Figure B-13.

Main Harness 1 of 3: 2013 Softail (FXS/B)

ACC

OFF

IGN

BN
TN

W/BE

W/BK

BE/W

BE/O

CAN Low

CAN High

High Beam Indicator

Battery Fuse

Neutral Indicator

Ground

Oil Pressure Indicator

Fuel Level

Left Turn Indicator

Right Turn Indicator

Ignition

Switch

Speedometer

W/R

W/BK

W/R

W/O

W/Y

R/O

BE/PK

BK/GN

BE/W

R/BN

BE/O

7 8 4 5 6 2 1 3

Left Turn Indicator

High Beam Indicator

Oil Pressure Indicator

Right Turn Indicator

Neutral Indicator

Battery Fuse

Indicator

Lamps

Fuel Pump Power

Fuel Level Sender

Sender Ground

Pump Ground

Front WSS High

Front Fuel Injector

Running Lights Power

Fuel Level

System Power

Sender Ground

Front WSS Low

Fuel

Pump

W/O

R/O

W/R

R/O

BE/PK

GN/Y

BK/GN

BE/BK

BK/GN

BE/PK

BK/GN

BE/PK

BK/GN

Sensor

See Front Lighting

And Hand Controls

See Front Lighting

And Hand Controls

[31A]

[22A-2]

Rear

Fuel Injector

R/GN

BK/W

GY/Y

DLC

Fuse

Block

Ignition

Coil

[64B]

W/R

W/BK

R/BE

BE/R

P&A

15A

Battery

15A

Main

40A

R/Y

R/O

R/BE

R/GN

B C D

GN/BE

GY/BE

LGN/BN

LGN/V

GN/GY

GN/V

R/W

W/R

R/W

TPS

B C

MAP Sensor

Active Intake

See

Main

Har

ness

3):

FXS

and

FLS

IAT

IAC

B C D

B C

B C D

BK/W

R/GN

GY/O

GN/O

GN/W

GY/W

B C D

800

200

BK/W

W/BK

BE/O

W/GY

R/Y

R/O

R/W

O/BE

BE/Y

BE/W

BK/O

O/BK

BE/R

R/BN

W/BE

W/GY

W/BK

[22A-1]

[33B]

[33A]

[39B]

[39A]

[21B]

[21A]

W/BK

BE/Y

BE/W

O/BE

O/BK

W/R

W/Y

See Front

Lighting

And Hand

Controls

Fuel

Gauge

R/O

See Front

Lighting

And Hand

Controls

Front

Fuel

Injector

Front
WSS
(ABS
Only)

R/GN

GN/Y

[24A]

[38A]

Sensor

Rear

Ignition

Coil

System

Rear

Fuel

Injector

Sensor

Ground

ION

Sense

ront

Ignition

Coil

LGN/BK

LGN/Y

LGN/O

LGN/GY

LGN/BE

GY/BN

GN/BN

BE/BK

GND 1

R/GN

[91A]

[88A]

[88B]

[178A]

[178B]

[89A]

[89B]

[80A]

[80B]

[87A]

[87B]

[84B]

[84A]

[117B]

[117A]

[83B]

[83A]

[90B]

[90A]

[85B]

[85A]

High

Map

Input

Sensor

System

Activ

Intak

Sensor

Ground

Sensor

Ground

ACR

[203FA]

[203FB]

System

ACR

[203RA]

[203RB]

System

Sensor

Ground

TPS

9 10 13 14 15 16 17 18

9 10 11 12 13 14 15

Rear

Ignition

Coil

ront

Ignition

Coil

ront

HO2

Heater

Ground

VSS

Input

ront

Fuel

Injector

Rear

Fuel

Injector

Map

Input

JSS

Signal

ION

Sense

Ground

CAN

High

Rear

HO2

Heater

Ground

CKP

Sensor

High

ront

HO2

Sensor

High

CKP

Sensor

Activ

Intak

Exhaust

Actuator

Enab

Purge

Solenoid

Sensor

Ground

Sensor

Ground

High

Exhaust

eedbac

TPS

16 17 18

9 10 11 12 13 14 15 16 17 18

System

Rear

HO2

Sensor

Batter

Fuse

ECM

[78B-1]

