Ford E-350 (2012 year). Manual - part 8

When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system
will store the last one in the remaining presets.

RBDS: Available only in FM mode. This feature allows you to search
RBDS-equipped stations for a certain category of music format:
CLASSIC, COUNTRY, INFORM, JAZZ/RB, ROCK, etc.
To activate, press MENU repeatedly until RBDS (ON/OFF) appears in
the display. Use

to toggle RBDS ON/OFF. When RBDS is OFF,

you will not be able to search for RBDS equipped stations or view the
station name or type.

To search for specific RBDS music categories: When the desired
category appears in the display, press

to find the desired type,

then press and release

SEEK, SEEK

or press and hold SCAN to

begin the search.

To view the station name or type: When the desired category appears
in the display, press TEXT/SCAN to toggle between displaying the station
type (COUNTRY, ROCK, etc.) or the station name (WYCD, WXYZ, etc.).

BASS: Press MENU to reach the bass setting. Use

to adjust.

TREB (Treble): Press MENU to reach the treble setting. Use

adjust.

BAL (Balance): Press MENU to reach the balance setting. Use

to adjust the audio between the left (L) and right (R) speakers. Press
OK to close and return to the main menu.

FADE (If equipped with four speaker audio system): Press MENU
to reach the fade setting. Use

to adjust the audio between the

back (B) and front (F) speakers.

SPEED VOL (Speed sensitive volume, if equipped): Press MENU to
reach the SPEEDVOL setting. Radio volume automatically gets louder
with increasing vehicle speed to compensate for road and wind noise.
Use

to adjust.

The default setting is off; increasing your vehicle speed will not change
the volume level.

Adjust 1–7: Increasing this setting from 1 (lowest setting) to 7 (highest
setting) allows the radio volume to automatically change slightly with
vehicle speed to compensate for road and wind noise.

Recommended level is 1–3; SPEED OFF turns the feature off and level 7
is the maximum setting.

Entertainment Systems

TRACK/FOLDER MODE: Available only on MP3 discs in CD mode.

In track mode, press

SEEK, SEEK

to scroll through all tracks on

the disc.

In folder mode, press

SEEK, SEEK

to scroll through tracks

within the selected folder.

Press

FOLDER, FOLDER

to access the previous/next folder (if

available).

COMPRESS (Compression): Available only in CD/MP3 mode. Press

MENU until COMPRESS ON/OFF appears in the display. Use

toggle ON/OFF. When COMPRESS is ON, the system will bring the soft
and loud CD passages together for a more consistent listening level.

4. AUX: Press repeatedly to cycle
through LINE IN (auxiliary audio
mode), SYNC

威, SAT1, SAT2 and

SAT3 modes (satellite radio, if equipped).
For location and further information on auxiliary audio mode, refer to
Auxiliary input jack later in this chapter.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

5. SEEK: In radio mode,
press

to access the

previous/next strong station.

In CD mode, press

access the previous/next CD track.

In satellite radio mode (if equipped), press

SEEK, SEEK

seek to the previous/next channel. If a specific category is selected,
(Jazz, Rock, News, etc.), press

SEEK, SEEK

to seek to the

previous/next channel in the selected category. Press and hold

SEEK, SEEK

to fast seek through the previous /next channels.

In TEXT MODE, press

SEEK, SEEK

to view the

previous/additional display text.
In CATEGORY MODE, press

SEEK, SEEK

to select a

category.
Satellite radio is available only with a valid SIRIUS subscription.
Check with your authorized dealer for availability.

Entertainment Systems

(Play/Pause): This control is
operational in CD/MP3 mode. When
a CD/MP3 is playing, press to pause or play the current CD/MP3. The
CD/MP3 status will display in the radio display.

OK: Use in various menu selections.

7. SHUFFLE: Press SHUFFLE to
engage shuffle mode. SHUFFLE ON
will appear in the display. If you
wish to engage shuffle mode right away, press SEEK to begin random
play. Otherwise, random play will begin when the current track is
finished playing. CD SHUF will appear in the display.
To disengage, press SHUFFLE. SHUFFLE OFF will appear in the display.

Note: In track mode, all tracks on the current disc will shuffle in
random order. In MP3 folder mode, the system will randomly play all
tracks within the current folder.

8. FOLDER

: In folder mode,

press FOLDER

to access next

folder on MP3 discs, if available.

FOLDER: In folder mode,

press

FOLDER to access the

previous folder on MP3 discs, if
available.

10. FF (Fast forward): Press FF
to manually advance in a CD/MP3
track.

11. REW (Rewind): Press REW to
manually reverse in a CD/MP3 track.

12. Memory presets: To set a
station, select the desired frequency
band, AM, FM1 or FM2. Tune to the
desired station. Press and hold a preset button until sound returns and
PRESET # SAVED appears in the display. You can save up to 18 stations,
six in AM, six in FM1 and FM2.

Entertainment Systems

In satellite radio mode (if equipped), there are 18 available presets,
six each for SAT1, SAT2 and SAT3. To save satellite channels in your
memory presets, tune to the desired channel then press and hold a
preset control until sound returns.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

13. TEXT/SCAN: In radio and
CD/MP3 mode, press and hold for
a brief sampling of radio stations or
CD tracks. Press again to stop.
In MP3 mode, press and release to display track title, artist name, and
disc title.

In satellite radio mode (if equipped), press and release to enter
TEXT MODE and display the current song title. While in TEXT MODE,
press again to scroll through the current song title, artist, channel
category and the SIRIUS long channel name.

In TEXT MODE, sometimes the display requires additional text to be
displayed. When the “>” indicator is active, press SEEK

to view the

additional display text. When the “<” indicator is active, press

SEEK

to view the previous display text.

In satellite radio mode (if equipped), press and hold to hear a brief
sampling of the next channels. Press again to stop. In CATEGORY
MODE, press SCAN to hear a brief sampling of the channels in the
selected category. Press again to stop.
Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

14. AM/FM: Press to select
AM/FM1/FM2 frequency band.

15. ON/OFF/Volume: Press to turn
ON/OFF. Turn to increase/decrease
volume.

Note: If the volume is set above a
certain level and the ignition is
turned off, the volume will come back on at a “nominal” listening level
when the ignition switch is turned back on.

16. CD: Press to enter CD/MP3
mode. If a CD/MP3 is already loaded
into the system, CD/MP3 play will
begin where it ended last. If no CD is loaded, NO DISC will appear in the
display.

Entertainment Systems
