336

uu

Customized Features

u

Features

■

Customization flow

Select Settings.

Clock

Wallpaper

Others

Clock/Wallpaper Type

*1

/Clock Type

*2

Clock Adjustment

Clock Format

Clock

Clock

Auto Time Zone

*

Manual Time Zone

*

Auto Daylight Saving Time

Clock Display

Overlay Clock Location

Clock Reset

Info Screen Preference

Clock

Wallpaper

Others

Clock/Wallpaper Type

*1

/Clock Type

*2

Clock Adjustment

Clock Format

Clock

Auto Time Zone

*

Manual Time Zone

*

Auto Daylight Saving Time

Clock Display

Overlay Clock Location

Clock Reset

Info Screen Preference

Info

HondaLink

Diagnostic & Location Data

HondaLink

Diagnostic & Location Data

*1 : Does not appear when you change the screen interface design.
*2 : Appears only when you change the screen interface design.

* Not available on all models

337

uu

Customized Features

u

Continued

Features

Bluetooth On/Off Status

Bluetooth Device List

Edit Pairing Code

Wi-Fi On/Off Status

Wi-Fi Device List

Wi-Fi

Bluetooth

Bluetooth/Wi-Fi

Wi-Fi Information

Text/Email

Bluetooth Device List

Edit Speed Dial

Ring Tone

Phone

Automatic Phone Sync

HondaLink Assist

Enable Text/Email

Select Account

New Message Notification

Phone

LaneWatch

*

Fixed Guideline

Dynamic Guideline

Show with Turn Signal

Rear Camera

Camera

Display Time after Turn Signal Off

Reference Line

HD Radio Mode (FM)

*

RDS INFO

Audio

FM/AM

HD Radio Mode (AM)

*

Apple CarPlay

Android Auto

Smartphone

Priority Device Settings

* Not available on all models

338

uu

Customized Features

u

Features

Audio Source Pop-Up

Cover Art

Tune Start

SportsFlash Setup

Traffic & Weather Setup

Other

SXM

*

Bluetooth Device List

Bluetooth

Multiple Channel Mix Preset

Home Screen Edit Order

Configuration of Instrument Panel

Tachometer Setting

Display Settings

Background Color

*1

Display

System

Touch Panel Sensitivity

Brightness

Contrast

Black Level

Blue

Amber

Red

Violet

BlueGreen

Home

Menu icon position

*2

*1 : Does not appear when you change the screen interface design.
*2 : Appears only when you change the screen interface design.

* Not available on all models

339

uu

Customized Features

u

Continued

Features

Guidance Volume

*

Text Message Volume

Sound/Beep

Voice Recog. Volume

Verbal Reminder

Beep Volume

Meter Volume - List Reading

Meter Volume - Alphabetic Reading

Voice Prompt

Voice Recog. Volume

Song by Voice

Song by Voice Phonetic Modification

Phonebook Phonetic Modification

Automatic Phone Sync

One Press Voice Operation

Voice Recog.

* Not available on all models

340

uu

Customized Features

u

Features

Clock

Clock/Wallpaper Type

*1

/

Clock Type

*2

Clock Adjustment

Clock Format

Auto Time Zone

*

Manual Time Zone

*

Auto Daylight Saving Time

Clock Display

Overlay Clock Location

Clock Reset

Clock

Wallpaper

*1 : Does not appear when you change the screen interface design.
*2 : Appears only when you change the screen interface design.

Language

Voice Command Tips

Remember Last Screen

*1

Memory Refresh

Refresh Time Adjustment

Change Skin

Factory Data Reset

Climate Screen Timeout

Detail Information

Others

* Not available on all models

341

uu

Customized Features

u

Continued

Features

Driver Assist System Setup

*

Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep

Lane Keeping Assist Suspend Beep
Road Departure Mitigation Setting

Adjust Outside Temp. Display

“Trip A” Reset Timing

“Trip B” Reset Timing

Vehicle

Meter Setup

Adjust Alarm Volume

Speed/Distance Units

Fuel Efficiency Backlight

*

New Message Notifications

Tachometer

Cancel

TPMS Calibration

*

Calibrate

Turn By Turn Auto Display

Shift Up Backlight

*

Language Selection

* Not available on all models

342

uu

Customized Features

u

Features

Lighting Setup

Interior Light Dimming Time

Headlight Auto Off Timer

Auto Light Sensitivity

*

Auto Interior Illumination Sensitivity

Auto Door Lock

Key And Remote Unlock Mode

Door/Window Setup

Maintenance Info.

