Lexus RX300 (MCU15). Service manual - part 479

PP1DR–01

PP–36

–

PREPARATION

AUTOMATIC TRANSAXLE

LEXUS RX300   (RM785E)

SSM (Special Service Materials)

08833–00080

Adhesive 1344

THREE BOND 1344

LOCTITE 242 or equivalent

Shift lever knob screw

PP1E7–02

–

PREPARATION

PROPELLER SHAFT

PP–37

LEXUS RX300   (RM785E)

PROPELLER SHAFT

SST (Special Service Tools)

09316–60011

Transmission  & Transfer  Bearing

Replacer

Dust cover

(09316–00011)

Replacer Pipe

09325–20010

Transmission Oil Plug

Oil leakage prevention

09330–00021

Companion Flange Holding Tool

Companion flange

09370–50010

Drive Line Angle Gauge

Joint angle

09950–40011

Puller B Set

Front and rear flange

(09951–04020)

Hanger 200

(09952–04010)

Slide Arm

(09953–04030)

Center Bolt 200

(09954–04010)

Arm 25

(09955–04061)

Claw No.6

(09957–04010)

Attachment

PP–38

–

PREPARATION

PROPELLER SHAFT

LEXUS RX300   (RM785E)

(09958–04011)

Holder

PP1E8–02

–

PREPARATION

PROPELLER SHAFT

PP–39

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09040–00011

Hexagon Wrench Set .

(09043–20060)

Socket Hexagon Wrench 6.
