This feature is activated through the color settings or by holding
the Back switch (1) for five seconds on the right hand control.
The feature cannot be activated while the display is showing
night colors.

1180565

Back switch

Figure 133. Right Hand Control

PROJECTION MODE

When connected and enabled, the Phone icon on the home
screen will switch to the Apple CarPlay icon.

Projection mode in Apple CarPlay will be enabled or disabled
via calibration to meet individual country regulation or
requirements.

Navigate:

Home > Setup.

Select:

On or Off.

Other Features 197

vidson.com to check for the latest version.

MODE/UP/DN Switch.....................................................38
Push-To-Talk (PTT)/Volume (VOL) Switch.....................38
Enabling Rear Controls..................................................38

Headset Connection.............................................................39

Microphone Positioning..................................................41

Media Compartment: USB Port............................................42

Media Compartment: Fixed Fairing Vehicles..................42
Media Compartment: Fork Mounted Fairing Vehicles.....43

Speakers..............................................................................44

Fairing Speakers............................................................44
Fairing Lower Speakers.................................................44
Saddlebag Speakers......................................................44
Tour-Pak Speakers.........................................................45

Amplifier...............................................................................45
Antennas and Reception......................................................45
Bluetooth..............................................................................46
Turning Motorcycle On, Off or to Accessory Mode..............46
Disconnecting the Vehicle Battery.......................................47

SETUP

Home Screen.......................................................................49
Screen Menu Bar.................................................................50
Checkbox and Multiselect....................................................50
Scroll Controls......................................................................51
Keyboard..............................................................................52

Colors.............................................................................61
Theme............................................................................61
High Contrast.................................................................61

TABLE OF CONTENTS

AUDIO

AM-FM-WB Radio................................................................73

Media...................................................................................80

Media Screen.................................................................80

Satellite Radio......................................................................90

TABLE OF CONTENTS

III

VEHICLE STATUS

See Figure 134.

Select:

Vehicle Status button to display various

information. Press the button again to exit the screen.

1167968

Information (Vehicle Status) Button

Figure 134. Information (Vehicle Status)

INFORMATION

This screen provides information for a current trip and current
status (start and end time, current speed, current altitude,
current temperature and how far until next turn).

1154129

Departure time/estimated arrival time/distance

Current speed

Actual time/actual distance

Distance until next turn

Air temperature

Altitude

Figure 135. Trip Information Screen

ENGINE INFORMATION

This screen provides current engine information (PSI, distance
to empty, distance traveled since last service, EITMS activation
notification).

INFORMA

TION

(VEHICLE

TUS)

Information (Vehicle Status) 199

Bluetooth............................................................................106

Enabling Bluetooth.......................................................106
Pairing a Bluetooth Device...........................................107
Listening to Music.........................................................108
Connecting/Disconnecting a Bluetooth Device............109
Reconnecting After Vehicle Turns On..........................109
Deleting a Paired Device..............................................110

CARE AND CLEANING

Audio System Care............................................................111

Screen..........................................................................111
Cleaning the Radio.......................................................111
Speaker Care...............................................................111

TABLE OF CONTENTS

PHONE

Phone Compatibility...........................................................113
Bluetooth and USB Connections For Phones....................113
Phone Menu.......................................................................113
Call Screen.........................................................................114
iPhone: Using Siri...............................................................115
Making a Call.....................................................................115

Receiving a Call.................................................................118

Accepting/Ignoring........................................................118
Radio Turned Off..........................................................118

Call Options........................................................................118

Ending a Call................................................................118
Adjusting Call Volume..................................................119
Muting Call Audio.........................................................119
Routing Call Audio........................................................119
Multiple Calls................................................................119

Voice Mail...........................................................................119
Phone Book........................................................................120

Phone Book..................................................................120

Text Messaging..................................................................122

Enabling Text Messaging: SMS....................................123
Enabling New Message Pop-Up..................................123
Text Message (SMS) Auto-reply...................................123
Viewing/Playing A Text Message.................................124
Enabling Text Message Notification: Apple Devices.....125

Ring Tone...........................................................................125

Selecting.......................................................................125
Adding New Ring Tone: USB.......................................125

Resuming Calls After Vehicle Shutdown............................126
Transferring a Call Back to the Phone...............................126
Changing the Emergency Phone Number.........................127
Apple CarPlay....................................................................127

NAVIGATION

Navigation..........................................................................131

One Box Search (OBS)................................................131

TABLE OF CONTENTS

1154891

Front tire pressure

Rear tire pressure

Low tire pressure (amber tire color)

Sensor battery low

Figure 137. Tire Pressure Monitoring System (TPMS)

Front and rear tires:

Each tire is shown as either white (to

indicate normal tire pressure) or amber (to indicate a low tire
pressure condition).

