Takeuchi Hydraulic Excavator TB175W (No. 175400095~). Operator's Manual

CONTROLS

Doors and Covers

Opening

Starter Key

1. Pull the knob (1) to open the door.

E4B003

W2B004

The starter key is used not only to start and

stop the engine, but also to lock and unlock

To open the door from inside, push the

the following places:

lever (2) forward.

Fuel filler cap

2. Open the door fully and press it against the

Cab door

cab to lock it in place.

Covers

Closing

Cab Door

WARNING

When mounting and dismounting the

cab, first open the door fully to the

locked position and check that it does

W2B005

not move.

1. Either push release lever (3) to the front or

Open the door fully and press it against the

lower release lever.

catch at the back of the door to lock it in

2. Close the released door.

place. Always lock the door when mounting

and dismounting and when operating the

machine.

Lock and unlock

W2B003

1. Insert the starter key and turn it.

CONTROLS

Doors and Covers

Front Window

WARNING

Grasp the handles firmly with both

hands when opening and closing the

front window. Your head or hands may

get caught if they slip.

W2B008

If you open the front window, be sure to

4. Grasp the lower handle (3) with the left

lock it in place with the lock pins on the

hand, the upper handle (2) with the right

left and right sides. The window may

hand, then lift and slide to the rear.

fall if it is not locked in place.

5. Once the window frame is against the

stopper, move the lock pins (1) to the

Opening

outside to lock the front window.

1. Park on a level surface and stop the

engine.

Closing

2. Set the safety lock lever to the locked

position.

WARNING

When closing the front window, lower the

window slowly so as not to hit your head.

Lowering the window abruptly may result

in injury or damage the front window.

1. Pull the left and right lock pins (1) to the

inside and turn them to the locked position

W2B006

to unlock the front window. If the lock pins

(1) are partially sticking out they may cause

damage.

2. Grasp the front (lower) handle (3) with the

left hand, the rear (upper) handle (2) with

the right hand, then slowly lower the front

window.

3. Move the lock pins (1) to the outside to lock

the front window.

W2B007

3. Pull the left and right lock pins (1) to the

inside then turn them to the locked position

to unlock the front window. If the lock pins

(1) are partially sticking out they may cause

damage.

CONTROLS

Doors and Covers

1. Open the front window and stow it in the ceiling.

Emergency Exit

2. Grasp the protruding parts (4) on the left and

Front window (excluding machines with a front

right with your fingers and slowly lift the lower

guard)

front window off.

W2B010

If you should become trapped inside the cab,

3. Hold the glass firmly, place the lower front

open the front window to get out.

window through the guides (5) at the rear, then

set it on the supports (6) and fasten it in place.

Emergency hammer (optional)

Side Window

An emergency hammer is installed to be used

C4C007

to escape from the cab in an emergency. When

1. Grasp the catch (7), unlock it and open the side

escaping, break the windows with the hammer.

window.

2. To close the side window, close it until a click is

Applicable machine models

heard.

175400373 or later

Tool Box

Lower Front Window

Removing

W2B036

W2B009

1. After using tools, store them back in the tool box.

CONTROLS

Doors and Covers

Front Cover (Tool Box)

Side Covers

CAUTION

Never jump off the machine. Use the

When opening the side cover, open it

steps and handrails when climbing on

firmly to the locked position.

and off the machine, and always support

When opening and closing the side

your body at three points with your

cover, be careful not to get your hands

hands and feet.

or other parts of your body caught.

When opening the front cover, open it

firmly to the stopped position.

When opening and closing the front

cover, be careful not to get your hands

or other parts of your body caught.

The grease gun and tools are stored under

the cover.

L3B054

Opening

1. Insert the starter key and turn it

counterclockwise to unlock the side

cover.

2. Lift the side cover (1) fully until it stops.

3. Press the stay (2) to fix the side cover.

Engine hood unlock knob (3) is located

L3B007

behind the right side cover.

Opening

1. Insert the starter key and turn it

Closing

counterclockwise to unlock the front cover

1. Support the side cover (1) by hand and

(1).

release the stay (2).

2. Tilt the front cover (1) until it stops.

2. Close the side cover (1) and press it down

until a click is heard.

Closing

1. Support the front cover (1) by hand and

release the stay (2).

2. Close the front cover (1).

3. Insert the starter key and turn it clockwise

to lock the front cover (1).

CONTROLS

Doors and Covers

Engine Hood

Maintenance Cover

WARNING

Before opening the engine hood, be sure

Before opening the maintenance cover,

to stop the engine. If your hands or tools

be sure to stop the engine.

should get caught in the fan or fan belt

When performing maintenance on the

while the engine is running they may be

machine, clean up the foot area and

severed.

strictly observe the following so as not

to fall:

• Do not spill oil or grease.

• Do not leave tools laying around.

• When walking, watch your step.

Never jump off the machine. Use the

steps and handrails when climbing on

and off the machine, and always support

your body at three points with your

hands and feet.

Use protective equipment as required

Opening

by job conditions.

1. Open the right side cover.

2. Pull the engine hood unlock knob (3).

Refer to page 43 “Side Covers”.

3. Lift the engine hood (1) fully.

Closing

1. Close the engine hood and press it down

until a click is heard.

L3B053

Opening

1. Insert the starter key and turn it

counterclockwise to unlock the

maintenance cover (1).

2. Pull the knob (2), then lift the maintenace

cover (1) fully until it stops.

Closing

1. Support the maintenance cover (1) by hand

and release the stay (3).

2. Close the maintenance cover (1).

3. Insert the starter key and turn it clockwise

to lock the maintenance cover (1).

CONTROLS

Doors and Covers

Fuel Filler Cap

WARNING

Never jump off the machine. Use the

steps and handrails when climbing on

and off the machine, and always support

your body at three points with your

hands and feet.

Do not smoke or permit open

flames while fueling or near fueling

operations.

