Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

To Use Maintenance Minder

TM

Maintenance items, which should be serviced at the same time that you replace the
engine oil, appear on the multi-information display.
You can view them on the engine oil life screen at any time.
1. Turn the ignition switch to ON

(

w

*1

.

2. Press the

 (Information) button repeatedly until the engine oil life appears

on the multi-information display.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Displaying the Maintenance Minder Information

Models with multi-information display

1

Displaying the Maintenance Minder Information

Based on the engine operating conditions, the
remaining engine oil life is calculated and displayed
as a percentage.

There is a list of maintenance main and sub items you
can view on the information display.

Maintenance Service Items P. 497

Displayed Engine Oil

Life (%)

Calculated Engine Oil

Life (%)

100

100 to 91

90

90 to 81

80

80 to 71

70

70 to 61

60

60 to 51

50

50 to 41

40

40 to 31

30

30 to 21

20

20 to 16

15

15 to 11

10

10 to 6

5

5 to 1

0

0



Button

Maintenance
Item Codes

Remaining
Engine Oil
Life

496

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

The system message indicator (

) comes on along with the Maintenance Minder message.

Maintenance Minder Messages on the Multi-Information
Display

Maintenance Message

Oil Life Display

Explanation

Information

Maintenance Due Soon

15 %

The remaining engine oil life is 15 to
6 percent. Once you switch the

display by pressing the



(Information) button, this message
will go off.

The engine oil is approaching the end
of its service life, and the maintenance
items should be inspected and serviced
soon.

Maintenance Due Now

5 %

The remaining engine oil life is 5 to 1

percent. Press the

 button to

switch to another display.

The engine oil has almost reached the
end of its service life, and the
maintenance items should be inspected
and serviced as soon as possible.

Maintenance Past Due

Negative Distance

The remaining engine oil life has
passed its service life, and a negative
distance appears after driving over
10 miles (U.S. models) or 10 km
(Canadian models). Press the

 button to switch to another

display.

The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.

497

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

Maintenance Service Items

1

Maintenance Service Items

Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.

Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.

Maintenance Minder
Message

System Message
Indicator

Sub Items

Main Item

*1: If a message Maintenance does not appear more than 12 months after the display is reset, change

the engine oil every year.

# : See information on maintenance and emissions warranty.

CODE

Maintenance Main Items

A

Replace engine oil

*1

B

Replace engine oil

*1

 and oil filter

Inspect front and rear brakes

Check parking brake adjustment

Inspect tie rod ends, steering gearbox, and boots

Inspect suspension components

Inspect driveshaft boots

Inspect brake hoses and lines (Including ABS/VSA)

Inspect all fluid levels and condition of fluids

Inspect exhaust system

#

Inspect fuel lines and connections

#

*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and

from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).

CODE

Maintenance Sub Items

1

Rotate tires

2

Replace air cleaner element

*2

Replace dust and pollen filter

*3

Inspect drive belt

3

Replace transmission fluid

4

Replace spark plugs

Inspect valve clearance

5

Replace engine coolant

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

498

Main

tenan

ce

Reset the maintenance minder information display if you have performed the
maintenance service.

1. Turn the ignition switch to ON

(

w

*1

.

2. Press the

 button to select Maintenance Info., then press the SEL/RESET

button.

3. Select Reset with the

 button, then press the SEL/RESET button.

u

The displayed maintenance items disappear, and the engine oil life display
returns to 100%.

To cancel the oil life reset mode, select Cancel, then press the SEL/RESET button.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Resetting the Display

1

Resetting the Display

NOTICE

Failure to reset the Maintenance Minder

TM

 display

after a maintenance service results in the system
showing incorrect maintenance intervals, which can
lead to serious mechanical problems.

The dealer will reset the Maintenance Minder

TM



display after completing the required maintenance
service. If someone other than a dealer performs
maintenance service, reset the Maintenance
Minder

TM

 display yourself.