[78A-1]

[78B-2]

[78A-2]

[20B]

[20A]

BK/PK

LGN/BE

LGN/BK

LGN/GY

GN/GY

GN/BE

LGN/BN

LGN/V

LGN/O

LGN/R

LGN/Y

R/W

R/O

W/R

GN/BN

GY/BE

BK/GN

GY/BN

R/GN

BK/O

GY/W

GY/Y

GN/W

W/BK

GN/O

GN/V

BK/W

GY/O

GN/Y

BK/PK

LGN/R

R/GN

[141B]

[141A]

[167B]

[167A]

et00581

Figure B-14. Main Harness 2 of 3: 2013 Softail (FLS)

Figure B-14.

Main Harness 2 of 3: 2013 Softail (FLS)

R/BK

GY/BN

BK/W

R/GR

Starter

Solenoid

[128B]

[128A]

Rear

Brake

Switch

BE/GN

Oil

Pressure

Switch

W/O

Neutral

Switch

[131B-2]

[131A-2]

[131B-1]

[131A-1]

[122B-1]

[122A-1]

[254B]

[254A]

[122B-2]

[122A-2]

LGN/Y

BK/GN

B C

VSS

[65B]

[65A]

R/W

Purge

Solenoid

[95B]

[95A]

[166B]

[166A]

R/GN

LGN/BK

JSS

[133A]

[133B]

[120A]

[120B]

LGN/GY

R/W

3 4

BE/R

BE/V

BE/BN

BK/GN

A3 A4 B2 C3 C4 D2 D3 E2 E3 E4 F3

G4 H2

K2 K3 K4 L2 L3

M2 M3 M4

Star

Enab

Secur

ity

Antenna

Secur

ity

Antenna

Ignition

Switch

Input

Engine

Stop

Switch

Input

CAN

High

Neutr

Switch

Input

CAN

Oil

Pressure

Switch

Input

Hor

Switch

Input

Fuel

Pump

Ground

Secur

ity

Siren

Running

Light

Right

Rear

Signal

Light

Left

Rear

Signal

Star

ter

Solenoid

System

ront

Running/F

Light

PWR

Accessor

High

Beam

Batter

BCM

Secur

ity

Antenna

High

A4 B2 C3 C4 D2 D3 E2 E3 E4 F3

G4 H2

ront

Right

Signal

ront

Left

Signal

J4 K2 K3 K4 L2 L3

L4 M2 M3 M4

BE/R

BE/O

BE/GN

BK/GN

BE/BK

BE/V

BE/BN

BE/PK

R/BN

R/GN

R/BK

W/BE

W/GY

R/V

W/BK

BE/W

BE/Y

W/GN

W/R

R/Y

W/O

[259A]

[259B]

[255A]

[255B]

[179A]

[179B]

[242A]

[242B]

[209A]

[209B]

[168A]

[168B]

Rear WSS

(ABS Only)

O/BN

O/PK

Rear HCU

(ABS Only)

B C D

O/Y

O/V

O/W

Active

Exhaust

LGN/O

LGN/BE

R/GN

Security

Antenna

Battery

Starter

Stud

Front

HO2 Sensor

CKP

Sensor

[79A]

[79B]

BK/W

GN/BN

BK/GN

W/GN

R/O

Front HCU

(ABS Only)

Horn

O/GN

O/GY

O/R

R/V

(ABS Only)

ECU

ront

HCU

ront

HCU

Apply

ront

HCU

Release

ront

WSS

Ground

Rear

HCU

Release

Rear

HCU

Apply

Rear

HCU

Batter

Rear

WSS

Rear

WSS

High

ront

WSS

High

CAN

High

CAN

Batter

O/GN

O/BN

O/GY

O/BK

O/PK

O/BE

W/BK

O/R

O/W

W/R

O/Y

O/V

W/R

BK/W

W/BK

W/GY

R/Y

R/O

R/W

O/BE

BE/Y

BK/O

BE/W

BE/O

O/BK

BE/R

R/BN

W/BE

LGN/BK

LGN/Y

LGN/O

LGN/GY

LGN/BE

GY/BN

GN/BN

BE/BK

BK/PK

BE/PK

GND 2

GND 1

Voltage

Regulator

Stator

[77A]

