

details.

■

During customization

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift lever to P.

Also, to prevent 12-volt battery discharge,

leave the hybrid system operating while

customizing the features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact any authorized Lexus retailer or Lexus authorized repairer, or
any reliable repairer for further details.

Settings that can be changed using the Center Display

Settings that can be changed using the meter control switches

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Center Display or at
any authorized Lexus retailer or
Lexus authorized repairer, or any
reliable repairer.

Customizing vehicle features

WARNING

■

During customization

As the hybrid system needs to be operat-

ing during customization, ensure that the

vehicle is parked in a place with ade-

quate ventilation. In a closed area such as

a garage, exhaust gases including harm-

ful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to

death or a serious health hazard.

NOTICE

■

During customization

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while customizing features.

Customizable features

462

8-2. Customization

Settings that can be changed by any authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer

Definition of symbols: O = Available,



= Not available

■

Gauges, meters and multi-information display (



P.99, 103, 109)

Function

Default setting

Customized setting

Language

*2, 3

English

French



German

Spanish

Italian

Russian

Arabic

Turkish

Dutch

Ukrainian

Units

*2, 3

km (L/100 km)

km (km/L)



miles (MPG)

Speedometer display

Digital

Analog



Analog and digital

Drive information 1

Current fuel con-

sumption

Customizable items:



P.110



Average fuel econ-

omy (after reset)

Drive information 2

Distance (driving

range)

Average vehicle

speed (after reset)

Clock

24-hour display

12-hour display



Pop-up display

Off



Tachometer setting

Change according

to driving mode

Always tachometer



Always Hybrid Sys-

tem Indicator

463

8-2. Customization

Vehic

le spe

cif

ion
s

: For details about each function:



P.113

: The default setting varies according to country.

: The customized setting varies according to country.

: Except F SPORT models

: F SPORT models

■

Head-up Display

(



P.115)

: If equipped

Rev indicator

4000 r/min

2000 - 5700 r/min



Off

Rev peak

Off



EV indicator

Off



Suggestion function

On (when the vehi-

cle is stopped)



Off

Function

Default setting

Customized setting

Gauge information

Hybrid System Indi-

cator

Tachometer



No content

Route guidance to destina-
tion/street name

Off



Driving support system dis-
play

Off



Compass

Off



Audio system operation sta-
tus

Off



Function

Default setting

Customized setting

464

8-2. Customization

■

Door lock (



P.128, 133, 439)

■

Rear seat reminder (



P.130)

■

Smart entry & start system and wireless remote control (



P.128, 140)

Function

Default setting

Customized setting

Unlocking using a mechani-
cal key

All doors unlocked

in one step

Driver’s door

unlocked in one

step, all doors

unlocked in two step

 

Speed linked door locking
function

Off



Shift lever linked door locking
function

Off



Shift lever linked door
unlocking function

Off



Driver’s door linked door
unlocking function

Off



Locking/unlocking of the
trunk when all doors are
locked/unlocked

Off

 

Function

Default setting

Customized setting

Rear seat reminder function

Off



Function

Default setting

Customized setting

Operation signal (Emer-
gency flashers)

Off



Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being unlocked

30 seconds

60 seconds

 

120 seconds

Open door warning buzzer
(When locking the vehicle)

Off

 

465

8-2. Customization

Vehic

le spe

cif

ion
s

■

Smart entry & start system (



P.128, 140)

: The default setting varies according to country.

■

Wireless remote control (



P.124, 128, 133)

■

Trunk (



P.133)

: If equipped

Function

Default setting

Customized setting

Smart entry & start system

Off



Smart door unlocking

All the doors

Driver’s door



Time elapsed before unlock-
ing all the door when gripping
and holding the driver’s door
handle

2 seconds

Off

 

1.5 seconds

2.5 seconds

Number of consecutive door
lock operations

As many as desired

2 times

 

Function

Default setting

Customized setting

Wireless remote control

Off

 

Unlocking operation

All doors unlocked

in one step

Driver’s door

unlocked in one

step, all doors

unlocked in two step



Trunk unlocking operation

Press and hold

(short)

One short press

 

Push twice

Press and hold

(long)

Off

Function

Default setting

Customized setting

Hands Free Power Trunk Lid
(kick sensor)

Off



Buzzer when the kick sensor

detects a foot

Off

 

