43

Frequently asked questions

  Reducing consumption / Fuel

   Question

   Answer

 How can I optimise my fuel consumption?

 Give preference to  AUTO  mode as it selects in the best way the "driving energy source" to
use in order to reduce fuel consumption.
 You should also adapt your driving style to the characteristics of hybrid vehicles to get the
best out of it, for example by taking your foot off the accelerator pedal rather than braking
and by anticipating decelerations which allows the recovery of "free" energy for charging
the battery (entering a built-up area, stop at traffic lights, stop at halt signs, ...).

 Why do I not manage to reduce my fuel consumption
even though I often drive in  ZEV  (Zero Emissions
Vehicle) mode?

 It is not  ZEV  mode but  AUTO  mode that is the most appropriate for reducing fuel
consumption, as it selects the best "driving energy source".
  ZEV  mode (100% electric running) can reduce fuel consumption in some cases. However,
recharging the traction battery has an energy cost.
 This is why we recommend using  AUTO  mode more often.

 Why does the fuel consumption histogram sometimes
display consumption of 28 mpg (10 litres/100 km) in
town?

 In traffic jams, the fuel consumption graph may temporarily display high values but, as the
distance covered is low, this has very little impact on the average fuel consumption.
 In urban driving, your Hybrid4 will remain more efficient in terms of fuel consumption
compared to a conventional vehicle.

 Why is my battery rarely fully charged?

 A partly charged battery is normal operation (4 to 5 bars on average in  AUTO  mode).
 This allows some capacity to be left free for the recovery of energy when decelerating.

 Why are there so may fuel alert messages when
starting to use the reserve?

 To encourage you to refuel as soon as possible and to avoid loosing the possibility of all
electric running.

  Air conditioning / Heating

   Question

   Answer

 It seems to me that the vehicle runs less on electric
when the heating or air conditioning is operating, is that
right?

 The demand for heating or air conditioning may require the starting of the HDi Diesel
engine until the desired level of comfort is attained.
 Normal operation of the Hybrid4 system is simply put back. The period can be longer
under very low or very high ambient temperatures.

 It seems to me that when it is very hot and the air
conditioning is working, the vehicle runs on electric for
shorter periods. Is that right?

 When it is hot, the periods when the HDi Diesel engine is put on standby and the vehicle
runs on electric are necessarily restricted in order to limit the difference between the
temperature in the vehicle and the level of comfort selected.
 In very hot weather, it is possible to press the " ECO OFF " button (which brings the vehicle
out of  ZEV  mode and prevents electric running or the stopping of the engine) to give
preference to temperature control (keeps the air conditioning running).

  Miscellaneous

   Question

   Answer

 Is towing possible with my Hybrid4 vehicle?

 For information on the towing ability of your Hybrid4 vehicle, refer to "Weights and towed
loads" in the "Technical data" section.
 This allows a jet ski or two-wheeler on a trailer to be towed, for example.
 This limit is related to maintaining adequate cooling capacity for the HDi Diesel engine as
well as the components of the Hybrid4 system that are also cooled by the engine's cooling
system.

 Why does engine braking seem so strong?

 If the high voltage battery is not fully charged, the engine braking results mainly from the
energy recovery by the electric motor. The power of this engine braking is higher than that
of an internal combustion engine.