[77B]

[47B]

[47A]

See Rear Lighting

See

Main

Har

ness

(1
or
2

of
3):

FXS

/B
or
FLS

[121A-2]

[121B-2]

[121A-1]

[121B-1]

Security Siren

(Optional)

[142B]

[142A]

[137B]

[137A]

[142B]

[142A]

W/GN

R/O

(If

Equipped)

Anti-theft

Tracking Module

Signal

Ground

Star

Enab

Not

Used

Not

Used

R/O

W/GN

[266B]

[266A]

Secur

ity

Antenna

Secur

ity

Antenna

High

Front O2 Heater
Ground

5V Sensor Power

JSS Signal

Sensor Ground

CKP Sensor Low

CKP Sensor High

Oil Pressure Switch
Input

System Power

5V Sensor
Ground

Front O2 Sensor

System

ront

HCU

ront

HCU

Apply

ront

HCU

Release

Ground

Exhaust

eedbac

Exhaust

Actuator

Ground

Hor

Rear

HCU

Release

Rear

HCU

Apply

Rear

HCU

Star

ter

Solenoid

System

Sensor

VSS

Input

Ground

Purge

Solenoid

Secur

ity

Siren

Ground

Rear

WSS

Rear

WSS

High

[19A]

3 4

[40A]

Rear HO2

Sensor

System

Rear

Heater

Ground

Rear

Sensor

Ground

[18A]

[138B]

[138A]

et00582

Figure B-15. Main Harness 3 of 3: 2013 Softail (FXS/B and FLS)

Figure B-15.

Main Harness 3 of 3: 2013 Softail (FXS/B and FLS)

LP/

Stop/Tail

Canada

R/Y

[40B]

[18B] & [19B] - FXS/B

DOM

[18B]

[40B]

[19B]

HDI

Left Rear
LED STT

Right Rear

LED STT

[18B] & [19B] - FLS

Left & Right

Rear STT

Left & Right

Rear STT

Left & Right

Rear STT

Left & Right

Rear STT

[18B] & [19B] - FLS

[40B]

[18B] & [19B] - FXS/B

O/W

Right Rear
Directional

Lamp

1
2
3
4

5
6
7

4
3
2
1

1
2

Left Rear

Directional

Lamp

1
2

Stop/Tail

Lamp

HDI

Only

Rear Lighting

FLSTC,FLSTF/B

FLSTN

See

Main Harness

(2 Of 2)

See

Main Harness

(2 Of 2)

See

Main Harness

(2 Of 2)

FXST

4
3
2
1

[19B]

[19A]

[7B]

[18B]

[18A]

[40B]

[40A]

BK/BN

BE/BN
BE/BK

BE/BK

BE/BN
BK/BN

BK/V

BE/V

BE/R

BK/V

BE/V

O/W

R/Y

1
2
3

5
6
7

[7B]

BE/BN
BE/BK
BE/V

BE/R

Tail Lamp

Tail

HDI Only

Tail

HDI Only

Fendertip Lamp

Only Available On DOM FLSTC

Left Rear

Directional

Lamp

Brake Light

Tail

DOM Only

Tail

DOM Only

1
2

1
2
3

1
2

1
2
3

1
2

4
3
2
1

Right Rear
Directional

Lamp

Left Rear

Directional

Lamp

Brake Light

Tail Lamp

1
2

1
2
3

1
2

4
3
2
1

Right Rear
Directional

Lamp

[18A]

[18B]

[19B]

[18B]

[19A]

[18A]

[93B]

[93A]

O/W

R/Y

O/W

R/Y

O/W

R/Y

O/W

R/Y

[93B]

[93A]

[45A]

[45B]

[19A]

[94B]

[94A]

[94B]

[94A]

BE/V

BE/R

BE/BN

BE/BK

1
2
3

5
6
7

[7B]

BE/BN
BE/BK
BE/V

BE/R

BE/V

BE/R

BE/BN

BE/BK

et00583

Figure B-16. Rear Lighting: 2013 Softail

Figure B-16.

