Honda Fit (2019 year). Manual - part 9





127

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and the tailgate.
You can lock/unlock the doors and the
tailgate within a radius of about 32 inches (80
cm) of the outside door handle or tailgate
release button.

Locking the doors and tailgate

Press the door lock button on the front door
or the tailgate.

u

Some exterior lights flash; the beeper
sounds; all the doors and tailgate lock;
and the security system sets.

Using the Smart Entry with Push Button Start System

*

1

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated

position, the interior lights come on when you press

the unlock button.

No doors opened: The lights fade out after 30 seconds.

Doors relocked with the remote transmitter: The

lights go off immediately.

1

Using the Smart Entry with Push Button Start System

*

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the smart entry
system, the doors will automatically relock.
You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors and tailgate while
someone else with the remote is within range.

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

If you grip a door handle wearing gloves, the door
sensor may be slow to respond or may not respond
by unlocking the doors.

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and the
tailgate with the smart entry remote if it is above or
below the outside handle.

The smart entry remote may not operate if it is too
close to the door and door glass.

Door Lock Button

Lock Button

* Not available on all models

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

128

Co
ntrols

Locking the vehicle (Walk away auto
lock)

When you walk away from the vehicle while
carrying the smart entry remote, the doors will
automatically lock.
The auto lock function activates when all
doors and tailgate are closed, and the smart
entry remote is within about 5 feet (1.5 m)
radius of the outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).
1. While within about 5 feet (1.5 m) radius of

the vehicle.

u

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

u

Some exterior lights flash; the beeper
sounds; all doors and tailgate will then
lock.

1

Locking the vehicle (Walk away auto lock)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen or MID.
If you set the auto lock function to ON using the
audio/information screen or the MID, only the remote
transmitter that was used to unlock the driver’s door
prior to the setting change can activate auto lock.

Customization flow P. 112

After the auto lock function has been activated, when
you stay within the locking/unlocking operation range,
the indicator on the smart entry remote will continue
to flash until the doors are locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be delayed until all doors and tailgate are closed.

When all doors and tailgate have been closed and the
smart entry remote is inside the vehicle, or if the
smart entry remote is not detected within about
5 feet (1.5 m) of the vehicle, auto lock function will
not be activated.

When all doors and  tailgate have been closed, the
warning beeper will sounds to indicate that the smart
entry remote is not detected within the operation
range.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Continued

129

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock  Unlock  Lock  Unlock.

u

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function

• Walk away at least more than about 5 feet

(1.5 m) away from the vehicle while
carrying the smart entry remote.

1

Locking the vehicle (Walk away auto lock)

The auto lock function does not operate when any of
the following conditions are met.

The smart entry remote is inside the vehicle.

A door or the hood is not closed.

The power mode is set to any mode other than
OFF.

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

The smart entry remote is put inside the vehicle
through a window.

You are located too close to the vehicle.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

130

Co
ntrols

Unlocking the doors and tailgate

Grab the driver’s door handle:

u

The driver’s door unlocks.

u

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

u

All the doors and the tailgate unlock.

u

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate release button:

u

All the doors and the tailgate unlock.

u

Some exterior lights flash twice and the
beeper sounds twice.

Using the Tailgate Outer Handle/

Release Button P. 146

1

Using the Smart Entry with Push Button Start System

*

The light flash, beep and door unlock mode settings
can be customized using the multi-information
display.

Customized Features P. 111

Tailgate Release
Button

* Not available on all models

Continued

131

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

Locking the doors and tailgate

Press the lock button.
Once:

u

Some exterior lights flash, all the doors
and tailgate lock, and the security system
sets.

Twice (within five seconds after the first
push):

u

A beeper sounds and verifies the security
system is set.

Using the Remote Transmitter

1

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.

The remote will not lock the vehicle when a door or
the tailgate is open.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote transmitter will not work when the key is
in the ignition switch.

You can lock or unlock doors using the remote
transmitter or smart entry system only when the
power mode is in VEHICLE OFF.

Models without smart entry system

Models with smart entry system

LED

Unlock Button

Lock Button

Unlock Button

LED

Lock Button

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

132

Co
ntrols

Unlocking the doors and tailgate

Press the unlock button.
Once:

u

Some exterior lights flash twice, and the driver’s door unlocks.

Twice:

u

The remaining doors and tailgate unlock.

1

Using the Remote Transmitter

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

Replacing the Button Battery P. 534

You can customize the door lock mode and keyless
lock acknowledgement setting.

Customized Features P. 111

Models with multi-information display

* Not available on all models

Continued

133

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

If the smart entry remote battery

*

, remote transmitter

*

 or the vehicle battery is dead,

use the key instead of the smart entry remote

*

 or remote transmitter

*

Fully insert the key and turn it.

Locking/Unlocking the Doors Using a Key

1

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors and tailgate lock at the same time. When
unlocking, the driver’s door unlocks first. Turn the
key a second time within a few seconds to unlock the
remaining doors and the tailgate.

You can customize the door unlock mode setting.

