Honda Civic Coupe (2019 year). Manual

352

Customized Features

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.
*3:The default setting varies depending on the model.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Display

Display
Settings

Brightness

Changes the brightness of the audio/information
screen.

—

Contrast

Changes the contrast of the audio/information
screen.

—

Black Level

Changes the black level of the audio/information
screen.

—

Background Color

Changes the background color of the audio/
information screen.

Blue/Amber/Red

Violet/BlueGreen

Touch Panel Sensitivity

Sets the sensitivity of the touch panel screen.

High/Low

Sound/
Beep

Guidance Volume

Changes the sound volume.
Adjusts the guidance volume of the navigation
system.

1~6

~11

Text Message Volume

Changes the text/e-mail message reading
volume.

1~6

~11

* Not available on all models

353

Customized Features

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Sound
/Beep

Voice Recog. Volume

Changes the volume of the voice prompt.

1~6

~11

Meter Volume - List
Reading

Changes the list reading volume.

1~6

~11

Meter Volume -
Alphabetic Reading

Changes the alphabetic reading volume.

1~6

~11

Verbal Reminder

Turns the verbal reminders on and off.

/Off

Beep Volume

Changes the beep volume.

Off/1/2

Voice
Recog.

One Press Voice
Operation

Changes the setting of the

(Talk) button operation when

using the voice operation.

/Off

Voice Prompt

Turns the voice prompt on and off.

/Off

Voice Recog. Volume

Changes the volume of the voice prompt.

1~6

~11

Song by Voice

Turns the Song By Voice

on and off.

/Off

Song by Voice
Phonetic Modification

Modifies a voice command for music stored in the system or
an iPod/iPhone.

2 Phonetic Modification P. 283

—

Phonebook Phonetic
Modification

Modifies a voice command for the phonebook.

2 Phonebook Phonetic Modification P. 408

—

Automatic Phone Sync

Sets phonebook and call history data to be automatically
imported when a phone is paired to HFL.

/Off

354

Customized Features

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.
*3:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Clock

Clock/
Wallpaper
Type

Clock
Type

Clock

See

Info

on P. 344

Wallpaper

Clock Adjustment

Auto Time Zone

Manual Time Zone

Auto Daylight Saving Time

Clock Format

Clock Display

Overlay Clock Location

Clock Reset

Others

Language

Change the display language.

English

/Français/

Español

* Not available on all models

355

Customized Features

Continued

Features

*1:Default Setting
*2:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.
*3:Does not appear when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

System

Others

Voice Command Tips

Alerts you when manual control of the system is
disabled to prevent distraction while driving.
Only voice commands are available.

/Off

Remember Last Screen

Selects whether the device remembers the last
screen.

On/Off

Memory Refresh

Turns on the audio system automatically and
restores the fragmentation of memory when the
ignition switch is set to LOCK

(

/Off

Refresh Time Adjustment

Sets the time for Memory Refresh. —

Change Skin

Changes the screen interface design.

Yes/No

Factory Data Reset

Resets all the settings to their factory default.

2 Defaulting All the Settings P. 361

Yes/No

356

Customized Features

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System

Others

Climate Screen Timeout

Changes the length of time the climate control
display stays on when you press the CLIMATE
button.

Never/5 Seconds/10
Seconds

/20

Seconds

Detail Information

Displays the details of the head unit and
operating system information.

—

Default

Cancels/Resets all customized items in the
System group as default.

Yes/No

Vehicle

TPMS Calibration

Cancels/Calibrates the TPMS.

Cancel/Calibrate

Driver
Assist
System
Setup

Forward Collision Warning
Distance

Changes CMBS

alert distance.

Long/Normal

/Short

ACC Forward Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC/ACC with LSF range.

On/Off

Lane Keeping Assist
Suspend Beep

Causes the system to beep when LKAS is
suspended.

On/Off

Road Departure Mitigation
Setting

Changes the setting for the road departure
mitigation system.

Normal

/Wide/

Warning Only

* Not available on all models

357

Customized Features

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Meter
Setup

Language Selection

Changes the displayed language on the driver
information interface.

