80

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Shift Lever
Position
Indicator

*

Indicates the current shift lever
position.

Shifting P. 444, 446

Transmission
System
Indicator

*

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Blinks if the transmission system
has a problem.

Blinks while driving - Avoid sudden
starts and acceleration and have your
vehicle checked by a dealer immediately.

M (7-speed
manual shift
mode) Indicator/
Shift Indicator

*

Comes on when 7-speed manual
shift mode is applied.

7-Speed Manual Shift Mode P. 448

Shift Up
Indicator

*

Comes on when shifting up is
recommended.

Shift Up/Down Indicators

*

 P. 451

Shift Down
Indicator

*

Comes on when shifting down is
recommended.

Shift Up/Down Indicators

*

 P. 451

* Not available on all models

81

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

Comes on and the beeper sounds
if you are not wearing a seat belt
when you turn the ignition switch
to ON

(

w

*1

.

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

Blinks while driving if either you or
the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

Stays on after you or the front
passenger has fastened the seat belt
- A detection error may have occurred in
the sensor. Have your vehicle checked by
a dealer.

Seat Belt Reminder P. 40

82

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Low Fuel
Indicator

Comes on when the fuel reserve is
running low (approximately 1.8
U.S. gal/7.0 Liter left).

Blinks if there is a problem with the
fuel gauge.

Comes on - Refuel your vehicle as soon
as possible.

Blinks - Have your vehicle checked by a
dealer.

Anti-lock Brake
System (ABS
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

If it comes on at any other time,
there is a problem with the ABS.

Stays on constantly - Have your vehicle
checked by a dealer. With this indicator
on, your vehicle still has normal braking
ability but no anti-lock function.

Anti-lock Brake System (ABS) P. 535

Supplemental
Restraint System
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if a problem with any of
the following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

Stays on constantly or does not come
on at all
- Have your vehicle checked by
a dealer.

Auto High-Beam
Indicator

*

• Comes on when all the operating

conditions of the auto high-beam
are met.

Auto High-Beam

*

 P. 170

* Not available on all models

83

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist® (VSA®)
System Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Blinks when VSA® is active.

Comes on if there is a problem
with the VSA® system or hill start
assist system.

Stays on constantly - Have your vehicle
checked by a dealer.

Vehicle Stability Assist® (VSA®), aka

Electronic Stability Control (ESC),
System
 P. 459

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Vehicle Stability
Assist® (VSA®)
OFF Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on when you partially
disable VSA®.

VSA® On and Off P. 460

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

84

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Electric Power
Steering (EPS)
System Indicator

• Comes on when you turn the

ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

• Comes on if there is a problem

with the EPS system.

• Stays on constantly or does not come

on at all - Have your vehicle checked by
a dealer.

If the Electric Power Steering (EPS)

System Indicator Comes On P. 641

SPORT Mode
Indicator

*

• Comes on when you press the

SPORT button.

• The shift up backlight remains lit

up in red as long as SPORT mode
is on.

SPORT Mode

*

 P. 453

* Not available on all models

85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Low Tire
Pressure/TPMS
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

.

May come on briefly if the ignition
switch is turned to ON

(

w

*1

 and

the vehicle is not moved within 45
seconds, to indicate the calibration
process is not yet complete.

Comes on and stays on when:
- One or more tires’ pressures are

determined to be significantly
low.

- The system has not been

calibrated.

Comes on while driving - Stop in a safe
place, check tire pressures, and inflate the
tire(s) if necessary.

Stays on after the tires are inflated to
the recommended pressures
- The
system needs to be calibrated.

TPMS Calibration P. 463

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS, or when a compact
spare tire

*

 is temporarily installed.

Blinks and remains on - Have your
vehicle checked by a dealer. If the vehicle
is fitted with a compact spare, get your
regular tire repaired or replaced and put
back on your vehicle as soon as you can.

Comes on if the TPMS is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

U.S.
models

* Not available on all models

86

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

System Message
Indicator

• Comes on for a few seconds

when you turn the ignition switch
to ON

(

w

*1

, then goes off.

• Comes on along with a beep

when a problem is detected. A
system message on the driver
information interface appears at
the same time.

• While the indicator is on, press the



(display/information) button to see the
message again.

• Refer to the Indicators information in this

chapter when a system message appears
on the driver information interface. Take
the appropriate action for the message.

• The driver information interface does not

return to the normal screen unless the
warning is canceled, or the

 button

is pressed.

Turn Signal and
Hazard Warning
Indicators

• Blinks when you operate the turn

signal lever.

• Blink along with all turn signals when

you press the hazard warning button.

• Does not blink or blinks rapidly

Replacing Light Bulbs P. 576, 578, 579

High Beam
Indicator

• Comes on when the high beam

headlights are on.

Lights On
Indicator

• Comes on when the light switch

in a position other than OFF or
when the switch is set to AUTO

*



and the exterior lights come on.

• If you remove the key from the ignition

switch

*1

 while the exterior lights are on, a

chime sounds when the driver’s door is
opened.

Fog Light
Indicator

*

• Comes on when the fog lights are

on.