Rear Lighting: 2013 Softail

TABLE OF CONTENTS

SUBJECT

............................................................................................................................

PAGE NO.

APPENDIX

ABS

C.1

FASTENER TORQUE VALUES

FASTENER TORQUE VALUES IN THIS
CHAPTER

The table below lists torque values for all fasteners presented
in this chapter.

NOTES

TORQUE VALUE

FASTENER

C.5 ABS BRAKE LINES, HCU to Front Brake Cal-
iper

4.1-5.4 Nm

36-48

in-lbs

ABS front brake line 90 degree fitting bolt

C.3 HYDRAULIC CONTROL UNIT (HCU), Front
Hydraulic Control Unit (HCU)

13.6-16.3 Nm

120-144

in-lbs

Banjo bolts to front HCU

C.3 HYDRAULIC CONTROL UNIT (HCU), Rear
Hydraulic Control Unit (HCU)

13.6-16.3 Nm

120-144

in-lbs

Banjo bolts to rear HCU

C.5 ABS BRAKE LINES, HCU to Front Brake Cal-
iper

23.1-29.9 Nm

17-22 ft-lbs

Banjo bolt to front caliper

C.5 ABS BRAKE LINES, Front Master Cylinder to
Front HCU

23.1-29.9 Nm

17-22 ft-lbs

Banjo bolt-to-front master cylinder

C.5 ABS BRAKE LINES, Front Master Cylinder to
Front HCU

13.6-16.3 Nm

120-144

in-lbs

Banjo bolt to HCU

C.5 ABS BRAKE LINES, HCU to Front Brake Cal-
iper

13.6-16.3 Nm

120-144

in-lbs

Banjo bolt to HCU

C.5 ABS BRAKE LINES, Rear HCU to Rear Brake
Caliper

13.6-16.3 Nm

120-144

in-lbs

Banjo bolt to HCU

C.5 ABS BRAKE LINES, Rear HCU to Rear Brake
Caliper

23.1-29.9 Nm

17-22 ft-lbs

Banjo bolt to rear caliper

C.5 ABS BRAKE LINES, Rear Master Cylinder to
Rear HCU

13.6-16.3 Nm

120-144

in-lbs

Banjo bolt to rear HCU

C.5 ABS BRAKE LINES, Rear Master Cylinder to
Rear HCU

23.1-29.9 Nm

17-22 ft-lbs

Banjo bolt to rear master cylinder

C.3 HYDRAULIC CONTROL UNIT (HCU), Rear
Hydraulic Control Unit (HCU)

5.0-10.0 Nm

36-72

in-lbs

HCU, rear, bracket screws

C.3 HYDRAULIC CONTROL UNIT (HCU), Rear
Hydraulic Control Unit (HCU)

2.7-4.7 Nm

24-42

in-lbs

HCU, rear, clamp screw

C.3 HYDRAULIC CONTROL UNIT (HCU), Front
Hydraulic Control Unit (HCU)

6.1-9.5 Nm

54-84

in-lbs

HCU screws, lower front

C.3 HYDRAULIC CONTROL UNIT (HCU), Front
Hydraulic Control Unit (HCU)

2.7-4.1 Nm

24-36

in-lbs

HCU screws, rear cover to front

C.3 HYDRAULIC CONTROL UNIT (HCU), Front
Hydraulic Control Unit (HCU)

5.4-8.1 Nm

48-72

in-lbs

HCU screws, upper front

C.4 WHEEL SPEED SENSORS, Rear Wheel
Speed Sensor

4.1-5.4 Nm

36-48

in-lbs

Splash guard screw

C.2 ELECTRONIC CONTROL UNIT
(ECU), Installation: All But FXSB

4.1-5.4 Nm

36-48

in-lbs

Splash guard screw: all but FXSB

C.5 ABS BRAKE LINES, Rear Master Cylinder to
Rear HCU/Use LOCTITE 565 THREAD SEALANT

16.3-20.3 Nm

12-15 ft-lbs

Stoplight switch, rear

C.5 ABS BRAKE LINES, Rear Master Cylinder to
Rear HCU

40.6-47.4 Nm

30-35 ft-lbs

Stoplight switch bracket fastener

HOME

2013 Softail Service: Appendix C ABS C-1

C.2

ELECTRONIC CONTROL UNIT (ECU)

REMOVAL: ALL BUT FXSB

Remove seat.