English

/Français/

Español

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few
degrees.

-5°F ~ ±0°F

~ +5°F

(U.S.)
-3°C ~ ±0°C

~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A
and average fuel economy A.

When Refueled/IGN
Off/Manually Reset

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B
and average fuel economy B.

When Refueled/IGN
Off/Manually Reset

Adjust Alarm Volume

Changes the alarm volume, such as buzzers,
warnings, turn signal sound, and so on.

High/Mid

/Low

Shift Up Backlight

Turns the shift up backlight blink feature on and
off.

2 Shift Up Backlight

P. 112

/Off

Fuel Efficiency Backlight

Turns the ambient meter feature on and off.

/Off

Turn By Turn Auto Display

Selects whether the turn-by-turn display comes
on during the route guidance.

/Off

* Not available on all models

358

Customized Features

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Meter
Setup

New Message
Notifications

Used to select whether a pop-up alert comes on
the screen when HFL receives a new text/e-mail
message.

/Off

Speed/Distance Units

Selects the trip computer units.

mph∙miles

/km/h∙km

(U.S.)
mph∙miles/km/h∙km

(Canada)

Tachometer

Selects whether the tachometer comes on the
driver information interface.

/Off

Keyless
Access
Setup

Remote Start System ON/
OFF

Turns the remote engine start feature on and off.

/Off

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

All Doors

Keyless Access Light Flash

Causes some exterior lights to flash when you
unlock/lock the doors.

/Off

Keyless Access Beep

Causes the beeper to sound when you unlock/
lock the doors.

/Off

* Not available on all models

359

Customized Features

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

15seconds/
30seconds

60seconds

Headlight Auto Off Timer

Changes the length of time the exterior lights
stay on after you close the driver’s door.

0seconds/
15seconds

30seconds/
60seconds

Auto Light Sensitivity

Changes the timing for the headlights to come
on.

Max/High/Mid

Low/Min

Auto Interior Illumination
Sensitivity

Changes the sensitivity of the brightness of the
instrument panel when the headlight switch is in
the AUTO position.

Max/High/Mid

Low/Min

Auto Headlight ON With
Wiper ON

Changes the settings for the wiper operation
when the headlights automatically come on while
the headlight switch is in the AUTO position.

/Off

* Not available on all models

360

Customized Features

Features

*1:Default Setting
*2:Continuously variable transmission models

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle

Door/
Window
Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle

Speed

/Shift from

/Off

Auto Door Unlock

Changes the setting for when the doors unlock
automatically.

All Doors When

Driver’s Door

Opens

/All Doors

When Shifted to

Park

/All Doors

When Ignition

Switched Off/Off

Key And Remote Unlock
Mode

Sets up the driver’s door or both doors to unlock
on the first push of the remote.

Driver Door

/All

Doors

Keyless Lock Answer Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

/Off

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening either door.

90seconds/
60seconds/
30seconds

Walk Away Auto Lock

Changes the settings for the auto lock function
when you walk away from the vehicle.

On/Off

Maintenance Info.

Used to reset the engine oil life display when the
maintenance service has been performed.

—

Default

Cancels/Resets all customized items in the
Vehicle group as default.

Yes/No

* Not available on all models

361

Customized Features

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select the Others tab.
5. Select Factory Data Reset.

A confirmation message appears on the
screen.

6. Select Yes to reset the settings.
7. Select Yes again to reset the settings.

A confirmation message appears on the
screen. Select OK.

After selecting OK, the system will
reboot.

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform Factory Data Reset, it will reset the
preinstalled apps to their factory default.

If you perform Factory Data Reset, you cannot use
the HondaLink® because it becomes off line.