466

8-2. Customization

■

Driving position memory

(



P.147)

: If equipped

■

Outside rear view mirrors

/Digital Side-view Monitor

(



P.154, 157)

: If equipped

■

Power windows and moon roof (



P.172, 174)

Function

Default setting

Customized setting

Selecting doors linked to the
memory recall function

Driver’s door

All doors

 

Driver’s seat slide movement
when exiting the vehicle

Full

Off



Partial

Steering wheel movement

Tilt only

Off

 

Telescopic only

Tilt and telescopic

Function

Default setting

Customized setting

Automatic mirror folding and
extending operation

Linked to the lock-

ing/ unlocking of the

doors

Off

 

Linked to operation
of the power switch

Function

Default setting

Customized setting

Mechanical key linked opera-
tion (open)

Off

 

Mechanical key linked opera-
tion (close)

Off

 

Wireless remote control
linked operation (open)

Off

 

Wireless remote control
linked operation (close)

Off

 

Wireless remote control
linked operation signal
(buzzer)

Off

 

467

8-2. Customization

Vehic

le spe

cif

ion
s

■

Automatic light control system (



P.202)

■

Lights (



P.202)

■

AHS (Adaptive High-beam System)

(



P.205)

Function

Default setting

Customized setting

Light sensor sensitivity

Normal

Brighter



Bright

Dark

Darker

Extended Headlight Lighting
(Time elapsed before head-
lights automatically turn off)

30 seconds

60 seconds

 

90 seconds

120 seconds

Function

Default setting

Customized setting

Welcome lighting

Off

 

Function

Default setting

Customized setting

Adaptive High-beam System
function

Off

 

Speed at which the lights
switch automatically to high
beams

Operates at approx-

imately 15 km/h (10

mph) or more

Operates at approx-

imately 30 km/h (19

mph) or more

 

Operates at approx-
imately 60 km/h (37

mph) or more

Intensity adjustment of the
high beams when driving
around a curve (illuminates
the area in the direction vehi-
cle is turning more brightly)

Off

 

Projection distance adjust-
ment of the low beams
according to the distance to a
preceding vehicle

Off

 

468

8-2. Customization

: If equipped

: The lights will switch automatically between high beams and low beams even if this is

changed to “Off”. (



P.473)

: These settings will also be changed to “Off” if the operation of the Adaptive High-beam

System function is changed to “Off”.

■

Multi Weather Lights

(



P.212)

: If equipped

■

PCS (Pre-Collision System)

(



P.225)

: If equipped

: The system is automatically enabled each time the power switch is turned to ON mode.

■

LTA (Lane Tracing Assist)

(



P.237)

Illumination of the cornering
lights when starting off

Off

 

High beam light distribution
control for rain

Off

 

Light distribution control for
urban areas

Off

 

Function

Default setting

Customized setting

Multi Weather Lights

Off

 

Function

Customized setting

Adjust alert timing

Early, Middle, Late



PCS (Pre-Collision Sys-
tem)

On, Off



Function

Customized setting

Lane centering function

On, Off



Alert type

Steering wheel vibration, Buzzer



Alert sensitivity

High, Standard



Function

Default setting

Customized setting

469

8-2. Customization

Vehic

le spe

cif

ion
s

: If equipped

■

RSA (Road Sign Assist)

(



P.246)

: If equipped

: The system is automatically enabled each time the power switch is turned to ON mode.

: If a speed limit with supplemental mark is exceeded, the notification buzzer does not

operate.

: Vehicles with navigation system

■

Dynamic radar cruise control with full-speed range

(



P.250)

: If equipped

Vehicle sway warning func-
tion

On, Off



Vehicle sway warning sensi-
tivity

High, Standard, Low



Function

Customized setting

RSA (Road Sign Assist)

On, Off



Excess speed notification
method

Display only, No notification, Display and

buzzer



Excess speed notification
level

2 km/h (1 mph), 5 km/h (3 mph), 10 km/h

(5 mph)



No overtaking notification
method

Display only, No notification, Display and

steering wheel vibration



Other notifications method
(No-entry notification)

Display only, No notification, Display and

buzzer



Function

Customized setting

Curve speed reduction func-
tion

High, Low, Off



Dynamic Radar Cruise Con-
trol with Road Sign Assist

Off, On



Function

Customized setting

Lexus ES (2023 year). Manual in english - page 29
