Fig. 199: Installing Clutch Slave Cylinder
Courtesy of FORD MOTOR CO.

INSTALLATION

TRANSMISSION

Special Tool(s)



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission - F150 Pickup



Fig. 200: Identifying Special Tool(s)
Courtesy of FORD MOTOR CO.

All Vehicles

1. Using the special tool, raise and position the transmission.

2. Install the six engine-to-transmission bolts.



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission - F150 Pickup



Fig. 201: Installing Engine-To-Transmission Bolts
Courtesy of FORD MOTOR CO.

3. Install the two engine oil pan-to-transmission bolts.



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission - F150 Pickup



Fig. 202: Installing Engine Oil Pan-To-Transmission Bolts
Courtesy of FORD MOTOR CO.

4. Raise the transmission, then install the muffler and tail pipe into the exhaust hanger insulators.