Supply fuel in a well ventilated place and

with the engine stopped.

Clean up spilled fuel immediately.

Do not fill the fuel tank to capacity. Allow

room for expansion.

Tighten the fuel filler cap securely.

Open

L3B011E

Opening

1. Open the key cover, insert the key and turn

it clockwise to unlock the fuel cap.

2. Turn the fuel cap counterclockwise and

remove it.

Closing

1. Set the fuel cap in place and turn it

clockwise.

2. Turn the key counterclockwise to lock the

fuel cap, then remove the key.

CONTROLS

Seat and Seat Belt

Lower lever (2) to adjust the front angle of

Seat

the seat cushion.

1. To raise the front angle of the seat cushion,

WARNING

apply your weight to the seat back while

Adjust, secure and latch the operator’s

holding the lever down.

seat.

2. To lower the front angle of the seat cushion,

apply your weight to the front of the seat

cushion while holding the lever down.

To adjust the height of the seat, adjust the

front and rear angles of the seat cushion

alternately.

(5 steps, 60 mm (2.36 in.) adjustment

range)

Example : . First raise the front angle of the

seat cushion, then raise the rear

angle of the seat cushion by the

same amount. This raises the

height of the seat.

After adjusting to the desired position,

release the lever to lock it.

L3B012

WARNING

(A) Lumber adjustment

Do not set the seat back to its maximum

1. Turning knob (1) in the direction of the arrow

reclining position and slide the seat

causes the lumber of the seat back to

backwards at the same time. Doing

curve outwards for greater back support.

so may break the rear window glass,

2. Turning the knob (1) further then removes

resulting in injury.

the curve and returns the seat back to its

Be careful not to allow the force of the

original position.

spring to bring the seat back sharply

The knob (1) cannot be turned counter to

forward.

the direction of the arrow.

1. Raising your torso, sitting down firmly in

(B) Seat cushion angle and height

the seat.

adjustment

2. Pulling lever (3) allows you to use the

Lift lever (2) to adjust the rear angle of the

pressure of the springs in the seat pressing

seat cushion.

against your back to adjust the reclining

1. To raise the rear angle of the seat cushion,

angle of the seat back. Release the lever

raise yourself slightly off the seat while

(3) at the desired angle and the seat back

lifting the lever.

will remain fixed in that position.

2. To lower the rear angle of the seat cushion,

apply your weight to the rear of the seat

cushion while lifting the lever.

CONTROLS

Seat and Seat Belt

(D) Fore-and-aft adjustment

Seat Belt

1. Pull on lever (4) and slide the seat backward

or forward to bring it to the optimum

CAUTION

position for operating the machine.

2. Release the lever (4) at the desired position

Always fasten the seat belt securely before

and the seat will remain fixed there.

starting the engine.

Adjustment stroke: 17 steps,160 mm (6.3

in.)

Fastening the seat belt

1. Adjust the seat to the optimum position for

operating, raise your torso, and sit back

firmly into the seat.

2. Pull the seat belt to the desired length.

L3B013

(E) Weight adjustment

1. Turn handle (5) and set it to indicate

the weight of the person to operate the

E4B023

machine.

May be set to any value from 50 to 120 kg

3. Make sure that the belt is not twisted and

(110 to 265 lbs.)

then insert the tongue plate (A) into the

buckle (B) of the seat belt until you hear a

(F) Lever stand adjustment

clicking sound as it locks in place.

1. Pull on lever (6) and slide the lever

stand backward or forward to bring it to

Releasing the seat belt

the optimum position for operating the

machine.

2. Release the lever (6) at the desired position

and the lever stand will remain fixed

there.

Adjustment stroke: 70mm (2.8 in.)

(G) Headrest adjustment

E4B024

The position of the headrest (7) can be

adjusted in the up and down directions.

1. To remove the seat belt, simply press the

1. Grasp the headrest with both hands and

button (C) located on the buckle.

move it upwards or downwards.

The seat belt is automatically stowed

away.

CONTROLS

Instrument Cluster

FC H

W3B0101

4. Air Cleaner Warning Lamp

Warning Lamps

This lamp flashes and an

IMPORTANT: If a warning lamp flashes and

alarm is sounded if the air

an alarm is sounded, stop all operations

cleaner filter is clogged while

immediately and inspect and maintain the

G4B010

the engine is running.

appropriate part.

Refer to page 160 “Troubleshooting”.

5. Water Separator Warning Lamp

This lamp flashes and an

1. Battery Charge Warning Lamp

alarm is sounded if the water

This lamp flashes and an

is detected within the water

alarm is sounded if a problem

L3B015

separator while the starter

arises in the charging system

switch is in the ON position.

C4B030

while the engine is running.

6. Fuel Level Warning Lamp

2. Engine Oil Pressure Warning Lamp

This lamp lights when the

This lamp flashes and an

fuel level is low while the

alarm is sounded if the

starter switch is in the ON

lubricant oil pressure drops

L3B016

position.

C4B031

abnormally while the engine

is running.

3. Coolant Temperature Warning Lamp

This lamp flashes and an

alarm is sounded if the

engine coolant temperature

C4B012

rises abnormally while the

engine is running.

CONTROLS

Instrument Cluster

Indicators

Hour Meter

7. Slow Speed Slew Lamp

This lamp lights when slow

speed slew switch pressed,

the slew speed decreases.

L3B017

8. Glow Lamp

This lamp turns off when

engine preheating is

L7B020

completed.

This displays the total engine running time

C4B013

in hours.

The rightmost digit indicates tenths of hours (6

9. Power Mode Lamp

minutes).Set the inspection and maintenance

These lamps

intervals according to the time displayed on

indicates

the hour meter.

L FC H

the engine

N1B007

speed.

Engine Fault Warning Lamp

Meters

10. Water Temperature Gauge

This gauge indicates the

temperature of the engine

coolant water.

The needle should be within

the green range during machine operation.