Engine Oil Life

SEL/RESET
Button

Maintenance Item Codes



(Information)
Button

499

Main

tenan

ce

Maintenance Under the Hood

Maintenance Items Under the Hood

Brake/Clutch

*

 Fluid

(Black Cap)

Engine Coolant Reserve Tank

Radiator Cap

Washer Fluid
(Blue Cap)

Engine Oil Dipstick
(Orange)

Engine Oil Fill Cap

Battery

* Not available on all models

500

uu

Maintenance Under the Hood

u

Opening the Hood

Main

tenan

ce

Opening the Hood

1. Park the vehicle on a level surface, and set

the parking brake.

2. Pull the hood release handle under the

driver’s side lower outside corner of the
dashboard.

u

The hood will pop up slightly.

3. Push the hood latch lever (located under

the front edge of the hood to the center) to
the side and raise the hood. Once you have
raised the hood slightly, you can release the
lever.

4. Remove the support rod from the clamp

using the grip. Mount the support rod in
the hood.

When closing, remove the support rod, and
stow it in the clamp, then gently lower the
hood. Remove your hand at a height of
approximately 12 inches (30 cm) and let the
hood close.

1

Opening the Hood

NOTICE

Do not open the hood when the wiper arms are
raised.
The hood will strike the wipers, resulting in damage
to the hood and/or the wipers.

When closing the hood, check that the hood is
securely latched.

If the hood latch lever moves stiffly, or if you can
open the hood without lifting the lever, the latch
mechanism should be cleaned and lubricated.

Hood Release Handle

Lever

Support
Rod

Grip

Clamp

501

uu

Maintenance Under the Hood

u

Recommended Engine Oil

Main

tenan

ce

Recommended Engine Oil

Oil is a major contributor to your engine’s
performance and longevity. If you drive the
vehicle with insufficient or deteriorated oil,
the engine may fail or be damaged.

This seal indicates the oil is energy conserving
and that it meets the American Petroleum
Institute’s latest requirements.

Use a Genuine Honda Motor Oil or another
commercial engine oil of suitable viscosity for
the ambient temperature as shown.

Synthetic oil

You may also use synthetic motor oil if it is labeled with the API Certification Seal
and is the specified viscosity grade.

• Genuine Honda Motor Oil
• Premium-grade 0W-16, 0W-20 detergent oil with an API Certification

Seal on the container.

1

Recommended Engine Oil

Engine Oil Additives
Your vehicle does not require oil additives. In fact,
they may adversely affect the engine performance
and durability.

Ambient Temperature

502

uu

Maintenance Under the Hood

u

Oil Check

Main

tenan

ce

Oil Check

We recommend that you check the engine oil level every time you refuel.
Park the vehicle on level ground.
Wait approximately three minutes after turning the engine off before you check the
oil.

1. Remove the dipstick (orange).
2. Wipe the dipstick with a clean cloth or

paper towel.

3. Insert the dipstick back all the way into its

hole.

4. Remove the dipstick again, and check the

level. It should be between the upper and
lower marks. Add oil if necessary.

1

Oil Check

If the oil level is near or below the lower mark, slowly
add oil, being careful not to overfill.

Upper Mark

Lower Mark

503

uu

Maintenance Under the Hood

u

Adding Engine Oil

Main

tenan

ce

Adding Engine Oil

1. Unscrew and remove the engine oil fill cap.
2. Add oil slowly.
3. Reinstall the engine oil fill cap, and tighten

it securely.

4. Wait for three minutes and recheck the

engine oil dipstick.

1

Adding Engine Oil

If any oil spills, wipe it away immediately. Spilled oil
may damage the engine compartment components.

NOTICE

Do not fill the engine oil above the upper mark.
Overfilling the engine oil can result in leaks and
engine damage.

Engine Oil Fill Cap

504

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Main

tenan

ce

Changing the Engine Oil and Oil Filter

You must change the engine oil and oil filter regularly in order to maintain the
engine’s lubrication. The engine may be damaged if they are not changed regularly.

Change the oil and filter in accordance with the Maintenance Minder message on
the information display

*

/multi-information display

*

.

