368

uu

Customized Features

u

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.
*3:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

Info

Clock

Clock/
Wallpaper
Type

*2

/

Clock
Type

*3

Clock

Changes the clock display type.

Analog/Digital

*1

/

Small Digital/Off

Wallpaper

●

Changes the wallpaper type.

●

Imports an image file for a new wallpaper.

●

Deletes an image file for a wallpaper.

Blank/Galaxy

*1

/

Metallic/Time Zone

Clock Adjustment

Adjusts Clock.

—

Auto Time Zone

*

Automatically adjusts the clock when driving
through different time zones.

On

*1

/Off

Manual Time Zone

*

Changes the time zone manually.

—

Auto Daylight Saving Time

Select On to have the GPS automatically adjust
the clock to daylight savings time. Select Off to
cancel this function.

On

*1

/Off

Clock Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

Clock Display

Selects whether the clock display comes on.

On

*1

/Off

Overlay Clock Location

Changes the clock display layout.

Upper Right

*1

/Upper

Left/Lower Right/
Lower Left/Off

Clock Reset

Resets the clock settings to the factory default.

Yes/No

* Not available on all models

369

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Info

HondaLink

Diagnostic &
Location Data

Turns HondaLink® on and off.

On

*1

/Off

Others

Info Screen
Preference

Selects the top menu when the

 (display/

information) button is pressed.

●

Info Top- A brief menu pops up.

●

Info Menu- A full menu pops up.

●

Off- A menu does not pop up.

Info Top/Info
Menu

*1

/Off

Default

Cancels/Resets all customized items in the Info settings
group as default.

Yes/No

Camera

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on the rear
camera monitor.

2 Multi-View Rear Camera P. 547

On

*1

/Off

Dynamic Guideline

Selects whether the guidelines adjust to the movement
of the steering wheel.

2 Multi-View Rear Camera P. 547

On

*1

/Off

Default

Cancels/Resets all customized items in the Rear Camera
setting group as default.

Yes/No

LaneWatch

*

Show with Turn
Signal

Selects whether the LaneWatch display comes on when
you move the turn signal lever to indicate a right turn.

On

*1

/Off

Display Time after
Turn Signal Off

Changes the length of time the LaneWatch display stays
on after the turn signal lever returns to the center.

0 second

*1

/2 seconds

* Not available on all models

370

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera

LaneWatch

*

Reference Line

Selects whether the reference lines come on
the LaneWatch monitor.

On

*1

/Off

Default

Cancels/Resets all customized items in the
LaneWatch group as default.

Yes/No

Cross Traffic Monitor

*

Turns on and off the cross traffic monitor.

On

*1

/Off

Bluetooth /
Wi-Fi

Bluetooth

Bluetooth On/Off Status

Changes the Bluetooth® status.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone.

2 Phone Setup P. 418

—

Edit Pairing Code

Edits a pairing code.

2 To change the pairing code setting P. 419

Random/Fixed

*1

Wi-Fi

Wi-Fi On/Off Status

Changes the Wi-Fi mode.

On/Off

*1

Wi-Fi Device List

Connects, disconnects, or deletes the Wi-Fi
device.

—

Wi-Fi Information

Shows the Wi-Fi information of the head unit.

—

Default

Cancels/Resets all customized items in the
Bluetooth / Wi-Fi group as default.

Yes/No

* Not available on all models

371

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone

Phone

Bluetooth Device List

Pairs a new phone to HFL, connects or
disconnects a paired phone.

2 Phone Setup P. 418

—

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

2 Speed Dial P. 424

—

Ring Tone

Selects the ring tone.

Fixed/Mobile
Phone

*1

Automatic Phone Sync

Sets a phonebook and call history data to be
automatically imported when a phone is paired
to HFL.

On

*1

/Off

HondaLink Assist

Turns HondaLink Assist on and off.

On

*1

/Off

Text/Email

Enable Text/Email

Turns the text/e-mail message function on and
off.

On

*1

/Off

Select Account

Selects a text or e-mail message account.

—

New Message Notification

Selects whether a pop-up alert comes on the
screen when HFL receives a new text/e-mail
message.

On/Off

*1

Default

Cancels/Resets all customized items in the Phone
settings group as default.

Yes/No

372

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

FM/AM

HD Radio Mode (FM)

*

HD Radio Mode (AM)

*

Selects whether the audio system automatically
switches to the digital radio waves or receives
the analog waves only.

Auto

*1

/Analog only

RDS INFO

Turns on and off the RDS information.

On

*1

/Off

SXM

*

TuneStart

Turns on and off, starts the song from the
beginning as you change preset stations.

On

*1

/Off

SportsFlash
Setup

Interrupt

Turns on and off the sports alert function.

Off

*1

/On(One Time)/

On(Continue)

Favorite
Team

Selects your favorite sports teams.

2 Live Sports Alert P. 298

—

Interrupt
Beep

Causes the system to beep when the sports alert
is notified.

On

*1

/Off

Traffic & Weather Setup

Selects the region you want to receive the
information.

