CG938H Wheel Loader. Manual - part 3



14

18.

 Stop notice plate                                     21. Bucket forerake and rollback

















                                            22. Rise and down of lift arm



















20. Product nameplate (on left side of the fore frame)



  23. Powr off prompt sign



















15

24. Burn prevention symbol                           27. Symbol of lift arm support

















25. Binding symbol                                   28. Housing rollover switch symbol

2





26. Symbol of escape exit from the cab                    29. Master switch symbol






















16

Ⅱ Safety rules

2.1  EU Safety Requirements

1． Noise limit requirement

Complying with the 2000/14/EC directive, this machine meets the following requirements:

L

PA

：

≤85dB(A)

L

WA

：

≤105 dB(A)



2． The vibration value of the seat of cab of this machine meets the requirements of ISO

7096-2000.

3． Electromagnetic compatibility

The electromagnetic compatibility of this machine complies with the relevant requirements of

ISO13766 Standard. The machines can maintain its normal functions in centain electromagnetic

environments and the electromagnetism generated during the operation does not cause damages

to surrounding environment.

4．  The cab of this machine has ROPS – rollover protective structure and FOPS – falling

object protective structure.

2.2  Safety of Operator

Pay attention to location of all safety and warning symbols on the machine and comprehend their

meanings. The symbols and warnings that are obscure or damaged during use shall be replaced by

new ones.

When the operator is in one of the following status, he shall not operate the machine:

z  When the operator is exhausted, he shall not operate

the machine.

z  When the operator has taken medicines that may cause

sleepiness, he shall not operate the machine.

z  The operator shall not operate the machine after

drinking alcohol.

z  The operator shall wear work clothes, work cap and work gloves for the servicing of the

machine. The operator shall not wear clothes or ornamental articles that may either hook or

entangle the machine, or cause combustion or sparkles in contact with electrical devices.



17

z  Personnel who is not approved or certificated (operation qualification certificate) is not allowed

to conduct operation, repair, or maintenance of the machine.

z  Be familiar with the command signs and only follow the command signs of one person.

z  Before starting the machine, be clear of:

Location of fire extinguisher

Location of toolkit

Fire alarm telephone number

Emergency telephone number

Walk around the machine to ensure nobody is working around the machine and nobody is working

lying underneath the machine.

2.3 Safety Protective Appliances

z  When servicing the machine, determine the needed

individual pretective appliances according to the

specific work environment.

z  Do not wear clothes or ornamental articles that may

either hook or entangle the machine.

z  Do not wear clothes or ornamental articles that may

cause combustion or sparkles in contact with electrical devices.

z  All pretective appliances shall be checked prior to use for their usability.

2.4 Safety Device



Ensure that all protective devices and housing are in their proper position. Any damaged one shall be

repaired in time.

z  Properly use the safety device;

z  Do not dismantle the safety device and keep it under good conditions.

z  Improper use of the safety device will possibly cause personnel casualty.