To prevent accidental vehicle start-up, which could cause
death or serious injury, remove main fuse before pro-
ceeding. (00251b)

Disarm security system, if equipped and remove main
fuse.

Remove right side saddlebag, if present.

NOTE

Rear wheel may have to be raised slightly to allow for splash
guard removal.

Remove splash guard.

See

Figure C-1

. Detach body control module (BCM) (1)

from electrical panel and remove both electrical con-
nectors.

See

Figure C-2

. Detach electronic control unit (ECU) (1)

from electrical panel and remove electrical connector.

INSTALLATION: ALL BUT FXSB

TORQUE VALUE

FASTENER

4.1-5.4 Nm

36-48

in-lbs

Splash guard screw: all but
FXSB

See

Figure C-2

. Connect ECU connector and install ECU

(1) onto electrical panel.

See

Figure C-1

. Connect both BCM connectors and install

BCM (1) onto electrical panel.

Install splash guard. Tighten splash guard screw(s) to
36-48

in-lbs

(4.1-5.4 Nm).

Install right side saddlebag, if removed.

Install main fuse.

Be sure that all lights and switches operate properly before
operating motorcycle. Low visibility of rider can result in
death or serious injury. (00316a)

Test for correct operation.

After installing seat, pull upward on seat to be sure it is
locked in position. While riding, a loose seat can shift
causing loss of control, which could result in death or
serious injury. (00070b)

Install seat.

sm06996

1. BCM
2. Purge solenoid connector receptacle
3. Security siren connector receptacle
4. Wheel speed sensor connector
5. Security siren

Figure C-1. Body Control Module (BCM): All But FXSB

HOME

C-2 2013 Softail Service: Appendix C ABS

sm06997

1. Electronic control unit (ECU)
2. Electrical panel fasteners

Figure C-2. Electrical Panel

REMOVAL: FXSB

Remove main fuse.

Remove rear wheel. See

2.5 REAR WHEEL

Remove splash guard.

See

Figure C-3

. Remove WSS connector (1).

Disconnect ECU connector.

Remove ECU (2) from panel.

INSTALLATION: FXSB

See

Figure C-3

. Install ECU (2).

Connect ECU connector.

Install WSS connector (1).

Install splash guard.

Install rear wheel. See

2.5 REAR WHEEL

Install main fuse.

sm07685

1. WSS connector
2. ECU

Figure C-3. ECU

HOME

2013 Softail Service: Appendix C ABS C-3

C.3

HYDRAULIC CONTROL UNIT (HCU)

FRONT HYDRAULIC CONTROL UNIT (HCU)

TOOL NAME

PART NUMBER

DIGITAL TECHNICIAN II

HD-48650

BASIC VACUUM BRAKE BLEEDER

SNAP-ON BB200A

TORQUE VALUE

FASTENER

2.7-4.1 Nm

24-36

in-lbs

HCU screws, rear cover to
front

6.1-9.5 Nm

54-84

in-lbs

HCU screws, lower front

5.4-8.1 Nm

48-72

in-lbs

HCU screws, upper front

13.6-16.3 Nm

120-144

in-lbs

Banjo bolts to front HCU

Removal

Disconnect front HCU electrical connector.

NOTE

For best results, use the BASIC VACUUM BRAKE BLEEDER
(Part No. Snap-On BB200A) or equivalent tool to drain the
brake systems.

Drain front brake system.

NOTE

Plug open HCU ports and seal banjo fittings to prevent leakage
and contamination.

