Honda Civic (2019 year). Manual - part 7





96

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Message

Condition

Explanation

Appears when the engine coolant temperature gets
abnormally high.

Overheating P. 635

Appears when you turn the ignition switch to ON

(

w

*1

 without fastening the driver’s seat belt.

Fasten the seat belt properly before you start to drive.

Appears if the automatic brake hold is automatically
canceled while it is in operation.

Immediately depress the brake pedal.

Appears when the automatic brake hold system is
turned off.

Automatic Brake Hold P. 532

Continuously
variable
transmission models

Manual
transmission
models

97

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the automatic brake hold button is
pressed without wearing the driver’s seat belt.

Fasten the driver’s seat belt.

Automatic Brake Hold P. 532

Appears when the automatic brake hold button is
pressed without depressing the brake pedal while
the automatic brake hold is in operation.

Press the automatic brake hold button with the brake
pedal depressed.

Automatic Brake Hold P. 532

Appears when the parking brake is applied
automatically while it is in operation.

Automatic Brake Hold P. 532
Parking Brake P. 529

Continuously
variable
transmission models

Manual
transmission
models

98

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the electric parking brake switch is

pressed without depressing the brake pedal while
the electric parking brake is in operation.

• Press the electric parking brake switch with the brake

pedal depressed.

Parking Brake P. 529

Message

Condition

Explanation

Appears when you open the driver’s door while the
ignition key is in ACCESSORY

(

q.

• Turn the ignition switch to LOCK

(

0, then remove the

key.

• Appears when the ignition key is turned to

ACCESSORY

(

q from ON

(

w. (The driver’s door is

closed.)

• Appears when you open the driver’s door while the

ignition key is in LOCK

(

0.

• Remove the key from the ignition switch.

Continuously
variable
transmission models

Manual
transmission
models

Models without smart entry system

99

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears after you set the power mode to
ACCESSORY or ON.

Starting the Engine P. 437

Appears when the steering wheel is locked.

Move the steering wheel left and right while pressing the
ENGINE START/STOP button.

Models with smart entry system

Continuously
variable
transmission
models

Manual
transmission
models

Except U.S.
models with
continuously
variable
transmission

100

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if you push the ENGINE START/STOP
button to turn the engine off without the shift lever
in

(

P.

Move the shift lever to

(

P. The power mode changes to

VEHICLE OFF.

Move the shift lever to

(

P, then press the ENGINE

START/STOP button twice.

Appears when the power mode is in ACCESSORY.

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

Change the power mode to VEHICLE OFF.

ENGINE START/STOP Button P. 161

Appears when you close the door with the power
mode in ON without the smart entry remote inside
the vehicle.

Disappears when you bring the smart entry remote back
inside the vehicle and close the door.

Smart Entry Remote Reminder P. 163

Appears when the smart entry remote battery
becomes weak.

Replace the battery as soon as possible.

Replacing the Button Battery P. 596

Appears if the smart entry remote battery is too
weak to start the engine or the key is not within
operating range to start the engine.
A beeper sounds six times.

Bring the smart entry remote in front of the ENGINE
START/STOP
 button to be touched with.

If the Smart Entry Remote Battery is Weak P. 629

Models with smart entry system

Continuously
variable
transmission
models

U.S. models

Canadian models

101

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the starter system has a problem.

• As a temporary measure, press and hold the ENGINE

START/STOP button for up to 15 seconds while
pressing the brake pedal and clutch pedal (manual
transmission only), and manually start the engine.
Have your vehicle checked by a dealer.

• Appears as soon as a problem is detected in the

smart entry system or push button starting system.

• Appears constantly - Have your vehicle checked by a

dealer.

Message

Condition

Explanation

• Appears if there is a problem with the headlights.

• Appears while driving - The headlights may not be

on. When conditions allow you to drive safely, have your
vehicle checked by a dealer as soon as possible.

Models with smart entry system

U.S.

Canada

Models with LED headlights

102

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when ACC with LSF

*

 has been

automatically canceled.

You can resume the set speed after the condition that
caused ACC with LSF

*

 to cancel improves. Press the RES/

+ button.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when the distance between your vehicle
and the vehicle ahead of you is too close while ACC
with LSF

*

 is in operation.

ACC with LSF

*

 has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when pressing the –/SET button while the
distance between your vehicle and the vehicle
ahead of you is too close.

ACC with LSF

*

 cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when the driver’s seat belt is unfastened
while your vehicle is automatically stopped by ACC
with LSF.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Appears when pressing the –/SET button while the
driver’s seat belt is unfastened.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Models with Honda Sensing®

* Not available on all models

103

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if the VSA® or traction control function
operates while ACC with LSF

*

 is in operation.

ACC with LSF

*

 has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when the vehicle in front of you starts
moving while your vehicle is stopped automatically
by ACC with LSF.

Either press the RES/+ button or –/SET button, or
depress the accelerator pedal.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Appears when the shift lever is moved into any
position other than

(

D or

(

S while ACC with LSF is

in operation.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Appears when pressing the –/SET button while the
shift lever is in any position other than

(

D or

(

S.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Models with Honda Sensing®

* Not available on all models

104

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the vehicle is stopped on a very steep
slope while ACC with LSF is in operation.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Appears when pressing the –/SET button while the
vehicle is stopped on a very steep slope.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Models with Honda Sensing®

* Not available on all models

105

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when ACC with LSF

*

 is canceled due to

excessive high vehicle speed.

Reduce the speed, then reset ACC with LSF

*

.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when the speed of the vehicle is too high
for you to set ACC with LSF

*

.

Reduce the speed, then set ACC with LSF

*

.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when ACC is canceled due to excessive low
vehicle speed.

Raise the speed, then reset ACC.

