Honda Fit (2019 year). Manual - part 12





175

Continued

Co
ntrols

Adjusting the Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

uu

Adjusting the Seats

u

Front Seats

176

Co
ntrols

Adjusting the Seat Positions

1

Adjusting the Seat Positions

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment
Pull up on the bar to move the
seat, then release the bar.

Driver’s seat is shown.

Seat-back Angle
Adjustment
Pull up the lever to
change the angle.

Height Adjustment
(Driver side only)
Pull up or push down the lever
to raise or lower the seat.

Continued

177

uu

Adjusting the Seats

u

Front Seats

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

uu

Adjusting the Seats

u

Front Seats

178

Co
ntrols

Reclining the seat-backs on the front seats until they are level with the rear seat
cushions provides a large cushioned area that can (and should only) be used when
the vehicle is safely parked.

1. Remove the front head restraints while

pushing the release button.

u

Store the head restraints in the cargo
area.

2. Adjust the front seats forward as far as

possible.

3. While pulling the seat-back angle

adjustment lever, pivot the seat-back
backward until it is level with the rear seat
cushion.

4. Move the front seat backward until it

touches the rear seat.

5. Unlatch the detachable anchor from the

anchor buckle, and store the rear center
seat belt.

Seat Belt with Detachable Anchor P. 43

6. Adjust the rear seat-back to the desired

position.

To return the front seats and rear center seat
belt to their original positions, reverse this
procedure.
When you return a seat-back to its upright
position, hold the seat-back to keep it from
going up too quickly.

Reclining the Front Seats

1

Reclining the Front Seats

Both front seats must be returned to their normal
upright position, and the head restraints reinstalled
and properly adjusted before driving.

Removing and Reinstalling the Head

Restraints P. 184

179

uu

Adjusting the Seats

u

Rear Seats

Continued

Co
ntrols

Rear Seats

Pull the lever on the right to change the angle
of the right half of the seat-back, and left for
the left half.

Rear Seat-back Adjusting

Release Lever

uu

Adjusting the Seats

u

Rear Seats

180

Co
ntrols

The rear seats can be folded down separately to allow for additional storage space.

To fold down the seat

1. Store the center seat belt first. Insert the

latch plate into the slot on the side of the
anchor buckle.

2. Retract the seat belt into the holder on the

ceiling.

Seat Belt with Detachable Anchor P. 43

3. Lower the head restraint to its lowest

position.

4. Pull the release lever and fold down the

seat-back.

To return the seat to the original position, pull
up the seat-back in the upright position.

Folding Down the Rear Seats

1

Folding Down the Rear Seats

Make sure all items in the cargo area or items
extending to the rear seats are properly
secured. Loose items can fly forward if you have
to brake hard.

Remove any items from the rear seat cushion and
floor before you fold down the rear seat.

To lock the seat-back upright, push it backwards until
it locks.

Make sure the seat-back, head restraints and seat
cushion are securely latched back into place before
driving. Also, make sure all rear shoulder belts are
positioned in front of the seat-back, and the center
shoulder belt is re-positioned in the holding slot.

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

Passenger Front Airbag Off Indicator P. 58

Anchor
Buckle

Latch Plate

Release Lever

181

uu

Adjusting the Seats

u

Rear Seats

Co
ntrols

Separately lift up the left and right halves of
the rear seat cushions to make room for cargo
area.

Lifting up the seat cushion

1. Make sure the seat belt buckles are in their

loops on the seat.

2. Pull up the rear seat cushion.
3. Fold the seat leg down while pushing the

seat cushion firmly against the seat-back to
lock it.

Putting the seat in the original position

1. Hold the seat cushion in the upright

position, and pull up the seat leg fully.

u

The seat cushion can abruptly fall down
once you pull up the seat leg.

2. Slowly put down the seat cushion and set

the seat leg in the floor guide.

u

A latch comes out when the leg is set
properly.

Folding the Rear Seat Up

1

Folding the Rear Seat Up

After you fold the seat up, or put it back in the
original position, make sure the seat is firmly secured
by rocking it forward and back.

Check if there are any items on the seat before you
pull the seat cushion up. Check if there are any
obstacles around the floor guide before you put the
seat back in the original position.

Loop

Seat Leg

Floor Guide

Latch

Seat Leg

182

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant’s head rests against the
center of the restraint. The tops of the
occupant’s ears should be level with the
center height of the restraint.

To raise the head restraint: Pull it upward.
To lower the head restraint: Push it down
while pressing the release button.

Adjusting the front head restraint positions

1

Adjusting the front head restraint positions

In order for the head restraint system to work
properly:

Do not hang any items on the head restraints, or
from the restraint legs.

Do not place any objects between an occupant and
the seat-back.

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

183

uu

Adjusting the Seats

u

Head Restraints

Continued

Co
ntrols

A passenger sitting in a back seating position
should adjust the height of their head restraint
to an appropriate position before the vehicle
begins moving.
To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

Changing the Rear Seat Head Restraint Positions

Outer

Center

uu

Adjusting the Seats

u

Head Restraints

184

Co
ntrols

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

To remove and install the rear outer head restraint,
recline the seat-back slightly forward as the space
between the ceiling and the seat-back is limited.

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

185

uu

Adjusting the Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.
Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.
In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

186

uu

Adjusting the Seats

u

Armrest

*

Co
ntrols

Armrest

*

The console lid can be used as an armrest.

Using the Front Seat Armrest

* Not available on all models

187

Continued

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

ON

The interior lights come on regardless of
whether the doors are open or closed.

Door activated

The interior lights come on in the following
situations:
• When any doors are opened.
• You unlock the driver’s door.

• You remove the key from the ignition

switch.

• When the power mode is set to VEHICLE

OFF (LOCK).

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after 30 seconds in the following
situations:

When you unlock the driver’s door but do not open it.

When you remove the key from the ignition switch
but do not open a door.

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

The interior lights go off immediately in the following
situations:

When you lock the driver’s door.

When you turn the ignition switch to ON

(

w

*1

.

When you close the driver’s door with the key in
the ignition switch.

When you close the driver’s door in ACCESSORY
mode.

If you leave any of the doors open in VEHICLE OFF
(LOCK) mode, or without the key in the ignition
switch, the interior lights go off after about 15
minutes.

*1: Models with the smart entry system have an ENGINE
START/STOP
 button instead of an ignition switch.

Models without smart entry system

Models with smart entry system

Models without smart entry system

Models with smart entry system

On

Off

Door Activated Position

Front

*

Rear

Door Activated Position

Off

Models without smart entry system

Models with smart entry system

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

188

Co
ntrols

The map lights can be turned on and off by
pressing the lenses.

The light comes on when you open the
tailgate, and goes off when closed.

Map Lights

1

Map Lights

When the interior light switch is in the door activated
position and any door is open, the map light will not
go off when you press the lens.

Models with moonroof

Models with moonroof

Models without moonroof

Cargo Area Light

189

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box.

Pull the handle to open the console
compartment.

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Console Compartment

*

* Not available on all models

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

190

Co
ntrols

Front seat beverage holders

Pull the lid backward to use the front panel
beverage holder.

The beverage holder is at the front of each
door.

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Front Door















Content   ..  10  11  12  13   ..
