Chery Tiggo 5 (T21). Service manual - part 66

06–

106

06

DTC

P0322-00 Ign./Distributor Eng. Speed Inp. Circ. No Signal

ET21065010

37 38 39 40 41 42 43 44 45 46

47

48

25 26 27 28 29 30 31 32 33 34

35

36

13 14 15 16 17 18 19 20 21 22

23

24

1

2

3

4

5

6

7

8

9 10

11

12

B

E-033

B

E-035

49 50 51

63

64

15

16

31

32

47

48

33 34 35

17 18 19

1

2

3

52 53 54 55 56 57 58 59 60 61 62

36 37 38 39 40 41 42 43 44 45 46

20 21 22 23 24 25 26 27 28 29 30

4

5

6

7

8

9 10 11 12 13 14

ECM-2

ECM-1

E-033

E-035

1-32

1

WR

1-33

2

GW

WR

GW

2-63

2-64

1-47

Br

Br

B

B

Br

B

ENGINE
SPEED
SENSOR

S

N

1-48

28

29

1 2 3

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

31

35

39

40

41

42

32

33

36

37

38 34

27

28

29

30

B

E-007

E-007

E-038

B

E-016

E-016

E-026

E-028

06–

107

06

DTC Confirmation Procedure

Confirm that battery voltage is over 12 V before performing the following procedures.
 Turn ignition switch to LOCK.
 Connect X-431 3G diagnostic tester (the latest software) to Data Link Connector (DLC).
 Turn ignition switch to ON.
 Use X-431 3G diagnostic tester to record and clear the DTCs stored in the ECM.
 Select Read Code.
 If the DTC is detected, the malfunction indicated by the DTC is current. Go to the diagnosis

procedure - Step 1.

 If DTC is not detected, the malfunction indicated by the DTC is intermittent (

See page 06-18

).

Diagnosis Procedure

a. Turn ignition switch to LOCK.
b. Check ECM grounds E-026 and E-028 (

See page 06-18

).

DTC Code

DTC Definitions

DTC Detection

Conditions

Possible Cause

P0322-00

Ign./Distributor Eng.
Speed Inp. Circ. No
Signal

Engine running

 Engine speed sensor
 Flywheel gear ring
 Wire harness or connector
 ECM

CAUTION

 When performing circuit diagnosis and test, always refer to the circuit diagram for specific circuit and

component information.

1

Check ECM ground point

Repair or replace ground wire harness or
ground point

NG

OK

06–

108

06

a. Turn ignition switch to ON, start the engine and observe the signal waveform of engine speed sensor with

an oscilloscope.

a. Turn ignition switch to LOCK.
b. Disconnect engine speed sensor connector E-016.
c. Check engine speed sensor connector.

a. Remove engine speed sensor.
b. Check and clean engine speed sensor and installation area, and check for damage, foreign matter or

excessive movement, etc. that cause signal incorrectness.

2

Check engine speed sensor signal waveform

Oscilloscope

Normal Waveform of Engine Speed Senor Signal

RT21060200

Go to step 9

OK

3

Check engine speed sensor connector

NG

Repair or replace engine speed sensor
connector

NG

4

Check installation of engine speed sensor

OK

Clean or replace engine speed sensor

NG

OK

06–

109

06

a. Check resistance between engine speed sensor

terminals 1 and 2.
Normal resistance: 860 Ω ± 20% (at normal temperature)

a. Disconnect ECM connector E-035.
b. Check wire harness between engine speed sensor

connector terminals and ECM connector terminals.
Check for Open

Check for Short

5

Check resistance of engine speed sensor

-

+

3

2

1

RT21060210

Replace engine speed sensor

NG

6

Check engine speed sensor circuit

OK

E-016

E-035

37 38 39 40 41 42 43 44 45 46

47

48

25 26 27 28 29 30 31 32 33 34

35

36

13 14 15 16 17 18 19 20 21 22

23

24

1

2

3

4

5

6

7

8

9 10

11

12

1 2 3

-

+

RT21065042

Multimeter

Connection

Condition

Specified

Condition

E-016 (1) - E-035

(32)

Always

Continuity

E-016 (2) - E-035

(33)

Multimeter

Connection

Condition

Specified

Condition

E-016 (1) or

E-035 (32) - Body

ground

Always

No continuity

E-016 (1) or
E-035 (32) -

Battery positive

E-016 (2) or

E-035 (33) - Body

ground

E-016 (2) or
E-035 (33) -

Battery positive
