PP0CJ–01

–

PREPARATION

BRAKE

PP–41

86

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Torque wrench

Micrometer

Brake disc

Dial indicator

Brake disc

Vernier calipers

Brake disc

PP0CK–01

PP–42

–

PREPARATION

BRAKE

87

1997 LEXUS ES300   (RM511U)

LUBRICANT

Item

Capacity

Classification

Brake fluid

–

SAE J1703 or FMVSS No.116 DOT3

PP0AS–04

–

PREPARATION

STEERING

PP–43

88

1997 LEXUS ES300   (RM511U)

STEERING

SST (Special Service Tools)

09249–63010

Torque Wrench  Adaptor

PS vane pump

09521–24010

Drive Shaft Boot Clamping Tool

PS gear

09527–20011

Rear Axle Shaft Bearing Remover

PS gear

09612–00012

Rack & Pinion Steering Rack

Housing Stand

PS gear

09612–22011

Tilt Handle Bearing Replacer

PS gear

09612–24014

Steering Gear Housing Overhaul

Tool Set

(09613–22011)

Steering Rack Shaft Bushing

Puller

PS gear

09616–00010

Steering Worm Bearing Adjusting

Socket

PS gear

09631–10021

Rack Stopper Wrench

PS gear

09631–12071

Steering Rack Oil Seal Test Tool

PS gear

09631–20081

Seal Ring Tool

PS gear

09631–22020

Power Steering Hose Nut

14 x 17 mm Wrench Set

PS vane pump

PS gear

PP–44

–

PREPARATION

STEERING

89

1997 LEXUS ES300   (RM511U)

09631–33010

Steering Rack Cover ”I”

PS gear

09633–00020

Power Steering Hose Nut Wrench

PS gear

09640–10010

Power Steering Pressure Gauge

Set

(09641–01010)

Gauge Assy

Power steering fluid

(09641–01030)

Attachment B

Power steering fluid

(09641–01060)

Attachment E

Power steering fluid

09922–10010

Variable Open Wrench

PS gear

09950–50010

Puller C Set

(09951–05010)

Hanger 150

Tilt steering column

(09952–05010)

Slide Arm

Tilt steering column

(09953–05020)

Center Bolt 150

Tilt steering column

(09954–05020)

Claw No.2

Tilt steering column

09950–60010

Replacer Set