1. Run the engine until it reaches normal

operating temperature, and then turn the
engine off.

2. Open the hood and remove the engine oil

fill cap.

3. Remove the bolts and clips on the

undercarriage and remove the under
cover.

4. Remove the drain bolt and washer from

the bottom of the engine, and drain the
oil into a suitable container.

1

Changing the Engine Oil and Oil Filter

NOTICE

You may damage the environment if you do not
dispose of the oil in a suitable way. If you are
changing the oil by yourself, appropriately dispose of
the used oil. Put the oil in a sealed container and take
it to a recycling center. Do not throw the oil away
into a garbage can or onto the ground.

Under
Cover

Bolt

Clip

Washer

Drain Bolt

* Not available on all models

505

uu

Maintenance Under the Hood

u

Changing the Engine Oil and Oil Filter

Main

tenan

ce

5. Remove the oil filter and dispose of the

remaining oil.

6. Check that the filter gasket is not stuck to

the engine contact surface.

u

If it is stuck, you must detach it.

7. Wipe away dirt and dust adhering to the

contact surface of the engine block, and
install a new oil filter.

u

Apply a light coat of new engine oil to
the oil filter gasket.

8. Put a new washer on the drain bolt, then

reinstall the drain bolt.

u

Tightening torque:
29 lbf∙ft (39 N∙m, 4.0 kgf∙m)

9. Pour the recommended engine oil into the

engine.

u

Engine oil change capacity (including
filter):
3.5 US qt (3.3 L)

10. Reinstall the engine oil fill cap securely and

start the engine.

11. Run the engine for a few minutes, and

then check that there is no leak from the
drain bolt or oil filter.

12. Stop the engine, wait for three minutes,

and then check the oil level on the
dipstick.

u

If necessary, add more engine oil.

1

Changing the Engine Oil and Oil Filter

You will need a special wrench to replace the oil
filter. You can buy this wrench from a dealer.

When installing the new oil filter, follow the
instructions supplied with the oil filter.

Reinstall the engine oil fill cap. Start the engine. The
low oil pressure indicator should go off within five
seconds. If it does not, turn off the engine, and check
your work.

Oil Filter

506

uu

Maintenance Under the Hood

u

Engine Coolant

Main

tenan

ce

Engine Coolant

This coolant is premixed with 50% antifreeze and 50% water. Do not add any
straight antifreeze or water.

We recommend you check the engine coolant level every time you refuel. Check the
reserve tank first. If it is completely empty, also check the coolant level in the
radiator. Add the engine coolant accordingly.

1. Make sure the engine and radiator are cool.
2. Check the amount of coolant in the reserve

tank.

u

If the coolant level is below the MIN
mark, add the specified coolant until it
reaches the MAX mark.

3. Inspect the cooling system for leaks.

Specified coolant: Honda Long Life Antifreeze/Coolant Type 2

Reserve Tank

1

Engine Coolant

NOTICE

Genuine Honda engine coolant is a 50/50 mixture of
antifreeze and water that can withstand freezing at
temperatures as low as about -31°F (-35°C). If your
vehicle is consistently subjected to temperatures
below this, the concentration of antifreeze in the
coolant should be increased. Consult a dealer for
details.

If Honda antifreeze/coolant is not available, you may
use another major brand of non-silicate coolant as a
temporary replacement. Check that it is a high quality
coolant recommended for aluminum engines.
Continued use of any non-Honda coolant can result in
corrosion, causing the cooling system to malfunction
or fail. Have the cooling system flushed and refilled
with Honda antifreeze/coolant as soon as possible.

Do not add rust inhibitors or other additives to your
vehicle’s cooling system. They may not be compatible
with the coolant or with the engine components.

3

WARNING

Removing the radiator cap while the
engine is hot can cause the coolant to spray
out, seriously scalding you.

Always let the engine and radiator cool
down before removing the radiator cap.

Reserve Tank

MAX

MIN

507

uu

Maintenance Under the Hood

u

Engine Coolant

Main

tenan

ce

1. Make sure the engine and radiator are

cool.