Fog Lights

*

 P. 169

* Not available on all models

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.
*2:Canadian models only: Apply and hold the brake pedal before turning the ignition on.
*3:Canadian models without smart entry system
*4:Canadian models with smart entry system
*5:Continuously variable transmission models
*6:Manual transmission models

Indicator

Name

On/Blinking

Explanation

Message

Immobilizer
System Indicator

• Blinks if the immobilizer system

cannot recognize the key
information.

• Blinks - You cannot start the engine.

Turn the ignition switch to LOCK

(

0

*1

pull the key out

*2

, and then insert the key

and turn it to ON

(

w

*1

 again.

Indicator

*3, *5

*3, *6

*3

*4, *5

*4, *6

*4, *5

*4, *6

88

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Immobilizer
System Indicator

• Blinks if the immobilizer system

cannot recognize the key
information.

Repeatedly blinks - The system may be
malfunctioning. Have your vehicle
checked by a dealer.

Do not attempt to alter this system or add
other devices to it. Electrical problems can
occur.

Security System
Alarm Indicator

• Blinks when the security system

alarm has been set.

Security System Alarm P. 153

ECON Mode
Indicator

*

Comes on when you press the
ECON button.

ECON Mode

*

 P. 454

CRUISE MAIN
Indicator

*

Comes on when you press the
CRUISE button.

Cruise Control* P. 456

CRUISE
CONTROL

Indicator

*

Comes on if you have set a speed
for cruise control.

Cruise Control* P. 456

Indicator

Indicator

* Not available on all models

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation (RDM)
Indicator

*

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

Comes on if there is a problem
with the RDM system.

Stays on constantly - Have your vehicle
checked by a dealer.

Comes on if the RDM is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

* Not available on all models

90

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation (RDM)
Indicator

*

Comes on when the RDM system
shuts itself off.

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera P. 526

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

Front Sensor Camera P. 526

Comes on if there is a problem
with the RDM system.

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 431

Stays on constantly - Have your vehicle
checked by a dealer.

* Not available on all models

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (ACC
with Low Speed
Follow (LSF)

*



Indicator
(Amber)

*

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if there is a problem
with ACC with LSF

*

.

Comes on while driving - Have your
vehicle checked by a dealer.

Comes on if the ACC with LSF

*

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Comes on if there is a problem
with ACC with LSF

*

.

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

ACC with LSF

*

 has been

automatically canceled.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 431

Stays on constantly - Have your vehicle
checked by a dealer.

Adaptive Cruise
Control (ACC
with Low Speed
Follow (LSF)

*



Indicator
(Green)

*

Comes on when you press the
MAIN button.

Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF)

*

 P. 483

Adaptive Cruise Control (ACC)

*

 P. 499

* Not available on all models

92

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

*

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

Comes on if there is a problem
with the LKAS.

Stays on constantly - Have your vehicle
checked by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(Green)

*

Comes on when you press the
MAIN button.

Lane Keeping Assist System (LKAS)

P. 514

* Not available on all models

93

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

• Comes on for a few seconds

when you turn the ignition switch
to ON

(

w

*1

, then goes off.

• Comes on when you deactivate

the CMBS

TM

. A driver information

interface message appears for five
seconds.

• Comes on if there is a problem

with the CMBS

TM

.

Stays on constantly without the
CMBS

TM

 off - Have your vehicle checked

by a dealer.

Collision Mitigation Braking

System

TM

 (CMBS

TM

) P. 473

• Comes on if the CMBS

TM

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

• Drive a short distance at more than 12

mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

* Not available on all models

94

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

Indicator

*

• Comes on when the CMBS

TM



shuts itself off.

• Stays on - The area around the camera is

blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

Front Sensor Camera P. 526

• When the radar sensor gets dirty, stop

your vehicle in a safe place, and wipe off
dirt using a soft cloth.

• Have your vehicle checked by a dealer if

the indicator does not go off even after
you clean the sensor cover.

Collision Mitigation Braking

System

TM

 (CMBS

TM

) P. 473

• Stays on - The temperature inside the

camera is too high. Use the climate control
system to cool down the camera. The
system activates when the temperature
inside the camera cools down.

Front Sensor Camera P. 526

Comes on if there is a problem
with the CMBS

TM

.

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit P. 431

Stays on constantly - Have your vehicle
checked by a dealer.

* Not available on all models

95

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

The following messages appear only on the driver information interface. Press the

 (display/information) button to see the message

again with the system message indicator on.

Message

Condition

Explanation

Appears if any door or the trunk is not completely
closed.

Appears if any door or the trunk is opened while
driving. The beeper sounds.

Goes off when all doors and the trunk are closed.

Appears when the washer fluid gets low.

Refill the washer fluid.

Refilling Window Washer Fluid P. 571

Appears when the scheduled maintenance is due
soon.

Consequently, Maintenance Due Now and
Maintenance Past Due follow.

Maintenance Minder Messages on the Driver

Information Interface P. 553

Appears when there is a problem with the sensor on
the battery.

Have your vehicle checked by a dealer.

Checking the Battery P. 594

Appears along with the battery charging system
indicator when the battery is not charging.

Turn off the climate control system and rear defogger to
reduce electricity consumption.

If the Charging System Indicator Comes On P. 637

Canadian models















Content   ..  4  5  6  7   ..