Tire pressure data:

Tire pressure is displayed as psi or kPa,

according to the unit settings for the radio. Dashes (--) indicate
that there is no current data for the tire pressure.

Sensor battery low icon:

The TPMS sensor battery is low for

the indicated tire. See a Harley-Davidson dealer for service.

Low tire pressure icon:

The system detects low pressure for

the indicated tire. Safely stop the vehicle and use a tire pressure
gauge to check the pressure of each affected tire. Inflate the
tires according to specifications in the vehicle owner's manual
or as specified on the label on the frame downtube.

High tire pressure icon:

The system displays

HIGH

for the

corresponding tire pressure on the TPMS screen rather than
a numeric pressure value. Safely stop the vehicle and use a
tire pressure gauge to check the pressure of each affected tire.
Deflate the tire according to specifications in the vehicle owner's
manual or as specified on the label on the frame downtube.

Low Tire Pressure Alert

See Figure 138. An alert is displayed when a low tire pressure
condition has been detected.

Search for fuel station:

For vehicles with navigation, the radio

will prompt to navigate to a nearby fuel station. Select

Yes

display a list of nearby fuel stations.

Details:

Displays the TPMS screen.

An alert will be displayed only once for each tire. Turn off and
restart the motorcycle to reset the alert feature.

Information (Vehicle Status) 201

vidson.com to check for the latest version.

Map Compass Setting..................................................132
Full-Size Compass (equipped without Navigation).......132
Full-Size Compass (equipped with Navigation)............133

Map....................................................................................133

Route..................................................................................142

Rides..................................................................................149

Trails...................................................................................153

Record a Trail...............................................................154
Rename a Trail.............................................................154
Navigating a Trail..........................................................154

TABLE OF CONTENTS

Deleting a Trail.............................................................155

Exporting a Route..............................................................155
Importing a Route...............................................................156

USB Drive.....................................................................156
Mobile App...................................................................157

Traffic.................................................................................157

Navigation Prompts............................................................165

Navigation Prompts: Turning On/Off............................165
Navigation Prompts: Adjusting Volume Using Menus...166
Navigation

Controls........................................................................166
Navigation Prompts: Speaker/Headset Selection........166

Navigation Database and Software...................................166
Ride Planner......................................................................167

COMMUNICATIONS

Voice Recognition..............................................................171

Intercom.............................................................................176

Turning Intercom On/Off...............................................177
Adjusting Microphone Sensitivity: VOX........................177
Speed Volume..............................................................178
Adjusting

Headsets......................................................................178
Operating Intercom: Voice Activation, VOX..................179
Operating Intercom: PTT Switch..................................179

Whim..................................................................................179

TABLE OF CONTENTS

VII

WHAT EVERY RESPONSIBLE CITIZENS
BAND (CB) STATION OPERATOR SHOULD
KNOW AS PREPARED BY THE FEDERAL
COMMUNICATIONS COMMISSION,
WASHINGTON, D.C.

Subpart D-Citizens Band (CB) Radio Service
General Provisions

Sec. 95.401 (CB Rule 1) What is the Citizens Band Radio
Services?

The Citizens Band (CB) Radio Service is a private, two-way,
short-distance voice communications service for personal or
business activities of the general public. The CB Radio Service
may also be used for voice paging.

Sec. 95.401 (CB Rule 2) How do I use these rules?

(a) You must comply with these rules (See CB Rule 21 Sec.
95.421, for the penalties for violations) when you operate a
station in the CB Service from:

Within or over the territorial limits of places where radio
services are regulated by the FCC (see CB Rule 5, Sec.
95.405);

Aboard any vessel or aircraft registered in the United
States; or

Aboard any unregistered vessel or aircraft owned or
operated by a United States citizen or company.

(b) Your CB station must comply with technical rules found in
subpart E of part 95.

(d) Where the rules use the word "person," the rules are
concerned with an individual, a corporation, a partnership, an
association, a joint stock company, a trust, a state, territorial
or local government unit, or other legal entity.

(e) Where the rules use the term "FCC", that means the Federal
Communications Commission.

(f) Where the rules use the term "CB station", that means a
radio station transmitting in the CB Radio Service.

Sec. 95.403 (CB Rule 3) Am I eligible to operate a CB
station?

You are authorized to operate a CB station unless:

(a) You are a foreign government, a representative of a foreign
government, or a federal government agency; or

(b) The FCC has issued a cease and desist order to you, and
the order is still in effect.

Sec. 95.404 (CB Rule 4) Do I need a license?

You do not need an individual license to operate a CB station.
You are authorized by this rule to operate your CB station in
accordance with the rules in this subpart.

