Honda Accord Sedan (2016 year). Manual - part 18





272

uu

Audio System Basic Operation

u

HondaLink®

Features

To link with HondaLink®

You can see the Connection Guide screen
after launching HondaLink®. If you do not
need this guide, select check-box and select
OK.

273

uu

Audio System Basic Operation

u

HondaLink®

Continued

Features

You can check the messages that are received quickly in the shortcut operation.

1. A message appears and notifies you of a

new message on the header area.

u

When the message is received, a
notification ring can be heard.

2. A message icon is continuously displayed in

the header area until the new message is
read.

Vehicle Information and Message from Honda Tips

Message
Icon
(yellow)

274

uu

Audio System Basic Operation

u

HondaLink®

Features

3. From the top of the screen, swipe down to

see the messages.

4. Select a new message to open.

275

uu

Audio System Basic Operation

u

Wi-Fi Connection

Continued

Features

Wi-Fi Connection

You can connect the display audio to the Internet using Wi-Fi and browse websites
or use online services on the audio/information touch screen. If your phone has cell
hotspot capabilities, the system can be tethered to the phone. Use the following
steps to setup.

1. Select .
2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Wi-Fi tab.
5. Select Wi-Fi On/Off Status, then On.
6. Select Wi-Fi Network List.

u

Make sure your phone’s Wi-Fi setting is
in access point (tethering) mode.

u

Select the phone you want to connect to
the system.

u

If you do not find the phone you want to
connect in the list, select Scan.

7. Select Connect.

u

Enter a password for your phone, and
select OK.

u

When the connection is successful, the

 icon is displayed on the list.

8. Select

 to go back to the home screen.

Wi-Fi mode (setting for the first time)

1

Wi-Fi mode (setting for the first time)

You cannot go through the setting procedure while a
vehicle is moving. Park in a safe place to setup the
Wi-Fi connection.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

Check your phone manual to find out if the phone
has Wi-Fi connectivity.

You can confirm whether Wi-Fi connection is on or
off with the

 icon on Wi-Fi Network List

Transmission speed and others will not be displayed
on this screen.

uu

Audio System Basic Operation

u

Wi-Fi Connection

276

Features

Make sure your phone's Wi-Fi setting is in access point (tethering) mode.

Wi-Fi mode (after the initial setting has been made)

1

Wi-Fi mode (after the initial setting has been made)

You may need to go through an initial setup for Wi-
Fi connection again after you boot your phone.

iPhone users

277

uu

Audio System Basic Operation

u

Apple CarPlay

Continued

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via USB, you can
use the audio/information touch screen, instead of the iPhone display, to make a
phone call, listen to music, view maps (navigation), and access messages.

USB Port(s

*

) P. 187

1

Apple CarPlay

Only iPhone5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To use Apple CarPlay, connect the USB cable to the
front USB port. The USB port located in the center
console storage will not enable Apple CarPlay
operation.

USB Port(s

*

) P. 187

To directly access the Apple CarPlay phone function,
select Phone on the home screen. While connected
to Apple CarPlay, calls are only made through Apple
CarPlay. If you want to make a call with Bluetooth®
HandsFreeLink®, turn Apple CarPlay OFF or detach
the USB cable from your iPhone.

Setting Up Apple CarPlay P. 279

When your iPhone is connected to Apple CarPlay, it is
not possible to use the Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Apple CarPlay is connected.

Phone Setup P. 383

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

* Not available on all models

uu

Audio System Basic Operation

u

Apple CarPlay

278

Features

Phone

Access the contact list, make phone calls, or listen to voice mail.

Messages

Check and reply to text messages, or have messages read to you.

Music

Play music stored on your iPhone.

Maps

Display Apple CarPlay map and use the navigation function just as you would on
your iPhone.

Only one navigation system (pre-installed navigation or Apple CarPlay map) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

Apple CarPlay Menu

1

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations
Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Home Screen

Apple CarPlay Menu

Go back to
the home
screen.

Apple CarPlay Icon

Go back to the Apple CarPlay menu screen.

