Honda Civic Hybrid (2015 year). Manual - part 11





160

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Select Settings to go to the Settings

screen.

2. Select System.
3. Select the Display tab.
4. Select Display Settings.
5. Select the setting you want.
6. Select OK.

1. Select Settings to go to the Settings

screen.

2. Select System.
3. Select the Display tab.
4. Select Background Color.
5. Select the setting you want.
6. Select OK.

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

Changing the Screen’s Color Theme

161

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

*1:Some or all of the lists may not be displayed.



)

PLOHV

Audio/Information Screen

Tune Icons
Select

 or

 to tune the radio

frequency.

BACK
Select to go back to the previous display.

 (Power) Button

Press to turn the audio system
on and off.

Seek Icons
Select

 or

 to search up

and down the selected band for a
station with a strong signal.

MENU
Select to display the menu items.

VOL (Volume)
Select to adjust the volume.

Open/Close Icon

*1

Displays/hides the detailed
information.

Preset Icons
Tune the radio frequency for preset memory.
Select and hold the preset icon to store that station.
Select

 to display preset 7 onwards.

Scan
Select to scan each station with a strong signal.

uu

Audio System Basic Operation

u

Playing AM/FM Radio

162

Features

To store a station:
1. Tune to the selected station.
2. Select MENU.
3. Select Save Preset.
4. Select the preset number you want to store that station.

You can also store a preset station by the following procedure.
1. Select open/close icon to display a channel list.
2. Select Preset tab.
3. Press and hold the preset number for the station you want to store until you hear

a beep.

Provides text data information related to your selected RDS-capable FM station.

To find an RDS station from Station List

1. Select MENU while listening to an FM station.
2. Select Station List.
3. Select a station.

Manual update

Updates your available station list at any time.
1. Select MENU while listening to an FM station.
2. Select Station List.
3. Select Refresh.

Preset Memory

Radio Data System (RDS)

1

Playing AM/FM Radio

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the SOURCE button on the steering wheel or
select SOURCE on the list.

Audio Remote Controls P. 152

You can also switch the mode by selecting Change
Source
 on the MENU screen.

You can store 6 AM stations and 12 FM stations into
the preset memory.

1

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

163

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Features

Radio text

Displays the radio text information of the selected RDS station.
1. Select MENU.
2. Select View Radio Text.

Scan

Samples each of the strongest stations on the selected band for 10 seconds.
1. Select MENU.
2. Select Scan.
To turn off scan, select Cancel.

164

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

Features

Playing SiriusXM® Radio

*

*1:Some or all of the lists may not be displayed.

 (Power) Button

Press to turn the audio system
on and off.

MENU
Select to display the menu items.

BACK
Select to go back to the previous display.

Audio/Information Screen

Channel Icons
Select

 or

 to go to the

previous or next channel.
In channel mode, selecting and
holding a channel icon can move
channels the rapidly.

VOL (Volume)
Select to adjust the volume.

Category Icons
Select

 or

 to display and

select a SiriusXM® Radio
category.

Open/Close Icon

*1

Displays/hides the detailed
information.

Preset Icons
Tune the radio frequency for preset memory.
Select and hold the preset icon to store that station.
Select

 to display preset 7 onwards.

Scan
Select to scan each station with a strong signal.

* Not available on all models

Continued

165

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

Features

1. Select SiriusXM® mode.

Audio Remote Controls P. 152
Audio/Information Screen P. 155

From the Status Mode screen:
2. Select a channel using the

 or

 icon.

To select a preset station:
2. Select open/close icon to display a preset channel list.
3. Select a channel from the list.

To switch between channel and category modes:
1. Select SiriusXM® mode.
2. Select MENU.
3. Select XM Tune Mode.
4. Select Channel Mode or Category Mode.

To Play SiriusXM® Radio

1

Playing SiriusXM® Radio

*

In channel mode, all available channels are selectable.
In category mode, you can select a channel within a
category (Jazz, Rock, Classical, etc.).

There may be instances when SiriusXM® Radio does
not broadcast all the data fields (artist name, title).
This does not indicate a problem with your audio
system.

* Not available on all models

uu

Audio System Basic Operation

u

Playing SiriusXM® Radio

*

166

Features

To store a station:
1. Tune to the selected station.
2. Select MENU.
3. Select Save Preset.
4. Select the preset number for the station you want to store.

