Citroen C3 (2017 year). Manual - part 18

Transversal-Citroen_en_Chap00_debut

AUDIO AND TELEMATICS GUIDE

Transversal-Citroen_en_Chap00_debut

On-line handbook

If the "MyCITROËN" function is not available on the CITROËN public

website for your country, you can ﬁ nd your handbook at the following

address:
http://service.citroen.com/ddb/

Find your handbook and the audio and telematic systems on the

CITROËN website, under "MyCITROËN".

Find your handbook and the audio and telematic systems on the

Select:

Select one of the following means of access to view your handbook on-

line...

the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of

registration of your vehicle.

Referring to the handbook on-line also gives you access to the latest

information available, easily identiﬁ ed by the bookmark, associated with

this symbol:

Audio and Telematics

CITROËN Connect Nav

GPS satellite navigation - Applications - Multimedia audio - Bluetooth

GPS satellite navigation - Applications - Multimedia audio - Bluetooth telephone

Contents

First steps

Steering mounted controls

Menus 6
Voice commands

Navigation

Connected navigation

Applications

Radio Media

Telephone 66
Settings

Frequently asked questions

The system is protected in such a way
that it will only operate in your vehicle.
Displaying of the

Energy Economy

Mode message signals that a change

to standby is imminent.

The different functions and settings
described vary according to the version
and configuration of your vehicle.

The link below gives access to OSS
(Open Source Software) codes for the
system.
http://www.psa-peugeot-citroen.com/oss

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the

vehicle stationary

and the ignition on.

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

Audio and Telematics

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen. All
of the touch areas of the screen are white.
Press the cross to go back a level.
Press "OK" to confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with
no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

12:13

18,5

21,5

23 °C

Audio and Telematics

  Select the audio source (depending on
version):
   -   FM / DAB *  / AM *  radio stations.
  -   USB memory stick.
  -

CD player.

- Media player connected via the auxiliary

socket (Jack, cable not supplied).

- Telephone connected by Bluetooth * using

Bluetooth * audio streaming.

* Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
- Reminder of the air conditioning

information and direct access to the
corresponding menu.

- Go directly to the selection of the audio

source, to the list of radio stations (or list of
titles depending on the source).

- Go to the message notifications, emails,

map updates and, depending on the
services, the navigation notifications.

- Go to the settings for the touch screen and

the digital instrument panel.

In very hot conditions, the volume may
be limited to protect the system. It may
go into standby (screen and sound off)
for at least 5 minutes.
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with
the possibility of entering a multitude
of settings (radio presets, audio
settings, navigation history, contact
favourites, ...); these settings are taken
into account automatically.

Audio and Telematics

Steering mounted controls

Media (short press): change the

multimedia source.

Telephone (short press): call.

Call in progress (short press):

access to telephone menu.

Telephone (long press): reject an

incoming call, end call, access to
telephone menu.

Decrease volume.

Voice commands :

Short press, system voice
commands.
Long press, smartphone voice
commands via the system.

Mute / Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one of
the two volume buttons.

Radio (rotate): automatic search for

the previous / next station.

Media (rotate): previous / next track,

move in a list.

Short press : confirm a selection;

other than selection, access to
presets.

Radio : display the list of stations.

Media : display the list of tracks.

Radio (press and hold): update the

list of stations received.

Increase volume.

12:13

18,5

21,5

23 °C

21,5

18,5

12:13

23 °C

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Connected navigation

Driving

Applications

Enter navigation settings and choose a
destination.
Use services available in real time, depending
on equipment.

Activate, deactivate and configure certain
vehicle functions.

Operate certain applications on a smartphone
connected via CarPlay

or MirrorLink

Check the state of the Bluetooth

and Wi-Fi

connections.

Menus

Air conditioning

Manage the various temperature and air flow
settings.

According to version

FM/87.5 MHz

87.5MHz

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Settings

Radio Media

Telephone

Configure a personal profile and/or configure
the sound (balance, ambience, ...) and the
display (language, units, date, time, ...).

Select an audio source, a radio station, display
photographs.

Connect a telephone by Bluetooth

, read

messages and emails and send quick
messages.

Audio and Telematics

Voice commands

First steps

Steering mounted controls

Information - Using the system

Press the Push To Talk
button and tell me what you'd
like after the tone. Remember
you can interrupt me at any

time by pressing this button. If you
press it again while I'm waiting for you
to speak, it'll end the conversation. If
you need to start over, say "cancel".
If you want to undo something, say
"undo". And to get information and tips
at any time, just say "help". If you ask
to me do something and there's some
information missing that I need, I'll
give you some examples or take you
through it step by step. There's more
information available in "novice" mode.
You can set the dialogue mode to
"expert" when you feel comfortable.

To ensure that voice commands are
always recognised by the system,
please observe the following
recommendations:
- speak in a normal tone without

breaking up words or raising your
voice.

- always wait for the "beep" (audible

signal) before speaking.

- for best operation, it is

recommended that the windows
and opening roof be closed to
avoid extraneous interference
(according to version).

- before making a voice command,

ask other passengers to not speak.

The voice commands, with a choice
of 12 languages (English, French,
Italian, Spanish, German, Dutch,
Portuguese, Polish, Turkish, Russian,
Arabic, Brazilian), are made using the
language previously chosen and set in
the system.

