Honda CR-V (2018 year). Manual

Gauges and Displays

Driver Information Interface

128

strum

nt Pa

nel

■

For the Driver Attention Monitor to function

• the vehicle must be traveling above 25 mph (40 km/h).
• the electric power steering (EPS) system indicator must be off.

■

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances.

• the steering assist function of the Lane Keeping Assist System (LKAS)

is active.

2 Lane Keeping Assist System (LKAS)

P. 501

• the condition of the road is poor, e.g. the surface is unpaved or bumpy.
• it is windy.
• the driver is frequently operating the vehicle in an assertive manner such as

changing lanes or accelerating.

■

Customizing

You can change the Driver Attention Monitor settings. Select Tactile And Audible
Alert, Tactile Alert, or OFF.

2 Customized Features P. 351

For the Driver Attention Monitor to function

The bars in the Driver Information Interface remain
grayed out unless the Driver Attention Monitor is
functioning.

* Not available on all models

Continued

129

Gauges and Displays

Driver Information Interface

strum

nt Pa

nel

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■

Adjusting the outside temperature display

Adjust the temperature reading up to ±5°F or ±3°C if the temperature reading
seems incorrect.
Use the driver information interface's

or audio/information display's

customized

features to correct the temperature.

2 Customized Features P. 351

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

The indicators on the display show the
amount of torque being transferred to the
right front, left front, right rear, and left rear
wheels.

2 Real Time AWD with Intelligent Control

System

P. 517

■

Outside Temperature

■

Instant Fuel Economy

■

AWD Torque Distribution Monitor

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

* Not available on all models

Gauges and Displays

Driver Information Interface

130

strum

nt Pa

nel

Shows you turn-by-turn driving directions to your destination linked with the
navigation system.

2 Refer to the Navigation System Manual

Show the current audio information.

2 Audio System Basic Operation P. 260

Show the current phone information.

2 Bluetooth® HandsFreeLink® P. 387

■

Turn-by-Turn Directions

■

Audio

■

Phone

Turn-by-Turn Directions

The driver information interface shows a compass
when the route guidance is not used.

You can select whether the turn-by-turn display
comes on during the route guidance.

2 Customized Features P. 351

* Not available on all models

132

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the ignition switch in ON

(

■

Using the MENU/CLOCK button

1. Press and hold the MENU/CLOCK button.

Adjust Clock is selected.

2. Rotate

to change hour, then press

3. Rotate

to change minute, then press

4. To enter the selection, rotate

and select

Set, then press

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Adjusting the Time

Adjusting the Clock

The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 351

Models with navigation system

Models with color audio system

Models without navigation system

Using the MENU/CLOCK button

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

Models with color audio system

133

Clock

Adjusting the Clock

Co
ntrols

■

Using the Settings menu on the audio/
information screen

1. Select Settings.
2. Select Clock.
3. Select Clock Adjustment.
4. Select

change

hour.

5. Select

to change minute, then

select OK.

Models with Display Audio

Using the Settings menu on the audio/information screen

You can customize the clock display to show the 12
hour clock or 24 hour clock and turn the clock display
on and off.

2 Customized Features P. 351

The clock is automatically updated when your
smartphone is connected to the audio system.
You can also adjust the clock by touching the clock
displayed on the upper right corner of the display.
1. Touch the clock on the display for a few seconds.
2. Select Clock Adjustment.
3. Select

to change hour.

4. Select

to change minute, then select OK.

Models with Display Audio

134

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the key to start and stop the engine, and to lock and unlock the doors and
tailgate. You can also lock and unlock the doors and tailgate pressing the buttons
on remote transmitter.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.
To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

■

Keys

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps protect against vehicle
theft.

2 Immobilizer System P. 161

The keys contain precision electronics.
Adhere to the following advice to prevent damage to
the electronics:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the one-way
smart entry remote.

2 Remote Engine Start with Vehicle

Feedback

P. 464

Models with remote engine starter

■

Built-in Key

Smart Entry Remote

Ignition Keys with Remote
Transmitter

Built-in Key

Release Knob

* Not available on all models

135

Locking and Unlocking the Doors

Key Types and Functions

Co
ntrols

Can be used to start and stop the engine, and
lock and unlock driver's door.

Contains a number that you will need if you
purchase a replacement key.

■

Valet Key

Valet Key

When you need to leave a key with a third party,
leave the valet key.

Gray

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

* Not available on all models

136

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors, opening the tailgate, or to start the engine.

In the following cases, locking/unlocking the doors, opening the tailgate, or starting
the engine may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

137

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and open the
tailgate.
You can lock/unlock the doors within a radius
of about 32 inches (80 cm) of the outside door
handle. You can open the tailgate within
about 32 inches (80 cm) radius from the
tailgate release button.