See

Figure C-4

. Remove banjo bolts (6) to release brake

lines from front HCU. Discard sealing washers.

Remove screws (4, 7, 11) and separate front HCU (13)
from front and rear covers (8, 12).

Installation

See

Figure C-4

. Place rear cover (12) on front HCU (13)

and secure with screws (11). Tighten screws to 24-36

in-lbs

(2.7-4.1 Nm).

Attach electrical connector to front HCU (13).

Place front cover (8) into position and secure with screws
(4, 7). Tighten screws to the following torque specs.

Screws (7) to 54-84

in-lbs

(6.1-9.5 Nm).

Screws (4) to 48-72

in-lbs

(5.4-8.1 Nm).

Install banjo bolts (6) with

new

sealing washers (5).

Tighten to 120-144

in-lbs

(13.6-16.3 Nm).

When any hydraulic brake component, line or connection
is loosened or replaced on an ABS motorcycle, Digital
Technician II must be used during the brake bleeding
procedure to verify all air is removed from the system.
Failure to properly bleed the brake system could adversely
affect braking, which could result in death or serious injury.
(00585c)

Fill and bleed brake systems. See

2.15 BLEEDING

BRAKES

NOTE

For best results, use the BASIC VACUUM BRAKE BLEEDER
(Part No. Snap-On BB200A) or equivalent tool.

To confirm that the brake systems are properly connected
and air is completely purged, install master cylinder
reservoir covers, connect motorcycle to DIGITAL TECH-
NICIAN II (Part No. HD-48650) and perform "ABS Service"
procedure in the "Tool Box" menu.

After repairing the brake system, test brakes at low speed.
If brakes are not operating properly, testing at high speeds
can cause loss of control, which could result in death or
serious injury. (00289a)

Test brake system.

Turn ignition switch ON. Pump brake hand lever to
verify operation of the brake lamp.

Test ride the motorcycle. If the brakes feel spongy,
bleed the system again.

HOME

C-4 2013 Softail Service: Appendix C ABS

sm06941

1. Master cylinder-to-front HCU line
2. Clip (3)
3. Front HCU-to-caliper line
4. Screw (2)
5. Sealing washer (4)
6. Banjo bolt (2)
7. Screw (2)
8. Front cover
9. Clip (2)
10. Bracket
11. screw (2)
12. Rear cover
13. Front hydraulic control unit

Figure C-4. Front Hydraulic Control Unit

REAR HYDRAULIC CONTROL UNIT (HCU)

TOOL NAME

PART NUMBER

DIGITAL TECHNICIAN II

HD-48650

BASIC VACUUM BRAKE BLEEDER

SNAP-ON BB200A

TORQUE VALUE

FASTENER

5.0-10.0 Nm

36-72

in-lbs

HCU, rear, bracket screws

2.7-4.7 Nm

24-42

in-lbs

HCU, rear, clamp screw

13.6-16.3 Nm

120-144

in-lbs

Banjo bolts to rear HCU

Removal

Remove electrical panel. See

7.3 ELECTRICAL PANEL

Disconnect rear HCU electrical connector.

NOTE

For best results, use the BASIC VACUUM BRAKE BLEEDER
(Part No. Snap-On BB200A) or equivalent tool to drain the
brake systems.

Drain rear brake system.

NOTE

Plug open HCU ports and seal banjo fittings to prevent leakage
and contamination.

See

Figure C-5

. Remove banjo bolts (6) to release brake

lines from rear HCU. Discard sealing washers.

Remove screw (9), clamp (10), and rear HCU (11).

Installation

See

Figure C-5

. If bracket (1) was removed, install bracket

with washers (2) and screws (3). Tighten screws to 36-72

in-lbs

(5.0-10.0 Nm).

Install rear HCU, and secure with clamp (10) and screw
(9). Tighten screw to 24-42

in-lbs

(2.7-4.7 Nm).

Attach electrical connector to rear HCU (11).

Loosely install banjo bolts (6) with

new

sealing washers

(5).

Install alignment cover (7) over banjo bolts.