L7B030

The red range indicates overheating.

IMPORTANT: If the lamp flashes, check

the flashing pattern, stop the engine and

then contact a Takeuchi sales or service

11. Fuel Gauge

outlet for help. Do not run the engine

This gauge indicates the

while the lamp is flashing. Otherwise, the

amount of fuel in the tank.

specified engine performance cannot

Be sure to top off the tank

be obtained or more serious error can

before running out of fuel.

occur.

When the starter switch is turned to the ON

position, the lamp lights up and stays on for

2 seconds and then goes out.

If a problem rises in the engine or controls, the

lamp starts flashing using the corresponding

flashing pattern to the type of problem.

CONTROLS

Control Console

W3B020

The switches and indicators needed for

3. Suspension Lock Switch

driving on a road are grouped in the control

console.

WARNING

Do not lock the suspension while traveling.

Switches

Doing so may create a dangerous situation.

Be sure to lock the suspension only when

1. Hazard Switch

working on the machine.

Depress the hazard symbol on this

switch to blink the hazard lamps. The turn

Lock the suspension of the front axle

signal indicator also blinks.

(wobbling) with this switch to prevent the

cylinder from moving.

2. Light Switch

LOCK

............ Locks the suspension of the front

CAUTION

axle. Push the LOCK side of the

It is NOT permitted to light the work lights

switch to secure the machine

during on-road driving.

when working.

When this switch is depressed, the lights are

Neutral

Unlocks the suspension. Keep

illuminated as follows:

the switch in this neutral position

............ Headlights

while traveling (2nd speed: site

neutral

OFF

travel switch is off).

............ Parking lights

Work lights can be turned on in

this position.

CONTROLS

Control Console

............ The suspension is automatically

Indicators

AUTO

locked if the brake is pressed

7. Working Light Indicator Lamp

when traveling at low speed (1st

This lamp illuminates when the work lights

speed:

), and it is unlocked

are turned on.

when the brake is released.

When traveling at high speed (2nd

8. Brake Oil Pressure Warning Lamp

speed: site travel switch is off), the

suspension is not locked even if

the brake is pressed.

CAUTION

Wait 5 seconds after this lamp has gone

4. Creeping Travel Switch

out before operating the machine.

Depress the “creeping gear” symbol on

If this lamp is illuminated while traveling on

this switch to change the travel speed from

a road, pull over as soon as possible.

site travel to creeping travel gear.

This switch only functions when the site travel

This lamp illuminates when the brake oil

switch is on.

pressure drops abnormally while the engine

Slow down sufficiently when switching the

is running.

travel gear.

Depress the other side of the switch to

9. Turn Signal Indicator Lamp

change into site travel gear.

This lamp blinks when the turn signal

switch or hazard switch is operated.

5. Site Travel Switch

Depress the “slow” symbol on this switch

10. Safety Lock Button

to change the travel speed from road travel

to site travel gear.

CAUTION

Stop the machine and engage the brake

pedal lock and then shift the travel gear.

Before traveling on a road, use this button

Depress the other side of the switch to

to lock the right and left operating levers.

change into road travel gear.

The button operates when the lock lever

6. Parking Brake Switch

is in the free position.

Depress the parking brake symbol on

If the button is pressed, the hoe attachment

this switch to engage the parking brake.

cannot move, even if the operating levers are

Depress the other side of the switch to

accidently engaged. In this configuration, the

disengage the parking brake, when the safety

light comes on in the switch.

lock lever is fully lowered to the unlocked

The operating levers are re-activated by

position while the engine is running.

pressing the switch again.

CONTROLS

Switches

Starter Switch

Battery Switch

IMPORTANT: Never set this switch to

OFF

the OFF (O) position while the engine is

running.

START

Doing so will cause the engine and the

electrical circuits to fail.

L3B043

IMPORTANT: Do not repeatedly switch the

key from OFF to ON and ON to OFF over

a short period. Doing so will cause engine

breakdown.

W3B030

OFF

Position for stopping the engine

and inserting or removing the

OFF (O)

Switches off the electrical circuit.

key.

Be sure to set this switch to the

Position in which the engine

OFF (O) position when storing

is running. At this position,

the machine for a long period, or

all the electrical equipment is

when performing maintenance of

functional.

the electrical system.

When the coolant temperature is

ON ( I )

Connects the electrical system.

low, the air heater is energized and

Check that this switch is in the

automatic preheating is done.

ON ( I ) position before starting

START

Position for starting the engine.

the engine.

When the key is released, the

switch automatically returns to

Supplement: Setting this switch to the

the ON position.

OFF (O) position will shut down all electrical

circuits, but the memory of the radio preset

tuning keys will be retained.

CONTROLS

Switches

Horn Button

Selector Button (2-Piece boom)

WARNING

Pressing (switching ON or OFF) the

selector button while the boom swing

pedal is depressed is dangerous, since the

attachment will move unexpectedly.

Always set the boom swing pedal back to

the neutral position before operating the

W2B014

selector button.

Press the button on the right operating lever

to blow the horn.

Decel. Button

WARNING

Set the operating and travel levers to

W3L010

neutral before operating the decel. button.

The machine’s operating speed will

This button changes from the boom

change abruptly if the button is operated

swing operation to the intermediate boom

while the levers are engaged.

operation.

Press this button to change over to operation

of the intermediate boom. The intermediate

boom operation indicator lamp will light. One

more press of this button will result in a return

to boom swing operation. Actual operation is

performed with the boom swing pedal.

W3B040

Press the button on the right operating lever

to lower the engine speed to low idling.

Press the button again to return to the engine

speed set with the throttle or power mode

buttons.

Supplement: The one-touch decelerator is

a device for lowering the engine speed and

reducing fuel consumption when little engine

output is required, for example when the

operating and travel levers are in neutral.

