Honda Fit (2019 year). Manual - part 17

255

Audio System Basic Operation

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

*1 : Some or all of the lists may not be displayed.

(Back)

Select to go back to the previous display.

Seek Icons
Select

to search up

and down the selected band for a
station with a strong signal.

VOL/

(Power/volume) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

(Menu)

Select to display the menu items.

Tune Icons
Select

to tune the radio frequency.

Scan Icon
Select to scan each station with a strong signal.

Preset Icons
Tune the radio frequency for
preset memory.
Select and hold the preset
icon to store that station.
Select

to display beyond

preset 7.

Audio/Information Screen

Open/Close Icon

Displays/hides the detailed
information.

Audio System Basic Operation

Playing AM/FM Radio

256

Features

To store a station:
1. Tune to the selected station.
2. Select and hold the preset number for the station you want to store.

You can also store a preset station by the following procedure.
1. Tune to the selected station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

Lists the strongest stations on the selected band.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list.
2. Select the Station List tab.
3. Select Refresh.

■

Preset Memory

■

Station List

Preset Memory

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the SOURCE button on the steering wheel or
select SOURCE on the screen.

2 Audio Remote Controls

P. 210

You can store 6 AM stations and 12 FM stations into
preset memory.

HD Radio Technology manufactured under license
from iBiquity Digital Corporation. U.S. and Foreign
Patents. For patents see http://dts.com/patents. HD
Radio, Artist Experience, and the HD, HD Radio, and
"ARC" logos are registered trademarks or
trademarks of iBiquity Digital Corporation in the
United States and/or other countries.

Models with HD Radio

* Not available on all models

Continued

257

Audio System Basic Operation

Playing AM/FM Radio

Features

Samples each of the strongest stations on the selected band for 10 seconds. To turn
off scan, select Cancel or

Displays the subchannel list when an HD Radio

station is selected while listening to

an FM station.
1. Select .
2. Select HD Subchannel.
3. Select the channel number.

Provides text data information related to your selected RDS-capable FM station.

■

To find an RDS station from Station List

1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select the station.

■

Manual update

Updates your available station list at any time.
1. Select the open/close icon to display a list while listening to an FM station.
2. Select the Station List tab.
3. Select Refresh.

■

Scan

■

HD Subchannel

■

Radio Data System (RDS)

Models with HD Radio

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

258

Audio System Basic Operation

Playing AM/FM Radio

Features

■

Radio text

Displays the radio text information of the selected RDS station.
1. Select .
2. Select View Radio Text.

■

Scan

Samples each of the strongest stations on the selected band for 10 seconds.

To turn off scan, select Cancel or

259

Audio System Basic Operation

Playing SiriusXM® Radio

Continued

Features

Playing SiriusXM® Radio

*1 : Some or all of the lists may not be displayed.

(Back)

Select to go back to the previous display.

Skip Icons
Select

change section in the
channel.
Select and hold to move
rapidly within the section.

VOL/

(Power/volume) Knob

Press to turn the audio system on
and off.
Turn to adjust the volume.

Open/Close Icon

Displays/hides the detailed
information.

(Menu)

Select to display the menu items.

Audio/Information Screen

Category Icons
Select

to display and select a

SiriusXM® Radio category.

Scan Icon
Select to scan each channel.

Preset Icons
Tune the radio frequency
for preset memory. Select
and hold the preset icon to
store that station. Select

to display beyond

preset 7.

Station Art

Album Art

Channel Icons
Select

to the

previous or next channel.
Select and hold to rapidly
skip 10 channels at a time.

Audio System Basic Operation

Playing SiriusXM® Radio

260

Features

1. Select .
2. Select Tune Mode.
3. Select Channel Mode or Category Mode.

■

To Change the Tune Mode

Playing SiriusXM® Radio

In the channel mode, all available channels are
selectable. In the category mode, you can select a
channel within a category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

SiriusXM® Radio stations load in ascending order,
which can take about a minute. Once they have
loaded you will be able to scroll up or down to make
your selections.