Tighten banjo bolts to 120-144

in-lbs

(13.6-16.3 Nm).

See

Figure C-6

. Verify both brake lines at rear HCU are

properly positioned.

Fill and bleed brake systems. See

2.15 BLEEDING

BRAKES

NOTE

For best results, use the BASIC VACUUM BRAKE BLEEDER
(Part No. Snap-On BB200A) or equivalent tool.

Install electrical panel. See

7.3 ELECTRICAL PANEL

10. To confirm that the brake systems are properly connected

and air is completely purged, install master cylinder
reservoir covers, connect motorcycle to DIGITAL TECH-
NICIAN II (Part No. HD-48650) and perform "ABS Service"
procedure in the "Tool Box" menu.

HOME

2013 Softail Service: Appendix C ABS C-5

11. Test brake system.

Turn ignition switch ON. Pump brake foot pedal to
verify operation of the brake lamp.

Test ride the motorcycle. If the brakes feel spongy,
bleed the system again.

sm06946

1. Bracket
2. Washer (2)
3. Screw (2)
4. Sealing washer (4)
5. Rear HCU-to-caliper line
6. Banjo bolt (2)
7. Alignment cover
8. Master cylinder-to-rear HCU line
9. Screw
10. Clamp
11. Rear HCU

Figure C-5. Rear Hydraulic Control Unit (HCU)

sm07072

1. Rear HCU-to-caliper line
2. Master cylinder-to-rear HCU line
3. Rear HCU
4. Alignment cover

Figure C-6. Rear HCU Fittings Properly Installed

HOME

C-6 2013 Softail Service: Appendix C ABS

C.4

WHEEL SPEED SENSORS

FRONT WHEEL SPEED SENSOR

Removal

NOTE

Fuel tank crossover hose does not need to be disconnected.
Once all other connections to fuel tank have been removed,
fuel tank can be slid back enough to reveal handlebar switch
assembly connectors.

Slide fuel tank rearward. See

4.6 FUEL TANK

See

Figure C-7

Figure C-8

. Disconnect front WSS

connector (1).

See

Figure C-9

. Cut cable straps (1) and remove clips (3)

to release front wheel speed sensor cable from brake
hose.

All but FLSTC:

Remove clip (2).

FLSTC:

Cut cable straps (4).

See

Figure C-10

. Remove front wheel speed sensor clip.

Retract axle until front wheel speed sensor is free. See

2.4 FRONT WHEEL

NOTE

The wheel speed sensor works in conjunction with the ABS
encoder bearing installed in the wheel hub. If necessary, see

2.8 SEALED WHEEL BEARINGS

for removal and installation

instructions.

ed03156

1. Front WSS [167]
2. Left hand control [24]
3. Headlamp [38]
4. Auxiliary lamp switch [109]

Figure C-7. Under Fuel Tank Left Side: FXS

sm07179a

1. Instruments [20]
2. Left hand control [24]
3. Fuel gauge [117]
4. Front wheel speed sensor [167]
5. Headlamp [38]
6. Front fender tip lamp [32]: FLSTC

Figure C-8. Under Fuel Tank Left Side

sm07056

1. Cable strap (2)
2. Clip: all but FLSTC
3. Clip (3)
4. Cable strap: FLSTC (2)

Figure C-9. WSS Cable Rounting

HOME

2013 Softail Service: Appendix C ABS C-7

sm07049

Figure C-10. Front Wheel Speed Sensor Cable Clip

Installation

NOTES

•

Always keep the wheel speed sensor and ABS encoder
bearing away from magnetic fields. Items such as magnetic
parts trays, magnetic base dial indicators, alternator rotors,
etc. will damage sensor. Never pull wheel speed sensor
cable taut or use to retain wheel, axle or other compon-
ents.

•

Install wheel speed sensor with index pin on the outboard
side or sensor will be damaged during installation.

Push axle through

new

front wheel speed sensor and left

fork slider.

Secure front wheel. See

2.4 FRONT WHEEL

. Be sure to

rotate front wheel speed sensor until index pin makes
contact with shoulder on fork slider as shown in

Figure C-11

See