The voice commands in Arabic for:
"Navigate to address" and "Display POI
in the city", are not available.

Alternative synonyms can be used for
some voice commands.
E.g. Guide to / Navigate to / Go to /...

Example of a "voice command" for
navigation:

"Navigate to address 11 Regent

Street, London" .
Example of a "voice command" for
the radio and media:

"Play artist Madonna" .
Example of a "voice command" for
the telephone:

"Call David Miller" .

Pressing this button activates the
voice commands function.

Audio and Telematics

Global voice commands

These commands can be made from any screen page after pressing the "Voice command" or "Telephone" button located on the steering
wheel, as long as there is no telephone call in progress.

"Voice command"

Help message

Help

There are lots of topics I can help you with.
You can say: "help with phone", "help with navigation", "help with media" or "help with
radio". For an overview on how to use voice controls, you can say "help with voice
controls".

Voice command help

Navigation help

Radio help

Media help

Telephone help

Set dialogue mode as <...>

Select "beginner" or "expert" mode.

Select profile <...>

Select profile 1, 2 or 3.

Yes

Say "yes" if I got that right. Otherwise, say "no" and we'll start that again.

Audio and Telematics

"Navigation" voice commands

These commands can be issued from any screen page after pressing the "Voice command" or "Telephone" button on the steering wheel, as
long as there is no telephone call in progress.

Depending on the country, give the destination instructions (address) in the language used by the system.

"Voice command"

Help message

Navigate home

To start guidance or add a stopover, say "navigate to" and then the address or contact
name.
For example, "navigate to address 11 Regent Street, London", or "navigate to contact, John
Miller".
You can specify if it's a preferred or recent destination.
For example, "navigate to preferred address, Tennis club", "navigate to recent destination,
11 Regent Street, London". Otherwise, just say, "navigate home".
To see points of interest on a map, you can say things like "show hotels in Banbury" or
"show nearby petrol station".
For more information you can ask for "help with route guidance".

Navigate to work

Navigate to preferred address <...>

Navigate to contact <…>

Navigate to address <...>

Show nearby POI <...>

Remaining distance

To get information about your current route, you can say "tell me the remaining time",
"distance" or "arrival time".
Try saying "help with navigation" to learn more commands.

Remaining time

Arrival time

Stop route guidance

Audio and Telematics

"Radio Media" voice commands

These commands can be issued from any screen page after pressing the "Voice command" or "Telephone" button on the steering wheel, as
long as there is no telephone call in progress.

"Voice command"

Help message

Tune to channel <...>

You can pick a radio station by saying "tune to" and the station name or frequency.
For example "tune to channel Talksport" or "tune to 98.5 FM". To listen to a preset radio
station, say "tune to preset number". For example "tune to preset number five".

What's playing

To display the details of the current "track", "artist" and "album", you can say "What's
playing"

Play song <...>

Use the command "play" to select the type of music you'd like to hear.
You can pick by "song", "artist", or "album".
Just say something like "play artist, Madonna", "play song, Hey Jude", or "play album,
Thriller".

Play artist <…>

Play album <...>

Media voice commands are available only for a USB connection.

Audio and Telematics

"Voice command"

Help message

Call contact <...> *

To make a phone call, say "call" followed by the contact name, for example: "Call David
Miller".
You can also include the phone type, for example: "Call David Miller at home". To make a
call by number, say "dial" followed by the phone number, for example,
"Dial 107776 835 417".
You can check your voicemail by saying "call voicemail".
To send a text, say "send quick message to", followed by the contact, and then the name of
the quick message you'd like to send.
For example, "send quick message to David Miller, I'll be late". To display the list of calls,
say "display calls".
For more information on SMS, you can say "help with texting".

Dial <...> *

Display contacts *

Display calls *

Call (message box | voicemail) *

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and if the download has

been done.

"Telephone" voice commands

If a telephone is connected to the system, these voice commands can be issued from any main screen page after pressing the "Telephone"
button on the steering wheel, as long as there is no telephone call in progress.
If there is no telephone connected by Bluetooth, a voice message announces: "Please first connect a telephone" and the voice session will be
closed.

Audio and Telematics

"Voice command"

Help message

Send text to <...>

To hear your messages, you can say "listen to most recent message".
When you want to send a text, there's a set of quick messages ready for you to use. Just
use the quick message name and say something like "send quick message to Bill Carter,
I'll be late".
Check the phone menu for the names of the supported messages.

Please say "call" or "send quick message to", and then select a line from the list.
To move around a list shown on the display, you can say "go to start", "go to end", "next
page" or "previous page". To undo your selection, say "undo".
To cancel the current action and start again, say "cancel".

Listen to most recent message *

"Test message" voice commands

If a telephone is connected to the system these voice commands can be issued from any main screen page after pressing the "Telephone"
button on the steering wheel, as long as there is no telephone call in progress.
If no telephone has been connected by Bluetooth, a voice message announces: "Please first connect a telephone" and the voice session will be
closed.

* This function is only available if the telephone connected to the system supports downloading of contacts and recent calls and if the download has

been done.

The system only sends pre-recorded "Quick messages".

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Navigation

According to version

Level 1

Level 2

Level 3

Content .. 16 17 18 19 ..