CONTROLS

Switches

First Auxiliary Hydraulic Switches

Turn Signal Switch

Auxiliary Hydraulic Switch

(Proportional control)

Supplement: The machine has auxiliary

proportional controls for first and second

auxiliary hydraulics.

Proportional control allows for slow-to-fast

movement of auxiliary functions.

Example: If you move the auxiliary switch

W2B021

half way, the auxiliary function will move at

approximately one-half speed.

Move this switch to blink the turn lights and

sound the horn.

(A)

Left turn lights

(B)

Right turn lights

Horn

Power Mode Buttons

W2B018

Move this switch to control the flow of the oil

in the first auxiliary hydraulic lines.

(A)

Hydraulic oil flows to left auxiliary line(a)

(B)

Hydraulic oil flows to right auxiliary

line(b)

Auxiliary Hydraulic Buttons

L3B025

The engine speed can be changed at the

touch of a button. When one of these buttons

is pressed, the engine is set to the set speed

and the power mode indicator lights.

Press those buttons to control the flow of the

oil in the first auxiliary hydraulic lines.

(A’)

Hydraulic oil flows to left auxiliary line(a)

L FC H

Proportional control of the auxiliary

hydraulic circuit is not possible.

N1D003

CONTROLS

Switches

L: This mode is always set when the engine

Throttle Buttons

is started.

Use it for light and very light

operations.

FC: Use this mode for light operations and

leveling operations which do not require

speed. Using this mode reduces fuel

consumption and noise.

H: Use this mode for general digging and

loading operations requiring power and

L3B026

speed.

The engine speed increases and decreases

Changing the engine revolutions

continuously while these buttons are pressed.

The engine revolutions can be changed in the

When the button is released, the engine

L and FC modes.

speed is set to the speed at the time the

Do the following steps to change.

button is released.

1. Start the engine.

Engine speed increases

2. Press and hold the L or FC mode button

Engine speed decreases

for two seconds or more to cause the

When the throttle buttons are operated and

mode lamp start flashing on the instrument

the engine speed is at a point between the

cluster.

different modes, the lamps on both sides light.

3. Press the throttle button while pressing

When the speed is changing, only the lamp

down the L or FC mode button.

for the nearest engine speed lights.

(Each pressing increases/decreases the

revolutions by 10 revolutions)

Engine revolutions increases

Engine revolutions decreases

4. Listen to the engine sound and release

the button when you hear the desired

revolution sound.

To return to the initially set revolutions, press

and hold the L or FC mode button for five

seconds or more.

CONTROLS

Switches

Slew Speed Button

Working Light Switch

L3B027

L3B028

Pressing this button shifts rotation into

When this switch is turned while the starter

Slow speed, bringing its speed down to the

switch and parking light switch are at ON, the

minimum. Slow speed is useful for performing

lights turn on as follows:

tasks that require precision handling even at

Off

the cost of speed or efficiency.

Work light, side lights and boom light

turn on.

Slow speed

The lamps on the button and instrument panel

Wiper Switch

will light up. Used for low speed slew.

The maximum set speed in slow speed can

IMPORTANT: I f n o w a s h e r f l u i d i s

be adjustable.

discharged, do not operate the washer.

Upon shipment, it is set to 7.6 min^-1 (7.6 rpm).

Doing so may damage the pump.

Contact a Takeuchi sales or service outlet

IMPORTANT: Operating the wiper with no

for change.

moisture on the windshield will scratch the

glass. Apply water or washer fluid when

Normal speed

operating the wiper.

The lamps will go out and slew will return to

IMPORTANT: In cold seasons, the wiper

its normal speed.

blade may freeze to the glass. Operating

Supplement: As a safety precaution, the

the wiper forcibly may damage the wiper

machine is designed so that you cannot

motor.

switch to normal speed while slewing in slow

speed. You must instead bring the rotation

to a temporary halt and then press the slew

speed button to return to normal speed.

PUSH

L3B0291

Off

Wiper INT

Wiper

PUSH

Washer

CONTROLS

Levers and Pedals

Safety Lock Lever

Swing Lock Pin

WARNING

Before leaving the operator’s seat, set

the safety lock lever securely to the

lock position and stop the engine. If any

controls should be touched accidentally

when the safety lock lever has not be

locked, the machine will move suddenly,

W2B024

and cause serious injury or death.

Note that the dozer blade control is not

To lock the hoe attachment and upperstructure

locked, even when the safety lock lever

for transport and on-road driving use the pin

is set to the lock position. Do not touch

as follow:

this control accidentally.

1. Lift the pin (1) out of the bracket near the

Be careful not to touch the operating

operator’s seat.

levers when raising and lowering the

2. Swing the coupling (2) forward.

safety lock lever.

3. Align equipment and upperstructure.

4. Lower the pin (1) fully into the lock.

IMPORTANT: Operation of the excavator

and slewing of the upperstructure is

possible only if the pin is in the bracket

near the operator’s seat. A side from small

correctional movements, any swinging

can result in damage to the machine.

W2B023

This device is for locking the hoe attachment,

auxiliary hydraulic systems and slewing.

When the lever is lifted, the lever stand springs

up and the lever is locked.

CONTROLS

Levers and Pedals

Steering Wheel

CAUTION

Check the position of the upperstructure

in relation to the undercarriage. If the

steering axle is not located beneath the

cab, changes in direction and steering

wheel turns will not coincide.

The position of the steering wheel can

be adjusted in up/down and front/back

directions.

Up/Down

1. Turn the cap (3) counterclockwise and pull

up or push down the wheel.

2. Tighten the cap (3).

Forward/backward

1. Press the lever (4) to the right and tilt the

The steering contains the steering wheel (1)

steering wheel forward or backward.

and turn signal switch (2) for driving.

2. Release the lever (4) at the desired angle.

Change direction by carefully turning the

wheel. The additional steering knob makes

major steering wheel movement easier.

Adjusting the position of the steering

wheel

WARNING

Be sure to adjust the position of the

steering wheel before driving the

excavator.

