Westfalia. Testing repair electrical manual - part 90
PE67.29-D-2000-
60H
Legend for wiring diagram of
heated rear window
MODEL YD1##, YD2##,
YD3##, YD4##, YD5##,
YD6##, YD7##, WD1##,
WD2##, WD3##, WD6##,
WD7## ### as of 605788 as
of 1.12.03
MODEL 903.66# /67#,
904.66# ## as of 605788 as
of 1.12.03
with CODE (FZ4) Anti-theft
alarm with interior motion
sensor and anti-towing
protection
with CODE (H22) Heated
rear window
with CODE (ZU7) National
version Canada
MODEL 903.66# /67#,
904.66# ## as of 605788 as
of 1.12.03
with CODE (FZ4) Anti-theft
alarm with interior motion
sensor and anti-towing
protection
with CODE (H22) Heated
rear window
with CODE (ZU8) National
version USA
Code
Designation
Coordinate
A82
EDW control unit
10L
E60
Right heated rear window
7L
E61
Left heated rear window
12L
F63
Heated rear window fuse (30 A)
1H
J16
Circuit 30 connector sleeve
1L
J19
Circuit 61 connector sleeve
16E
J22
Circuit 15 fused connector sleeve
15E
J46
Circuit 58 connector sleeve
16G
J60
Circuit 15 fused connector sleeve
1E
J386
Right heated rear window connector sleeve, ATA [EDW]
10E
J387
Left heated rear window connector sleeve, ATA [EDW]
12E
J486
Right heated rear window relay actuation connector sleeve
14E
K3
Heated rear window relay
4A