You can also store a preset station by the following procedure.
1. Tune to the selected station.
2. Select open/close icon. The preset channel list appears.
3. Select Preset tab.
4. Press and hold the preset number for the station you want to store until you hear

a beep.

1. Select MENU.
2. Select Channel List.
3. Select the station.

1. Select MENU.
2. Select Scan.

u

In channel mode, all channels are sampled for a few seconds each.

u

In category mode, channels within a category are sampled for a few seconds
each.

3. Select Cancel to stop scanning channels and to continue listening to the sampling

channel.

Preset Memory

To Select a Channel from a List

Scan

1

Playing SiriusXM® Radio

*

Switching audio mode
Press the SOURCE button on the steering wheel or
select SOURCE on the list.

Audio Remote Controls P. 152

You can also switch the mode by selecting Change
Source
 on the MENU screen.

You can store 12 SiriusXM® stations into the preset
memory.

* Not available on all models

167

uu

Audio System Basic Operation

u

Playing a CD

Continued

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or
AAC

*1

 format. With the CD loaded, select the CD mode.

*1:Only AAC format files recorded with iTunes are playable on this unit.
*2:Some or all of the lists may not be displayed.

ᵎᵏᴾᵤᶇᶊᶃᴾᵟᵟᵟ

ᵟᶐᶒᶇᶑᶒᴾᵟᵟᵟ

ᵟᶊᶀᶓᶋᴾᵟᵟᵟ

ᵎᵏᴾᵤᶍᶊᶂᶃᶐᴾᵟᵟᵟ

Audio/Information Screen

BACK
Select to go back to the previous display.

 (Power) Button

Press to turn the audio system on and off.

Track Icons

Select

 or

 to change tracks

(files in MP3, WMA, or AAC).
Select and hold to move rapidly
within a track.

MENU
Select to display the menu items.

CD Slot
Insert a CD about halfway into the CD
slot.

 (CD Eject) Button

Press to eject a CD.

VOL (Volume)
Select to adjust the volume.

Folder Icons
Select

 to skip to the next folder, and

 to skip to the beginning of the

previous folder in MP3, WMA, or AAC.

Open/Close Icon

*2

Displays/hides the detailed
information.

uu

Audio System Basic Operation

u

Playing a CD

168

Features

1. Select MENU and select Music Search.

2. Select a folder.

3. Select a track.

How to Select a File from the Music Search List (MP3/WMA/
AAC)

1

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA files protected by digital rights management
(DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

Text data appears on the display under the following
circumstances:

When you select a new folder, file, or track.

When you change the audio mode to CD.

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

Folder Selection

Track Selection

169

uu

Audio System Basic Operation

u

Playing a CD

Features

You can select scan, repeat, and random modes when playing a track or file.

1. Select MENU.
2. Select Scan or Random/Repeat.
3. Select a mode.

To turn off a play mode

1. Select MENU.
2. Select the mode you want to turn off.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders
 (MP3/WMA/AAC): Provides 10-second
sampling of the first file in each of the main folders.
Scan Tracks: Provides 10-second sampling of all
tracks on the CD (all files in the current folder in MP3,
WMA, or AAC).

Random/Repeat
Repeat Folder
 (MP3/WMA/AAC): Repeats all files in
the current folder.
Repeat Track: Repeats the current track/file.
Random in Folder (MP3/WMA/AAC): Plays all files
in the current folder in random order.
Random All Tracks: Plays all tracks/files in random
order.

Random/Repeat is selected.

170

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your dock connector to the USB port or the USB adapter
cable, then select the iPod mode.

USB/HDMI® Port P. 149
USB Adapter Cable P. 150

*1:Some or all of the lists may not be displayed.

ᵥᶃᶌᶐᶃᴾᵟᵟᵟ

ᵟᶐᶒᶇᶑᶒᴾᵟᵟᵟ

ᵎᵏᴾᵱᶍᶌᶅᴾᵟᵟᵟ

ᵟᶊᶀᶓᶋᴾᵟᵟᵟ

123456

Genre AAA

Song AAA

Artist AAA

Audio/Information Screen

BACK
Select to go back to the previous display.

VOL (Volume)
Select to adjust the volume.

Song Icons

Select

 or

 to change songs.

Select and hold to move rapidly
within a song.

MENU
Select to display the menu items.

 (Power) Button

Press to turn the audio system on and off.

Open/Close Icon

*1

Displays/hides the detailed
information.

Continued

171

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Select MENU and select Music Search.
2. Select the items on that menu.