If you attempt to adjust it while

driving the excavator, steering will

become unstable, possibly resulting in

accidents.

Check that the steering wheel is

securely locked in place.

After adjusting it. If not it may move

unexpectedly, and this is dangerous.

CONTROLS

Levers and Pedals

Brake Pedal

W2B029

Use the travel pedals to drive the machine and

W2B027

to control the machine travel speed.

Forwards

The brake pedal (1) operates the brakes

Rearwards

(arrow = brakes). The pedal (1) can be locked

in position by pressing fully down. Press on

the Release lever (2) to release the lock.

IMPORTANT: When using the bucket, lock

the brake.

Boom Swing Pedal

WARNING

Forward Travel Pedal

When not using the boom swing pedal,

Reverse Travel Pedal

engage the boom swing pedal lock.

Stepping on the pedal accidentally when

it is not locked may lead to unexpected

DANGER

accidents.

Before reversing, check that there

is nothing behind you and that the

upperstructure and undercarriage

are aligned. If the steering axle is not

beneath the cab, forward and backward

movements are reversed.

When traveling, do not step on the

travel pedal for the opposite direction.

Doing so is dangerous as it causes the

machine to stop suddenly.

W2B033

Use this pedal to operate the boom swing.

Operation switches to the intermediate boom

when the selector switch is pressed.

(A)

Boom swing left /

Intermediate boom raise

(B)

Boom swing right /

Intermediate boom lower

Refer to page 82 “Operating the Boom Swing

F R

and Intermediate Boom”.

W2B028

CONTROLS

Levers and Pedals

Pedal Lock

Blade Lever

WARNING

When not using the blade lever, engage

the blade lever lock. Touching the lever

accidentally when it is not locked may lead

to unexpected accidents.

W2B0321

Pivot the pedal lock (1) over the pedal to

lock it.

Operating Levers

WARNING

W2B031

Use this lever to operate the dozer blade and

Be careful to check which pattern

outriggers.

of lever control arrangement you

(A)

Blade Raise / Outriggers Raise

are operating with before beginning

(B)

Blade Lower / Outriggers Lower

operations.

Refer to page 82 “Operating the Dozer

The explanations in this manual are for

Blade”.

the ISO pattern.

Lever Lock

W2B030

W2D028

Use

these levers

to operate the boom, arm,

When the blade lever is at the neutral position,

bucket and upperstructure (slew).

turn the lock plate (1) to lock the blade lever.

Refer to page 74

“Lever Pattern”.

Refer to page 81 “Operating the

Working

Equipment”.

CONTROLS

Accessories

Outlets

Heater

WARNING

Always be sure to allow sufficient

ventilation.

Do not place combustible or explosive

objects near the air outlets.

W2C001

Fan Switch

Move knob (1) up and down or left and right

to adjust the direction of the air.

OFF

Supplement: Use the heater with care in

warm seasons. Coolant circulates in the

heater even when the heater switch is turned

off.

When the heater is no longer needed, stop

L3B037

coolant circulation as follows:

OFF ... Off

Heater fan rotates at low speed.

IMPORTANT: Use the valve (1) either fully

Heater fan rotates at high speed.

open or fully closed.

Cooling water could leak when the valve

Heater / Defroster / Ventilation /

is set at a halfway position.

Circulation Switch

L3B038

L3C003

Use this switch to heat the cab and to defrost

1. Park on a flat surface and stop the

the windshield.

engine.

...... Heater

2. Open the maintenance cover.

....... Windshield defroster

3. Turn the valve (1) clockwise until it stops to

.... Full ventilation

close it.

..... Half ventilation

....... Internal circulation

CONTROLS

Accessories

b. With the engine running at low idle

First Auxiliary Hydraulic Lines

operate the auxiliary hydraulic switches

repeatedly (approx. 10 times) to purge

WARNING

air from the hydraulic lines.

Oil may spurt out if caps or filters are

c. Stop the engine and wait for more than

removed or pipes disconnected before

5 minutes until bubbles escape from the

releasing the pressure in the hydraulic

hydraulic oil in the tank.

system.

When disconnecting hoses, release the

IMPORTANT: Follow the procedures for

internal pressure before removing.

purging air as instructed by the attachment

manufacturer if specified to do so.

These lines deliver the hydraulic oil necessary

for operating a hydraulic breaker, crusher or

6. Check for leaks.

other attachments.

Disconnecting the hydraulic circuits

1. Release the pressure remaining in the lines

then close the stop valve.

Refer to

“Releasing the residual

pressure”.

2. Disconnect the lines from ports (a) and (b).

3. Install the plugs.

W2C005

Releasing the residual pressure

Stop valve

: Closed

: Open

After using the auxilliary hydraulic circuits,

pressure remains in the circuits. This is called

Connecting the Hydraulic Circuits

the residual pressure. Release this residual

To connect the attachment hydraulic lines,

pressure before disconnecting the lines.

use the following procedures:

1. Release the pressure remaining in the lines

then close the stop valve.

Refer to

“Releasing the residual

pressure”.

2. Remove the plugs.

3. Connect the attachment hydraulic lines to

ports (a) and (b).

When fitted with a hydraulic breaker,

W2B018

connect the return circuit to port (b) and

the supply circuit to port (a).

1. Stop the engine.

4. Open the stop valves.

2. Turn the starter switch to the ON position.

When fitted with a hydraulic breaker, open

3. Fully lower the safety lock lever.

the selector valve (1).

4. Within 10 minutes after the engine comes

Refer to page 63 “Selector Valve”.

to a complete stop, move the 1st auxiliary

5. When connecting is complete, purge air

hydraulic switch to the right and left several

from the hydraulic lines.

times.

a. Start and run the engine at low idle with

5. Place the safety lock lever to the lock

no load for 10 minutes.

position.

CONTROLS

Accessories

Selector valve

Use those sockets as an external power

supply. When using this socket, be careful

not to exceed 12V/5A.