2 HondaLink® P. 292

362

Features

HomeLink® Universal Transceiver

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

■

Important Safety Precautions

HomeLink® Universal Transceiver

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

363

HomeLink® Universal Transceiver

Training HomeLink

Continued

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the I and III HomeLink

buttons for about 10 seconds, until the
green indicator blinks. Release the buttons,
and proceed to step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Indicator

I HomeLink
Button

III HomeLink
Button

HomeLink® Universal Transceiver

Training HomeLink

364

Features

■

Programming a Button

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

1. Press and hold the desired HomeLink button until

the HomeLink indicator begins to slowly flash
orange. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from orange to rapidly flashing green.
This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simply press and release the programmed
HomeLink button. Activation will now occur for the
trained device.

Questions
For questions or comments, visit
www.HomeLink.com, www.youtube.com/
HomeLinkGentex, or by calling the HomeLink Hotline
(North America only) at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

Training
Complete

HomeLink LED is
continuously on green.

YES

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink® button you want to program.

3b. Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from slowly flashing orange to
rapidly flashing or continuously on
green? The process should take less
than 60 seconds.

2. Press and release the desired HomeLink button. Is the HomeLink indicator (LED) slowly

flashing orange?

3a. Hold the button on the remote

transmitter. Does HomeLink indicator
(LED) change from slowly flashing
orange to rapidly flashing green or
continuously on green? The process
should take less than 60 seconds.

5. Press and hold the HomeLink button again.

HomeLink indicator rapidly flashes
green.

5a. The remote has a rolling code. Press the

“learn” button on the remote-controlled
device (e.g. garage door opener).

6. Press and hold the HomeLink button

again.
The remote-controlled device should
operate.

Training Complete

5b. Within 30 secs, press and hold the

programmed HomeLink button for 2
secs.

4. Press and hold the programmed HomeLink

button for about a second. Does the device
(garage door opener) work?

365

Continued

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle’s audio system, without handling your cell phone.

Using HFL

(Pick-up) button: Press to go directly to the Phone screen or to answer an

incoming call.

(Hang-up/back) button: Press to end a call or to cancel a command.

(Talk) button: Press to call a number with a stored voice tag.

(Phone) button: Press to go directly to the Phone screen.

Selector knob: Rotate

to select an item on the screen, then press

■

HFL Buttons

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit automobiles.honda.com/handsfreelink/,
or call 1-888-528-7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528-7876.

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

•

Press and release the

button when you want to

call a number using a stored voice tag. Speak
clearly and naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a vehicle.

If you receive a call while using the audio system, the
system resumes its operation after ending the call.

Up to 20 speed dial entries can be stored. If there is
no entry in the system, Speed Dial is disabled.

2 Speed Dial P. 381

Up to 20 call histories can be stored. If there is no call
history, Call History is disabled.

Models with color audio system

(Talk) Button

Volume Up

Microphone

(Pick-up)

Button

Volume Down

Selector Knob

(Phone) Button

(Hang-up/Back)

Button

Bluetooth® HandsFreeLink®

Using HFL

366

Features

The audio/information screen notifies you
when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries can be called using voice commands while
the vehicle is in motion.

2 Speed Dial P. 381

■

HFL Status Display

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

HFL Mode

Battery Level Status

Signal Strength

Bluetooth Indicator
Appears when your
phone is connected
to HFL.

Roam Status

Call Name

■

Limitations for Manual Operation

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

367

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

HFL Menus

The ignition switch must be in ACCESSORY

(

q or ON

(

w to use HFL.

HFL Menus

To use HFL, you must first pair your Bluetooth-compatible

cell phone to the system while the vehicle is parked.

Some functions are limited while driving. A message
appears on the screen when the vehicle is moving
and the operation is canceled.

Display the last 20 outgoing calls.

Display the last 20 incoming calls.

Display the last 20 missed calls.

Phone

Speed Dial

Add New

Select a phone number from the call history to
store as a speed dial number.

Call History

Phonebook

Select a phone number from the phonebook to
store as a speed dial number.

Phone Number

Enter a phone number to store as a speed dial
number.

Dialed Calls

Received Calls

Missed Calls

Phonebook

Dial

Call History

Display the paired phones’s phonebook.

Enter a phone number to dial.

(Existing entry list)

*1: Appears only when a phone is connected to HFL.

Honda Civic Coupe (2019 year). Manual - part 23
