Honda Insight (2019 year). Manual - part 33

Continued

511

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

Driving

The system can be used when the following conditions are met.
• The lane in which you are driving has detectable lane markers on both sides, and

your vehicle is in the center of the lane.

• The vehicle speed is between 45 and 90 mph (72 and 145 km/h).
• You are driving on a straight or slightly curved road.
• The turn signals are off.
• The brake pedal is not depressed.
• The wipers are not in continuous operation.

■

How to activate the system

1. Press the MAIN button.

u

The LKAS is on in the driver information
interface.
The system is ready to use.

2. Press the LKAS button.

u

Lane outlines appear on the driver
information interface.
The system is activated.

■

When the System can be Used

1

When the System can be Used

If the vehicle drifts toward either left or right lane line
due to the system applying torque, turn off the LKAS
and have your vehicle checked by a dealer.

MAIN Button

LKAS Button

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

512

Driving

3. Keep your vehicle near the center of the

lane while driving.

u

The dotted outer lines change to solid
ones once the system starts operating
after detecting the left and right lane
markings.

To cancel the LKAS:
Press the MAIN or LKAS button.

The LKAS is turned off every time you turn the
power system off, even if you turned it on the
last time you drove the vehicle.

■

To Cancel

1

To Cancel

Pressing the MAIN button also turns ACC with LSF
on and off.

MAIN Button

LKAS
Button

513

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

Continued

Driving

■

The system operation is suspended if
you:

• The wipers are set to HI.

u

Turning the wipers off resumes the
LKAS.

• Set the wiper switch to AUTO and the

wipers operate at high speed.

u

The LKAS resumes when the wipers stop
or operate at low speed.

• Decrease the vehicle speed to about 40 mph

(64 km/h) or less.

u

Increasing the vehicle speed to about
45 mph (72 km/h) or more resumes the
LKAS.

• Depress the brake pedal.

u

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

■

The LKAS may automatically be suspended when:

• The system fails to detect lane lines.
• The steering wheel is quickly turned.
• You fail to steer the vehicle.
• Driving through a sharp curve.
• Driving at a speed in excess of approximately 90 mph (145 km/h).
Once these conditions no longer exist, the LKAS automatically resumes.

When the LKAS is suspended,
the lane lines on the driver
information interface change to
contour lines, and the beeper
sounds (if activated).

Models with automatic intermittent wipers

All models

514

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

Driving

■

The LKAS may automatically be canceled when:

• The camera temperature gets extremely high or low.
• The camera behind the rearview mirror, or the area around the camera, including

the windshield, gets dirty.

• The ABS or VSA® system engages.
The beeper sounds if the LKAS is automatically canceled.

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of a lane under certain conditions, including the following:

■

Environmental conditions

• Driving in bad weather (rain, fog, snow, etc.).
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• There is little contrast between lane lines and the roadway surface.
• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Driving in the shadows of trees, buildings, etc.
• Shadows of adjacent objects are parallel to lane markings.
• Roadway objects or structures are misinterpreted as lane markers.
• Reflections on the interior of the windshield.
• Driving at night or in a dark condition such as a tunnel.

■

LKAS Conditions and Limitations

515

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

Continued

Driving

■

Roadway conditions

• Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,

reflected lights, road spray, high contrast).

• Driving on a road with temporary lane markings.
• Faint, multiple, or varied lane markings are visible on the roadway due to road

repairs or old lane markings.

• The roadway has merging, split, or crossing lines (e.g., such as at an intersection

or crosswalk).

• The lane markings are extremely narrow, wide, or changing.

• The vehicle in front of you is driving near the lane lines.
• The road is hilly or the vehicle is approaching the crest of a hill.
• Driving on rough or unpaved roads, or over bumpy surfaces.

Faded lines

Duplicate lines

Tire tracks

Very wide or narrow traffic lane

516

uu

Honda Sensing®

u

Lane Keeping Assist System (LKAS)

Driving

• When objects on the road (curb, guard rail, pylons, etc.) are recognized as white

lines (or yellow lines).

• Driving on roads with double lines.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet

snow, etc.

• The inside of the windshield is fogged.
• The camera temperature gets too high.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire

*

, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.

