Honda Accord Sedan (2016 year). Manual - part 20





304

uu

Customized Features

u

Features

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Display

Brightness

Changes the brightness of the audio/information
screen.

Contrast

Changes the contrast of the audio/information
screen.

Black Level

Changes the black level of the audio/information
screen.

Beep

Selects whether a beeper sounds when you
operate the selector knob.

On

*1

/Off

Blue-
tooth

Bluetooth On/Off

Turns the Bluetooth® on and off.

On

*1

/Off

Bluetooth Device List

Pairs a new phone to HFL, edits and deletes a
paired phone, and create a security PIN.

Phone Setup P. 350

Edit Pairing Code

Changes a pairing code.

To change the pairing code setting P. 352

Random/Fixed

*1

Voice
Recog

Voice Prompt

Turns the voice prompt on and off.

Beginner

*1

/Expert

305

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

System
Settings

Clock

Clock/
Wallpaper
Type

Clock Type

Changes the clock display type.

Analog/Digital

*1

/

Small Digital/Off

Wallpaper

Changes the wallpaper type.

Imports an image file for a new wallpaper.

Deletes an image file for a wallpaper.

Wallpaper Setup P. 195

Blank/Galaxy

*1

/

Metallic/Add New

Clock Adjustment

Adjusts Clock.

Clock P. 114

Clock Format

Selects the digital clock display from 12H to 24H.

12H

*1

/24H

Others

Language

Changes the display language.

English

*1

/French/

Spanish

Background Color

Changes the background color of the audio/
information screen.

Blue

*1

/Amber/Red/

Green

Header Clock Display

Selects whether the clock display comes on.

On

*1

/Off

Factory Data Reset

Resets all the settings to their factory default.

Defaulting All the Settings P. 315

Yes/No

Default

Cancels/Resets all customized items in the
System Settings group as default.

Yes/No

306

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

TPMS Calibration

Cancels/Calibrates the TPMS.

Cancel

*1

/Calibrate

Driver
Assist
System
Setup

*

Forward Collision Warning
Distance

*

Changes at which distance the CMBS

TM

 alerts.

Long/Normal

*1

/Short

ACC Forward Vehicle
Detect Beep

*

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out of
the ACC range.

On/Off

*1

ACC Display Speed Unit

*

Changes the speed unit for ACC on the multi-
information display.

mph

*1

/km/h

(U.S.)
mph/km/h

*1

(Canada)

Road Departure Mitigation
Setting

*

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/

Warning Only

Lane Keeping Assist
Suspend Beep

*

Causes the system to beep when the LKAS is
suspended.

On/Off

*1

* Not available on all models

307

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Meter
Setup

Adjust Outside Temp.
Display

Adjusts the temperature reading by a few
degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

(U.S.)
-3°C ~ ±0°C

*1

 ~ +3°C

(Canada)

“Trip A” Reset Timing

Changes the setting of how to reset trip meter A
and average fuel economy A.

With Refuel/IGN Off/
Manually Reset

*1

“Trip B” Reset Timing

Changes the setting of how to reset trip meter B
and average fuel economy B.

With Refuel/IGN Off/
Manually Reset

*1

Fuel Efficiency Backlight

Turns the ambient meter feature on and off.

On

*1

/Off

Keyless Start Guidance
Screens

*

Displays the push button start guidance when
conditions are met to change power mode.

On

*1

/Off

Remote Start System ON/
OFF

*

Turns the remote engine start feature on and off.

On

*1

/Off

Driving
Position
Setup

*

Memory Position Link

Changes the driver’s seat position to a stored
setting.

On

*1

/Off

* Not available on all models

308

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Keyless
Access
Setup

*

Door Unlock Mode

Changes which doors unlock when you grab the
driver’s door handle.

Driver Door Only

*1

/

All Doors

Keyless Access Light Flash

Causes some exterior lights to blink when you
unlock/lock the doors.

On

*1

/Off

Keyless Access Beep

Sets the beeper sound or not when you grab
either front door handle.

On

*1

/Off

Lighting
Setup

Interior Light Dimming
Time

Changes the length of time the interior lights stay
on after you close the doors.

60seconds/
30seconds

*1

/

15seconds

Headlight Auto Off Timer

Changes the length of time the exterior lights
stay on after you close the driver's door.

60seconds/
30seconds/
15seconds

*1

/

0seconds

Auto Light Sensitivity

Changes the timing for the headlights to come
on.

Max/High/Mid

*1

/

Low/Min

* Not available on all models

309

uu

Customized Features

u

Continued

Features

*1:Default Setting
*2:Automatic transmission/CVT models

Setup

Group

Customizable Features

Description

Selectable Settings

Vehicle
Settings

Door
Setup

Auto Door Lock

Changes the setting for when the doors
automatically lock.

With Vehicle Speed

*1

/

Shift from P

*2

/Off

Auto Door Unlock

Changes the setting for when the doors
automatically unlock.

All Doors When
Driver’s Door Opens

*1

/

All Doors When
Shifted to Park

*2

/All

Doors When Ignition
Switched Off
/Off

Key And Remote Unlock
Mode

Sets up either the driver's door or all doors to
unlock on the first push of the remote.

Driver Door

*1

/All

Doors

Keyless Lock Answer Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/Off

Security Relock Timer

Changes the time it takes for the doors to relock
and the security system to set after you unlock
the vehicle without opening any door.

90seconds/
60seconds/
30seconds

*1

Mainte-
nance
Info.

Maintenance Reset

Resets the engine oil life display when you have
performed the maintenance service.