Models with navigation system

Continued

279

uu

Audio System Basic Operation

u

Apple CarPlay

Features

After you have connected your iPhone to the system via USB, use the following
procedure to set up Apple CarPlay. Use of Apple CarPlay will result in the
transmission of certain user and vehicle information (such as vehicle location, speed,
and status) to your iPhone to enhance the Apple CarPlay experience. You will need
to consent to the sharing of this information on the audio/information touch screen.

Enabling Apple CarPlay

• Enable Once: Allows only once. (Prompt

shows again next time.)

• Always Enable: Allows anytime. (Prompt

does not show again.)

• Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

Setting Up Apple CarPlay

1

Setting Up Apple CarPlay

You can also use the method below to set up Apple
CarPlay:
Select HOME

Settings

Smartphone

Apple

CarPlay

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.

uu

Audio System Basic Operation

u

Apple CarPlay

280

Features

Press and hold the talk button to activate Siri Eyes Free.

Operating Apple CarPlay with Siri Eyes Free

1

Operating Apple CarPlay with Siri Eyes Free

Below are examples of questions and commands for
Siri Eyes Free:

What movies are playing today?

Call dad at work.

What song is this?

How’s the weather tomorrow?

Read my latest email.

Find a table for four tonight in Chicago.

For more information, please visit
www.apple.com/ios/siri.

 (Talk) button:

Press and hold to activate Siri Eyes Free.
Press and release to activate standard voice recognition system.

 (Hang-up/back) button:

Press to deactivate Siri Eyes Free.

281

uu

Audio System Basic Operation

u

Android Auto

Continued

Features

Android Auto

When you connect an Android phone to the Display Audio system via USB, Android
Auto is automatically initiated. When connected via Android Auto, you can use the
audio/information touch screen to access the Phone, Google Maps (Navigation),
Google Play Music, and Google Now functions. When you first use Android Auto, a
tutorial will appear on the screen. We recommend that you complete this tutorial
while safely parked before using Android Auto.

USB Port(s

*

) P. 187

Auto Pairing Connection P. 283

1

Android Auto

To use Android Auto, you need to download the
Android Auto app from Google Play to your
smartphone.

Only Android 5.0 (Lollipop) or later versions are
compatible with Android Auto. Bluetooth A2DP
cannot be used with Android Auto phone.

Park in a safe place before connecting your Android
phone to Android Auto and when launching any
compatible apps.

To use Android Auto, connect the USB cable to the
front USB port. The USB port in the center console
storage will not enable Android Auto operation.

USB Port(s

*

) P. 187

To directly access the Android Auto phone function,
select Phone on the home screen. While connected
to Android Auto, calls are only made through
Android Auto. If you want to make a call with
Bluetooth® HandsFreeLink®, turn Android Auto OFF
or detach the USB cable from your Android phone.

Auto Pairing Connection P. 283

When your Android phone is connected to Android
Auto, it is not possible to use Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Android Auto is connected.

Phone Setup P. 383

* Not available on all models

uu

Audio System Basic Operation

u

Android Auto

282

Features

a

 Maps (Navigation)

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

b

 Phone (Communication)

Make and receive phone calls as well as listen to voicemail.

c

 Google Now (Home screen)

Display useful information organized by Android Auto into simple cards that appear
just when they’re needed.

d

 Music and audio

Play Google Play Music and music apps that are compatible with Android Auto. To
switch between music apps, press this icon.

e

 Go back to the Home screen

f

 Voice

Operate Android Auto with your voice.

Android Auto Menu

1

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Android Auto Operating Requirements &
Limitations
Android Auto requires a compatible Android phone
with an active cellular connection and data plan.
Your carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

Only one navigation system (pre-installed navigation
or Android Auto) can give directions at a time. When
you are using one system, directions to any prior
destination set on the other system will be canceled,
and the system you are currently using will direct you
to your destination.
The audio/Information screen shows you turn-by-turn
driving directions to your destination.

Models with navigation system

: Go back to

the home screen.

Android Auto Icon

6

Continued

283

uu

Audio System Basic Operation

u

Android Auto

Features

When you connect an Android phone to the unit via USB, Android Auto is
automatically initiated.