Customized Features P. 111

Models with multi-information display

Lock

Unlock

* Not available on all models

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

134

Co
ntrols

Locking the driver’s door

Push the lock tab forward

a

 or push the

master door lock switch in the lock direction

b

, and close the door.

Locking the passengers’ doors

Push the lock tab forward and close the door.

Lockout prevention system

The doors and the tailgate cannot be locked when the key is in the ignition switch.

The doors and the tailgate cannot be locked when the smart entry remote is inside
the vehicle.

Locking a Door Without Using a Key

1

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
and tailgate lock at the same time.
Make sure you have the key in your hand when you
lock the driver's door, any of the other doors or the
tailgate, otherwise you may end up locking the key
inside the vehicle.

Models without smart entry system

Models with smart entry system

135

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Inside

Locking a door

Push the lock tab forward.

Unlocking a door

Pull the lock tab rearward.

Using the Lock Tab

1

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all the other doors and the tailgate lock
at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

136

Co
ntrols

Pull the front door inner handle.

u

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors.

To avoid all the doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door. This setting works for one time only.

u

If you do not want all the doors to be unlocked all the time, customize the
Auto Door Unlock setting to Off using the master door lock switch, multi-
information display

*

, or audio/information screen

*

.

Auto Door Locking/Unlocking

*

 P. 139

Unlocking Using the Front Door Inner Handle

1

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

Childproof Door Locks P. 138

Inner Handle

Models with auto door locking/unlocking

* Not available on all models

137

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Press the master door lock switch in as shown
to lock or unlock all doors and the tailgate.

Using the Master Door Lock Switch

1

Using the Master Door Lock Switch

When you lock/unlock the driver’s door using the
master door lock switch, all the other doors and the
tailgate lock/unlock at the same time.

To Lock

To Unlock

Master Door
Lock Switch

138

uu

Locking and Unlocking the Doors

u

Childproof Door Locks

Co
ntrols

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

When opening the door

Open the door using the outside door handle.

Setting the Childproof Door Locks

1

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

Lock

Unlock

139

uu

Locking and Unlocking the Doors

u

Auto Door Locking/Unlocking

*

Co
ntrols

Auto Door Locking/Unlocking

*

Your vehicle locks or unlocks all doors automatically when a certain condition is met.

Drive lock mode

All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

Driver’s door open mode

All doors unlock when the driver’s door is opened.

Auto Door Locking

Auto Door Unlocking

1

Auto Door Locking/Unlocking

*

You can turn off or change to another auto door
locking/unlocking setting using the master door lock
switch.

Customizing the Auto Door Locking/

Unlocking Setting

*

 P. 140

You can turn off or change to another auto door
locking/unlocking setting using the multi-information
display.

Customized Features P. 111

Models with multi-information display

* Not available on all models

140

uu

Locking and Unlocking the Doors

u

Customizing the Auto Door Locking/Unlocking Setting

*

Co
ntrols

Customizing the Auto Door Locking/Unlocking Setting

*

You can customize the auto door locking/unlocking setting to your liking using the master door lock switch.

Auto door locking

Auto door unlocking

*1 : Default setting

List of the Auto Door Locking/Unlocking Customizable Options

Mode

Description

Drive Lock Mode

*1

All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

Off

The auto door locking is deactivated all the time.

Mode

Description

Driver’s Door Open
Unlock Mode

*1

All doors unlock when the driver’s door is opened.

Park Unlock Mode

All doors unlock when the transmission is put into

(

P with the brake pedal depressed.

Off

The auto door unlocking is deactivated all the time.

Continuously variable
transmission models

* Not available on all models

141

uu

Locking and Unlocking the Doors

u

Customizing the Auto Door Locking/Unlocking Setting

*

Continued

Co
ntrols

*1 : Default setting
*2 : Models without smart entry system
*3 : Models with smart entry system

Customizing Flow for Auto Door Locking Options

Steps

Drive Lock Mode

*1

Off

1

Apply the parking brake.

Move the shift lever to

(

P.

2

The driver’s door must be closed at this stage.

Open the driver’s door.

3

Turn the ignition switch to ON

(

w

*2

.

Push the ENGINE START/STOP button twice without depressing the brake pedal

*3

.

4

Move the shift lever out of

(

P with the brake pedal depressed.

5

Press and hold the front of the master door lock switch on the driver’s door. You will hear a click more than five seconds elapsed.
Release the switch.

6

Move the shift lever to

(

P.

Continuously variable transmission models

Continuously variable transmission models

Continuously variable transmission models

142

uu

Locking and Unlocking the Doors

u

Customizing the Auto Door Locking/Unlocking Setting

*

Co
ntrols

*1 : Default setting
*2 : Models without smart entry system
*3 : Models with smart entry system

Steps

Drive Lock Mode

*1

Off

7

Turn the ignition switch to OFF

(

0 within 20 seconds

*2

.

Push the ENGINE START/STOP button once without depressing the brake pedal

*3

.

u

Customization is completed.

u

All doors unlock and all turn signals blink three times.















Content   ..  7  8  9  10   ..