45

Alphabetical index

Advice on driving ............................................ 23

Air conditioning .........................................22, 25

Bag hook ......................................................... 31

Back up starting .............................................. 18

Battery, 12 V ...................................................... 5

Battery, high voltage ........................5, 27-29, 39

Boot floor, removable ...................................... 31

Cable, high voltage ......................................... 28

Car wash ......................................................... 36

Cooling, high voltage battery .......................... 29

Defrosting ........................................................ 25

Demisting ........................................................ 25

Display screen, instrument panel ......... 8, 10, 13

Driving economically....................................... 24

Eco-driving  ..................................................... 24

ECO OFF (switch) ........................................... 22

Electric running (ZEV) ............ 11, 20, 22, 24, 25

Electronic key .......................................15, 17, 18

Emergency switching off ................................. 18

Energy flows ............................................. 10, 11

Energy recovery .................................... 9, 11, 24

Keyless Entry and Starting ..................15, 17, 18

Key not recognised ......................................... 18

Kit, temporary puncture repair ........................ 37

Filter, particle ........................................ 5, 26, 42

Fittings, boot ................................................... 31

Flat bed (recovery) .......................................... 38

Four-wheel drive (4WD) ................ 19, 21, 23, 38

Fuel consumption .................................. 9, 12, 24

Gearbox, electronic ...................5, 15, 23-25, 32

Gear selector, electronic gearbox .................. 32

Engine compartment ...................................... 30

Engine, Diesel .....................5, 19, 22, 25, 36, 40

Environment .................................................... 24

Opening the bonnet ........................................ 30

Ignition on........................................................ 17

Indicator, power................................................. 9

Instrument panel ............................................... 8

Head-up display .............................................. 16

Heating ......................................................22,  25

High voltage .............................................. 27, 28

Histogram, fuel consumption .......................... 12

Mode selector ......................................... 2, 7, 19

Motor, electric ....................................... 5, 19, 39

Parcel shelf, rear ............................................. 31

Parking brake, electric ........................15, 23, 36

Power indicator ............................................. 8, 9

Puncture .......................................................... 37

A

B

C

D

E

H

I

K

F

G

M

O

P

Ventilation, high voltage battery ..................... 29

Washing (advice)............................................. 36

Weights ........................................................... 41

Table of weights .............................................. 41

Tables: of engine, motor ...........................39, 40

Technical data ............................................39-41

Tools ................................................................ 37

Touch screen....................................... 10, 12, 14

Towed loads .................................................... 41

Towing eye ...................................................... 37

Triangle, warning............................................. 31

Trip computer ............................................. 12-14

Tyres ................................................................ 37

Selector, gear ............................................32, 36

Snow chains .................................................... 38

Speedometer .................................................... 8

Starting the Hybrid4 system ..................... 15, 18

State of charge, battery .................. 5, 10, 25, 27

Stop & Start ....................................... 4, 6, 11, 27

Storage ............................................................ 31

Switching off the Hybrid4 system ............. 15, 18

READY lamp .....................................8, 9, 28, 30

Recovery of the vehicle .................................. 38

Regeneration of the particle filter ............... 5, 26

Reset histogramme ......................................... 14

Reset trip ................................................... 13, 14

Retaining strap ................................................ 31

V

W

T

S

R

4Dconcept

Diadeis

Interak

08-15

 Labels are fi tted in various areas of your vehicle. They

carry safety warnings as well as vehicle identifi cation

information. Do not remove them: they form an integral part

of your vehicle.

  Automobiles CITROËN declares, by application of the

provisions of the European regulation (Directive 2000/53)

relating to End of Life Vehicles, that it achieves the

objectives set by this regulation and that recycled materials

are used in the manufacture of the products that it sells.

 Printed in the EU

 Anglais

  For any work on your vehicle, use a qualifi ed workshop

that has the technical information, competence and

equipment required, which a CITROËN dealer is able to

provide.

   Reproduction or translation of all or part of this document

is prohibited without written authorisation from Automobiles

CITROËN.

   We draw your attention to the following points:
   -  The fi tting of electrical equipment or accessories not

listed by CITROËN may cause faults and failures
with the electrical system of your vehicle. Contact
a CITROËN dealer for information on the range of
recommended accessories.

  -   As a safety measure, access to the diagnostic socket,

used for the vehicle's electronic systems, is reserved
strictly for CITROËN dealers or qualifi ed workshops,
equipped with the special diagnostic tool required (risk
of malfunctions of the vehicle's electronic systems that
could cause breakdowns or serious accidents). The
manufacturer cannot be held responsible if this advice is
not followed.

  -  Any modifi cation or adaptation not intended or

authorised by Automobiles CITROËN or carried out
without meeting the technical requirements defi ned by
the manufacturer would lead to the suspension of the
legal and contractual warranties.
