Honda CR-V (2018 year). Manual - part 7





96

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Road Departure
Mitigation (RDM)
Indicator

*

Comes on when the RDM system
shuts itself off.

- Indicator may come on temporarily when

passing through an enclosed space, such as
tunnel.

- The area around the radar sensor is

blocked by dirt, mud, etc. Stop your vehicle
in a safe place, and wipe it off with a soft
cloth.

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the radar sensor.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 532

Comes on when the RDM system
shuts itself off.

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera

*

 P. 479

* Not available on all models

97

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Road Departure
Mitigation
(RDM) Indicator

*

Comes on when the RDM system
shuts itself off.

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

Front Sensor Camera

*

 P. 479

* Not available on all models

98

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Adaptive Cruise
Control (ACC
with Low Speed
Follow (LSF)
Indicator
(Amber)

*

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

Comes on if there is a problem
with ACC with LSF.

Comes on while driving - Have your
vehicle checked by a dealer.

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

ACC with LSF has been
automatically canceled.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 451

Stays on constantly - Have your vehicle
checked by a dealer.

Comes on if anything covers the
radar sensor cover and prevents
the sensor from detecting a
vehicle in front.

May come on when driving in bad
weather (rain, snow, fog, etc.)

ACC with LSF has been
automatically canceled.

When the radar sensor gets dirty, stop
your vehicle in a safe place, and wipe off
dirt using a soft cloth.

Have your vehicle checked by a dealer if
the indicator does not go off even after
you clean the sensor cover.

Comes on if the ACC with LSF is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

* Not available on all models

99

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Adaptive Cruise
Control (ACC
with Low Speed
Follow (LSF)
Indicator
(Green)

*

Comes on when you press the
MAIN button.

Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF)

*

 P. 481

Comes on when ACC with LSF is
in operation, but the temperature
inside the front sensor camera is
too high. ACC with LSF cancels
automatically. The beeper sounds
simultaneously.

Use the climate control system to cool
down the camera.

Goes off - The camera has been cooled
down. Pressing the MAIN button can
resume the system.

Front Sensor Camera

*

 P. 479

Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF)

*

 P. 481

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

*

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

Comes on if there is a problem
with the LKAS.

Stays on constantly - Have your vehicle
checked by a dealer.

* Not available on all models

100

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Lane Keeping
Assist System
(LKAS) Indicator
(Green)

*

Comes on when you press the
MAIN button.

Lane Keeping Assist System (LKAS)

*



P. 501

Comes on when the LKAS is in
operation, or the LKAS button is
pressed, but the temperature
inside the front sensor camera is
too high. The LKAS cancels
automatically. The beeper sounds
simultaneously.

Use the climate control system to cool
down the camera.

Goes off - The camera has cooled down
and the system is working normally.

Front Sensor Camera

*

 P. 479

Comes on when the area around
the camera is blocked by dirt,
mud, etc. Stop your vehicle in a
safe place, and wipe it off with a
soft cloth.

May come on when driving in bad
weather (rain, snow, fog, etc.)

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

* Not available on all models

101

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

Comes on when you deactivate
the CMBS

TM

. A driver information

interface message appears for five
seconds.

Comes on if there is a problem
with the CMBS

TM

.

Stays on constantly without the
CMBS

TM

 off - Have your vehicle checked

by a dealer.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 532

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 451

Comes on if the CMBS

TM

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Comes on when the CMBS

TM



system shuts itself off.

Stays on  - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

Front Sensor Camera

*

 P. 479

Have your vehicle checked by a dealer if
the indicator does not go off even after
you cleaned the camera.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 532

* Not available on all models

102

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

Comes on when the CMBS

TM



system shuts itself off.

Stays on - The temperature inside the
camera is too high. Use the climate control
system to cool down the camera. The
system activates when the temperature
inside the camera cools down.

Front Sensor Camera

*

 P. 479

Indicator may come on temporarily when
passing through an enclosed space, such
as tunnel.

- The area around the radar sensor is blocked

by dirt, mud, etc. Stop your vehicle in a safe
place, and wipe it off with a soft cloth.

Have your vehicle checked by a dealer if
the indicator does not go off even after
you clean the sensor cover.

Collision Mitigation Braking

System

TM

 (CMBS

TM

)

*

 P. 532

* Not available on all models

103

uu

Indicators

u

Information Display Warning and Information Messages

*

In

strum

e

nt Pa

nel

Information Display Warning and Information Messages

*

The following messages appear only on the information display.

Message

Condition

Explanation

Appears when there is a problem with the sensor on
the battery.

Stays on constantly - Have your vehicle checked by a
dealer.

* Not available on all models

104

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

*

The following messages appear only on the driver information interface. Press the

 (display/information) button to see the message

again with the system message indicator on.

Message

Condition

Explanation

Appears if any door or the tailgate is not completely
closed.

Appears if any door or the tailgate is opened while
driving. The beeper sounds.

Goes off when all doors and the tailgate are closed.

Appears if there is a problem with the shutter grill,
and the radiator coolant temperature is too high.

Power output will be reduced, so you may not be able to
accelerate or maintain your current speed. Have your
vehicle checked by a dealer.

Appears when the washer fluid gets low.

Refill the washer fluid.

Refilling Window Washer Fluid P. 585

Appears when the scheduled maintenance is due
soon.

Consequently, Maintenance Due Now and
Maintenance Past Due follow.