2. Turn the radiator cap 1/8 turn counter-

clockwise and relieve any pressure in the
cooling system.

3. Push down and turn the radiator cap

counter-clockwise to remove it.

4. The coolant level should be up to the base

of the filler neck. Add coolant if it is low.

5. Put the radiator cap back on, and tighten it

fully.

Radiator

1

Radiator

NOTICE

Pour the fluid slowly and carefully so you do not spill
any. Clean up any spills immediately; they can
damage components in the engine compartment.

Radiator Cap

508

uu

Maintenance Under the Hood

u

Transmission Fluid

Main

tenan

ce

Transmission Fluid

Have a dealer check the fluid level and replace if necessary.

Do not attempt to check or change the continuously variable transmission (CVT)
fluid yourself.

Have a dealer check the fluid level and replace if necessary.

Do not attempt to check or change the manual transmission fluid yourself.

Continuously Variable Transmission (CVT) Fluid

Specified fluid: Honda HCF-2 Transmission Fluid

Manual Transmission Fluid

Specified fluid: Honda Manual Transmission Fluid (MTF)

Continuously variable transmission models

1

Continuously Variable Transmission (CVT) Fluid

NOTICE

Do not mix HCF-2 with other transmission fluids
Using a transmission fluid other than HCF-2 may
adversely affect the operation and durability of your
vehicle's transmission, and damage the transmission.
Any damage caused by using a transmission fluid that
is not equivalent to HCF-2 is not covered by Honda's
new vehicle limited warranty.

Manual transmission models

1

Manual Transmission Fluid

If Honda MTF is not available, you may use the API
certificated SAE 0 W-20 or 5 W-20 viscosity motor oil
as a temporary measure.
Replace with MTF as soon as possible. Motor oil does
not contain the proper additives for the transmission
and continued use can cause decreased shifting
performance and lead to transmission damage.

509

uu

Maintenance Under the Hood

u

Brake/Clutch

*

 Fluid

Main

tenan

ce

Brake/Clutch

*

 Fluid

Use the same fluid for both the brakes and clutch.

The fluid level should be between the MIN
and MAX marks on the side of the reservoir.

The brake fluid reservoir is also used for your
vehicle’s clutch fluid. As long as you keep the
brake fluid level as instructed above, there is
no need for checking the clutch fluid level.

Specified fluid: Honda Heavy Duty Brake Fluid DOT 3

Checking the Brake Fluid

1

Brake/Clutch

*

 Fluid

NOTICE

Brake fluid marked DOT 5 is not compatible with your
vehicle’s braking system and can cause extensive
damage.

If the specified brake fluid is not available, you should
use only DOT 3 or DOT 4 fluid from a sealed
container as a temporary replacement.

Using any non-Honda brake fluid can cause corrosion
and decrease the longevity of the system. Have the
brake system flushed and refilled with Honda Heavy
Duty Brake Fluid DOT 3 as soon as possible.

If the brake fluid level is at or below the MIN mark,
have a dealer inspect the vehicle for leaks or worn
brake pads as soon as possible.

MIN

MAX

Manual transmission models

* Not available on all models

510

uu

Maintenance Under the Hood

u

Refilling Window Washer Fluid

Main

tenan

ce

Refilling Window Washer Fluid

Check the amount of window washer fluid by
looking at the reservoir.
If the level is low, fill the washer reservoir.

If the washer fluid is low, the washer level
indicator

*

 appears on the instrument panel or

a message appears on the multi-information
display

*

.

Pour the washer fluid carefully. Do not overflow the reservoir.

1

Refilling Window Washer Fluid

NOTICE

Do not use engine antifreeze or a vinegar/water
solution in the window washer reservoir.
Antifreeze can damage your vehicle’s paint. A
vinegar/water solution can damage the window
washer pump.

Window Washer
Reservoir

Models without washer level sensor

Models with washer level sensor

* Not available on all models















Content   ..  30  31  32  33   ..