Lane void of lines at junction

* Not available on all models

517

uu

Honda Sensing®

u

Road Departure Mitigation (RDM) System

Continued

Driving

Road Departure Mitigation (RDM) System

Alerts and helps to assist you when the system detects a possibility of your vehicle
unintentionally crossing over detected lane markings and/or leaving the roadway
altogether.

The front camera behind the rearview mirror
monitors left and right lane markings (in white
or yellow). If your vehicle is getting too close
to detected lane markings without a turn
signal activated, the system, in addition to a
visual alert, applies steering torque and alerts
you with rapid vibrations on the steering
wheel, to help you remain within the detected
lane.

2 Customized Features P. 153, 359, 366

As a visual alert, the Lane Departure
message appears on the driver information
interface.

If the system determines that its steering input is insufficient to keep your vehicle on
the roadway, it may apply braking.

u

Braking is applied only when the lane markings are solid continuous lines.

The system cancels assisting operations when you turn the steering wheel to avoid
crossing over detected lane markings.

If the system operates several times without detecting driver response, the system
beeps to alert you.

■

How the System Works

1

Road Departure Mitigation (RDM) System

Important Safety Reminder
Like all assistance systems, the RDM system has
limitations.
Over-reliance on the RDM system may result in a
collision. It is always your responsibility to keep the
vehicle within your driving lane.

The RDM system only alerts you when lane drift is
detected without a turn signal in use. The RDM
system may not detect all lane markings or lane or
roadway departures; accuracy will vary based on
weather, speed and lane marker condition. It is
always your responsibility to safely operate the
vehicle and avoid collisions.

You can read about handling information for the
camera equipped with this system.

2 Front Sensor Camera P. 528

The RDM system may not work properly or may work
improperly under the certain conditions:

2 RDM Conditions and Limitations P. 520

There are times when you may not notice RDM
functions due to your operation of the vehicle, or
road surface conditions.

In the following case, a beeper sounds, a message
related to the ACC with LSF appears on the driver
information interface, and the braking function
controlled by the RDM system is canceled.

•

The vehicle has repeatedly applied the brakes to
maintain the set speed (for example, you are
descending a long slope).

uu

Honda Sensing®

u

Road Departure Mitigation (RDM) System

518

Driving

The system becomes ready to start searching for lane markings when all the
following conditions are met:
• The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).
• The vehicle is on a straight or slightly curved road.
• The turn signals are off.
• The brake pedal is not depressed.
• The wipers are not in continuous operation.
• The vehicle is not accelerating or braking, and the steering wheel is not being

turned.

• The system makes a determination that the driver is not actively accelerating,

braking or steering.

■

How the System Activates

1

Road Departure Mitigation (RDM) System

If LKAS is off and you have selected Narrow from the
customized options using the driver information
interface or audio/information screen, the message
below will appear in case the system determines a
possibility of your vehicle crossing over detected lane
markings.

2 Customized Features P. 359, 366

1

How the System Activates

The RDM system may automatically shut off and the
safety support indicator (amber) comes and stays on.

2 Indicators P. 80

RDM system function can be impacted when the
vehicle is:

•

Not driven within a traffic lane.

•

Driven on the inside edge of a curve, or outside of
a lane.

•

Driven in a narrow lane.

Continued

519

uu

Honda Sensing®

u

Road Departure Mitigation (RDM) System

Driving

When you turn the RDM on and off, do the
following.
1. Press the safety support switch.
2. Roll the left selector wheel to the



symbol and push it.

u

The message appears on the driver
information interface when the system
becomes on or off.

The RDM is in the previously selected ON or
OFF setting each time you turn the power
system on.

■

RDM On and Off

1

RDM On and Off

When you have selected Warning Only from the
customized options using the driver information
interface or audio/information screen, the system
does not operate the steering wheel and braking.

The vehicle stability assist® (VSA®) system, vehicle
stability assist® (VSA®) OFF, adaptive cruise control
(ACC) with low speed follow (LSF), safety support
and low tire pressure/TPMS indicators may come on
in amber along with a message in the driver
information interface when you set the power mode
to ON after re-connecting the 12-volt battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Safety Support Switch

Left Selector Wheel

520

uu

Honda Sensing®

u

Road Departure Mitigation (RDM) System

Driving

The system may not properly detect lane markings and the position of your vehicle
under certain conditions. Some examples of these conditions are listed below.