Maintenance Minder Messages on the Driver

Information Interface P. 565

Canadian models

* Not available on all models

105

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Message

Condition

Explanation

Appears when the engine coolant temperature gets
abnormally high.

Overheating P. 633

Appears when you turn the ignition switch to ON

(

w

*1

 without fastening the driver's seat belt.

Fasten the seat belt properly before you start to drive.

Appears when there is a problem with the sensor on
the battery.

Have your vehicle checked by a dealer.

Checking the Battery P. 606

Appears along with the battery charging system
indicator when the battery is not charging.

Turn off the climate control system and rear defogger to
reduce electricity consumption.

If the Charging System Indicator Comes On P. 637

Appears if the automatic brake hold is automatically
canceled while it is in operation.

Immediately depress the brake pedal.

Appears when the automatic brake hold system is
turned off.

Automatic Brake Hold P. 528

Appears when the automatic brake hold button is
pressed without wearing the driver’s seat belt.

Fasten the driver’s seat belt.

Automatic Brake Hold P. 528

Appears when the automatic brake hold button is
pressed without depressing the brake pedal while
the automatic brake hold is in operation.

Press the automatic brake hold button with the brake
pedal depressed.

Automatic Brake Hold P. 528

106

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the parking brake is applied
automatically while it is in operation.

Automatic Brake Hold P. 528
Parking Brake P. 524

Appears when the electric parking brake switch is
pressed without depressing the brake pedal while
the electric parking brake is in operation.

Appears while driving - Press the electric parking
brake switch with the brake pedal depressed.

Parking Brake P. 524

Appears if there is something wrong with the vehicle
while you are driving.

Immediately stop in a safe place.

Have your vehicle checked by a dealer.

Appears if the shift position cannot be changed to

(

P due to a problem with the vehicle.

Apply the parking brake once you have stopped.

Parking Brake P. 524

Have your vehicle checked by a dealer.

107

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when you open the driver’s door while the
ignition key is in ACCESSORY

(

q.

Turn the ignition switch to LOCK

(

0, then remove the

key.

Appears when the ignition key is turned to
ACCESSORY

(

q from ON

(

w. (The driver's door is

closed.)

Appears when you open the driver’s door while the
ignition key is in LOCK

(

0.

Remove the key from the ignition switch.

Message

Condition

Explanation

Appears after you set the power mode to
ACCESSORY or ON.

Starting the Engine P. 462

Appears when the steering wheel is locked.

Move the steering wheel left and right while pressing the
ENGINE START/STOP button.

Models without smart entry system

Models with smart entry system

108

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if you push the ENGINE START/STOP
button to turn the engine off without the shift lever
in

(

P.

Move the shift lever to

(

P. The power mode changes to

VEHICLE OFF.

Move the shift lever to

(

P, then press the ENGINE

START/STOP button twice.

Appears if you push the ENGINE START/STOP
button and the parking brake is not activated or the
shift lever is in

(

N position.

Move the shift lever to

(

P position and start the engine.

Appears when the power mode is in ACCESSORY.

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

Press the ENGINE START/STOP button twice with your
foot off the brake pedal to change the power mode to
VEHICLE OFF (LOCK).

Appears when you close the door with the power
mode in ON without the smart entry remote inside
the vehicle.

Disappears when you bring the smart entry remote back
inside the vehicle and close the door.

Smart Entry Remote Reminder P. 174

Appears when the smart entry remote battery
becomes weak.

Replace the battery as soon as possible.

Replacing the Button Battery P. 608

U.S. models

Canadian models

109

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if the smart entry remote battery is too
weak to start the engine or the key is not within
operating range to start the engine.
A beeper sounds six times.

Bring the smart entry remote in front of the ENGINE
START/STOP
 button to be touched with.

If the Smart Entry Remote Battery is Weak P. 627

Appears when the starter system has a problem.

As a temporary measure, press and hold the ENGINE
START/STOP
 button for up to 15 seconds while pressing
the brake pedal and manually start the engine.
Have your vehicle checked by a dealer.

Appears as soon as a problem is detected in the
smart entry system or push button starting system.

Appears constantly - Have your vehicle checked by a
dealer.

Appears if the vehicle is being driven in a manner
consistent with drowsy or inattentive driving.

Driver Attention Monitor P. 126

U.S.

Canada

110

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if there is a problem with the light control
system.

Appears while driving - Manually turn the lights on,
and have your vehicle checked by a dealer.

Appears if there is a problem with the headlights.

Appears while driving - The headlights may not be on.
When conditions allow you to drive safely, have your
vehicle checked by a dealer as soon as possible.

Models with LED headlight

111

uu

Indicators

u

Driver Information Interface Warning and Information Messages

*

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when ACC with LSF has been
automatically canceled.

You can resume the set speed after the condition that
caused ACC with LSF to cancel improves. Press the RES/
+
 button.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 481

Appears when the distance between your vehicle
and the vehicle ahead of you is too close while ACC
with LSF is in operation.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 481

Appears when pressing the –/SET button while the
distance between your vehicle and the vehicle
ahead of you is too close.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 481

Appears when the driver’s seat belt is unfastened
while your vehicle is automatically stopped by ACC
with LSF.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 481

Appears when pressing the –/SET button while the
driver’s seat belt is unfastened.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 481

Models with ACC with LSF

* Not available on all models















Content   ..  5  6  7  8   ..