Default

Cancels/Resets all customized items in the
Vehicle Settings group as default.

Yes/No

310

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Audio
Settings

Sound

Adjusts the settings of the audio speaker’s sound.

Adjusting the Sound P. 197

-6 ~ C

*1

 ~ +6 (Bass

Treble and SUBW

*

), -9

C

*1

 ~ +9 (Fader and

Balance), Off/Low/
Mid

*1

/High (SVC)

Source Select Popup

Selects whether the list of selectable audio
sources comes on when the AUDIO button is
pressed.

On/Off

*1

Cover Art

Turns on and off the cover art display.

On

*1

/Off

Connect Audio

Connects, disconnects or pairs a Bluetooth®
Audio device to HFL.

Bluetooth Device List

Edits or deletes a Bluetooth® Audio device paired
to HFL.

Default

Cancels/Resets all customized items in the Audio
Settings
 group as default.

Yes/No

iPod, USB, or Pandora®

*

 mode

Bluetooth® Audio or Pandora®

*

 mode

Bluetooth® Audio or Pandora®

*

 mode

* Not available on all models

311

uu

Customized Features

u

Continued

Features

Setup

Group

Customizable Features

Description

Selectable Settings

Info
Settings

Clock/
Wall-
paper
type

Clock Type

See System Settings on  P. 304 to  P. 305

Wallpaper

Clock Adjustment

Clock Format

Default

Cancels/Resets all customized items in the Info
Settings
 group as default.

Yes/No

312

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone
Settings

Connect Phone

Pairs a new phone to HFL, connects or
disconnects a paired phone.

Phone Setup P. 350

Bluetooth Device List

Pairs a new phone to HFL, edits or deletes a
paired phone, or creates a security PIN.

Phone Setup P. 350

Phone

Edit Speed Dial

Edits, adds or deletes a speed dial entry.

Speed Dial P. 361

Auto Transfer

Sets calls to automatically transfer from your
phone to HFL when you enter the vehicle.

On

*1

/Off

Auto Answer

Sets whether to automatically answer an
incoming call after about four seconds.

On/Off

*1

Ring Tone

Selects the ring tone.

Fixed/Mobile
Phone

*1

/Off

Automatic Phone Sync

Sets a phonebook data to be automatically
imported when a phone is paired to HFL.

On

*1

/Off

313

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone
Settings

Text
Messages

Enable Text Message

Turns the text message function on and off.

On

*1

/Off

New Text Message Alert

Selects whether a pop-up alert comes on the
screen when HFL receives a new text message.

On/Off

*1

Message Auto Reading

Sets the system to automatically read an
incoming text message.

On- A text message is always read aloud.

Off- A text message is not read aloud.

Auto- A text message is read aloud only when
driving.

On/Off/Auto

*1

Default

Cancels/Resets all customized items in the Phone
Settings
 group as default.

Yes/No

314

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Camera
Settings

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on the
rear camera monitor.

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come on
the rear camera monitor.

On

*1

/Off

Default

Cancels/Resets all customized items in the
Camera Settings group as default.

Yes/No

315

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

u

Repeat the procedure to select Other
then Factory Data Reset.

u

The confirmation message will appear.

3. Rotate

 to select Yes, then press

 to

reset the settings.

4. Rotate

 to select Yes, then press



again to reset the settings.

u

The confirmation message will appear.
Press

 to select OK.

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

The following settings will be reset:

Audio preset settings

Phonebook entries

Other display and each item settings.

316

Features

Customized Features

Use the audio/information touch screen to customize certain features.

How to customize

With the ignition switch in ON

(

w

*1

, select Settings, then select a setting item.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

1

Customized Features

When you customize settings:

Make sure that the vehicle is at a complete stop.

Shift to

(

P.

Set the parking brake.

To customize other features, select Settings.

List of customizable options P. 325

Automatic transmission/CVT models

Manual transmission models

Models with two displays

Audio/Information
Touch Screen

317

uu

Customized Features

u

Continued

Features

Customization flow

Select Settings.

Brightness

Contrast

Black Level

Sound/Beep

System

Display

Display Settings

Background Color

Guidance Volume

Text Message Volume

Select .

Voice Recog

Voice Prompt

Blue

Amber

Red

Violet

Voice Recog. Volume

Beep Volume

Voice Recog. Volume

Song by Voice

*

Song by Voice Phonetic Modification

*

Phonebook Phonetic Modification

Automatic Phone Sync

One Press Voice Operation

Verbal Reminder

*

Blue Green

* Not available on all models

318

uu

Customized Features

u

Features

Language

Default

System

Others

Clock/Wallpaper Type

Clock Adjustment

*

Clock

Clock

Wallpaper

Manual Time Zone

*

Auto Daylight

Clock Display

Touch Panel Sensitivity

Clock Format

Auto Time Zone

*

Detail Information

Factory Data Reset

Clock Reset

* Not available on all models

319

uu

Customized Features

u

Continued

Features

Vehicle

Driver Assist

System Setup

*

Forward Collision Warning Distance

*

ACC Forward Vehicle Detect Beep

*

Road Departure Mitigation Setting

*

Lane Keeping Assist Suspend Beep

*

Meter Setup

Language Selection

Adjust Outside Temp Display

“Trip A” Reset Timing

“Trip B” Reset Timing

Fuel Efficiency Backlight

Keyless Start Guidance Screens

*

Driving Position

Setup

*

Memory Position Link

TPMS Calibration

ACC Display Speed Unit

*

* Not available on all models















Content   ..  18  19  20  21   ..