—

Multiple Channel Mix
Preset

Turns multiple channel mix preset on and off.

On

*1

/Off

FM/AM mode

SiriusXM® mode

* Not available on all models

373

uu

Customized Features

u

Continued

Features

*1:Default Setting
*2:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

Bluetooth

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone.

2 Phone Setup P. 418

—

Other

[Your selected media]
Cover Art

Turns the cover art display on and off.

On

*1

/Off

Audio Source Pop-Up

Selects whether the list of selectable audio source
comes on when Audio is selected on the home
screen.

On/Off

*1

Default

Cancels/Resets all customized items in the Audio
settings group as default.

Yes/No

System

Home

Home Screen Edit Order

Changes the home screen icon layout.

—

Menu Icon Position

*2

Changes the position of the menu icons on the
Audio, Phone, and Info screen.

—

Configuration of
Instrument Panel

Changes the Instrument Panel screen icon
layout.

—

Tachometer Setting

Turns on and off the tachometer display.

On

*1

/Off

Bluetooth® mode

iPod or USB mode

374

uu

Customized Features

u

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Display

Display
Settings

Brightness

Changes the brightness of the audio/information
screen.

—

Contrast

Changes the contrast of the audio/information
screen.

—

Black Level

Changes the black level of the audio/information
screen.

—

Background Color

*2

Changes the background color of the audio/
information screen.

Blue/Amber/Red/
Violet/BlueGreen

*1

Touch Panel Sensitivity

Sets the sensitivity of the touch panel screen.

High/Low

*1

Sound/
Beep

Guidance Volume

Changes the sound volume.
Adjusts the guidance volume of the navigation
system.

1~6

*1

~11

Text Message Volume

Changes the text/e-mail message reading
volume.

1~6

*1

~11

375

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Sound/
Beep

Voice Recog. Volume

Changes the volume of the voice prompt.

1~6

*1

~11

Meter Volume - List
Reading

Changes the list reading volume.

1~6

*1

~11

Meter Volume -
Alphabetic Reading

Changes the alphabetic reading volume.

1~6

*1

~11

Verbal Reminder

Turns the verbal reminders on and off.

On

*1

/Off

Beep Volume

Changes the beep volume.

Off/1/2

*1

/3

Voice
Recog.

One Press Voice
Operation

Changes the setting of the

 (Talk) button operation when

using the voice operation.

On

*1

/Off

Voice Prompt

Turns the voice prompt on and off.

On

*1

/Off

Voice Recog. Volume

Changes the volume of the voice prompt.

1~6

*1

~11

Song by Voice

Turns the Song By Voice

TM

 on and off.

On

*1

/Off

Song by Voice
Phonetic Modification

Modifies a voice command for music stored in the system or

an iPod/iPhone.

2 Phonetic Modification P. 305

—

Phonebook Phonetic
Modification

Modifies a voice command for the phonebook.

2 Phonetic Modification P. 305

—

Automatic Phone Sync

Sets phonebook and call history data to be automatically

imported when a phone is paired to HFL.

On/Off

376

uu

Customized Features

u

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.
*3:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Clock

Clock/Wallpaper
Type

*2

/Clock

Type

*3

Clock

See

Info

 on P. 368

Wallpaper

Clock Adjustment

Auto Time Zone

*

Manual Time Zone

*

Auto Daylight Saving Time

Clock Format

Clock Display

Overlay Clock Location

Clock Reset

Others

Language

Change the display language.

English (United
States)

*1

/Français/

Español

* Not available on all models

377

uu

Customized Features

u

Continued

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Others

Voice Command Tips

Alerts you when manual control of the system is
disabled to prevent distraction while driving.
Only voice commands are available.

On

*1

/Off

Remember Last Screen

*2

Selects whether the device remembers the last
screen.

On/Off

*1

Memory Refresh

Turns on the audio system automatically and restores
the fragmentation of a memory when the power
mode is VEHICLE OFF (LOCK).

On

*1

/Off

Refresh Time Adjustment

Sets the time for Memory Refresh. —

Swipe Direction

Sets the vertical swipe direction on the audio remote
controls.

Normal

*1

/Invert

4way Switch Gesture

Turns the vertical swipe direction on the audio
remote controls on or off.

On

*1

/Off

Volume Gestures

Turns the volume swipe direction on the audio
remote controls on or off.

On

*1

/Off

Change Skin

Changes the screen interface design.

Yes/No

Factory Data Reset

Resets all the settings to their factory default.

2 Defaulting All the Settings P. 383

Yes/No

378

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Others

Climate Screen
Timeout

Changes the length of time the climate control display
stays on when you press the CLIMATE button.

Never/5 Seconds/10
Seconds

*1

/20 Seconds

Detail Information

Displays the details of the head unit and operating
system information.

—

Default

Cancels /Resets all customized items in the System
group as default.

Yes/No

Vehicle

TPMS Calibration

Cancels/Calibrates the tire pressure monitoring system
(TPMS).