Switching the Audio Mode
Press the SOURCE button on the steering wheel or
select SOURCE on the screen.

2 Audio Remote Controls

P. 210

Tune Start:
When you change to a preset channel, a song being
played on that channel restarts from the beginning
with this function. This can be turned on or off from
the Audio Settings screen.

2 Customized Features P. 328

* Not available on all models

Continued

261

Audio System Basic Operation

Playing SiriusXM® Radio

Features

To store a channel:
1. Tune to the selected channel.
2. Select to hold the preset number for the station you want to store.
3. Select Replace.

You can also store a channel by the following procedure.
1. Tune to the selected channel.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number for the station you want to store.

■

Multi-channel preset (for music channels only)

You can store up to four of your preferred music channels per preset.

1. Tune a station.
2. Select the open/close icon to display a list.
3. Select the Preset tab.
4. Select and hold the preset number you

want to add a music channel.

A message appears if there are no
available presets.

5. Select Combine.

■

Preset Memory

Playing SiriusXM® Radio

You can store 12 SiriusXM® channels into the preset
memory.

Audio System Basic Operation

Playing SiriusXM® Radio

262

Features

Suggested channel listing received from SiriusXM® can be displayed and selected.
1. Select the open/close icon to display a channel list.
2. Select the Channel List tab.
3. Select the featured channel list title you want to listen to.

The selected channel list of the title is displayed.

4. Select the channel.

■

Listening to Featured Channels

Listening to Featured Channels

Up to three featured channels by SiriusXM® can be
displayed.

Featured channel lists are at the top of the channel
list.

Continued

263

Audio System Basic Operation

Playing SiriusXM® Radio

Features

The system can record up to the last 60 minutes of your currently tuned channel’s
broadcast, as well as the last 30 minutes of your preset channel’s broadcast, starting
from the moment you turn the vehicle on. If you tuned to preset channel, the system
records up to 60 minutes of a broadcast instead of up to 30 minutes. You can
rewind and replay the last 30 or 60 minutes of a broadcast.
1. Select .
2. Select Playback.
3. Move the gauge to the position you want to replay.

The following items are available on the pop-up screen:

(Skip Down): Skips to the previously stored channel. Select and hold to

fastrewind the current selection.

(Skip Up): Skips to the next channel. Select and hold to fast-forward the

current selection.

(15sec Back): Select to skip back 15 seconds in the current selection. Select and

hold to fast-rewind the current selection.

(15sec Skip): Select to skip forward 15 seconds in the current selection. Select

and hold to fast-forward the current selection.

Select OK or

to close the pop-up menu. Replay in playback mode continues.

To play or pause on playback mode:
1. Select .
2. Select Play/Pause.

■

Returning to real-time broadcast

1. Select .
2. Select Go to Live.

■

Replay Function

Replay Function

The system starts storing broadcast in memory when
the power mode is turned ON. You can go back to
the program from that point.

You can no longer replay any program once the
power mode is turned off as it erases memory.
You can check how long the program has been
stored in memory from the audio/information screen.

After 30 or 60 minutes of recording the system will
automatically start deleting the oldest data.

(A): Shows how much time the replayed segment is
behind the real-time broadcast
(B): Replayed segment
(C): Length stored in memory

Audio/Information Screen

(C)

(B)

(A)

Audio System Basic Operation

Playing SiriusXM® Radio

264

Features

While listening to other channel, you can receive sports alerts such as scores from
your favorite teams.

■

To set up a favorite team

1. Select .
2. Select Settings.
3. Select Audio.
4. Select the SXM tab.
5. Select SportsFlash Setup.
6. Select Favorite Team.
7. Select a team.

■

To set up a alert message

1. Select .
2. Select Settings.
3. Select Audio.
4. Select the SXM tab.
5. Select SportsFlash Setup.
6. Select Interrupt.
7. Select On(one time) or On(continue).

■

Live Sports Alert

Live Sports Alert

The sports alert function at SiriusXM® mode only.

