Lexus RX300 (MCU15). Service manual - part 464

LU04G–03

B12308

N·m (kgf·cm, ft·lbf)

: Specified torque

LH Wiper Arm and Blade Assembly

Hood to Cowl Top Seal

Wiper Motor with Wiper Link

Outer Cowl Top Panel

x 6

Wiper Motor Connector

24 (245, 18)

RH Cowl Top
Ventilator Louver

LH Cowl Top Ventilator Louver

RH Wiper Arm and Blade Assembly

–

LUBRICATION

OIL PUMP

LU–5

LEXUS RX300   (RM785E)

OIL PUMP

COMPONENTS

B12307

RH Fender Apron Seal

Alternator
Drive Belt

PS Pump Drive
Belt

A/C Compressor
Connector

25 (250, 18)

64 (650, 47)

32 (320, 23)

No.2 RH Engine Mounting
Bracket

Engine Moving
Control Rod

Ground Strap

z

 Gasket

N·m (kgf·cm, ft·lbf) : Specified torque

PS Pump



Drive



Belt

Adjusting Strut

56 (570, 41)

z

 Gasket

z

 Non–reusable part

No.2 Front Exhaust Pipe

A/C Compressor

Alternator Drive Belt
Adjusting Bar Bracket

Alternator

Alternator
Wire

Alternator
Connector

z

 Gasket

56 (570, 41)

25 (250, 18)

80 (810, 59)

Master Cylinder
Reservoir

Front Upper
Suspension Brace

Cruise Control Actuator

80 (810, 59)

Cruise Control Actuator
Connector

WU–TWC

62 (630, 46)

LU–6

–

LUBRICATION

OIL PUMP

LEXUS RX300   (RM785E)

B12309

No.2 Timing Belt Cover

Timing Belt

Timing Belt Guide

No.2 Generator
Bracket

RH Engine Mounting Bracket

Crankshaft
Pulley

Engine Wire
Protector

RH Camshaft Timing Pulley

No.2 Idler Pulley

Crankshaft
Timing Pulley

Dust Boot

Timing Belt Plate

Plate Washer

L

215 (2,200, 159)

43 (440, 32)

27 (280, 20)

Timing Belt Tensioner

N·m (kgf·cm, ft·lbf) : Specified torque

z

 Non–reusable part

28 (290, 21)

No.1 Timing Belt Cover

125 (1,300, 35)
*88 (900, 65)

LH Camshaft
Timing Pulley

No.1 Idler Pulley

34 (350, 25)

L

 Precoated part

* For use with SST

125 (1,300, 94)

–

LUBRICATION

OIL PUMP

LU–7

LEXUS RX300   (RM785E)

B04148

N·m (kgf·cm, ft·lbf) : Specified torque

z

 Non–reusable part

No.3 Timing Belt Cover

Gasket

Bushing

Collar

A/C Compressor
Housing Bracket

Oil Pan Baffle Plate

Crankshaft
Position Sensor
Connector

Crankshaft Position
Sensor

Oil Pump

Engine Wire

Flywheel Housing
Under Cover

Oil Strainer

No.2 Oil Pan

x 10

x 6

x 9

z

 O–Ring

No.1 Oil Pan

z

 Gasket

Drain Plug

8.5 (85, 74 in.·lbf)

8 (80, 69 in.·lbf)

8 (80, 69 in.·lbf)

10 mm Head 8 (80, 69 in.·lbf)
12 mm Head 19.5 (200, 14)

10 mm Head 8 (80, 69 in.·lbf)
12 mm Head 19.5 (200, 14)
14 mm Head 37.2 (380, 27)

8 (80, 69 in.·lbf)

45 (460, 33)

8 (80, 69 in.·lbf)

x 6

x 19

LU–8

–

LUBRICATION

OIL PUMP

LEXUS RX300   (RM785E)