FCC

CITIZENS

BAND

INFORMA

TION

FCC Citizens Band Information 203

vidson.com to check for the latest version.

1167684

Figure 138. Low Tire Pressure Alert

TRIP SUMMARY

This screen summarizes a current trip (average speed, distance
traveled, fuel used, start and end times and length of time).

1154895

Average speed/MPG

Distance traveled

Fuel used/stops

Destination arrival date

Time spent traveling

Destination start date

Figure 139. Trip Summary Screen

202 Information (Vehicle Status)

vidson.com to check for the latest version.

Reset Factory Headset Settings...................................185
Fault Reset...................................................................185

Citizen Band (CB) Radio....................................................186

FAVORITES

Favorites............................................................................193
Setting a Favorite...............................................................193
Selecting a Favorite...........................................................193

OTHER FEATURES

Waiting Popup....................................................................195
Next Letter Jumping...........................................................195

Popups...............................................................................196
Quick Keys.........................................................................196

Quick Jump..................................................................196
High Contrast...............................................................197

Projection Mode.................................................................197

INFORMATION (VEHICLE STATUS)

Vehicle Status....................................................................199
Information.........................................................................199
Engine Information.............................................................199

Reset Last Service.......................................................200

Tire Pressure Monitoring System (TPMS).........................200

Low Tire Pressure Alert................................................201

Trip Summary.....................................................................202

FCC CITIZENS BAND INFORMATION

What Every Responsible Citizens Band (CB) Station Operator
Should Know as Prepared by the Federal Communications
Commission, Washington, D.C..........................................203

Subpart D-Citizens Band (CB) Radio Service General
Provisions.....................................................................203
How to Operate a CB Station.......................................205
Other Things You Need to Know..................................211

TABLE OF CONTENTS

VIII

LIMITED RADIO WARRANTY

2019 LIMITED RADIO WARRANTY..................................215

Other Rights.................................................................216

LIMITED RADIO WARRANTY (AUSTRALIA)

WARRANTY.......................................................................217

Your Consumer Rights.................................................217

Warranty.......................................................................217
Warranty Period............................................................217
Exclusions....................................................................218
Obtaining Warranty Service..........................................218

APPENDIX

H-D U.S.A., LLC Trademark Information...........................219
Product Registered Marks..................................................219

TABLE OF CONTENTS

YOUR OWNER'S MANUAL

This manual has been prepared to acquaint you with the
operation, care and maintenance of your motorcycle. It also
provides important safety information. Follow these instructions
carefully for maximum motorcycle performance and for your
personal motorcycling safety and pleasure.

Your owner's manual contains instructions for operation and
minor maintenance. Major repairs are covered in the
Harley-Davidson service manual. Major repairs require the
attention of a skilled technician and the use of special tools
and equipment. Your Harley-Davidson dealer has the facilities,
experience and Genuine Harley-Davidson parts necessary to
render this valuable service. We recommend that any emission
system

maintenance

performed

authorized

Harley-Davidson dealer.

Harley-Davidson reserves the right to change specifications,
equipment or designs at any time without notice and without
incurring obligation.

This owner's manual should be considered a permanent part
of the motorcycle and should remain with the motorcycle if it
is resold.

CUSTOMER SERVICE ASSISTANCE

Most sales or service issues are resolved at the dealership.

Discuss your problem with the appropriate personnel at
the dealership in the Sales, Service or Parts area. If that
proves unsuccessful, speak to the owner of the dealership
or the general manager.

If you cannot resolve the issue with the dealership, contact
the

Harley-Davidson

Customer

Support

Center.

Harley-Davidson

Motor

Company

Attention:

Harley-Davidson Customer Support Center P.O. Box 653
Milwaukee, Wisconsin 53201 1-800-258-2464 (U.S. only)
1-414-343-4056

For

customers

outside

the

US,

contact

your

local

Harley-Davidson market office, call 1-414-343-4056 or visit
harley-davidson.com.

INTRODUCTION

Introduction 1

Table 1. Vehicle and Personal Data

DEALER INFORMATION

PERSONAL INFORMATION

Date of Purchase:

Name:

Address:

Sales Contact:

Vehicle Identification Number:

Service Contact:

Key Number:

2 Introduction

SAFETY DEFINITIONS

Statements in this manual preceded by the following words are
of special significance:

WARNING

WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury. (00119a)

CAUTION

CAUTION indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
(00139a)

NOTICE

NOTICE indicates a potentially hazardous situation which,
if not avoided, may result in property damage. (00140b)

NOTE

Refers to important information and is placed in italic type. It
is recommended that you take special notice of these items.