To set up a favorite team

Sports alerts cut in only when SiriusXM® mode is on.
Selecting On(one time) from the customize settings
disables the alert feature next time you turn the
power mode to ON.

2 Customized Features P. 328

You can also set up a favorite team by the following
procedure.
1. Select Audio.
2. Select .
3. Select Settings.
4. Select the SXM tab.

Continued

265

Audio System Basic Operation

Playing SiriusXM® Radio

Features

■

To set up a alert beep

1. Select .
2. Select Settings.
3. Select Audio.
4. Select the SXM tab.
5. Select SportsFlash Setup.
6. Select Interrupt Beep.
7. Select On.

■

Receiving a sports alert

1. A pop-up appears and notifies you of a sports alert.
2. Select Listen.

You can use the same items as the playback mode pop-up screen.

2 Replay Function P. 263

To go back to the previous screen, select Back.

To set up a alert beep

You can also set up a alert beep by the following
procedure.
1. Select Audio.
2. Select .
3. Select Settings.
4. Select the SXM tab.

Audio System Basic Operation

Playing SiriusXM® Radio

266

Features

You can receive traffic and weather information.

■

To set up a traffic & weather information

1. Select .
2. Select Settings.
3. Select Audio.
4. Select the SXM tab.
5. Select Traffic & Weather Setup.
6. Select the region.

When you do not want to receive the information, select Unregistered.

■

Listening to traffic and weather information

1. Select .
2. Select Traffic & Weather.

Play mode can also use the any items same as playback mode.

2 Replay Function P. 263

To go back to the previous screen, select OK.

Sample each channel on the selected mode for 10 seconds.
1. Select Scan.
2. Select Scan Channels.

You can select the desired channel by songs using Scan Song in Presets.

To turn off scan, select Cancel Scan.

■

Traffic and Weather Information

■

Scan

Traffic and Weather Information

The traffic and weather information function at
SiriusXM® mode only.

You can also set up the traffic and weather
information by the following procedure.
1. Select Audio.
2. Select .
3. Select Settings.
4. Select the SXM tab.

Scan

The “Scan Songs in Presets” function is based on
TuneScan

technology of SiriusXM®.

The “Featured Channels” function is based on
Featured Favorites

technology of SiriusXM®.

TuneScan

and Featured Favorites

are registered

trademarks of SiriusXM® Radio, Inc.

267

Audio System Basic Operation

Playing an iPod

Continued

Features

Playing an iPod

Connect the iPod using your USB connector to the USB port, then select the iPod
mode.

2 USB Port(s) P. 207

*1 : Some or all of the lists may not be displayed.

USB Indicator
Appears when an iPod is connected.

Song Icons
Select

to change songs.

Select and hold to move rapidly within a song.

Audio/Information Screen

Cover Art

(Back)

Select to go back to the previous display.

VOL/

(Power/volume) Knob

Press to turn the audio system on and off.
Turn to adjust the volume.

(Menu)

Select to display the menu items.

Open/Close Icon

Displays/hides the detailed
information.

Audio System Basic Operation

Playing an iPod

268

Features

1. Select

and

select

Music Search.

2. Select the items on that menu.

■

How to Select a Song from the Music Search List

Playing an iPod

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

2 iPod/USB Flash Drive P. 313

If you operate the music app on your iPhone/iPod
while the phone is connected to the audio system,
you may no longer be able to operate the same app
on the audio/information screen.
Reconnect the device if necessary.

Item Selection

Category Selection

269

Audio System Basic Operation

Playing an iPod

Features

You can select repeat and shuffle modes when playing a file.

Select a mode.

■

To turn off a play mode

Select the mode you want to turn off.

■

How to Select a Play Mode

How to Select a Play Mode

Play Mode Menu Items
Shuffle Albums: Plays all available albums in a
selected list (playlists, artists, albums, songs,
podcasts, genres, composers, or audiobooks) in
random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs,
podcasts, genres, composers, or audiobooks) in
random order.
Repeat Song: Repeats the current track.