■

Locking the doors and tailgate

Touch the door lock sensor on the front door
or press the lock button on the tailgate.

Some exterior lights flash; the beeper
sounds; all the doors and tailgate lock;
and the security system sets.

■

Using the Smart Entry with Push Button Start System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors and tailgate.
No doors opened: The light fades out after 30
seconds.
Doors and tailgate relocked: The light goes off
immediately.

2 Interior Lights P. 207

Using the Smart Entry with Push Button Start System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the smart entry
system, the doors and tailgate will automatically
relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

Door Lock
Sensor

Lock Button

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

138

Co
ntrols

■

Locking the vehicle (Walk away auto
lock)

When you walk away from the vehicle while
carrying the smart entry remote, the doors will
automatically lock.
The auto lock function activates when all
doors are closed, and the smart entry remote
is within about 5 feet (1.5 m) radius of the
outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).
1. While within about 5 feet (1.5 m) radius of

the vehicle.

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors will then lock.

Locking the vehicle (Walk away auto lock)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.

2 Customized Features P. 351

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the smart entry
remote will continue to flash until the doors are
locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be canceled.

When all doors have been closed and the smart entry
remote is inside the vehicle, or if the smart entry
remote is not detected within about 5 feet (1.5 m) of
the vehicle, auto lock function will not be activated.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Continued

139

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock

Unlock

Lock

Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• Walk away at least more than about 5 feet

(1.5 m) away from the vehicle while
carrying the smart entry remote.

Locking the vehicle (Walk away auto lock)

The auto lock function does not operate when any of
the following conditions are met.

•

The smart entry remote is inside the vehicle.

•

A door or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The smart entry remote is put inside the vehicle
through a window.

•

You are located too close to the vehicle.

•

The smart entry remote is put inside the tailgate.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

140

Co
ntrols

■

Unlocking the doors and tailgate

Grab the driver’s door handle:

The driver’s door unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and tailgate unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the tailgate release button:

The tailgate unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

2 Using the Tailgate Release Button

P. 159

Using the Smart Entry with Push Button Start System

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors and tailgate while
someone else with the remote is within range.

•

The door may be locked or unlocked if the door
handle is covered with water in heavy rain or in a
car wash if the smart entry remote is within range.

•

If you grip a front door handle or touch a door lock
sensor wearing gloves, the door sensor may be
slow to respond or may not respond by locking or
unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the smart
entry remote if it is above or below the outside
handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

•

The light flashes, and beeper sounds and unlock
settings can be customized on the audio/
information screen.

2 Customized Features P. 351

Release Button

* Not available on all models

Continued

141

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, all the doors
and tailgate lock, and the security system
sets.

Twice (within five seconds after the first
push):

The beeper sounds and verifies the
security system is set.

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, and the
driver's door unlocks.

Twice:

The remaining doors and tailgate unlock.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle with the remote
transmitter, the doors and tailgate will automatically
relock.

You can change the relock timer setting.

2 Customized Features P. 351

The remote transmitter will not work when:

•

The key is in the ignition switch.

•

The power mode is not in VEHICLE OFF.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote will not lock the vehicle when a door is
open.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 608

You can customize the door unlock mode setting.

2 Customized Features P. 351

Models with Display Audio

Ignition keys with remote transmitter

Models with smart entry remote

Models with Display Audio

LED

Unlock
Button

Lock
Button

Ignition keys with remote transmitter

Models with smart entry remote

LED

Unlock
Button

Lock
Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

142

Co
ntrols

If the smart entry remote battery or the vehicle battery is dead, use the key instead
of the smart entry remote.

Fully insert the key and turn it.

■

Locking/Unlocking the Doors Using a Key

Locking/Unlocking the Doors Using a Key

When you lock the driver's door with a key, all the
other doors and tailgate lock at the same time. When
unlocking, the driver's door unlocks first. Turn the
key a second time within a few seconds to unlock the
remaining doors and the tailgate.

You can customize the door unlock mode setting.

2 Customized Features P. 351

Unlocking the doors with the key causes the security
system to alarm. Always unlock the doors with the
remote transmitter.

Models with Display Audio

Lock

Unlock

143

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the driver's door

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Locking the passenger's doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors and tailgate cannot be locked when the key is in the ignition switch.

The doors and tailgate cannot be locked when the smart entry remote is inside the
vehicle.

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver's door, all the other doors
and tailgate lock at the same time.
Make sure you have the key in your hand when you
lock the driver's door, any of the other doors or the
tailgate, otherwise you may end up locking the key
inside the vehicle.

Ignition keys with remote transmitter

Models with smart entry remote

Honda CR-V (2018 year). Manual - part 9