Enabling Android Auto

• Enable Once: Allows only once. (Prompt

shows again next time.)

• Always Enable: Allows anytime. (Prompt

does not show again.)

• Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

Auto Pairing Connection

1

Enabling Android Auto

Only initialize Android Auto when you are safely
parked. When Android Auto first detects your phone,
you will need to set up your phone so that auto
pairing is possible. Refer to the instruction manual
that came with your phone.

You can use the method below to change Android
Auto settings after you have completed the initial
setup:
Select HOME

Settings

Smartphone

Android

Auto

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to/from your phone by Android Auto is
governed by Google’s Privacy Policy.

uu

Audio System Basic Operation

u

Android Auto

284

Features

Press and hold the talk button to operate Android Auto with your voice.

Operating Android Auto with Voice Recognition

1

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

Reply to text.

Call my wife.

Navigate to Honda.

Play my music.

Send a text message to my wife.

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function
by pressing the

 icon in the upper-right corner of

the screen.

 (Talk) button:

Press and hold to operate Android Auto with your voice.
Press and release to activate standard voice recognition system.

 (Hang-up/back) button:

Press to deactivate voice recognition.

285

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the

 (Talk) button on the steering wheel when your

iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system.

Phone Setup P. 383

Using Siri Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free while operating a vehicle.

1

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

 (Talk) Button

Press and hold until the display
changes as shown.

 (Hang-up/back) Button

Press to deactivate Siri Eyes Free.

While in Siri Eyes Free:
The display remains the same. No
feedback or commands appear.

Appears
when Siri is
activated in
Siri Eyes Free

286

Features

Audio Error Messages

CD Player

If a disc error occurs, you may see the following error messages.

*1:Models with one display
*2:Models with two displays

Error Message

Cause

Solution

Unplayable File

Track/file format not supported

Current track/file will be skipped. The next supported track/file
plays automatically.

Bad Disc
Please Check Owner’s
Manual
Push Eject

*1

Bad Disc
Please check Owner’s
Manual
Please push eject button

*2

Mechanical error

Press the   (eject) button and remove the disc, and check that the
error message is cleared.

Check that the disc is not damaged or deformed, and insert the
disc again.

Protecting CDs P. 293

If the error message reappears, press the   button, and pull out
the disc.

Insert a different disc.
If the new disc plays, there is a problem with the first disc.

If the error message repeats, or the disc cannot be removed,
contact a dealer.
Do not try to force the disc out of the player.

Mecha Error

Bad Disc
Please Check Owner’s
Manual

Servo error

Check Disc

Disc error

Check that the disc is not damaged or deformed.

Protecting CDs P. 293

Heat Error

High temperature

Turn the audio system off and allow the player to cool down until
the error message is cleared.

287

uu

Audio Error Messages

u

iPod/USB Flash Drive

Features

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact a dealer.

*1:Models with one display

*2:Models with two displays

Error Message

Solution

USB Error

Appears when there is a problem with the USB adapter unit. Check if the device is compatible with the
USB adapter unit.

Incompatible USB Device

Please Check Owner’s

Manual

*1

The connected USB device

has a problem.

See Owner’s Manual

*2

Appears when an incompatible device is connected. Disconnect the device. Then turn the audio system
off, and turn it on again. Do not reconnect the device that caused the error.

Unsupported Version

Appears when an unsupported iPod is connected. If it appears when a supported iPod is connected,
update the iPod software to the newer version.

Connect Retry

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Unplayable File

Appears when the files in the USB flash drive are DRM or an unsupported format. This error message
appears for about 3 seconds, then plays the next song.

No Data

Appears when the iPod is empty.

Appears when the USB flash drive is empty or there are no MP3, WMA, or AAC files in the USB flash
drive.

Check that compatible files are stored on the device.

Unsupported

Appears when an unsupported device is connected. If it appears when a supported device is connected,
reconnect the device.

iPod

USB flash drive

iPod and USB flash drive















Content   ..  16  17  18  19   ..