SAFETY INFORMATION

WARNING

Set volume levels and other controls on audio and
electronic devices before riding. Distractions can lead to
loss of control, resulting in death or serious injury.
(00088b)

WARNING

Set CB channel, squelch threshold and volume before
riding to minimize adjustments on the road. Distractions
can lead to loss of control, resulting in death or serious
injury. (00089a)

WARNING

Do not select a volume level that blocks out traffic noise
or interrupts the concentration necessary for safe
operation of the motorcycle. Distractions or a volume level
that blocks out traffic noise could cause loss of control
resulting in death or serious injury. (00539b)

NOTICE

There are no serviceable parts inside the unit; leave all
servicing to qualified service personnel. Disassembly of
the unit could result in equipment damage and/or
equipment malfunction. (00172a)

SAFETY

FIRST

Safety First 3

This manual explains the operation of the Boom!™ Box
Infotainment system. Investing time to learn about the features
and operation of your motorcycle and its infotainment system
will lead to safe enjoyable use of its full range of features. Read
this manual carefully and keep it with your motorcycle at all
times for reference. An online copy of this manual is available
at serviceinfo.harley-davidson.com.

See the owner's manual for your vehicle for important rider
safety information.

Follow all the warnings, cautions and safety tips shown
throughout this manual and your vehicle manual.

See Figure 1. Do not use any feature of this system to the
extent it becomes a distraction and prevents safe riding. The
first priority while riding should always be the safe operation
of the vehicle. While riding, observe all traffic regulations.

NOTE

The acceptance screen will clear after 15 seconds if ACCEPT
is not selected.

Pay attention while riding. Always concentrate on riding by
keeping your eyes and mind on the road. To prevent distraction,
some features are locked out, unavailable or limited in capability
while the motorcycle is in motion. Even if a feature is available,
do not allow it to distract you from operating the motorcycle
safely.

For safety, program the system when stopped. Perform system
setup and get familiar with the controls and features of the
infotainment system before operating the motorcycle on the
road.

This system cannot warn about such things as the safety of an
area, road conditions and availability of emergency services.

Use this system only in locations where it is legal to do so.

For additional instruction and information for setting up or
operating the system, see an authorized Harley-Davidson
dealer and online resources at serviceinfo.harley-davidson.com.

1154098

Figure 1. Warning and Acceptance

4 Safety First

NAVIGATION

The navigation, lane guidance and traffic features are intended
to assist you when traveling. Always use personal judgment
and observation of the actual road conditions while riding. In
some circumstances, information provided in the navigation
database may be incomplete, incorrect or outdated. Road
conditions, traffic laws and restrictions (such as no left turns,
street closures, one way streets, road construction detours,
and so on) can frequently change. Before following any
instruction from the system, check whether the instruction can
be done safely and legally.

If necessary, safely park the vehicle if there is difficulty following
the route guidance or if there is a need to program a new route.
In some circumstances, the system could temporarily provide
an inaccurate position of the vehicle or show errors in distance
between objects.

When importing routes from other devices or websites,
understand that there may be limitations to the accuracy or
reliability of the imported data. There may also be compatibility
limitations when importing data files from another device or
website.

Program and review navigation routes with the vehicle stopped.
When taking a long trip, plan and review the route before riding
the motorcycle. Install updates to the navigation database to
make sure you have the latest information available.

PRE-RIDE CHECKLIST

To make full use of features and minimize distraction while on
the road, configure the system with your personal preferences
before riding.

• Set brightness, background color and day/night color mode.

• Configure presets and favorites.

• Adjust

audio

settings

(volume,

tone,

fade

and

headset/speaker selection).

• Pair, connect and set up phone features through Bluetooth.

• Connect USB devices.

• Select station or media.

• Set up rides and navigation.

• Set up CB and intercom.

• Connect and put on headsets.

EMERGENCY PHONE NUMBER

Setting up an emergency phone number can provide access
to help when needed. See Making a Call (Page 115).

Phone numbers and navigation to nearby emergency resources
are also available on equipped systems. See Route (Page 142).

Safety First 5

EMERGENCY CB OPERATION

For vehicles equipped with a CB, channel 9 is reserved for
emergency use in most countries. When using this channel for
emergencies or assistance, clearly identify the nature of the
problem and your location. If no response is received, try other
channels or find another way to get help.

THERMAL POWER DOWN

See Figure 2. If a thermal issue is detected by the radio, a
warning screen displays

Radio Temperature Too High,

Shutting Down

. System shutdown will start automatically 15

seconds after the screen first displayed the warning.

Allow a five minute cool down period. Restart the radio. If the
restart fails, allow a longer cooling period.

1174396

Figure 2. Thermal Shut Down Screen

6 Safety First

Content .. 1 2 ..

///////////////////////////////////////