To use, raise the cap (1).

Closed/ 2-way

Open / 1-way

W2C002E

Interior Light

Open

When using a hydraulic

IMPORTANT: The battery capacity will

breaker (One-way flow)

decrease if the interior light is left on for

Closed

When using a reversible

long periods of time the engine stopped.

attachment (Two-way flow)

Turn the lamp off when leaving the

Change the direction of the hydraulic oil flow

machine.

by opening or closing the selector valve on

the machine body.

External Power Sockets (for EU)

WARNING

Only use applicable electric products with

those sockets.

OFF

Lamp is turned off all the time.

Lamp is turned on all the time,

with no regard for the door being

opened or closed.

W2C0031

for Beacon

N0C008

CONTROLS

Accessories

Cigarette Lighter

Ashtray

WARNING

Do not leave the cigarette lighter’s knob

Be sure to extinguish cigarettes and

pressed in. Doing so heats up the lighter,

matches completely before putting

and could be dangerous.

them in the ashtray, and always close

If the knob does not pop out after 30

the ashtray afterwards.

seconds, it may be broken. Pull it out

Do not overfill the ashtray with cigarette

by hand.

butts or put in paper or other easily

Do not use other cigarette lighters, as

burnable objects. Doing so could lead

they may get stuck.

to fire.

Only use applicable electric products

with this socket.

Do not touch metal parts of the lighter.

Doing so could cause burns.

This is the cigarette lighter and internal power

supply socket.

When using this socket, be careful not to

exceed 12V/5A.

W2C0041

Pull the ashtray out towards you to use it.

To clean, press the ash discharge button (1)

and pull out the ashtray.

L3B0411

1. Press the lighter in.

2. Release the lighter and wait for it to pop

out. The lighter pops out automatically

when the heater becomes red.

3. Once the lighter pops out, pull it out.

CONTROLS

Accessories

Radio (Cab Type)

Operating precautions

To ensure safe operation of the machine, always be sure to keep the volume of the radio

down to a level where you can easily hear sounds from outside the machine.

Do not keep the radio playing for long periods of time with the engine stopped. Doing so

will drain the battery of its charge and make it difficult or impossible to restart the engine.

Be careful not to allow water or other liquids to come into contact with the radio. Doing so

may result in it being rendered inoperable.

Names of the components

AUOC001

(1) POWER button

on the LCD. If this button is not pressed for

Use this button to turn on or off the radio.

six seconds while the frequency is displayed,

the LCD returns to the clock display.

(2) TONE control button

Use this button to select the tone. Press the

(5) AST button

button to select low tone. The TONE LOW

Use this button to automatically seek the

display appears on the LCD. Press the button

station information, store it into memory and

again to select high tone.

assign each preset button (1 to 6) a station.

(3) LCD

(6) PRESET STATION buttons (1 to 6)

Displays the time/the receiving frequency and

Use these buttons to store station information.

the operation mode.

Each button can store information on one FM

station and one AM station. For how to use

(4) CLOCK button

these buttons, refer to “Presetting stations”.

Use this button to switch between the clock

display and the receiving frequency display

CONTROLS

Accessories

(7) TUNE button

(13) AUX-IN jack

Use this button to tune to a radio station.

Use this jack to connect an external audio

Press and hold this button (

) for

source. Pull off the rubber cap and plug the

two seconds or more to start seeking the

stereo mini-plug of the external audio device

audible stations. The seeking stops when a

into this jack. Be sure that the jack is closed

station is found. To cancel tuning in progress,

with the rubber cap when not in use.

press the button again.

Pressing the

button will start seeking

Playing the radio

stations with higher frequencies. Pressing

1. Turn the ignition key to the ACC or ON

the

button will start seeking stations

position, and then press the power button

with lower frequency. The frequency will

(1) to turn on the radio.

continuously be increased/decreased if the

2. Select the band FM or AM with the band

button is held pressed.

button.

3. Select the station with the preset button or

(8) BAND button

the tuning button, and adjust the volume

Use this button to select FM or AM. The

with the volume button.

selected band and the receiving frequency

4. To turn off the radio, press the power

will be displayed on the LCD.

button.

(9) VOL buttons

Selecting a station — auto select

Use these buttons to control the sound

Press and hold the tune button

for two

volume. Press the button

to increase the

seconds or more to start seeking stations

volume and the button

to decrease the

in the higher frequencies direction. Press

sound volume. Press and hold each button to

and hold the button

for two seconds

continuously increase/decrease the volume.

or more to start seeking stations in the lower

frequencies direction. The radio will stop

(10) MUTE button

seeking when it finds an audible station and

Use this button to temporarily turn off the

start playing.

sound output. If pressed, the “mute is on”

mark

appears on the LCD. Press this

Selecting a station — manual select

button again to cancel mute.

The selection can be done manually. Press the

tune

button to seek stations with higher

(11) ZERO button

frequencies. Press the tune

button to

Use this button to set the minute to “00” when

seek stations with lower frequencies.

it is between “55” to “59” or “01” to “05”.

Presetting stations

(12) AUX button

1. Select the band (FM or AM) and the station

Use this button to choose which to listen

you want to preset.

to, the radio or the external audio source

2. To set the selected station to a preset

connected to the AUX-IN. If the external

button, choose the button to be set and

source is chosen, the AUX display appears

then press and hold the button for three

on the LCD.

seconds or more. The number of the preset

button chosen appears on the LCD.

CONTROLS

Accessories

3. For more stations, repeat the steps (1) and

Adjust the sound volume of the audio

(2) above.

player by using the volume control buttons

• If the preset button on which a station

on the radio.

has been set to is pressed and held

Do not connect a device with a larger

for two seconds or more, the preset

output compared with a portable audio

information will be modified.

player.

• If the stored information is erased during

battery replacement on the vehicle,

Setting the clock time

set the stations again to the preset

buttons.