How to Select a Song from the Music Search List

1

How to Select a Song from the Music Search List

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

iPod/USB Flash Drive P. 185

If you operate the music app on your iPhone/iPod
while the phone is connected to the display audio
system, you may no longer be able to operate the
same app on the display audio. Reconnect the device
if necessary.

Folder Selection

Track Selection

uu

Audio System Basic Operation

u

Playing an iPod

172

Features

You can select repeat and shuffle modes when playing a file.

1. Select MENU.
2. Select Shuffle/Repeat.
3. Select a mode.

To turn off a play mode

1. Select MENU.
2. Select the mode you want to turn off.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Repeat Song: Repeats the current track.
Shuffle: Plays all available albums in a selected list
(playlists, artists, albums, songs, genres, or
composers) in random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.

173

uu

Audio System Basic Operation

u

Playing Internet Radio

Continued

Features

Playing Internet Radio

Connect a compatible phone through Bluetooth®.

Phone Setup P. 211

You can also connect the phone using your dock connector to the USB port or the
USB adapter cable.
Select Source to select Pandora mode.

*1:Some or all of the lists may not be displayed.

U.S. models

Compatible phones only

1

Playing Internet Radio

Pandora®, the Pandora logo, and the Pandora trade
dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission. Pandora
is currently available exclusively in the United States.

To find out if your phone is compatible with this
feature, visit www.handsfreelink.honda.com, or call
1-888-528-7876.

To use this service in your vehicle, the Pandora® app
must first be installed on your phone. Visit
www.pandora.com. for more information.

iPhone only

Audio/Information Screen

 (Power) Button

BACK
Select to go back to the previous display.

VOL (Volume)
Select to adjust the volume.

MENU
Select to display the menu items.

Station Up/Down Icons
Select to change a station.

Skip Icon
Select to skip a song.
Play/Pause Icon
Select to resume or play a song.

Open/Close Icon

*1

Displays/hides the detailed information.

Like/Dislike Icons
Select to evaluate a song.

uu

Audio System Basic Operation

u

Playing Internet Radio

174

Features

You can operate some of the Pandora® menu items from your vehicle’s audio
system. The available items are:
• Bookmark
• Station List
• Change Station
• Change Source
• Sound

Operating a menu item

1. Select MENU.
2. Select an item.

Pandora® Menu

1

Playing Internet Radio

Pandora® is free, personalized radio that plays music
and comedy you’ll love. Just start with the name of
one of your favorite artists, songs, comedians or
composers and Pandora® will create a custom station
that plays similar tracks. Pandora® also features
hundreds of genre stations ranging from Dubstep to
Smooth Jazz to Power Workout.

If you cannot operate Pandora® through the audio
system, it may be streaming through Bluetooth®
Audio. Make sure Pandora® mode on your audio
system is selected.

Changing Stations
To change stations, activate the Pandora® menu,
select Station List, and then select a new station.

1

Pandora® Menu

Available operating functions vary on software
versions. Some functions may not be available on the
vehicle’s audio system.

If there is a problem, you may see an error message
on the audio/information screen.

Pandora® P. 186

Pandora® may limit the total number of skips allowed
on the service. If you dislike a track after the skip limit
has been reached, your feedback will be saved but
the current track will continue to play.

175

uu

Audio System Basic Operation

u

Playing a USB Flash Drive

Continued

Features

Playing a USB Flash Drive

Your audio system reads and plays sound files on a USB flash drive in either MP3, WMA or AAC

*1

 format.

Connect your USB flash drive to the USB port or the USB adapter cable, then select the USB mode.

USB/HDMI® Port P. 149
USB Adapter Cable P. 150

*1:Only AAC format files recorded with iTunes are playable on this unit.
*2:Some or all of the lists may not be displayed.

002300

75°

F

miles

Genre AAA

1’23’’

File AAA

Artist AAA

123

456

Audio/Information Screen

BACK
Select to go back to the previous display.

 (Power) Button

Press to turn the audio system on and off.

Track Icons
Select

 or

 to change files.

Select and hold to move rapidly
within a track.

MENU
Select to display the menu items.

USB Indicator
Appears when a USB flash drive is
connected.

Folder Icons
Select

 to skip to the next folder,

and

 to skip to the beginning of

the previous folder.

VOL (Volume)
Select to adjust the volume.

Open/Close Icon

*2

Displays/hides the detailed
information.















Content   ..  9  10  11  12   ..