Auto Headlight ON With Wiper ON

Keyless Lock Answer Back

Security Relock Timer

Walk Away Auto Lock

*

Keyless Access Setup

*

Door Unlock Mode

Keyless Access Light Flash

Keyless Access Beep

Remote Start System ON/OFF

*

Auto Door Unlock

* Not available on all models

343

uu

Customized Features

u

Continued

Features

■

List of customizable options

*1:Does not appear when you change the screen interface design.
*2:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

Clock

Clock

Clock/
Wallpaper
Type

*1

/Clock

Type

*2

Clock

See

Info

 on P. 344

Wallpaper

Clock Adjustment

Auto Time Zone

*

Manual Time Zone

*

Auto Daylight Saving Time

Clock Format

Clock Display

Overlay Clock Location

Clock Reset

HondaLink

Diagnostic & Location Data

Others

Info Screen Preference

Default

Cancels/Resets all customized items in the Clock
group as default.

Yes/No

* Not available on all models

344

uu

Customized Features

u

Features

*1:Default Setting
*2:Does not appear when you change the screen interface design.
*3:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

Info

Clock

Clock/
Wallpaper
Type

*2

/

Clock
Type

*3

Clock

Changes the clock display type.

Analog/Digital

*1

/

Small Digital/Off

Wallpaper

●

Changes the wallpaper type.

●

Imports an image file for a new wallpaper.

●

Deletes an image file for a wallpaper.

Blank/Galaxy

*1

/

Metallic/Time Zone

Clock Adjustment

Adjusts Clock.

—

Auto Time Zone

*

Automatically adjusts the clock when driving
through different time zones.

On

*1

/Off

Manual Time Zone

*

Changes the time zone manually.

—

Auto Daylight Saving Time

Select On to have the GPS automatically adjust
the clock to daylight savings time. Select Off to
cancel this function.

On

*1

/Off

Clock Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

Clock Display

Selects whether the clock display comes on.

On

*1

/Off

Overlay Clock Location

Changes the clock display layout.

Upper Right

*1

/Upper

Left/Lower Right/
Lower Left/Off

Clock Reset

Resets the clock settings to the factory default.

Yes/No

* Not available on all models

345

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Info

HondaLink

Diagnostic & Location
Data

Turns HondaLink® on and off.

On

*1

/Off

Others

Info Screen Preference

Selects the top menu when the

 button is

pressed.

●

Info Top- A brief menu pops up.

●

Info Menu- A full menu pops up.

●

Off- A menu does not pop up.

Info Top/Info
Menu

*1

/Off

Default

Cancels/Resets all customized items in the Info
group as default.

Yes/No

346

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

2 Multi-View Rear Camera P. 537

On

*1

/Off

Dynamic Guideline

Selects whether the guidelines adjust to the
movement of the steering wheel.

2 Multi-View Rear Camera P. 537

On

*1

/Off

Default

Cancels/Resets all customized items in the Rear
Camera setting group as default.

Yes/No

LaneWatch

*

Show with Turn Signal

Selects whether the LaneWatch display comes on
when you move the turn signal lever to indicate a
right turn.

On

*1

/Off

Display Time after Turn
Signal Off

Changes the length of time the LaneWatch
display stays on after the turn signal lever returns
to the center.

0 second

*1

/2 seconds

Reference Line

Selects whether the reference lines come on the
LaneWatch monitor.

On

*1

/Off

Default

Cancels/Resets all customized items in the
LaneWatch group as default.

Yes/No

* Not available on all models

347

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Bluetooth
/Wi-Fi

Bluetooth

Bluetooth On/Off Status

Changes the Bluetooth® status.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone.

