- 81 -

concentration of the additive will also increase wear of the water pump’s seal.

As the premixed coolant of the anti-icing liquid is not used, the coolant additive shall be

added.

As the coolant is added into the new or reworked engine for the first time, if the

antifreezing agent above is not used, 1L ancillary coolant additive or corresponding matter shall

be added in each 30L coolant, so the concentration of the ancillary additive in the cooling

system occupies up 3%~6%.

In order to maintain the concentration of 3%~6%, every 250 hours or in oil replacement

(later or first), the ancillary additive shall be added.

- 82 -

V Use Rule of Fuel



5.1 Precautions on Use of Fuel

 Upon completion of work every day, as the fuel is added, the wet air shall be discharged so

as to avoid condensation.

 Do not top off the fuel tank because the fuel possibly expands and overflows as the

temperature increases.

 Prior to installing the fuel filter, the fuel shall not be added into the fuel box. The fuel with

foreign substances will accelerate the wear of the fuel system’s parts.

 The fuel to be added shall be settled for 72 hours to ensure its cleanness.

 After beginning to add or filling the fuel into the fuel box, retention time of 5-10 minutes is

allowed to discharge the water and precipitate from the fuel box.

Upon the replacement of the fuel filter, the air shall be discharged from the system.

 Prior to filling up the fuel box, the water and precipitate in the fuel box shall be discharged

weekly to prevent that the water and precipitate access into the fuel system.

 Only the fuel recommended in this section can be used.

5.2 Category of Fuel

In order to offer optimal performance and service life of the engine, the fuel engine for the

CCG935G loader allows the use of distilled fuel, i.e. diesel fuel, fuel oil and gas oil.

Selection of diesel:

Solidifying

point of fuel

℃



10 0  -10 -20  -30 -40

Ambient

temperature

℃



〉

18 8～18 -2～8 -12～-2

-27-12

-37～-27

See the operating specification of engine for details.



- 83 -

VI Use Rule of Operation Oil



6.1



Diesel Engine Oil



Please use the following recommended diesel engine oil: API CD/SD, CD/SE, CD/SF,

CD/SG or CD.

 The percentage of sulfur in fuel will affect the use of the diesel. For the effect of the sulfur

content in fuel, the remaining and ingredients of the engine oil may be evaluated with

infrared analysis method and ASTM D2896 procedures. The production of sulfide depends

on the sulfur content in fuel, recipe of lubricant, working conditions of engine and ambient

temperature etc.

 It is a common rule that the TBN of the diesel oil is 20 times of sulfur content in fuel. It

may be modified by analyzing the oil employed. The effect of recipe of the lubricant

depends on the ingredient of the additive. The balanced additive mixture of low TBN has

the effects same as the additive mixture of high TBN. Based on the analysis on the oil

employed, these results may be attained.

Going against the suggestions above may shorten the service life of engine due to

carbon precipitate or excessive wear.

Selection of engine oil: The engine oil CF above shall be adopted.

Viscosity

10W  5W/30  10W/30 15W/30 15W/40

Ambient

temperature ℃

-20～-5 -25～25 -20～20 -10～25 -10～35

Viscosity 20W/40

30 40



Ambient

temperature ℃

-10～30 5～30

>25



This machine adopts SAE 15W-40 Mobil Delvac Super 1300.



6.2 Hydraulic System Oil

- 84 -

 The hydraulic oil employed may enable the components and hydraulic transmission parts of

the hydraulic system to attain a longer service life and optimal working performance. In

most hydraulic systems, the following recommended hydraulic oil shall be used: API CC,

CC/SF, CD/SF, CD/SG, CD, CE/SF, CE/SG or CE.

 In case the oil of different viscosity is required due to extremely bad ambient temperature,

the engine oil recommended by the SICHUAN CHENGDU CHENGGONG

CONSTRUCTION MACHINERY CO., LTD. may be used.

 The industrial hydraulic oil that is applied to large load and has anticorrosion, anti-bubble,

antirust and anti-oxidation additives may be used.

 This machine adopts Mobil DTE25-antiwear hydraulic oil.

6.3 Transmission Fluid

 Using the oil recommended by the SICHUAN CHENGDU CHENGGONG

CONSTRUCTION MACHINERY CO., LTD. may enable the transmission box to attain a

longer service life and optimal performance. The oil for transmission box/transmission

system oil recommended by the SICHUAN CHENGDU CHENGGONG

CONSTRUCTION MACHINERY CO., LTD. is the one in conformity with the API

CD/TO-2 code.

 Going against the suggestions above will possibly shorten the service life of the

transmission box due to insufficient performance of materials and inconformity of friction

materials with the friction requirements.

 Mixture of oil of various levels shall not be used for the transmission box. The oil mixture

of various levels uses high moleclar polymer as improver of viscosity index. Because of

permanent and temporary shear, the improver of viscosity index loses its viscosity

efficiency.