• Each preset button can store information

on one FM station and one AM

station.

Auto storing

Press the AST button for two seconds or

AUOC002

more while playing the radio. The radio starts

seeking the audible stations within the band

Be sure that the time is displayed on the

selected, store the information on the stations

LCD. If not, press the AUX button to display

obtained into memory, and assign each

the time.

preset button (1 to 6) a station.

Use the tune

button to set the minute.

Note: The previous station setting stored in

Use the tune

button to set the hour.

memory will be overwritten. If the arrangement

To set the minute digits to “00” when they

of the preset buttons to the corresponding

are from “55” to “59” or from “01” to “05”,

stations is not desirable, try the “Presetting

press the ZERO button.

stations” described above.

Resetting the radio

AUX audio connection

If there are any problems, such as the

Connect a portable audio player and

abnormal display of frequency or failure of

listen to your favorite music.

selection, reset the radio by pressing the

Plug a patch cord (without resistor) into the

power button and the ZERO button together.

headphone jack of the audio player.

Note that the memory containing the clock

Plug a stereo mini plug (3.5 mm) into the

setting and the channel setting is cleared

AUX-IN jack on the radio.

after reset.

To listen to the audio player, press the AUX

button. (The AUX display appears and the

frequency display is changed to the clock

display.)

To return to the radio, press the AUX button

again.

When connecting, adjust the sound

volume level of the audio player so that it

is same as that of the radio.

CONTROLS

Accessories

SPECIFICATIONS

Power source

12/24 VDC

(negative ground)

Power consumption

Maximum output power : 16 W + 16 W (4Ω)

(at DC 28.8 V input)

5W+5W (4Ω)

(at DC 14.4 V input)

Rated output power

14W + 14W (10%

distortion, 4 Ω) (at

DC28.8 V input)

3.8 W + 3.8 W(10%

distortion, 4Ω) (at

DC 14.4V input)

Dimensions

178 (W) x 50 (H) X

92 (D) mm (without

projections)

Receiving frequency

: MW (AM) 530 to

1602 kHz (EU, Asia),

1710 kHz (North,

Central and South

America) FM 87.9

to 108 MHz

Practical sensitivity

: MW (AM) 32 dB or

less (S/N 20 dB)

FM 12 dB or less

(S/N 30 dB)

S/N ratio

: MW(AM) 40 dB

or more

FM 60 dB or more

AUX IN

: Stereo mini jack

(3.5 mm); rated

input, 90 mV

Note: Specifications and dimensions may be

changed without notice.

OPERATION

Before Starting Operation

Mounting and Dismounting

Walk-Around Inspection

Perform the walk-around inspections once a

WARNING

day before starting the engine the first time

Do not jump on or off the machine.

that day.

Never attempt to mount or dismount a

Perform the inspections as descrAbed under

moving machine.

“Maintenance - Walk-Around Inspection”

When mounting and dismounting the

(pages 114 and 115).

cab, first open the door fully to the

locked position and check that it does

not move.

Daily Inspection

Perform the daily inspections once a day

before starting the engine the first time that

W2D001

day.

Perform the inspections as described under

“Maintenance - Daily Inspection” (pages

116 to 122).

W2D029

Always face the access system and

maintain a three point contact with

the recommended handrails and steps

while getting on and off the machine.

Keep steps and platform clean.

Never use the safety lock lever or

control levers as hand holds.

OPERATION

Starting and Stopping the Engine

• On Instrument Cluster

Before Starting the Engine

Check that the power mode lamp (L) is

1. Adjust the seat and fasten the seat belt.

lit.

All the warning lamps flash and an alarm

sounds for 2 seconds. The meters also

start functioning. After 2 seconds, only

the battery charge warning lamp (1) and

engine oil pressure warning lamp (2)

flash, and the other lamps go off.

W2B023

2. Check that the safety lock lever is in the

locked position.

3. Check that all the controls are in the neutral

position.

W3D010

OFF

• On Control Console

The brake oil and third auxiliary hydraulics

START

warning lamps illuminate and will stay lit

until the engine starts.

• Turn the light switches to check that all

the lights come on.

L3D001

• Check the fuel level.

4. Insert the key into the starter switch, turn

If the lamps do not light or the alarm does not

it to the ON position, then perform the

sound, the bulb may be burnt out or a wire

following inspection:

may be damaged. Contact a Takeuchi sales

or service outlet for repairs.

W3D0601

IMPORTANT: Do not start the engine

before the power mode lamp (L) lights.

OPERATION

Starting and Stopping the Engine

Starting in Cold Weather

Starting the Engine

WARNING

Clear the area of all persons.

Sound horn to alert everyone around the

machine.

IMPORTANT: Donot run the starter motor

W3D020

for more than 15 consecutive seconds.

If the engine fails to start, wait for 30

1. Make sure that the glow lamp (8) is lit.

seconds to protect the battery, and then

(The glow lamp lights for 15 seconds when

try again to start the engine.

coolant temperature is at -10°C (14F°).

Normal Starting

OFF

START

L3D003

2. After the glow lamp (8) turns off, then turn

1. Turn the key to the START position and

the key to the START position and start the

start the engine.

engine.

2. Once the engine starts, release the key.

3. Once the engine starts, release the key.

The key automatically returns to the ON

position.

3. Check that the warning lamps are off.

4. Check that the warning lamps are off.

4. Warm up the engine.

5. Warm up the engine.

Refer to page 73 “Warming Up the

Engine”.

OPERATION

Starting and Stopping the Engine

Warming Up the Engine

Stopping the Engine

IMPORTANT: Avoid racing the engine until

IMPORTANT: Do not stop the engine

it is warmed up.

suddenly when operating with heavy loads

Do not warm up the engine for long

or at maximum speed. Doing so may cause

periods of time (20 minutes or more).

the engine to overheat or seize. Never

bring the engine to a sudden stop except

in the case of emergency.