2 Phone Setup P. 399

—

Priority
Device
Settings

Priority On/
Off Status

Enables the system to or disables it from
automatically establishing a connection with a
Bluetooth® device which has been assigned
priority.

On

*1

/Off

Audio

Selects the priority device over another paired
audio device(s).

—

Phone

Selects the priority device over another paired
phone(s).

—

Edit Pairing Code

Edits a pairing code.

2 To change the pairing code setting P. 400

Random/Fixed

*1

Wi-Fi

Wi-Fi On/Off Status

Changes the Wi-Fi mode.

On/Off

*1

Wi-Fi Device List

Connects, disconnects, or deletes the Wi-Fi
device.

—

Wi-Fi Information

Shows the Wi-Fi information of the head unit.

—

Default

Cancels/Resets all customized items in the
Bluetooth/Wi-Fi group as default.

Yes/No

348

uu

Customized Features

u

Features

Setup

Group

Customizable Features

Description

Selectable Settings

Smart-
phone

Apple CarPlay

Sets up the Apple CarPlay connection.

—

Android Auto

Sets up the Android Auto connection.

—

Default

Cancels/Resets all customized items in the
Smartphone group as default.

Yes/No

349

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone

Phone

Bluetooth Device List

Pairs a new phone to HFL, connects or
disconnects a paired phone.

2 Phone Setup P. 399

—

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

2 Speed Dial P. 405

—

Ring Tone

Selects the ring tone.

Fixed/Mobile
Phone

*1

Automatic Phone Sync

Sets phonebook and call history data to be
automatically imported when a phone is paired
to HFL.

On

*1

/Off

HondaLink Assist

Turns HondaLink Assist on and off.

On/Off

*1

Text/Email

Enable Text/Email

Turns the text/e-mail message function on and
off.

On

*1

/Off

Select Account

Selects a text or e-mail message account.

—

New Message Notification

Selects whether a pop-up alert comes on the
screen when HFL receives a new text/e-mail
message.

On/Off

Default

Cancels/Resets all customized items in the Phone
settings group as default.

Yes/No

350

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

FM/AM

HD Radio Mode

*

Selects whether the audio system automatically
switches to the digital radio waves or receives the
analog waves only.

Auto

*1

/Analog Only

RDS INFO

Turns on and off the RDS information.

On/Off

*1

SXM

*

Tune Start

Turns on and off, starts the song from the
beginning as you change preset stations.

On

*1

/Off

SportsFlash
Setup

Interrupt

Turns on and off the sports alert function.

Off/On(one time)/
On(continue)

*1

Favorite
Team

Selects your favorite sports teams.

2 Live Sports Alert P. 275

—

Interrupt
Beep

Causes the system to beep when the sports alert
is notified.

On

*1

/Off

Traffic & Weather Setup

Selects the region you want to receive the
information.

—

Multiple Channel Mix
Preset

Turns multiple channel mix preset on and off.

On/Off

*1

FM/AM mode

SiriusXM® mode

* Not available on all models

351

uu

Customized Features

u

Continued

Features

*1:Default Setting
*2:Appears only when you change the screen interface design.

Setup

Group

Customizable Features

Description

Selectable Settings

Audio

Bluetooth

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone.

2 Phone Setup P. 399

—

Other

[Your selected media]
Cover Art

Turns the cover art display on and off.

On

*1

/Off

Audio Source Pop-Up

Selects whether the list of selectable audio
sources comes on when Audio is selected on the
home screen.

On/Off

*1

Default

Cancels/Resets all customized items in the Audio
settings group as default.

Yes/No

System

Home

Home Screen Edit Order

Changes the home screen icon layout.

—

Menu icon position

*2

Changes the position of the menu icons on the
Audio, Phone, and Info screen.

—

Configuration of
Instrument Panel

Changes the Instrument Panel screen icon
layout.

—

Tachometer Setting

Turns on and off the tachometer display.

On

*1

/Off

Bluetooth® mode

iPod or USB mode
