CG958H Wheel Loader. Manual - part 26

-  -

106

Loader’s Parking

Parking

Caution

The loader shall be parked on the leveled ground. If on a slope, the wheels shall be

padded well.

Do not close the parking brake while driving under exceptional circumstances



1.  Step on the service parking pedal to stop the loader.

2.  Make the shifting handle at the neutral position

3.  Close the parking brake.

4.  Place the bucket on the ground and press it slightly.



Shutdown of Engine

1.  After parking, the engine shall be idled at a low speed for 5 minutes.

2.  Turn the key switch to flame out the engine.

3.  Take away the key.

4.  Hold ladder with both hands and step down along the ladder facing the loader.

5.  Examine whether there exist some foreign substances in the engine cover. The foreign

substances and paper shall be got rid of to avoid fire. The flammables at the bottom of the

loader shall be eliminated to reduce the occurrence the fire.

6.  Turn off the power switch

7.  Install all protective covers and locks.

8.  After parking in winter or at a cold place, if the cooling liquid is not be added with

antifreeze, the water drain valve or water blocker on the engine body, radiator and intake

etc. shall be opened to discharge the cooling water in order to prevent freezing.









-  -

107

Repairing and Maintenance

Appropriate tools:

    We suggest that the user should select the service tools in accordance with the

ISO4510 Earth-moving machinery Service tools-Part 1: Common maintenance and

adjustment tool. Delivery tools please see the “ PACKING LIST”.

Only the tools applicable to the working task may be used. The use of damaged,

poor-quality and defective or temporarily substituted tools will possibly result in

personnel damage.

Precautions for hammer application

While using the hammer, the operator shall wear safety glasses, safety helmet and other

protective clothes, and shall pad one copper bar between the hammer and the part

hammered.

If use the hammer to hammer the hard parts, such as pin or bearing, note that the

fragment will fly into and damage eyes.

I  Knowledge on Tyre Inflation

1.1Tyre Inflation with Nitrogen (N2)

z  SICHUAN CHENGDU CHENGGONG CONSTRUCTION MACHINERY CO., LTD.

suggests that all rubber tyres and tyres’ pressure would be inflated and regulated with

nitrogen respectively. Nitrogen is a kind of inert gas and does not support combustion.

z  In order to avoid redundant nitrogen in the tyre, proper nitrogen inflation equipment

shall be used and necessary training on application of the equipment is required.

Improperly using the equipment may result in blowout of tyre possibly, even serious

personal injuries and death.

z  Because the pressure of the cylinder filled with nitrogen is about 15000kPa,

-  -

108

improperly using the inflation equipment will possibly result in blowout of tyre or

damage of wheel rim.

z  Besides the function of weakening the dangerousness of the explosion, the inflation with

nitrogen may also delay rubber’s aging and gradually wear of tyres (it is especially

important that the tyre has expected service life (four years above). In addition, it may red

In tyre inflation, an inflation chuck that clips tightly automatically shall be used. The

operator shall stand outside the tyre.

z  The set pressure of the modulating valve of the inflation equipment shall not exceed the

recommended pressure 300~340 kPa. The press of the tyre inflated with nitrogen shall be

same as the one with air. Please consult with the tyre supplier for information on working

pressure.



1.2Regulation of Inflation Pressure

z  If the loader works under a cold condition, the pressure for tyre inflation at a warm place

of 18℃~21℃ is too low. The low pressure will shorten the service life of the tyre.

z  Please see working and maintenance manual for the regulation of inflation pressure under

a cold condition.

1.3 Purchase of Tyres

    The tyre’s specification is 23.5-25-20PR, tubeless.As the tyre requires to be replaced, the user

may purchase the tyre of same specifications at the local store.

-  -

109

II  Standard for Screw Torque



Usually, fasteners will be dismantled in repairing. For reinstallation, the following items

shall be noted:

z  The bolts and nuts dismantled from the loader shall be kept well for reinstallation. In case a

new fastener is required, the size and grade of the new fastener shall be same as the old

one.

z  The strength of the material is marked with number (8.8, 10.9 etc.) on the head of the bolt

usually. The standard torque for the 8.8-grade bolt and nut is given in the following table.





the size of

screw thread



standard torque（N.m）

M6 12±4

M8 25±7

M10 55±10

M12 95±15

M14 150±20

M16 220±30

M20 450±70

M24 775±100

M30 1600±200

M36 2700±400