N1D008

1. Make sure that the power mode lamp (L)

W3D030

ligts, then idle the engine and run it for

about 5 minutes with no load.

1. Press the decel. button.

2. Idle the engine for about 5 minutes to

gradually let it cool.

OFF

START

L3D007

3. Turn the key to the OFF position to stop

the engine.

OPERATION

Machine Operation

Lever Pattern (ISO Pattern)

WARNING

Be careful to check which pattern of lever control arrangement you are operating with

before beginning operations.

The explanations in this manual are for the ISO pattern.

ISO

F R

W2D005

Brake

Forward Travel

Reverse Travel

Arm Out

Boom Lower

Arm In

Boom Raise

Upperstructure Left Slew

Bucket Load

Upperstructure Right Slew

Bucket Dump

Boom Swing Left

Dozer Blade Lower

Boom Swing Right

Dozer Blade Raise

Intermediate Boom Raise

Intermediate Boom Lower

(2-piece boom)

OPERATION

Machine Operation

Lever Pattern (JCB Pattern)

WARNING

Be careful to check which pattern of lever control arrangement you are operating with

before beginning operations.

The explanations in this manual are for the ISO pattern.

JCB

F R

W2D006

Brake

Forward Travel

Reverse Travel

Boom Lower

Arm Out

Boom Raise

Arm In

Upperstructure Left Slew

Bucket Load

Upperstructure Right Slew

Bucket Dump

Boom Swing Left

Dozer Blade Lower

Boom Swing Right

Dozer Blade Raise

Intermediate Boom Raise

Intermediate Boom Lower

(2-piece boom)

OPERATION

Machine Operation

Warming Up the Machine

(Hydraulic Oil)

WARNING

Operating the working equipment

without warming up the machine

(hydraulic oil) is dangerous, as response

W2D007

will be slow and the equipment may

2. Set the safety lock lever to the released

move in unexpected ways and safety

position and lift the bucket from the

devices may not operate properly.

ground.

Be sure to sufficiently warm up the

machine.

When traveling, do not step on the

travel pedal for the opposite direction.

Doing so is dangerous as it causes the

machine to stop suddenly.

IMPORTANT: D o n o t o p e r a t e t h e

levers suddenly when the hydraulic oil

temperature is below 20°C (68°F). The

W2D0121

proper hydraulic oil temperature during

3. Disengage the boom swing pedal

and

operation is 50 to 80°C (122 to 176°F), but

blade lever locks.

if operations must be performed at lower

temperatures, heat up the hydraulic oil to

at least 20°C (68°F).

Normal Warm-up

W2D008

4. Extend and retract each of the cylinders

several times with no load.

1. Run the engine at medium speed (FC

mode) for about 5 minutes with no load.

OPERATION

Machine Operation

Inspection After Warm-up

After warming up the engine and hydraulic

oil, perform the checks and inspections

described below, and repair if there is a

problem.

L FC H

5. Slew slowly left and right several times.

L7D0201

1. Check that the warning lamps and meters

are as follows:

• Are all the warning lamps off?

• Is the water temperature gauge’s needle

6. Travel slowly forward and backward

within the green range?

several times.

2. Check that there are no irregularities in the

exhaust color, sound and vibrations.

Warming Up in Cold Weather

1. Perform the normal warm-up procedure.

W2B023

3. Set the safety lock lever to the locked

E4D011

position and check that the operating

2. Set the bucket cylinder at the stroke end

levers and boom swing pedal are locked.

and keep it there.

Do not do this for more than 30 seconds.

3. Repeat step 2 until the bucket operating

speed is normal.

OPERATION

Machine Operation

When traveling on rough terrain or when

Traveling the Machine

carrying a load, lower the load and travel

slowly.

WARNING

Remove any obstacles in the machine’s

Never allow anyone to enter the slewing

path.

(swing) radius and machine path.

Signal your intention to move by

Preparing for Travel

sounding the horn.

1. Cab facing forward over steering axle,

There are blind spots to the rear of the

hoe equipment straight out in front,

machine.

dozer blade / outriggers (option) fully up.

If necessary, swing the cab around

2. Put the machine in the travel posture.

before backing up to check that the area

is safe and clear.

Road Travel Posture

• With 2-Piece Boom

W2A005

W2D013

Check the position of the upperstructure

in relation to the undercarriage. If the

Raise the boom fully, lower the intermediate

steering axle is not located beneath the

boom fully, position the arm vertically and

cab, changes in direction and steering

rollback the bucket.

wheel turns will not coincide.

Avoid sudden stops, start or turns.

• With Mono-Boom

Do not raise the safety lock lever while

traveling. This is dangerous, since

raising the safety lock lever will cause

the parking brake to operate and apply

the brake abruptly.

Do not switch off the starter switch

while traveling. Doing so will cause

sudden braking and is dangerous.

Avoid crossing over obstacles whenever

possible. If you must do so, keep the

Move the boom and arm to set them so

bucket close to the ground and travel

that the position pointers (1), (2) are in the

slowly. Never cross obstacles if they will

green ranges.

seriously tilt the machine (to an angle of

15° or greater).

OPERATION

Machine Operation

Site Travel Posture

2. Set the safety lock lever to the released

position.

Fold the hoe equipment and lower it to 30

W2D011

to 40 cm (12 to 16 in.) above the ground.

3. Press the safety lock button to lock the

operating levers.

W3D050

3. Engage the swing lock.

W2D026

Traveling Forward and Backward

4. Engage the blade lever and boom swing

pedal locks.

1. Increase the engine speed.

W3D0401

5. Press the axle lock switch down to

disengage the axle lock.

6. Press the site travel switch down to choose

the proper speed.

7. Press the parking brake switch down to

disengage the parking brake.

W2D007

8. Operate the travel pedals as described

below.

Takeuchi Hydraulic Excavator TB175W (No. 175400095~). Operator's Manual - page 2