■

Environmental conditions

• Driving in bad weather (rain, fog, snow, etc.).
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• There is little contrast between lane lines and the roadway surface.
• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Driving in the shadows of trees, buildings, etc.
• Shadows of adjacent objects are parallel to lane markings.
• Roadway objects or structures are misinterpreted as lane markers.
• Reflections on the interior of the windshield.
• Driving at night or in a dark condition such as a tunnel.

■

RDM Conditions and Limitations

521

uu

Honda Sensing®

u

Road Departure Mitigation (RDM) System

Driving

■

Roadway conditions

• Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,

reflected lights, road spray, high contrast).

• Driving on a road with temporary lane markings.
• Faint, multiple, or varied lane markings are visible on the roadway due to road

repairs or old lane markings.

• The roadway has merging, split, or crossing lines (e.g., such as at an intersection

or crosswalk).

• The lane markings are extremely narrow, wide, or changing.
• The vehicle in front of you is driving near the lane lines.
• The road is hilly or the vehicle is approaching the crest of a hill.
• Driving on rough or unpaved roads, or over bumpy surfaces.
• When objects on the road (curb, guard rail, pylons, etc.) are recognized as white

lines (or yellow lines).

• Driving on roads with double lines.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet

snow, etc.

• The inside of the windshield is fogged.
• The camera temperature gets too high.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire

*

, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.
• When tire chains are installed.

* Not available on all models

522

uu

Honda Sensing®

u

Traffic Sign Recognition System

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit, your vehicle
has just passed through, showing it on the driver information interface.

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.

The sign icon also may switch to another one or disappear when:

• The other designated limit is detected.
• You make a turn with a turn signal at an intersection.

■

How the System Works

1

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Continued

523

uu

Honda Sensing®

u

Traffic Sign Recognition System

Driving

If the system does not detect any traffic signs while you are driving, the image below
may appear.

1

Traffic Sign Recognition System

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, when parking, find a shady area or face
the front of the vehicle away from the sun. If you use
a reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears, the traffic sign recognition system does not
work, and

 will be displayed.

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the air flow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears, the traffic sign recognition system does not
work, and

 will be displayed.

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

uu

Honda Sensing®

u

Traffic Sign Recognition System

524

Driving

The traffic sign recognition system may not be able to recognize the traffic sign in
the following cases.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.
• The inside of the windshield is fogged.
• There are portions remaining to be wiped.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire

*

, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.

■

Environmental conditions

• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• When you drive in the shadows of trees, buildings, etc.
• Driving at night, in dark areas such as long tunnels.
• Driving in bad weather (rain, fog, snow, etc.).
• A vehicle in front of you is traveling flying up spray or snow.

■

Traffic Sign Recognition System Conditions and Limitations

1

Traffic Sign Recognition System Conditions and Limitations

When the traffic sign recognition system
malfunctions,

 appears on the driver information

interface. If this message does not disappear, have
your vehicle checked by a dealer.

* Not available on all models

525

uu

Honda Sensing®

u

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

• A sign is hard to be found since it is in a complicated area.
• A sign is located far away from your vehicle.
• A sign is located where the beam of the headlight is hard to reach.
• A sign is on a corner or bend in the road.
• Faded or bent signs.
• Rotated or damaged signs.
• A sign is covered with mud, snow, or frost.
• A part of the sign is hidden by the trees, or the sign itself is hidden by a vehicle

and others.

• Light (a streetlight) or a shadow is reflected on the surface of the sign.
• A sign is too bright or too dark (an electric sign).
• A sign of a small size.

■

Other conditions

• When you are driving at a high speed.

526

uu

Honda Sensing®

u

Traffic Sign Recognition System

Driving

The traffic sign recognition system may not operate correctly, such as displaying a
sign that does not follow the actual regulation for the roadway or does not exist at
all in the following cases.

u

A speed limit sign may display at a higher or lower speed than the actual speed
limit.

• There is a supplementary sign with further information such as weather, time,

vehicle type, school zone, etc.

• Figures on the sign are hard to read (electric signs, numbers on the sign are

blurred, etc.).

• A sign is in the vicinity of the lane you are driving even though it is not for the lane

(speed limit sign situated at the junction between the side road and the main
road, etc.).

• There are things that look similar to the color or shape of the recognition object

(similar sign, electric sign, signboard, structure, etc.).

• A track or another large vehicle with a sticker of the speed limit sign on the back

are traveling in front of you.