Cancel

*1

/Calibrate

Driver
Assist
System
Setup

*

Forward Collision
Warning Distance

Changes CMBS

TM

 alert distance.

Long/Normal

*1

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of the ACC range.

On/Off

*1

Blind Spot Info

Changes the setting for the blind spot information.

Audible and Visual
Alert

*1

/Visual Alert/Off

Lane Keeping Assist
Suspend Beep

Causes the system to beep when LKAS is suspended.

On/Off

*1

Road Departure
Mitigation Setting

Changes the setting for the road departure mitigation
system.

Normal

*1

/Wide/Warning

Only

Driver Attention
Monitor

Changes the setting for the driver attention monitor.

Tactile And Audible
Alert

*1

/Tactile Alert/OFF

* Not available on all models

379

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Meter
Setup

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A
and average fuel economy A.

When Refueled/IGN Off/
Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B
and average fuel economy B.

When Refueled/IGN Off/
Manually Reset

*1

Adjust Alarm Volume

Changes the alarm volume, such as buzzers,
warnings, turn signal sound, and so on.

High/Mid

*1

/Low

Fuel Efficiency Backlight

Turns the ambient meter feature on and off.

On

*1

/Off

Turn By Turn Auto
Display

Selects whether the turn-by-turn display comes on
during the route guidance.

On

*1

/Off

New Message
Notifications

Used to select whether a pop-up alert comes on the
screen when HFL receives a new text/e-mail message.

On

*1

/Off

Speed/Distance Units

Selects the trip computer units.

mph · miles

*1

/km/h · km

(U.S.)
km/h · km

*1

/mph · miles

(Canada)

Tachometer

Selects whether the tachometer come on the driver
information interface.

On

*1

/Off

380

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Driving
Position
Setup

*

Memory Position Link

Turns the driving position memory system on and
off.

On

*1

/Off

Keyless
Access
Setup

*

Remote Start System
On/Off

Turns the remote engine start feature on and off.

On

*1

/Off

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/All

Doors

Keyless Access Light
Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

On

*1

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/lock
the doors.

On

*1

/Off

Lighting
Setup

Interior Light
Dimming Time

Changes the length of time the interior lights stay
on after you close the doors.

60seconds/30seconds

*1

/

15seconds

Headlight Auto Off
Timer

Changes the length of time the exterior lights stay
on after you close the driver’s door.

60seconds/30seconds/
15seconds

*1

/0seconds

Auto Light Sensitivity

Changes the timing for the headlights to come on.

Max/High/Mid

*1

/Low/Min

Auto Interior
Illumination
Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in
the AUTO position.

Min/Low/Mid

*1

/High/Max

* Not available on all models

381

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Lighting
Setup

Auto Headlight ON
With Wiper ON

Changes the settings for the wiper operation
when the headlights automatically come on while
the headlight switch is in the AUTO position.

On

*1

/Off

Door/
Window
Setup

Auto Door Lock

Used to change the setting for when the doors
automatically lock.

With Vehicle Speed

*1

/Shift

from P/Off

Auto Door Unlock

Changes the setting for when the doors unlock
automatically.

All Doors When Driver’s
Door Opens

*1

/All Doors

When Shifted to Park/All
Doors When Ignition
Switched Off/Off

Key and Remote
Unlock Mode

Sets up the driver’s door or all the doors to unlock
on the first push of the remote.

Driver Door

*1

/All Doors

Keyless Lock Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/Off

Security Relock
Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening any door.

90seconds/60seconds/
30seconds

*1

Walk Away Auto
Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

On/Off

*1

382

uu

Customized Features

u

Features

Setup Group

Customizable Features

Description

Selectable Settings

Vehicle

Power
Tailgate
Setup

*

Hands-free Access
Mode

Changes the setting to open power tailgate by a
swift forward in and out kicking motion under
the rear bumper.

On

*1

/Off

Keyless Open Mode

Changes the keyless setting for when the power
tailgate opens.

Anytime

*1

/When

Unlocked

Power Open By Outer
Handle

Changes the setting to open power tailgate by
tailgate outer handle.

Off (Manual only)/
On (Power/
Manual)

*1

Maintenance Info.

Used to reset the engine oil life display when the
maintenance service has been performed.

—

Default

Cancels/Resets all customized items in the Vehicle
settings group as default.

Yes/No

Smartphone

Apple CarPlay

Sets up the Apple CarPlay

TM

 connection.

—

Android Auto

Sets up the Android Auto

TM

 connection.

—

* Not available on all models

383

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Select .
2. Select Settings.
3. Select System.
4. Select the Others tab.
5. Select Factory Data Reset.

u

A confirmation message appears on the
screen.

6. Select Next, then select Yes to reset the

settings.

7. Select Yes again to reset the settings.

u

A confirmation message appears on the
screen. Select OK.

u

After selecting OK, the system will
reboot.

Models with Display Audio

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform Factory Data Reset, it will reset the
preinstalled apps to their factory default.

If you perform Factory Data Reset, you cannot use
the HondaLink® because it becomes off line.

2 HondaLink® P. 314