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when the speed of the vehicle is too low for
you to set ACC.

Raise the speed, then set ACC.

Adaptive Cruise Control (ACC)

*

 P. 499

Models with Honda Sensing®

* Not available on all models

106

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the parking brake is applied
automatically while ACC with LSF is in operation.

ACC with LSF has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Parking Brake P. 529

Appears when pressing the –/SET button while the
parking brake is applied.

ACC with LSF cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Parking Brake P. 529

Appears when pressing the –/SET button while the
vehicle is moving and the brake pedal is depressed.

ACC with LSF

*

 cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Models with Honda Sensing®

Continuously
variable
transmission
models

Manual
transmission
models

* Not available on all models

107

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the clutch pedal is applied too long
while ACC is in operation.

ACC has been automatically canceled.

Adaptive Cruise Control (ACC)

*

 P. 499

Appears when pressing the –/SET button while the
vehicle is moving and the clutch pedal is depressed.

ACC cannot be set.

Adaptive Cruise Control (ACC)

*

 P. 499

Appears if ACC with LSF is canceled while your
vehicle is automatically stopped by ACC with LSF.

Immediately depress the brake pedal.

Flashes when the system senses a likely collision
with a vehicle in front of you.

Take the appropriate means to prevent a collision (apply
the brakes, change lanes, etc.)

Collision Mitigation Braking System

TM

 (CMBS

TM

)

P. 473

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

Models with Honda Sensing®

* Not available on all models

108

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the vehicle is driving out of a detected
line. The steering wheel vibrates rapidly.

Keep the vehicle within the lane you are driving.

Lane Keeping Assist System (LKAS) P. 514

Appears when the vehicle is driving out of a detected
lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected lane.

- The steering wheel vibrates rapidly when the

vehicle is drifting out of a detected line. The system
also steers the vehicle to help you remain within
your driving lane.

Keep the vehicle within the lane you are driving.

Road Departure Mitigation (RDM) System P. 522

You can change the setting for the road departure
mitigation system. NormalWide, and Warning Only
can be selected.

Customized Features P. 124, 337

Blinks when you fail to steer the vehicle. The beeper
sounds simultaneously.

Operate the steering wheel to resume the LKAS.

Appears when the LKAS is in operation, or the LKAS
button is pressed, but there is a problem with a
system related to the LKAS. The LKAS cancels
automatically. The beeper sounds simultaneously.

If any other system indicators come on, such as the VSA®,
ABS and brake system, take appropriate action.

Indicators P. 76

Models with Honda Sensing®

Lane Keeping Assist System (LKAS)

Road Departure Mitigation (RDM) System

When you selected Warning Only

When you selected Normal or Wide

109

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if anything covers the radar sensor cover

and prevents the sensor from detecting a vehicle in
front.

• May appear when driving in bad weather (rain,

snow, fog, etc.)

• When the radar sensor gets dirty, stop your vehicle in a

safe place, and wipe off dirt using a soft cloth.

• Have your vehicle checked by a dealer if the message

does not disappear even after you clean the sensor
cover.

Radar Sensor P. 528
Honda Sensing®

*

 P. 470

• Appears if the temperature inside the front sensor

camera is too high and some driver assist systems
cannot be activated.

• Use the climate control system to cool down the

camera.

• Disappears - The camera has been cooled down and

the systems are activated normally.

Front Sensor Camera P. 526
Honda Sensing®

*

 P. 470

Auto High-Beam

*

 P. 170

• Appears if the area around the front sensor camera

is blocked by dirt, mud, etc. and be prevented from
detecting a vehicle in front.

• May appear when driving in bad weather (rain,

snow, fog, etc.)

• When the front window gets dirty, stop your vehicle in

a safe place, and wipe it off with a soft cloth.

• Have your vehicle checked by a dealer if the message

does not disappear even after you cleaned the area
around the camera.

Front Sensor Camera P. 526
Honda Sensing®

*

 P. 470

Auto High-Beam

*

 P. 170

Models with Honda Sensing®

* Not available on all models

110

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if there is a problem with the auto high-

beam.

• Manually operate the headlight switch.
• If you are driving with the high beam headlights when

this happens, the headlights are changed to low beams.

Message

Condition

Explanation

• Appears when you unlock and open the driver’s

door while the engine is running by remote engine
start.

Remote Engine Start with Vehicle Feedback

*

 P. 439

Message

Condition

Explanation

• Appears if there is a problem with the adaptive

damper system.

• Have your vehicle checked by a dealer. With this message

appeared, your vehicle has normal damping ability
without the adaptive damper feature.

• Appears if the drive mode cannot be changed due

to certain situations, such as a system error or
adverse driving conditions.

SPORT Mode

*

 P. 453

Models with auto high-beam

Models with remote engine starter

Models with SPORT mode

* Not available on all models

111

Continued

In

strum

e

nt Pa

nel

Gauges and Driver Information Interface

Gauges

Gauges include the speedometer, tachometer, fuel gauge, and related indicators.
They are displayed when the ignition switch is in ON

(

w

*1

.

Displays your driving speed in mph or km/h.

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

Displays the temperature of the engine coolant.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Speedometer

Tachometer

Fuel Gauge

Temperature Gauge

1

Gauges

Press the

 (display/information) button

repeatedly until the

 icon is shown on the driver

information interface. Press ENTER, then press and
hold it again. The speedometer reading and the
displayed measurements will switch between mph
and km/h.

1

Tachometer

You can turn on or off the tachometer display.

Customized Features P. 124, 337

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

1

Temperature Gauge

NOTICE

Driving with the temperature gauge pointer in the
upper zone can cause serious engine damage. Pull
safely to the side of the road and allow engine
temperature to return to normal.

Overheating P. 635















Content   ..  5  6  7  8   ..
